Search Results (585)

The integration of electric railways with renewable energy sources is crucial for advancing sustainable transportation and building clean, low-carbon, and efficient energy systems in alignment with global sustainable development goals. However, the application of photovoltaic (PV) integration into railway traction power supply systems may exacerbate resonance phenomena between electric locomotives and the traction network. It is therefore necessary to study the impedance frequency characteristics (IFCs) of traction networks to minimize harmonic resonance overvoltage. In this paper, a harmonic impedance model of the sustainable traction power supply system (STPSS) is established, and an impedance analysis method is adopted to reveal the influence law of grid-connected PV inverters on the IFCs of STPSSs. Additionally, to improve the stability of STPSSs, a multi-parameter co-tuning method based on an improved particle swarm optimization algorithm is proposed. This method constructs a multi-objective function that includes resonance frequency, impedance magnitude, and filtering cost, thereby realizing the automatic optimization of the control parameters and filtering parameters of PV inverters. The results demonstrate a 56% reduction in the maximum impedance magnitude within the 0–5 kHz frequency range and a 10.8% cost reduction in the LCL filter implementation, confirming the effectiveness of the proposed optimization model. Results show that the maximum impedance magnitude of the optimized system in the frequency range of 0–5 kHz can be reduced by 56%. Moreover, the cost of LCL filters can be reduced by 10.8% through component value optimization. These findings validate the effectiveness of the proposed method. Full article

The widespread adoption of electric vehicles (EVs) is contingent on high-power fast-charging infrastructure that can also provide grid stabilization services through bidirectional power flow. While the constituent power stages of such off-board chargers are well-known, a critical research gap exists in their system-level integration, where sub-optimal dynamic interaction between independently controlled stages often leads to DC-link instability and poor transient performance. This paper presents a rigorous, system-level study to address this gap by developing and optimizing a unified control framework for a high-power bidirectional EV fast-charging system. The system integrates a three-phase active front-end rectifier with an LCL filter and a four-phase interleaved bidirectional DC/DC converter. The methodology involves a holistic dynamic modeling of the coupled system, the design of a hierarchical control strategy augmented with a battery current feedforward scheme, and the system-wide optimization of all Proportional–Integral (PI) controller gains using the Artificial Bee Colony (ABC) algorithm. Comprehensive simulation results demonstrate that the proposed optimized control framework achieves a critically damped response, significantly outperforming a conventionally tuned baseline. Specifically, it reduces the DC-link voltage settling time during charging-to-discharging transitions by 74% (from 920 ms to 238 ms) and eliminates voltage undershoot, while maintaining excellent steady-state performance with grid current total harmonic distortion below 1.2%. The study concludes that system-wide metaheuristic optimization, rather than isolated component-level design, is key to unlocking the robust, high-performance operation required for next-generation EV fast-charging infrastructure, providing a validated blueprint for future industrial development. Full article

This paper presents a robust control strategy for three-phase inverters that combines Sliding Mode Control with a Washout Filter (SMC-w) to achieve low harmonic distortion and high dynamic stability. The proposed approach addresses the critical challenge of maintaining the stability of a high-quality output signal while ensuring robustness against disturbances and adaptability under variable, unbalanced, and nonlinear loads. The proposed hybrid controller integrates the fast response and disturbance rejection capability of SMC with the filtering properties of the washout stage, effectively mitigating low-frequency chattering and steady-state offsets. A detailed stability analysis is provided to ensure the closed-loop convergence of the SMC–w. Simulation results obtained in MATLAB–Simulink demonstrate significant improvements in transient response, total harmonic distortion, and robustness under unbalanced and nonlinear load conditions compared to conventional control methods. The inverter demonstrated rapid tracking of the reference signals with a minimal error margin of 3%, effective frequency regulation with a low steady-state error, and resilience to input disturbances and load variations. For instance, under a load variation from 20 Ω to 5 Ω, the system maintained the output voltage accuracy within a 3% error threshold. In addition, the input perturbations and frequency shifts in the reference signals were effectively rejected, confirming the robustness of the control strategy. Furthermore, the integration of the SMC proved to be highly effective in reducing harmonic distortion and delivering a stable and high-quality sinusoidal output. The integration of the washout filter minimized the chattering phenomenon typically associated with the SMC, further enhancing the smooth response and reliability of the system. This study highlights the potential of SMC–w to optimize power quality and operational stability. This study offers significant insights into the development of advanced inverter systems that can operate in dynamic and challenging environments. Full article

