Model Predictive Control (MPC) has become very attractive for the efficient control of power converters. This paper compares Classical MPC (C-MPC) and Sequential MPC (S-MPC) for a three-level NPC converter. Although C-MPC is simple to implement, it faces challenges such as switching frequency variations and complex weighting factor tuning. S-MPC addresses these issues by prioritizing control objectives sequentially, eliminating weighting factors, and simplifying controller design. Simulation results show that S-MPC improves the tracking of output currents, reduces harmonic distortion, and enhances the balancing of dc–link voltages under steady-state and transient conditions. These findings establish S-MPC as a robust alternative to C-MPC, improving power quality and system performance in multilevel converter applications. Full article

This paper deals with the design and control of an enhanced grid-tied photovoltaic (PV) cascaded H-Bridge (CHB) inverter, which suffers from issues related to operation in the overmodulation region in the case of a deep mismatch configuration of PV generators (PVGs). This can lead to reduced system performance in terms of maximum power point tracking (MPPT) efficiency, or even instability (i.e., a lack of control action). The proposed solution is to insert into the cascade a power cell fed by a battery energy storage system (BESS) with the aim of providing an additional power contribution. The latter is useful to reduce the modulation index of the cell, delivering more power than the others when a preset threshold is crossed. Moreover, a suitable hybrid modulation method is used to achieve the desired result. A simulated performance in a PLECS environment proves the viability of the proposed solution and the effectiveness of the adopted control strategy. Full article

A grid-tied inverter needs excellent maximum power point tracking (MPPT) topology to extract the maximum energy from PV panels regarding energy creation. An efficient MPPT ensures that grid codes are met, maintains power quality and system reliability, minimizes power losses, and suppresses rapid response to power fluctuations due to solar irradiance. Moreover, appropriate MPPT enhances economic returns by increasing energy royalties and ensures high power quality with reduced harmonic distortion. For these reasons, an improved hybrid MPPT technique for a grid-tied solar system is presented based on particle swarm optimization (PSO) and grey wolf optimizer (GWO-PSO) to achieve these objectives. The proposed method is tested under MATLAB/Simulink 2024a for a 100 kW PV array connected with a boost converter to link with a voltage source converter (VSC). The simulation results show that the proposed GWO-PSO can reduce the overshoot on rise time along with settling time, meaning less time is wasted within the grid power system. Moreover, the suggested method is compared with PSO, GWO, and horse herd optimization (HHO) under different weather conditions. The results show that the other algorithms respond more slowly and exhibit higher overshoot, which can be counterproductive. These comparisons validate the proposed method as more accurate, demonstrating that it can enhance the real power quality that is transferred to the grid. Full article

Solar PV inverters require output filters to reduce unwanted harmonics in their output, where LCL filters are a more economical choice than larger inductance-only filters. A drawback of these filters is that they can introduce power quality disturbances, especially at higher frequencies (above 2 kHz). This paper investigates and characterises the resonance phenomenon introduced by different filter types, i.e., LC or LCL, and identifies their behavioural change when combined with multiple parallel grid-tied PV inverter systems. MATLAB/Simulink modelling aspects of PV inverter systems related to resonance phenomenon are presented, including establishing resonance at a specific frequency where potentially large variations in the parameter selection across manufacturers may exist. In addition, a method is developed to establish output filter frequency response through measurements, which is used to develop validated solar PV harmonic models for high-frequency analysis. The low-frequency harmonic models can be used up to the resonant frequency where the current flowing through the filter capacitor is insignificant compared to the current flowing into the electricity network. Full article

This paper introduces magnetic integrated high-order trap–trap–inductor (TTL) and inductor–trap–trap (LTT) filters featuring two LC-traps designed for grid-tied inverters, aimed at reducing the size of output-power multi-trap filters. The proposed filters exhibit excellent harmonic absorption capabilities alongside a compact design. Building on the conventional integrated inductor–capacitor–inductor (LCL) filter, the approach involves connecting a small capacitor in parallel with either the inverter-side or grid-side inductors to create an LC trap. Additionally, a second LC trap can be achieved by integrating the filter capacitor in series with the equivalent trap inductance, established by the magnetic coupling between the grid-side inductor and inverter-side one. This paper thoroughly analyzes the characteristics of the proposed filters. Moreover, a design method is presented to further minimize the size of the output filter components. Finally, validation through simulations and hardware-in-the-loop (HIL) experiments confirms the proposed approach’s effectiveness and feasibility. The integrated designs achieve a size reduction of 35.4% in comparison with the discrete windings. Moreover, these designed filters comply with IEEE standards, maintaining a grid-side current total harmonic distortion (THD) of less than 0.9%, with all current harmonics below 0.3% of the fundamental current. Full article

