A computational fluid dynamics (CFD) numerical simulation methodology was implemented to model transient heating processes in steel industry reheating furnaces, targeting combustion efficiency optimization and carbon emission reduction. The effects of oxygen concentration (O₂%) and different fuel types on the flow and heat transfer characteristics were investigated under both oxygen-enriched combustion and MILD oxy-fuel combustion. The results indicate that MILD oxy-fuel combustion promotes flue gas entrainment via high-velocity oxygen jets, leading to a substantial improvement in the uniformity of the furnace temperature field. The effect is most obvious at O₂% = 31%. MILD oxy-fuel combustion significantly reduces NOx emissions, achieving levels that are one to two orders of magnitude lower than those under oxygen-enriched combustion. Under MILD conditions, the oxygen mass fraction in flue gas remains below 0.001 when O₂% ≤ 81%, indicating effective dilution. In contrast, oxygen-enriched combustion leads to a sharp rise in flame temperature with an increasing oxygen concentration, resulting in a significant increase in NOx emissions. Elevating the oxygen concentration enhances both thermal efficiency and the energy-saving rate for both combustion modes; however, the rate of improvement diminishes when O₂% exceeds 51%. Based on these findings, MILD oxy-fuel combustion using mixed gas or natural gas is recommended for reheating furnaces operating at O₂% = 51–71%, while coke oven gas is not. Full article

To compensate for the instability of renewable energy sources during China’s energy transition, large thermal power plants must provide critical operational flexibility, primarily through deep peaking. To investigate the combustion performance and wear and tear of a 600 MW pulverized coal boiler under deep peaking, the gas–solid flow characteristics and distributions of flue gas temperature, wall heat flux, and wall wear rate in a 600 MW tangentially fired pulverized coal boiler under variable loads (353 MW, 431 MW, 519 MW, and 600 MW) are investigated in this study employing computational fluid dynamics numerical simulation method. Results demonstrate that increasing the boiler load significantly amplifies gas velocity, wall heat flux, and wall wear rate. The maximum gas velocity in the furnace rises from 20.9 m·s⁻¹ (353 MW) to 37.6 m·s⁻¹ (600 MW), with tangential airflow forming a low-velocity central zone and high-velocity peripheral regions. Meanwhile, the tangential circle diameter expands by ~15% as the load increases. The flue gas temperature distribution exhibits a “low-high-low” profile along the furnace height. As the load increases from 353 MW to 600 MW, the primary combustion zone’s peak temperature rises from 1750 K to 1980 K, accompanied by a ~30% expansion in the coverage area of the high-temperature zone. Wall heat flux correlates strongly with temperature distribution, peaking at 2.29 × 10⁵ W·m⁻² (353 MW) and 2.75 × 10⁵ W·m⁻² (600 MW) in the primary combustion zone. Wear analysis highlights severe erosion in the economizer due to elevated flue gas velocities, with wall wear rates escalating from 3.29 × 10⁻⁷ kg·m⁻²·s⁻¹ (353 MW) to 1.23 × 10⁻⁵ kg·m⁻²·s⁻¹ (600 MW), representing a 40-fold increase under full-load conditions. Mitigation strategies, including ash removal optimization, anti-wear covers, and thermal spray coatings, are proposed to enhance operational safety. This work provides critical insights into flow field optimization and wear management for large-scale coal-fired boilers under flexible load operation. Full article

The interaction mechanism of multi-physical fields in a 330 MW tangentially fired boiler is explored by coupling the CFD (computational fluid dynamics) model and the working fluid side hydrodynamic model under steady-state conditions. The research focuses on the flue gas flow field, the hydrodynamic safety of the water wall, the variation of the working fluid parameters and the formation and distribution characteristics of sulfide (SO₂, H₂S) under different steady loads (35%, 50%, 75%, 100% Boiler Maximum Continuous Rating). The results show that under high load, the flue gas attaches to the wall. The overall stagnation differential pressure ratio (1.85–2.07) and reversal differential pressure ratio (1.22–1.30) of the G1 tube group with the lowest heat flux are higher than the safety threshold (1.05), proving reliable operational safety under equilibrium conditions. The temperature distribution of the furnace center obtained by numerical simulation is consistent with the actual situation. The mass fraction of sulfide increases significantly with the increase in load. SO₂ is mainly distributed in the wall area of the middle and upper burners, while H₂S is mainly distributed in the wall area between the secondary air and the main burner. The maximum mass fractions of SO₂ and H₂S at 330 MW are 0.120% and 0.0524%, respectively. It is suggested that a wall-attached air system be added to inhibit the enrichment of corrosive gases. This work may provide theoretical support and engineering guidance for multi-objective optimization design and high temperature corrosion prevention and control of tangentially fired boilers. Full article

