Optical fiber-based biosensors have proven to be a powerful platform for chemical and biological analysis due to their compact size, fast response, high sensitivity, and immunity to electromagnetic interference. Among the various fiber designs, tapered optical fibers have gained prominence due to the increased evanescent fields that significantly improve light–analyte interactions, making them well-suited for advanced sensing applications. At the same time, advances in microfluidics have allowed for the precise control of small-volume fluids, supporting integration with optical fiber sensors to create compact and multifunctional optofluidic systems. This review explores recent developments in optical fiber optofluidic sensing, with a focus on two primary architectures: in-fiber and outside-fiber platforms. The advantages, limitations, and fabrication strategies for each are discussed, along with their compatibility with various sensing mechanisms. Special emphasis is placed on tapered optical fibers, focusing on design strategies, fabrication, and integration with microfluidics. While in-fiber systems offer compactness and extended interaction lengths, outside-fiber platforms offer greater mechanical stability, modularity, and ease of functionalization. The review highlights the growing interest in tapered fiber-based optofluidic biosensors and their potential to serve as the foundation for autonomous lab-on-a-fiber technologies. Future pathways for achieving self-contained, multiplexed, and reconfigurable sensing platforms are also discussed. Full article

In this paper, we demonstrate a broadband and simultaneous waveguide array light source based on water-soluble CdSe/ZnS quantum dots (QDs). We initially measure the fluorescence intensity for various cladding solution concentrations along the fiber axis to assess their impact on the propagation loss; the experimental results show that the fluorescent intensity decreases with fiber length, with higher concentrations showing a more pronounced decrease. Then, we showcase a synchronous QD light source in an optofluidic chip that fluoresces in red, green, and blue (RGB) within a microfluidic channel. Finally, a 3 × 3 QD array of a fluorescent display on a single PDMS chip is demonstrated. The QD waveguide represents a compact and stable structure that is readily manufacturable, making it an ideal light source for advancing high-throughput biochemical sensing and on-chip spectroscopic analysis. Full article

Interest grows in designing silicon-on-insulator slot waveguides to trap optical fields in subwavelength-scale slots and developing their optofluidic devices. However, it is worth noting that the inherent limitations of the waveguide structures may result in high optical losses and short optical paths, which challenge the device’s performance in optofluidics. Incorporating the planar silicon-based slot waveguide concept into a silica-based hollow-core fiber can provide a perfect solution to realize an efficient optofluidic waveguide. Here, we propose a subwavelength-scale liquid-core hybrid fiber (LCHF), where the core is filled with carbon disulfide and surrounded by a silicon ring in a silica background. The waveguide properties and the Stimulated Raman Scattering (SRS) effect in the LCHF are investigated. The fraction of power inside the core of 56.3% allows for improved sensitivity in optical sensing, while the modal Raman gain of 23.60 m⁻¹·W⁻¹ is two times larger than that generated around a nanofiber with the interaction between the evanescent optical field and the surrounding Raman media benzene-methanol, which enables a significant low-threshold SRS effect. Moreover, this in-fiber structure features compactness, robustness, flexibility, ease of implementation in both trace sample consumption and reasonable liquid filling duration, as well as compatibility with optical fiber systems. The detailed analyses of the properties and utilizations of the LCHF suggest a promising in-fiber optofluidic platform, which provides a novel insight into optofluidic devices, optical sensing, nonlinear optics, etc. Full article

In the field of biomedicine, efficiently and non-invasively isolating target cells has always been one of the core challenges. Optical fiber tweezers offer precise and non-invasive manipulation of cells within a medium and can be easily integrated with microfluidic systems. Therefore, this paper investigated the mechanism of cell manipulation using scattering force with optical fiber tweezers. We employed flat-ended single-mode fiber to drive and sort cells and derived the corresponding scattering force formula based on the T-matrix model. A single-mode optical tweezers system for cell sorting was developed, and an optofluidic experimental platform was constructed that effectively integrates the optical system with microfluidic chips. The chip, featuring an expanded cross-channel design, successfully achieved continuous separation of yeast cells (8~10 µm in diameter) and polystyrene microspheres (15~20 µm in diameter), with a sorting efficiency of up to 86% and maintaining viability in approximately 90% of the yeast cells. Compared to other sorting systems, this system does not require labeling and can achieve continuous sorting with cell viability at a lower cost of instrumentation. Full article