To address the problem of uncoordinated operation between distributed generation (DG) inverters and dedicated power quality devices, this paper proposes a coordinated optimization model for harmonic and voltage compensation in microgrids. The model considers the capacity constraints of DG inverters and compensation devices, aiming to realize efficient utilization of multi-resource compensation capabilities. A dual-objective optimization framework is established, which simultaneously minimizes total economic cost and enhances overall power quality performance. The first objective function reflects investment and operational costs, while the second quantifies system performance through total harmonic distortion (THD) and average voltage deviation (AVD). The Normal–Normal Constraint (NNC) method is adopted to ensure optimization stability and feasible trade-offs between the two objectives. The proposed approach is validated on the IEEE 33-bus microgrid system, and its results are compared with traditional heuristic algorithms such as PSO. Simulation results show that the proposed method effectively reduces total operating cost while significantly improving harmonic and voltage compensation performance. This study provides a practical reference for coordinated power quality management in microgrids. Full article

The authors of this paper highlight the creation of an experimental system for the implementation and testing of active low-voltage electronic power filters of the parallel type, with applicability in a wide range of electrical parameters. In this paper, the authors present the results obtained on an experimental test bench for power quality purposes. The experimental test bench is one of the results of a technology transfer project. One of the specific objectives of the project was to carry out industrial research and experimental development activities in order to develop a competitive, technical and economic solution for an intelligent power system, Active Power Filter (APF). Thus, this paper presents the experimental test bench for the design, implementation and testing of algorithms for current harmonics mitigation. The conceptual theoretical frame bases of both direct and indirect control have been presented by the authors. As a case study, both the simulation and experimental results of the indirect control strategy implemented on the test bench are provided. The indirect control method is chosen due to simplicity, no complex calculus requirements, and the use of a minimum number of transducers. By features comparison with modern control strategies, this study underlines the supremacy of the indirect control in active harmonics control. Full article

With the increasing penetration of renewable energy and the rising demand for power quality, the dynamic performance and accuracy of grid-voltage detection have become crucial for the control of grid-following devices such as dynamic voltage restorers (DVRs). However, the conventional moving average filter (MAF) in grid-voltage detection suffers from inherent limitations in dynamic response. To address this issue, this paper proposes a voltage-detection method, which is based on an adaptive variable-parameter filtering algorithm termed MAF-MATCH-V. First, a cascaded filter model is constructed by integrating a zero-pole matcher (MATCH) with the MAF. Frequency-domain analysis demonstrates that the MATCH compensates for the mid- and high-frequency magnitude attenuation and reduces the phase delay of the MAF, thereby accelerating the dynamic response while preserving its harmonic-rejection capability. Second, the influence of the matching coefficient on the time-domain response is investigated, and a time-varying adaptive strategy is designed to balance rapid disturbance recognition with steady-state convergence. Finally, experimental results under various non-ideal grid conditions demonstrate that the proposed method achieves superior overall performance compared with conventional approaches. Specifically, MAF-MATCH-V realizes millisecond-level event recognition and zero steady-state error convergence, making it a practical solution for the real-time control of grid-following equipment in modern power systems. Full article

Aiming at the significant challenges faced by active power filters (APFs) in suppressing low-order harmonic currents (such as second and fourth), this paper proposes a rarefaction suppression method based on quasi-proportional resonance (QPR) control. Firstly, the harmonic mathematical model of APFs in a synchronous, rotating coordinate system is established to reveal the inherent defects of traditional proportional–integral (PI) control in low-order harmonic suppression. Theoretical analysis shows that although the proportional resonant (PR) controller can achieve zero-steady-state-error tracking of specific frequency harmonics, its narrow bandwidth and low robustness may easily lead to system oscillation. Therefore, the QPR control strategy is introduced. By superimposing a low-pass filter with an adjustable cut-off frequency on the resonant link, the bandwidth is significantly broadened and the anti-frequency disturbance ability of the system is enhanced. In addition, the stability of QPR control parameters is analyzed. Finally, the verification based on the experimental platform demonstrates that the proposed method reduces the total harmonic distortion (THD) of the 380 V bus current from 82.18% to 3.45%, and the low-order harmonic current suppression performance is significantly better than the traditional scheme. This research provides an effective solution for the synergistic suppression of low-order harmonic currents. Full article