A flow cell is a critical measurement interface for many optical instruments. However, the flows are often sampled under harsh conditions, such as under high pressure and/or high temperature, in the presence of particles, moisture, vapors with high dew points or corrosive gases. Therefore, obtaining a high-optical-quality flow cell that does not perturb the measurement is a significant challenge. To address this challenge, we proposed a new flow cell that employs a unique laminar coaxial flow field (for the purge and sample flows). A test system was built to conduct particle size distribution (PSD) measurements with no sampling bias using a state-of-the-art analyzer (Malvern Panalytical Insitec). The results revealed that the measurement zone is well defined solely by the sample flow, and the optical windows are well protected by the purge flow, with minimal risk of any depositions from the sample flow. Using this flow cell, the Insitec can successfully measure PSD under high pressure and temperature under moist, corrosive conditions without generating any sampling bias. Importantly, we successfully applied this flow cell for on-line PSD measurement for the flue gas of a 100 kW_th pressurized oxy-coal combustor operating at 15 bara. Full article

This paper presents a numerical simulation and structural optimization study of the combustion process within the grate and boiler furnace of a 750 t/d waste incineration. The study focuses on adjusting the secondary air velocity, secondary air inclination angle, and the arrangement of secondary air nozzles. These adjustments aim to optimize parameters such as the temperature field, pollutant emission, flow field, particle residence time, and filling degree. The findings demonstrate that high-temperature zones, which lead to slagging problems, are likely to form beneath the front arch. The combustibles inside the furnace are thoroughly burnt, reflecting efficient combustion. The concentration of NOx in the flue gas at the furnace outlet generally ranges between 170 and 200 ppm. Optimal operating conditions are identified as a secondary air inclination angle of 20° with an air velocity of 55 m/s, and an angle of 30° with an air velocity of 55 m/s and 65 m/s, in conjunction with a relative arrangement of the nozzles. Under these conditions, the incineration furnace achieves its best operational state. Full article

To eliminate the flow dead zone and homogenize the asymmetric flow field of a grate furnace, spirally twisted tape inserts (STTIs) with a pitch ratio of 1.5 were installed in the vertical flues of an SCL1000-13.5/450 grate boiler. The arrangement schemes found to be present inside the chosen 1000 t/d grate furnace, determined using the orthogonal experimental method, included separate installation in chamber II, separate placement in chamber III, and simultaneous arrangement in both chamber II and chamber III. The effects of row spacing H, column spacing W, and mounting angle φ were investigated by means of the practicable and feasible numerical simulation method. With a focus on the uniformity degree of the flue gas, the results showed that temperature distribution is directly correlated with the velocity field. When it comes to the uniformity of the flow field, the exclusive use of STTIs in chamber II was better than that in chamber III. Under the optimal combination scheme of STTIs in both chamber II and chamber III (scheme N3₂₃), the exhaust gas temperature reached the minimum value and the uniformity index of temperature increased to the range of 0.994~0.997. The findings in this work could provide a reference for the optimization of the flow field in a grate furnace. Full article

To investigate the combustion process and reduce Nitric Oxide (NO) emissions in the vertical heating flue of air-staged coke ovens, a three-dimensional computational fluid dynamics method was applied to simulate the combustion process. The model integrates the k-ε turbulence model with a multi-component transport combustion model. The impact of air staging on the flow field and NO emissions in the vertical fire chamber was assessed through comparative validation with experimental data. The impact of air staging on the flow field and NO emissions in the vertical fire chamber was assessed through comparative validation with experimental data. Based on this research, the effects of the excess air coefficient and air inlet distribution ratio on NO emission levels at the flue gas outlet were further investigated. Analysis of the flow field structure, temperature at the center cross-section, component concentration, and NO emission levels indicates that as the excess air coefficient increases, the NO emission levels at the flue gas outlet initially decrease and then increase, accompanied by corresponding changes in outlet temperature. At an air excess factor of 1.3 and an air inlet distribution ratio of 7:3, NO emission levels are at their lowest—53% lower than those in a conventional coke oven—and the temperature distribution in the riser channel is more uniform. These results provide a theoretical foundation for designing the air-staged coke oven standing fire channel structure. Full article