Microcavity lasers are widely applied in bio-chemical sensing, molecular targeted detection, integrated labeling source, and optofluidic control. Particularly, the microstructured optical-fiber-based laser is expected to be a promising candidate for its high-quality factor, low threshold, high integration, and low energy consumption. Moreover, the latest nano technology improves its lasing performance in spectral range, linewidth, and circling lifetime. Considering the specificity in this paper, the discussion presented herein focuses on several typical cases of the microcavity lasers integrated in microstructured optical fiber over the past decades. These micro- and nano-scaled lasers are expected to become a priority in next-generation integrated optics and biomedical photonics. Full article

In this paper, a novel platform for lab-in-fiber-based biosensors is studied. Hollow-core tube lattice fibers (HC-TLFs) are proposed as a label-free biosensor for the detection of DNA molecules. The particular light-guiding mechanism makes them a highly sensitive tool. Their transmission spectrum is featured by alternations of high and low transmittance at wavelength regions whose values depend on the thickness of the microstructured web composing the cladding around the hollow core. In order to achieve DNA detection by using these fibers, an internal chemical functionalization process of the fiber has been performed in five steps in order to link specific peptide nucleic acid (PNA) probes, then the functionalized fiber was used for a three-step assay. When a solution containing a particular DNA sequence is made to flow through the HC of the TLF in an ‘optofluidic’ format, a bio-layer is formed on the cladding surfaces causing a red-shift of the fiber transmission spectrum. By comparing the fiber transmission spectra before and after the flowing it is possible to identify the eventual formation of the layer and, therefore, the presence or not of a particular DNA sequence in the solution. Full article

In this work, we investigated a platform for real-time emulsion droplet detection and size measurement in optofluidic platforms. An 8.2 µm core diameter input optical fiber and a multi-mode Gradient Refractive Index (GRIN) output fiber were integrated into an acrylic microfluidic channel platform consisting of three layers. Water-in-oil emulsions were investigated, since relevant applications have emerged in the recent past for these types of emulsions, such as drug encapsulation as well as droplet-based Polymerase Chain Reaction (PCR) amplification of DNA, among others. The main contribution of this work is in understanding the main physical phenomena (i.e., total internal reflection, refraction, and interference) behind the complex transmittance pattern obtained for these droplets. For this purpose, a frequency domain electromagnetic wave propagation modelling of the structure using the Finite Element Method (FEM) was used along with experimental measurements. Full article

We present a combination of micromachined optofluidic platforms equipped with a fiber-optic sensing configuration based on a three-path Mach–Zehnder interferometer (MZI) for simultaneous measurement of the refractive index of liquids and the autocalibration in dynamic regime. The sensing principle is based on the low-coherence interferometry, characterized by a generation of Gaussian enveloped interferograms, for which the position of its maximum depends on the optical path difference (OPD) between the sensing and reference arm of the MZI. When liquid flows through the central microchannel of the optofluidic platform it crosses the light beam between the two optical fibers in the sensing arm causing the OPD change. An algorithm has been applied for the calculation of the refractive index of liquids out of the raw interference signals. We obtained a very good agreement between the experimental results and literature data of refractive indices of subjected fluids. The accuracy of refractive index measurement is approximately 1%, predominantly determined by the accuracy of reading the position of the mechanical scanner. The proposed sensor is attractive for the label-free biological, biochemical, and chemical sensing owing autocalibration and high sensitivity yet consuming a very small sample volume of 1 µL. It is capable to measure the refractive index of various liquids and/or gases simultaneously in the process. Full article

