The spatial genes of rural settlements show a lot of different traditional settlement traits, which makes them a great starting point for studying rural spatial morphology. However, qualitative and macro-regional statistical indicators are usually used to find and extract rural settlement spatial genes. Taking Yubei Village in the Nanxi River Basin as an example, this study combined remote sensing images, real-time drone mapping, GIS (geographic information system), and space syntax, extracted 12 key indicators from five dimensions (landform and water features (environment), boundary morphology, spatial structure, street scale, and building scale), and quantitatively “decoded” the spatial genes of the settlement. The results showed that (1) the settlement is a “three mountains and one water” pattern, with cultivated land accounting for 37.4% and forest land accounting for 34.3% of the area within the 500 m buffer zone, while the landscape spatial diversity index (LSDI) is 0.708. (2) The boundary morphology is compact and agglomerated, and locally complex but overall orderly, with an aspect ratio of 1.04, a comprehensive morphological index of 1.53, and a comprehensive fractal dimension of 1.31. (3) The settlement is a “clan core–radial lane” network: the global integration degree of the axis to the holy hall is the highest (0.707), and the local integration degree R3 peak of the six-room ancestral hall reaches 2.255. Most lane widths are concentrated between 1.2 and 2.8 m, and the eaves are mostly higher than 4 m, forming a typical “narrow lanes and high houses” water town streetscape. (4) The architectural style is a combination of black bricks and gray tiles, gable roofs and horsehead walls, and “I”-shaped planes (63.95%). This study ultimately constructed a settlement space gene map and digital library, providing a replicable quantitative process for the diagnosis of Jiangnan water town settlements and heritage protection planning. Full article

The utilization of augmented reality (AR) is becoming increasingly prevalent in the integration of virtual reality (VR) elements into the tangible reality of the physical world. It facilitates a more straightforward comprehension of the interconnections, interdependencies, and spatial context of data. Furthermore, the presentation of analyses and the combination of spatial data with annotated data are facilitated. This is particularly evident in the context of mobile applications, where the combination of real-world and virtual imagery facilitates enhances visualization. This paper presents a proposal for the development of a multimodal system that is capable of identifying roof types in real time and visualizing them in AR on mobile devices. The current approach to roof identification is based on data made available by public administrations in an open-source format, including orthophotos and building contours. Existing computer processing technologies have been employed to generate objects representing the shapes of building masses, and in particular, the shape of roofs, in three-dimensional (3D) space. The system integrates real-time data obtained from multiple sources and is based on a mobile application that enables the precise positioning and detection of the recipient’s viewing direction (pose estimation) in real time. The data were integrated and processed in a Docker container system, which ensured the scalability and security of the solution. The multimodality of the system is designed to enhance the user’s perception of the space and facilitate a more nuanced interpretation of its intricacies. In its present iteration, the system facilitates the extraction and classification/generalization of two categories of roof types (gable and other) from aerial imagery through the utilization of deep learning methodologies. The outcomes achieved suggest considerable promise for the advancement and deployment of the system in domains pertaining to architecture, urban planning, and civil engineering. Full article

This work presents the mathematical definition and programming considerations of an efficient geometric algorithm used to add roofs to polyhedral 3D building models obtained from OpenStreetMap. The algorithm covers numerous roof shapes, including some well-defined shapes that lack an explicit reconstruction theory. These shapes include gabled, hipped, pyramidal, skillion, half-hipped, gambrel, and mansard. The input data for the developed code consist of latitude and longitude coordinates defining the target area. Geospatial data necessary for the algorithm are obtained through a request to the overpass-turbo service. The findings showcase outstanding performance for buildings with straightforward footprints, but they have limitations for the ones with intricate footprints. In future work, further refinement is necessary to solve the mentioned limitation. Full article