In this work, we attempt to explain the phenomenon of sulfur corrosion of power boiler water walls under the conditions of large fluctuations in carbon monoxide concentrations. To assess the conditions required for corrosion formation, a criterion based on the chemical and flow field parameters of the flue gas is proposed. The formulated sulfur corrosion criterion is based on the mixture fraction variance and the turbulence time scale. Numerical modeling of coal combustion in a 250 MW power boiler is performed using ANSYS. Two cases of combustion in a boiler are analyzed, with the first simulating the boiler operated using classic high-swirl burners and the second one accounting for boiler operation with modified low-swirl burners. Calculations of pulverized coal combustion are performed using the standard k-$\epsilon$ turbulence model and the combustion described by the mixture fraction. The simulation results reveal that the low-swirl burner is characterized by higher values of the mixture fraction variance and a higher frequency of fluctuation of the velocity field, which is strongly related to an increased corrosion rate. The study outcomes show the validity of using the criterion of the mixture fraction variance and velocity field fluctuations to determine the areas at risk of sulfur corrosion. Full article

Dense-phase-tower desulfurization technology is an emerging semi-dry flue-gas desulfurization ash process, i.e., the flue gas is allowed to enter the desulfurization tower from the bottom up and, at the same time, is sprayed with a desulfurizing agent that undergoes an acid–base reaction with the flue gas in the ascent process. The calcium sulfite and calcium sulfate produced by the reaction and the part of the desulfurization agent that is not involved in the reaction will enter the subsequent dust removal system, and what is retained is the by-product desulfurization ash. This desulfurization ash contains a large amount of calcium sulfite, which leads to its unstable nature; it is easily oxidized and expands in volume, and, if used in the field of building materials, it will lead to cracking and other problems, so it is difficult to effectively use it. In order to solve this problem, XRF, XRD, and iodometric and other analytical methods were used to determine the specific composition of desulfurization ash, and the muffle furnace and vertical tube furnace were used to study the thermal oxidative modification of calcium sulfite in desulfurization ash, to investigate the effects of the oxygen content, reaction temperature, medium flow rate, and chloride content on the oxidation of calcium sulfite, and to analyze the thermodynamics in the high-temperature oxidation reaction. The results showed that the oxidation rate of calcium sulfite increased with higher reaction temperatures. Increased oxygen content promoted the oxidation rate, particularly at low oxygen levels. The oxidation rate of calcium sulfite correlated positively with the medium flow rate until a rate of 75 mL·min⁻ was reached. At a reaction temperature of 420 °C and a gas flow rate of 85 mL·min⁻¹, the oxidation conversion efficiency exceeded 89%. Chloride content significantly reduced the oxidation rate of calcium sulfite, although this inhibition weakened at temperatures above 500 °C. Kinetic analysis suggested that the oxidation reaction of calcium sulfite predominantly occurred below 500 °C. These findings have both theoretical and practical implications for the thermal oxidation treatment and disposal of desulfurization ash. Full article

Numerical and experimental studies were conducted to study the nonlinear phenomena of a 1000 MW ultra-supercritical four-corner tangential pulverized coal boiler. In this paper, (1) a 3D model of a furnace with a symmetrical structure was established to analyze the asymmetric flow phenomenon and multi-solution phenomenon of flow for multiple timepoints under the same boundary conditions. (2) The visual experiment verified that the flow in the furnace also behaved asymmetrically. (3) On the basis of correctly predicting the nonlinear law, the “diagonal start up” method and the “sequential start up” method are proposed. (4) An uneven coefficient of velocity distribution M, deviation coefficient of flue gas mass flow rate E_q and gas temperature deviation coefficient E_T are proposed to quantitatively analyze the degree to which the actual tangent circle deviates from the ideal tangent circle. The tangent circle under the “sequential start up” method is the closest to the ideal, which can reduce the thermal deviation of the furnace outlet from 67 K under the “simultaneous start up” method to 41 K. In this paper, the initial steady-state flow field in the furnace is established by using the initial value sensitivity of the nonlinear system through different burner-opening methods, so as to reduce the thermal deviation at the furnace outlet and achieve the purpose of accurate control. Full article