Microscale optofluidic devices are a category of microscale devices combining fluidic and optical features. These devices typically enable in-situ fluid flow measurement for pharmaceutical, environmental or biomedical applications. In micro-optofluidic devices, in order to deliver, as close as possible, the input light to the sample or a specific chip section and, collect the output signal, it is necessary to miniaturize optical components. In this paper, two low-cost technologies, 3D Printing PDMS-based and laser cutting PMMA-based (PDMS stands for Poly-dimethyl-siloxane and PMMA for Poly-methyl-methacrylate), were investigated as novel methods to realize micro-optical waveguides ($\mu WGs$) comparing their performances. An ad-hoc master-slave protocol developed to realize PDMS components by 3D Printing has been fully optimized. The manufacturing technologies proposed require simple and low-cost equipment and no strictly controlled environment. Similar results are obtained for both the micro-optical waveguides realized. Their losses, disregarding the losses caused by the fibers’ alignment and the miss-match of the geometry with the waveguide, are of the order of $20\%$, almost equivalent for both approaches (PDMS-$\mu WG$ and PMMA-$\mu WG$). The losses are of the order of $10\%$ when the PDMS-$\mu WG$ is shielded by a copper layer, with a significant improvement of the signal acquired. The results obtained show the possibility of using the two low-cost technologies presented for the realization of micro-optical waveguides suitable to be integrated in micro-optofluidic devices and the potential of creating micro-optical paths inside micro-embedded systems. Full article

Using a fiber of that is 125 μm in diameter in rhodamine 6G ethanol solution, controllable multi- and single-whispering-gallery-mode (WGM) optofluidic lasers based on evanescent-wave-coupled gain are both available. With multi-mode WGM emission, lasing emission with almost pure TM (transverse magnetic) or almost TE (transverse electric) modes can be obtained when the pump laser has an electric field parallel (perpendicular) to the fiber axis, i.e., the polarization direction of output laser is the same as that of the pump laser. On the other hand, when the laser emission is single-mode, the TE output laser always emerges firstly above lasing threshold, then keeps TE mode while the pump laser’s intensity increases with polarization direction perpendicular to the fiber axis; on the contrary, TE emission will dwindle relatively, while the TM emission emerges and dominates the spectra, when the pump laser’s intensity increases with polarization parallel to the fiber axis. Our work proves that controlling the leakage of the evanescent wave from high-Q microcavities is crucial for both modes of lasing emission and its polarization. Full article

The consolidation of laser micro/nano processing technologies has led to a continuous increase in the complexity of optical fiber sensors. This new avenue offers novel possibilities for advanced sensing in a wide set of application sectors and, especially in the industrial and medical fields. In this review, the most important transducing structures carried out by laser processing in optical fiber are shown. The work covers different types of fiber Bragg gratings with an emphasis in the direct-write technique and their most interesting inscription configurations. Along with gratings, cladding waveguide structures in optical fibers have reached notable importance in the development of new optical fiber transducers. That is why a detailed study is made of the different laser inscription configurations that can be adopted, as well as their current applications. Microcavities manufactured in optical fibers can be used as both optical transducer and hybrid structure to reach advanced soft-matter optical sensing approaches based on optofluidic concepts. These in-fiber cavities manufactured by femtosecond laser irradiation followed by chemical etching are promising tools for biophotonic devices. Finally, the enhanced Rayleigh backscattering fibers by femtosecond laser dots inscription are also discussed, as a consequence of the new sensing possibilities they enable. Full article