This article designs and validates a P-Q-based shunt active power filter (SAPF) to mitigate voltage harmonics in EERSA’s 13.2 kV feeder 1500080T03. A CYMDIST feeder model, calibrated with field measurements, reveals worst-case voltage THD up to 9.48% due to legacy high-pressure sodium (HPS) street lighting. Co-simulation with a MATLAB/Simulink R2024b, controller guides the sizing of a 150 kVA SAPF at Substation 8. Simulations reduce peak THD at a representative node from 9.48% to 1.51%; replacing HPS with LEDs further improves efficiency while lowering distortion. The retrofit complies with IEEE Std 519-2022, enhances supply reliability, and yields an internal rate of return above 17%, indicating a technically and financially attractive solution for Latin American distribution networks. Full article

This paper presents the development and characterization of a reference high-voltage sensing chain for the calibration and conformity assessment of instrument transformers with Class 0.1-WB3, in the extended frequency range up to 150 kHz, according to IEC 61869. The sensing chain, composed of a high-voltage divider, precision attenuators and high-pass filters, has been specifically developed and characterized. The chain features two parallel measurement paths: the first path, comprising the high-voltage divider and attenuator, is optimized for measuring the fundamental frequency superimposed with high-amplitude harmonics; the second path, consisting of the high-voltage divider followed by a high-pass filter, is dedicated to measuring very-low-level superimposed harmonic components by enhancing the signal-to-noise ratio. These two paths are integrated with a digitizer to form a complete and modular measurement chain. The expanded uncertainty of measurement has been thoroughly evaluated and confirms the chain’s ability to support assessment of instrument transformers with Class 0.1-WB3 compliance. Additionally, the chain architecture enables a future extension up to 500 kHz, addressing the growing need to evaluate instrument transformers under high-frequency power quality disturbances and improving the sensing capability in this field. Full article

Against the backdrop of a high proportion of distributed renewable energy sources being integrated into the power grid, distribution networks are confronted with issues of grid-wide and decentralized harmonic pollution and voltage deviation, rendering traditional point-to-point governance methods inadequate for meeting collaborative governance requirements. To address this problem, this paper proposes a source-tracing-oriented harmonic mitigation and optimization control strategy for distribution networks. Firstly, it identifies regional dominant harmonic source mitigation nodes based on harmonic and reactive power sensitivity indices as well as comprehensive voltage sensitivity indices. Subsequently, with the optimization objectives of reducing harmonic power loss and suppressing voltage fluctuation in the distribution network, it configures the quantity and capacity of voltage-detection-based active power filters (VDAPFs) and Static Var Generators (SVGs) and solves the model using an improved Spider Jump algorithm (SJA). Finally, the effectiveness and feasibility of the proposed method are validated through testing on an improved IEEE-33 standard node test system. Through analysis, the proposed method can reduce the voltage fluctuation rate and total harmonic distortion (THD) by 2.3% and 2.6%, respectively, achieving nearly 90% equipment utilization efficiency with the minimum investment cost. Full article

Micro-Shell Resonator Gyroscopes have obvious SWaP (Size, Weight and Power) advantages and applicable accuracy for the autonomous navigation of Unmanned Ground Vehicles (UGVs), especially under GNSS-denied environments. When the Micro-Shell Resonator Gyroscope Rotary Inertial Navigation System (MSRG–RINS) operates in the whole-angle mode, its bias varies as an even-harmonic function of the pattern angle, which leads to difficulty in estimating and compensating the bias based on the MSRG in the process of attitude measurement. In this paper, an attitude measurement method based on virtual rotation self-calibration and rotary modulation is proposed for the MSRG–RINS to address this problem. The method utilizes the characteristics of the two operating modes of the MSRG, the force-rebalanced mode and whole-angle mode, to perform virtual rotation self-calibration, thereby eliminating the characteristic bias of the MSRG. In addition, the reciprocating rotary modulation method is used to suppress the residual bias of the MSRG. Furthermore, the magnetometer-aided initial alignment of the MSRG–RINS is carried out and the state-transformation extended Kalman filter is adopted to solve the large misalignment-angle problem under magnetometer assistance so as to enhance the rapidity and accuracy of initial attitude acquisition. Results from real-world experiments substantiated that the proposed method can effectively suppress the influence of MSRG’s bias on attitude measurement, thereby achieving high-precision autonomous navigation in GNSS-denied environments. In the 1 h, 3.7 km, long-range in-vehicle autonomous navigation experiments, the MSRG–RINS, integrated with a Laser Doppler Velocimetry (LDV), attained a heading accuracy of 0.35° (RMS), a horizontal positioning error of 4.9 m (RMS), and a distance-traveled accuracy of 0.24% D. Full article