A numerical model of a flue gas scrubber sump is developed with the aim of enabling optimization of the design of the sump in order to reduce energy consumption. In this model, the multiphase flow of the continuous phase, i.e., water, and the dispersed phase, i.e., air bubbles, is considered. The air that is blown in front of the agitators, as well as the influence of the flow field of the agitators on the distribution of the dispersed phase and the recirculation pumps as outlet, is modeled. The bubble Sauter mean diameter is modeled using the population balance model. The model is used to analyze operating parameters such as the bubble retention time, the average air volume fraction, bubble Sauter mean diameter, the local distribution of the bubble size and the amount of air escaping from the pump outlets at two operating points. The purpose of the model is to simulate the two-phase flow in the sump of the flue gas scrubber using air dispersion technology with a combination of spargers and agitators, which, when optimized, reduces energy consumption by 33%. The results show that the homogeneity of air is lower in the bottom part of the absorber sump and that the amount of air escaping through recirculation pipes equals 1.2% of the total air blown into the absorber sump. The escaping air consists mainly of bubbles smaller than 6 mm. Additional operating point results show that halving the magnitude of the linear momentum source lowers the air retention, as well as the average homogeneity of the dispersed air. Full article

Gas-fed reactors for CO₂ reduction processes are a solid technology to mitigate CO₂ accumulation in the atmosphere. However, since it is necessary to feed them with a pure CO₂ stream, a highly energy-demanding process is required to separate CO₂ from the flue gasses. Recently introduced bicarbonate zero-gap flow reactors are a valid solution to integrate carbon capture and valorization, with them being able to convert the CO₂ capture medium (i.e., the bicarbonate solution) into added-value chemicals, such as CO, thus avoiding this expensive separation process. We report here a study on the influence of the electrode structure on the performance of a bicarbonate reactor in terms of Faradaic efficiency, activity, and CO₂ utilization. In particular, the effect of catalyst mass loading and electrode permeability on bicarbonate electrolysis was investigated by exploiting three commercial carbon supports, and the results obtained were deepened via electrochemical impedance spectroscopy, which is introduced for the first time in the field of bicarbonate electrolyzers. As an outcome of the study, a novel low-loaded silver-based electrode fabricated via the sputtering deposition technique is proposed. The silver mass loading was optimized by increasing it from 116 μg/cm² to 565 μg/cm², thereby obtaining an important enhancement in selectivity (from 55% to 77%) and activity, while a further rise to 1.13 mg/cm² did not provide significant improvements. The tremendous effect of the electrode permeability on activity and proficiency in releasing CO₂ from the bicarbonate solution was shown. Hence, an increase in electrode permeability doubled the activity and boosted the production of in situ CO₂ by 40%. The optimized Ag-electrode provided Faradaic efficiencies for CO close to 80% at a cell voltage of 3 V and under ambient conditions, with silver loading of 565 μg/cm², the lowest value ever reported in the literature so far. Full article