The application of semantics in facade elements mainly involves the association between architectural elements and their cultural, historical, or functional significance. By analyzing the shape, layout, and decoration of various elements (such as windows, doors, decorative patterns) in facades, semantics helps us understand the symbolic meanings and cultural implications behind these design choices. This study selects twenty-eight pavilions and buildings from five temples and Taoist sites in Jingzhou City as the research objects, exploring the composition and patterns of religious architectural facades in Jingzhou through the extraction of structural and decorative elements. The study establishes the “Semantic System of Façade Elements in Jingzhou Religious Architecture”, from which the distinctive characteristics of Jingzhou religious building façades are identified. The study finds that side halls predominantly feature hard gable roofs, while the main halls use double-eave hip-and-gable roofs, reflecting differences in architectural hierarchy. The sack with three arrows pattern is the most widely used in door and window decorations, demonstrating the aesthetic preferences of the Jingchu region. Both side halls and main halls commonly adopt high podiums, with the main hall podiums typically exceeding twenty steps in height, which is closely related to Jingzhou’s climatic conditions and architectural hierarchy. This study provides scientific evidence for the preservation, new design, and harmonious integration of traditional culture and architectural features in regional religious architecture. Full article

An environmentally conscious architectural design of a railway station can have a substantial influence on government spending. Nevertheless, an extensive collection of guidelines for using sustainable design principles in the construction of a railway station can provide several advantages. The goal is to review design visions for railway stations in Thailand, as reflected in student theses and government proposals, from 1983 to 2022 for sustainable design aspects in tropical climates. We perform an analysis of architectural design aspects including service areas, shape, entrances, roofing, style, and development in order to uncover design trends and possible areas that may be enhanced. Station designs are mostly characterized by curved and gable roofs, with 3D curved buildings being the next most common feature. High speed rail (HSR) stations stress local cultural elements in their major entrances while also improving passenger flow. Public buildings frequently employ curved or gabled porticos to achieve a majestic look. Although university theses place a high importance on conceptual design and functionality, it is essential to also consider cost-effectiveness. Key design considerations for future railway stations are transparency, connection, efficient mobility, and cost–time efficiency. The research uncovers deficiencies in user-centered design for thermal comfort and inclusiveness (design-for-all) in Thailand’s tropical environment. Addressing these aspects is critical for future sustainable railway station design evaluations. Full article

The geometric shape of the roof and the opening position are important parameters influencing the internal cross-ventilation of buildings. Although there has been extensive research on natural ventilation, most of it has focused on flat or sloping roofs with the same opening positions. There is still limited research on the impact of different opening positions and sloping roofs on natural ventilation. In this study, computational fluid dynamics (CFD) was used to investigate the air exchange efficiency (AEE) in general isolated buildings. These buildings encompassed three distinct opening configurations (top–top, top–bottom, and bottom–top) and six varying slope angles for gable roofs (0°, 9°, 18°, 27°, 36°, and 45°). Computational simulations were carried out using the SST k-omega turbulence model, and validation was performed against experimental data supplied by the Japanese AIJ Wind Tunnel Laboratory. Grid independence validation was also conducted to ensure the reliability of the CFD simulation results. The study revealed that the highest AEE was 48.1%, achieved with the top–bottom opening configuration and a gable roof slope angle of 45°. Conversely, the lowest AEE was 31.4%, attained with the bottom–top opening configuration and a gable roof slope angle of 27°. Furthermore, it was observed that when the opening configuration was set to top–top and bottom–top, the slope angle of the gable roof had minimal influence on AEE, with an average AEE of only around 33%. When the opening configuration was top–bottom, it was found that there was a positive correlation between the gable roof slope angle and AEE. Full article

The demand for PV on roof installations in the household sector is increasing. In this paper, an investigation on optimizing the energy performance of PV on housing roofs is conducted. Three housing roof designs found in Gorontalo city are selected as the mounting planes for PV on roofs. The designs represent stacked gable roofs, complex gable roofs, and complex hip roofs. The purpose of the research is to find which roof shape is better for PV mounting in terms of sun radiation gain and access, mountable spaces, and orientation flexibility. This research employs Rhinoceros 3D to model the three roofs. The models are designed to face 12 directions, from 0° to 330°. Radiation analysis using Ladybug is utilized to study the roof’s performance in obtaining solar radiation in all 12 directions. It was found that the complex hip roof has more evenly distributed solar radiation on the roof planes, is flexible for PV mounting in any orientation, but has few mountable spaces. The stacked gable roof has two out of four suitable planes to gain solar radiation, but they are spacious. The complex gable roof has only one out of five suitable planes since they are narrow and prone to self-shading. Overall, a stacked gable roof provides a better option for PV installation compared to the other roof shapes. Full article