This paper presents a total phosphorus online real-time monitoring system integrated with on-chip digestion based on the merits of optofluidic technology. The integrated optofluidic device contains a hollow optical fiber employed for pretreatment and digestion of phosphorus solution samples, a polydimethylsiloxane (PDMS)-based micromixer with convergent–divergent walls designed to enable sufficient mixing and chromogenic reaction, and a couple of optical fiber collimators attached with a Z-shaped flow cell for optical detection. Details of system design and fabrication are introduced in this paper. In the experiment, on-chip digestion of four typical phosphates in aqueous solution including organophosphorus and inorganic phosphorus is investigated under different reaction conditions, such as digestion temperature, concentration of oxidant and pH value, and the optimal reaction parameters are explored under different conditions. Meanwhile, we demonstrate the online real-time monitoring function of the optofluidic device, and the digestion mechanisms of four different phosphates are analyzed and discussed. Compared with the national standard method, we find that the measurement accuracy and sensitivity are acceptable when the concentration of total phosphorus is between 0.005–0.9 mg/L (by weight of P) in aqueous solution, which covers the range defined in the national standard. The traditional digestion time of several hours is greatly reduced to less than 10 s, and the content of total phosphorus can be obtained in a few minutes. The integrated optofluidic device can significantly shorten the test time and reduce the sample amount, and also provides a versatile platform for the real-time detection and analysis of many biochemical samples. Full article

A hexagonal photonic crystal fiber (PCF) sensor with a dual optofluidic channel based on surface plasmon resonance (SPR) effect is proposed. The sensor characteristic is numerically explored by software integrated with the finite element method (FEM). The numerical results show that, when the analyte refractive index (RI) varies from 1.32 to 1.38, high linearity between resonance wavelength and analyte RI is obtained and the value of adjusted R² is up to 0.9993. Simultaneously, the proposed sensor has maximum wavelength sensitivity (WS) of 5500 nm/RIU and maximum amplitude sensitivity (AS) of 150 RIU⁻¹, with an RI resolution of 1.82 $\times$ 10⁻⁵ RIU. Besides, owing to a simple structure and good tolerance of the proposed sensor, it can be easily fabricated by means of existing technology. The proposed sensor suggests promising applications in oil detection, temperature measurement, water quality monitoring, bio-sensing, and food safety. Full article

Optofluidics is an exciting new area of study resulting from the fusion of microfluidics and photonics. It broadens the application and extends the functionality of microfluidics and has been extensively investigated in biocontrol, molecular diagnosis, material synthesis, and drug delivery. When light interacts with a microfluidic system, optical force and/or photothermal effects may occur due to the strong interaction between light and liquid. Such opto-physical effects can be used for optical manipulation and sensing due to their unique advantages over conventional microfluidics and photonics, including their simple fabrication process, flexible manipulation capability, compact configuration, and low cost. In this review, we summarize the latest progress in fiber optofluidic (FOF) technology based on optical force and photothermal effects in manipulation and sensing applications. Optical force can be used for optofluidic manipulation and sensing in two categories: stable single optical traps and stable combined optical traps. The photothermal effect can be applied to optofluidics based on two major structures: optical microfibers and optical fiber tips. The advantages and disadvantages of each FOF technology are also discussed. Full article

This paper presents a review of the development of optical fibers made of multiple materials, particularly including silica glass, soft glass, polymers, hydrogels, biomaterials, Polydimethylsiloxane (PDMS), and Polyperfluoro-Butenylvinyleth (CYTOP). The properties of the materials are discussed according to their various applications. Typical fabrication techniques for specialty optical fibers based on these materials are introduced, which are mainly focused on extrusion, drilling, and stacking methods depending on the materials’ thermal properties. Microstructures render multiple functions of optical fibers and bring more flexibility in fiber design and device fabrication. In particular, micro-structured optical fibers made from different types of materials are reviewed. The sensing capability of optical fibers enables smart monitoring. Widely used techniques to develop fiber sensors, i.e., fiber Bragg grating and interferometry, are discussed in terms of sensing principles and fabrication methods. Lastly, sensing applications in oil/gas, optofluidics, and particularly healthcare monitoring using specialty optical fibers are demonstrated. In comparison with conventional silica-glass single-mode fiber, state-of-the-art specialty optical fibers provide promising prospects in sensing applications due to flexible choices in materials and microstructures. Full article