In view of the tremendous emissions of toxic gases and particulate matter (PM) by low-power firewood-fueled fireplaces, there is an urgent need for effective measures to lower emissions to keep this renewable and economical source for private home heating available in the future. For this purpose, an advanced combustion air control system was developed and tested on a commercial fireplace (HKD7, Bunner GmbH, Eggenfelden, Germany), complemented with a commercial oxidation catalyst (EmTechEngineering GmbH, Leipzig, Germany) placed in the post-combustion zone. Combustion air stream control of the wood-log charge combustion was realized by five different control algorithms to describe all situations of combustion properly. These control algorithms are based on the signals of commercial sensors representing catalyst temperature (thermocouple), residual oxygen concentration (LSU 4.9, Bosch GmbH, Gerlingen, Germany) and CO/HC-content in the exhaust (LH-sensor, Lamtec Mess- und Regeltechnik für Feuerungen GmbH & Co. KG, Walldorf (Germany)). The actual flows of the combustion air streams, as calculated for the primary and secondary combustion zone, are adjusted by motor-driven shutters and commercial air mass flow sensors (HFM7, Bosch GmbH, Gerlingen, Germany) in separate feedback control loops. For the first time, the residual CO/HC-content (CO, methane, formaldehyde, etc.) in the flue gas is in-situ monitored with a long-term stable AuPt/YSZ/Pt mixed potential high-temperature gas sensor, which allows continuous estimation of the flue gas quality with an accuracy of about ±10%. This parameter is not only an essential input for advanced combustion air stream control but also provides monitoring of the actual combustion quality and logging of this value over a whole heating period. By many firing experiments in the laboratory and by field tests over four months, it could be demonstrated that with this long-term stable and advanced automated firing system, depression of the gaseous emissions by about 90% related to manually operated fireplaces without catalyst could be achieved. In addition, preliminary investigations at a firing appliance complemented by an electrostatic precipitator yielded PM emission depression between 70% and 90%, depending on the firewood load. Full article

The cement industry is one of the primary sources producing anthropogenic CO₂ emissions. The significant increase in the demand for cement in years has significantly contributed to the increase in carbon emissions. Among numerous CO₂ treatment technologies, calcium looping (CaL) is a practical approach to mitigating CO₂ emissions. This paper used calcium looping (CaL) to capture CO₂ from flue gas in a cement pre-calciner kiln system. The raw material exiting the lowest stage of the preheater is used as a calcium-based adsorbent, and the carbonation reactor is built between the tertiary and secondary preheaters, using the high-temperature flue gas exiting the tertiary preheater to provide heat for the reaction. The CFD (Computational Fluid Dynamics) simulation technology was used to evaluate the rationality of the carbonation reactor and the key factors affecting the carbon removal efficiency of the carbonation reactor. The results indicate that the velocity and pressure fields of the carbonation reactor conform to the general operating rules and are reasonable. The optimal operating speed of particles in the carbonation reactor is 15 m/s, with a separation efficiency of particles of 92.5%, ensuring the smooth discharge of reaction products. The factor analysis of the carbonation reactor shows that when the temperature is 911 K, the mass flow rate of CaO is 2.07 kg/s, and the volume fraction of CO₂ is 0.28, the carbonation reaction reaches a chemical equilibrium state, and the carbon removal efficiency is 90%. It should be noted that this carbon removal efficiency is the optimal carbon removal efficiency based on a combination of economic factors. In addition, the influencing factors show a precise sequence: CO₂ volume fraction > CaO addition amount > temperature. Finally, we investigated the impact of the addition of the carbonation reactor on the preheater system. The results show that adding the carbonation reactor causes an increase in the flue gas velocity at the outlet of the preheater and a decrease in pressure, reducing the separation efficiency. Although the separation efficiency decreases slightly, the impact on the pre-calciner system is minimal. Full article

In this study, the temperature and thermal stress fields of an internal combustion hot blast stove were calculated and analysed. Turbulent, species transport, chemical reaction, radiation, and porous media models were implemented in a computational fluid dynamics model. Thermal boundary conditions on the structure of the hot blast stove were calculated based on the analytic adiabatic Y-plus method. A method to interpolate the thermal boundary conditions to a finite element mesh was developed, and the boundary conditions were mapped through the proposed method. In the on-gas period, the vortex was generated in the dome, and it made the variation of the temperature field in the checker chamber. The maximum temperature of the flue gas reached 1841 K in the on-gas period. In the on-blast period, the flow was considerably even compared to the on-gas period, and the average blast temperature reached 1345 K. The outer region of the checker chamber is shown to be continuously exposed to a higher temperature, which makes the region the main domain in managing the deterioration of the refractory linings. The shell temperature did not change during the operation due to the lower thermal diffusivity of the refractory linings, where the inner surface of the refractory had a maximum temperature change from 1441 K to 1659 K. The maximum temperature of the shell was 418.4 K at the conical region of the checker chamber side. The conical region had the higher maximum and middle principal thermal stresses due to the presence of a large temperature gradient around the conical region, where the largest maximum and middle principal stresses were 300.6 MPa and 192.0 MPa, respectively. The conical region was found to be a significant area of interest where it had a higher temperature and thermal stress. Full article