Triangles are an ever-present feature in nature, which the building construction industry duly echoes. However, an exact expression intended to supply the radiant field of any triangle in an upright or inclined position has not been identified by previous research. In this case, the author has been able to solve, via direct integration, the canonical expression of radiative transfer. This result alone confers a myriad of possibilities, that had been inconceivable before, for studying in detail the three-dimensional heat-transfer behavior of volumes and figures in which triangles manifest, such as fins, windows, roof-gables and louvers of various kinds. Typically, shading devices, when tilted, give rise in their extremes to rhomboidal shapes which were difficult to take into account or had to be subject to discretization and subsequent Monte Carlo methods in order to perform an approximate calculation of their emissions. This implied a lengthy and inexact procedure that induced many errors and consumed computing time. We can now avoid all these former downsides due to the advances hereby presented. As this novel expression can be converted into an algorithm, it will be advantageously employed for simulation. This significant finding dovetails into the intricate puzzle of radiated heat and we believe that its consequences will greatly affect the conception and design of HVAC devices, aircraft manufacturing and specifically the building or lighting industries, among others. Full article

In this work, we report an optofluidic system for manipulation of orientation of zeolite crystals near the bottom of a rectangular cross-sectional, straight, quartz microfluidic channel. Manipulation is accomplished by using two computer-controlled syringe pumps that generate adequate hydrodynamic forces for translation and rotation of crystals. Rotation of a crystal around its longitudinal axis allows us to inspect its four major faces for defects. Coffin-shaped zeolite crystals have been studied by several authors by fixing them to a substrate, using two different crystals to assess the roof and gable orientations. The proposed system permits complete assessment of a single crystal by shifting it between roof and gable orientations; moreover the medium can be controlled. Computational fluid dynamics simulations show that crystals in free motion near the bottom of the channel should move faster than the velocity estimated from video. An opposing force, which prevents the crystals from moving freely, has been calculated in order to match translation velocities from simulations and experiments for three given flow rates. The reported optofluidic system is proposed as a novel tool that we believe will open new possibilities for individual zeolite crystal assessment by manipulation of its orientation and medium control. Full article

Cases of building decay and structural damage caused by the impact of snow loads are registered every year throughout the world. Such destruction not only results in property loss, but also leads to human losses. A database on 266 cases of roof collapse caused by snow loads in Russia for the period from 2001 to 2021 was collated for this study. The data were analyzed by date and place of collapse, building data, and number of victims. The analysis showed that civilian buildings are the most vulnerable, comprising 78% of the total number of collapses, followed by industrial buildings with 15% and agricultural buildings with only 7%. The relationships between roof shape, roofing material, number of floors, and type of collapsed building were determined. The data processing results showed that low-rise residential buildings (one to two floors) with a gable roof covered with fiber cement should be considered the most vulnerable. A linear relationship was revealed between a collapse area of more than 150 m² and the cumulative number of collapse cases. The obtained results have practical application for rating building vulnerability to natural hazards and assessing the risk of emergencies associated with snow loads. Full article

The adequacy of the directional and envelope procedures for the design of the main wind force resisting system is not well understood. The purpose of this study is to evaluate the directional and envelope procedures based on wind tunnel test data for a set of low-rise enclosed buildings with gable-shaped roofs in open terrain (Exposure C). The base shear force and the conditional reliability index are used to determine the adequacy of the procedures. The base shear was compared to the design base shear in each direction based on the horizontal component of the wind load on the wall and roof. The reliability index, β conditional on the occurrence of the design wind speed was computed for a range of system capacities. The main findings are (1) the directional procedure produced a larger design base shear compared to the envelope procedure, primarily due to the difference in external pressure coefficients, (2) the directional procedure provided a higher β, and (3) the envelope procedure provided a β that did not meet the standard target β equal to 3.0 for the main wind force resisting systems with low variability in capacity, but neither procedure met the standard target β for the main wind force resisting systems with high variability in capacity. Full article