With the rise of renewable energy penetration in the grid, photovoltaic (PV) panels are connected to the grid via inverters to supply solar energy. Transformer-less grid-tied PV inverters are gaining popularity because of their improved efficiency, reduced size, and lower costs. However, they can induce a path for leakage currents between the PV and the grid due to the absence of galvanic isolation. This leads to serious electromagnetic interference, loss in efficiency, and safety concerns. The leakage current is primarily influenced by the nature of the common mode voltage (CMV), which is determined by the switching techniques of the inverter. In this paper, a novel inverter topology of Hysteresis Controlled H5 with Two Clamping Diodes (HCH5-D2) is derived. The HCH5-D2 topology helps decouple the AC part (Grid) and DC part (PV) during the freewheeling period to make the CMV constant, thereby reducing the leakage current. Additionally, the extra diodes help reduce voltage spikes generated during the freewheeling period and maintain the CMV at a constant value. Finally, a 2.2 kW grid-connected single-phase HCH5-D2 PV inverter system’s MATLAB simulation is presented, showing better results compared to a traditional H4 inverter. Full article

Multilevel inverters have gained importance in modern power systems during the last few years because of their high power quality with lower THD. Various topologies developed include the packed U-cell inverter and its different modified versions that have emerged as a compact and efficient solution to distributed energy systems. Most of the available harmonic mitigation techniques, that is, passive filtering and individual optimization techniques, which include GA and PSO, are susceptible to a variety of shortcomings regarding their inherent complexity and inefficiency; hence, finding an appropriate convergence may be quite hard. This paper proposes a hybrid version of the GA-PSO algorithm that exploits the exploratory strengths of GA and the convergence efficiencies of PSO in determining the optimized switching angles for SHM techniques applied to modified five-level and seven-level PUC inverters. By utilizing the multi-objective optimization method, the approach minimizes THD while keeping voltage and efficiency constraints. Simulated in MATLAB/Simulink, the results were experimentally verified using hardware-in-the-loop testing on OP5700. A large THD reduction in both MPUC7 (11.68%) and MPUC5 (17.61%) was obtained. The proposed hybrid algorithm outperformed the standalone approaches of GA and PSO with respect to robustness and with precise harmonic suppression. Other appealing features are reduced computational complexity and improved waveform quality; hence, the method is highly suitable for both grid-tied and standalone renewable energy applications. This work lays a basis for efficient inverter designs that can adapt well under dynamic load conditions. Full article

This work proposes a model-based control scheme using a sliding mode controller (SMC) and an immersion and invariant (I&I) observer. The objective of the proposed control scheme is to be applied to a three-phase grid-tied inverter, which could operate as a shunt active power filter when the photovoltaic array is not generating power (night-time operation). The grid-tied inverter always remains operational, ensuring continuous support of the power quality improvement, as well as current harmonic compensation due to nonlinear loads and power factor correction. An external control loop is included to keep the voltage of the DC-link capacitor regulated. As can be explained in detail along with the work, a battery stack is avoided in this proposed research. Thus, a decision stage is added to the control scheme to select the night or day operation. Simulation results are carried out using Altair-PSIM© to demonstrate the effectiveness of the proposed control scheme in several scenarios. Full article

Distributed energy storage systems (DESSs), which would become key components in a new power system, can flexibly deliver peak load shaving and demand management. With the popularization of distributed renewable energy generation in a distribution network, the grid impedance varies and DESSs thus have to face stability issues. In order to enhance the system’s stability, a compensation strategy is proposed for the inverter in a DESS. First, a stability analysis model is developed to show the main factors that affect system stability. Then, an improved compensation strategy is proposed for the phase-locked loop (PLL) in a DESS, in which control parameters are adaptively tuned on-line according to real-time conditions to improve the stability of a grid-tied DESS. Simulation and hardware-in-the-loop (HIL) experimental results are given to validate the effectiveness of the proposed strategy. Simulation and experimental results show that the proposed strategy significantly increases the system’s tolerance to grid impedance variations, maintains total harmonic distortion (THD) below 5% during normal operation, and effectively reduces low-order harmonic content caused by impedance fluctuations. Moreover, the strategy is demonstrated to enhance system stability under low state-of-charge (SOC) conditions, showcasing its robustness and adaptability across various operating scenarios. Full article

Synchronized variable frequency soft-switching is analyzed and implemented in a 3-phase bidirectional grid-tied inverter. The common-mode connected topology and control allow for independent analysis of a single phase leg before six are combined into two interleaved, 3-phase inverters. Effective operation is enabled by discretizing the variable switching frequencies before synchronizing them with a control signal. The resulting inverter can operate at any power factor at power levels up to 50 kVA while maintaining zero-voltage switching (ZVS) throughout the grid cycle. Formal conditions for soft-switching and methods for achieving ZVS while maintaining global synchronization are presented. These conditions are then verified in a simulation. Finally, results for different power factors with and without interleaving are demonstrated in a prototype that achieves >98.1% efficiency when converting all real power. Full article