Compared to the L-filter, the LCL-filter provides superior high-frequency harmonic attenuation for a given inductance. However, it also introduces resonance issues that can compromise system stability. Consequently, the bandwidth of the inner current loop must be maintained well below the resonant frequency of the filter. This paper proposes a robust controller design strategy for LCL-filtered converters to extend the harmonic control range under wide variations in grid impedance. An analysis of the resonant controller phase-frequency characteristics reveals its capability to provide phase compensation up to 2π. Building on this finding, the damping ratio and phase leading angle are systematically optimized through a joint analysis of the phase characteristics introduced by the resonant controller and active damping, thereby enhancing system robustness. With these optimized parameters, the center frequency of the resonant controller can be tuned above the LCL-filter resonance frequency without inducing instability. In contrast to conventional methods, the proposed approach allows the LCL-filter to be designed with a lower resonance frequency. This enables improved attenuation of switching-frequency harmonics without compromising the tracking performance for higher-order harmonics. Such a capability is particularly beneficial in high-power and weak-grid scenarios, where the filter resonance frequency may fall to just a few hundred hertz. Experimental results validate the effectiveness of the proposed design strategy. Full article

To address the challenges posed by harmonic distortion and DC offset in the power grid, this paper proposes a novel Phase-Locked Loop (PLL) architecture tailored for single-phase grid-connected systems. The design integrates an Enhanced Adaptive Second-Order Generalized Integrator (EA-SOGI) with a Quasi-Proportional Resonant (QPR) controller. The proposed EA-SOGI extends the conventional SOGI by incorporating an all-pass filter and an additional integrator, which enhance the symmetry of the orthogonal signals and effectively suppress the estimation errors caused by DC offset. In addition, the conventional PI controller is replaced by a QPR controller, whose parameters are tuned using a hybrid Levy-AsyLnCPSO optimization algorithm to improve frequency locking performance and enhance system robustness under steady-state conditions. Simulation and experimental results demonstrate that the proposed PLL achieves a Total Harmonic Distortion (THD) as low as 2.8653% based on Fast Fourier Transform (FFT) analysis, indicating superior adaptability compared to conventional PLL structures and validating its effectiveness in DC offset suppression and harmonic mitigation. Full article

Battery Energy Storage Systems (BESSs) are critical to smart grid functioning but are exposed to mounting cybersecurity threats with their integration into IoT and cloud-based control systems. Current solutions tend to be deficient in proper multi-class attack classification, secure encryption, and full integrity and power quality features. This paper proposes a comprehensive framework that integrates machine learning for attack detection, cryptographic security, data validation, and power quality control. With the BESS-Set dataset for binary classification, Random Forest achieves more than 98.50% accuracy, while LightGBM attains more than 97.60% accuracy for multi-class classification on the resampled data. Principal Component Analysis and feature importance show vital indicators such as State of Charge and battery power. Secure communication is implemented using Elliptic Curve Cryptography and a hybrid Blowfish–RSA encryption method. Data integrity is ensured through applying anomaly detection using Z-scores and redundancy testing, and IEEE 519-2022 power quality compliance is ensured by adaptive filtering and harmonic analysis. Real-time feasibility is demonstrated through hardware implementation on a PYNQ board, thus making this framework a stable and feasible option for BESS security in smart grids. Full article

Due to the “low damping” characteristics of the DC distribution system, the traditional passive scheme is not suitable for DC fault detection and positioning. Therefore, this paper proposes an active injection fault identification method suitable for DC feeder line under single-pole grounding faults. Based on the high controllability of converters, this method uses the oscillation circuit characteristics of the DC side single-pole grounding fault to superimpose the harmonics of fixed frequency into the converter modulated wave, and derives the selection principles of harmonic amplitude and frequency. After the fault, the positive and negative current signals are extracted from the feeder lines, and the zero-mode current components are extracted by the Karrenbauer transformation and band-pass filter, the current phases are compared to achieve the fault feeder line selection. According to simulation verification, the power quality of the actively injected harmonics is within the standard range under the condition of global injection, and the single-pole grounding faults in each feeder line can be identified. Full article