The basic urban tissue of medieval European cities consisted of brick townhouses. In the cities of northern Europe, these tenements were characterised by a block based on an elongated rectangular plan, covered with a gable roof with a ridge oriented perpendicularly to the street. The side walls of the tenement house were common for both neighbours and constituted a basic structural element. The gable façades were not loaded with ceilings, providing freedom in shaping them. The aim of this work is to determine the reasons why this method of shaping tenement houses in historical city centres has survived to the present day, becoming an archetype for contemporary architectural and construction solutions, despite the passage of time, numerous historical events, war damage, changing architectural styles, fashions and building techniques and technologies. The historical centre of Gdańsk has become the research material in this paper, where by means of such methods as historical source material analysis (iconographic), observation (operationalisation of preserved historical objects), comparative analysis of completed contemporary investments, and 3D modelling of structural systems, an attempt has been made to determine the main factors determining contemporary architectural and structural solutions. The reason for the extraordinary durability of this type of construction model can be found in the enormous rationality and efficiency of this solution. It allows for very intensive use of land, easy access of all front elevations to the main communication routes, cheapness of construction resulting from small spans and use of common structural walls for the neighbouring buildings, ease of shaping gable elevations, and fire safety. Aesthetic considerations are probably also important here, although it should be assumed that their significance began to grow only in the second half of the 19th century. However, it seems that the most important factor which made the model of the mediaeval bourgeois tenement house become an archetype for contemporary architectural and construction solutions is the timeless message contained in this model, a specific code allowing it to be unambiguously identified as a form of urban house—a place of safe living and at the same time a visible sign of the rich history of European cities, an element creating their cultural and spatial identity, a component of the living, constantly transforming urban fabric. Full article

In this study, we have developed a numerical model based on an open source Computational Fluid Dynamics (CFD) package OpenFOAM, in order to investigate the flow pattern and pollutant dispersion in urban street canyons with different geometry configurations. In the new model, the pollutant transport driven by airflow is modeled by the scalar transport equation coupling with the momentum equations for airflow, which are deduced from the Reynolds Averaged Navier-Stokes (RANS) equations. The turbulent flow calculation has been calibrated by various two-equation turbulence closure models to select a practical and efficient turbulence model to reasonably capture the flow pattern. Particularly, an appropriate value of the turbulent Schmidt number has been selected for the pollutant dispersion in urban street canyons, based upon previous studies and careful calibrations against experimental measurements. Eventually, the numerical model has been validated against different well-known laboratory experiments in regard to various aspect ratios (a relationship between the building height and the width of the street canyon), and different building roof shapes (flat, shed, gable and round). The comparisons between the numerical simulations and experimental measurements show a good agreement on the flow pattern and pollutant distribution. This indicates the ability of the new numerical model, which can be applied to investigate the wind flow and pollutant dispersion in urban street canyons. Full article

The prospect of harnessing wind energy in urban areas is not promising owing to low wind speeds and the turbulence caused by surrounding obstacles. However, these challenges can be overcome through an improved design of wind turbine that can operate efficiently in an urban environment. This paper presents a novel design of a building integrated cross axis wind turbine (CAWT) that can operate under dual wind direction, i.e., horizontal wind and vertical wind from the bottom of the turbine. The CAWT consists of six horizontal blades and three vertical blades for enhancing its self-starting behavior and overall performance. The study employed a mock-up building model with gable rooftop where both of the developed CAWT and the conventional straight-bladed vertical axis wind turbine (VAWT) are mounted and tested on the rooftop. The height of the CAWT and the VAWT above the rooftop was varied from 100 to 250 mm under the same experimental conditions. The results obtained from the experimental study showed that there is significant improvement in the coefficient of power (C_p) and self-starting behavior of the building integrated CAWT compared to the straight-bladed VAWT. At 100 mm height, the C_p,max value of the CAWT increased by 266%, i.e., from 0.0345 to 0.1263, at tip speed ratio (TSR) (λ) of 1.1 and at wind speed of 4.5 m/s. Similar improvements in performance are also observed for all condition of CAWT heights above the rooftop where the CAWT outperformed the straight-bladed VAWT by 196%, 136% and 71% at TSR of 1.16, 1.08, and 1.12 for Y = 150, 200, and 250 mm, respectively. Moreover, the CAWT performs better at 10° pitch angle of the horizontal blade compared to other pitch angles. Full article