This paper presents a trajectory control model using finite state machines for a single-stage soft-switching grid-tied inverter designed with a fast dynamic response. The targeted application is a module-integrated inverter for a single photovoltaic (PV) panel which interfaces distributed energy sources with the grid. To minimize switching lossd provide advanced grid-connected functionality, the soft-switching operation is achieved through a resonant filter using a trajectory control scheme. In recent years, controllers based on digital signal processing platforms have been able to handle complex and high-speed control algorithms with precision for real-time control. In real-time control applications, the finite state machine (FSM) approach enhances responsiveness by minimizing latency with limited memory resources by executing rapid state transitions. The proposed model effectively manages the switching states of the single-stage soft-switching inverters during complex DC/AC bidirectional operations. By directly controlling the energy within the series resonant circuit, the model delivers a fast transient response while minimizing switching actions across all quadrants of operation. The control scheme has been digitally implemented on a Texas Instruments (TI) digital signal processor and validated through Hardware-In-the-Loop (HIL) testing. Full article

This paper studies the impacts of inverter clipping on bifacial PV modules under different weather and ground reflectivity. A 5 kW bifacial array was connected to a 3.8 kW grid-tied inverter, a 10 kWh Li-ion battery, and an EV charger. A PV output calculation model was developed to compare the estimated output of the modules with the actual measurements to evaluate the relation between ground reflectivity and clipping loss. The results showed that clipping potentially occurs on sunny days in summer from 10:00 to 15:00 during the period with the highest solar irradiance. Three colors of ground cover were also examined to compare the performance of bifacial modules under different albedo reflective properties. The results indicated that the white ground in winter leads to the highest bifacial gain (13.1%) and daily DC efficiency (22.2%) due to the combination of high reflectivity with low solar angle giving maximum upward reflection of direct sunlight. This same combination shows a minimal advantage in summer due to the clipping. The proposed model is evaluated, demonstrating 98.2% agreement between modeled and actual data for all conditions. Furthermore, simulation models based on the actual system with different system sizes and ground reflectivities have been studied to evaluate the impacts of the clipping in terms of technical losses and financial returns. The analysis shows that a high reflective ground condition can provide the best financial benefit, and the clipping loss does not have a great effect on the finance of the project since the loss is less than 4% of the annual production even in an extreme case. Full article

This paper proposes goal-function-based decentralized control of microgrids. In addition to being an instrument for maintaining the grid voltage and frequency stability, each grid-tie inverter generates a current component with the aim of compensating for voltage distortion in the node where it is connected. The designed goal-function does not need to rely on the assumption that a microgrid is dominantly inductive or resistive to derive its control law, as is mostly the case with the droop-based approach. The priorities of the proposed scheme can be adjusted according to user preferences. In addition, the control algorithm is independent of network topology, can be applied in both islanded and non-islanded microgrids, and secure system scalability. The proposed method is verified by detailed simulations. Full article

Recent advancements in residential solar electricity have revolutionized sustainable development. This paper introduces a methodology leveraging machine learning to forecast solar panels’ power output based on weather and air pollution parameters, along with an automated model for fault detection. Innovations in high-efficiency solar panels and advanced energy storage systems ensure reliable electricity supply. Smart inverters and grid-tied systems enhance energy management. Government incentives and decreasing installation costs have increased solar power accessibility. The proposed methodology, utilizing machine learning techniques, achieved an R-squared value of 0.95 and a Mean Squared Error of 0.02 in forecasting solar panel power output, demonstrating high accuracy in predicting energy production under varying environmental conditions. By improving operational efficiency and anticipating power output, this approach not only reduces carbon footprints but also promotes energy independence, contributing to the global transition towards sustainability. Full article

Numerous reviews are available in the literature on PV inverter topologies. These reviews have intensively investigated the available PV inverter topologies from their modulation techniques, control strategies, cost, and performance aspects. However, their compliance with industrial standards has not been investigated in detail so far in the literature. There are various standards such as North American standards (UL1741, IEEE1547, and CSA 22.2) and Australian and European safety standards and grid codes, which include IEC 62109 and VDE. These standards provide detailed guidelines and expectations to be fulfilled by a PV inverter topology. Adherence to these standards is essential and crucial for the successful operation of PV inverters, be it a standalone or grid-tied mode of operation. This paper investigates different PV inverter topologies from the aspect of their adherence to different standards. Both standalone and grid-tied mode of operation-linked conditions have been checked for different topologies. This investigation will help power engineers in selecting suitable PV inverter topology for their specific applications. Full article
