High-quality microgrooves obtained in micro-milling titanium alloy Ti6Al4V are still challenging work due to the dependence of burr formation and surface roughness on cutting parameters. In this paper, the systematic analysis of the micro-milling process was conducted to obtain high-quality titanium alloy Ti6Al4V microgrooves, which is based on single-factor experiments, orthogonal experiments, intuitive analysis, range analysis, regression analysis, and multi-objective optimization. The range of factors and factors of orthogonal experiments were determined by single-factor experiments. Orthogonal experiments were conducted with a three-factor three-level design, which regards the total top-burr width and the bottom surface roughness of microgrooves as the response variables, and factors are spindle speed, feed per tooth, and the axial depth of cut. The optimal cutting parameters, which minimize the surface roughness and burr formation, and the main influence factor were determined by intuitive analysis, range analysis, regression analysis, and NSGA-II multi-objective optimization. Simultaneously, high-quality complex microgrooves were achieved with the optimal cutting parameters. The method of systematic experimental design and data analysis in this paper can provide the theoretical guideline and technical support for the processing development of complex parts. Full article

Large overhang milling cutters face challenges, including poor cutting stability and surface quality when machining deep-cavity parts in aerospace and other industries. The combined interactions between overhang and process parameters significantly influence machining performance and the tool wear mechanism. In this study, the coupled effects of tool overhang length and feed per tooth on milling force, surface topography, chip morphology, and tool wear mechanism were systematically investigated under typical large overhang conditions. The tool stiffness decreased with increasing overhangs; the feed force decreased by approximately 32.4%~49.48%; and the chip morphology changed from continuous bands to fractures. The feed force increased by approximately 25.11%~67.34% with increasing the feed per tooth, resulting in reduced surface quality and accelerated tool wear. The novelty of this work lies in quantitatively revealing the coupling mechanism between overhang length and feed rate in large overhang milling, providing a theoretical basis for process optimization. The findings are directly applicable to the optimization of machining parameters for deep-cavity components such as aero-engine casings and optical mold cavities, where tool overhang is a critical factor affecting productivity and surface integrity. This study provides a theoretical foundation and experimental reference for optimizing process parameters when milling titanium alloy with long-overhang milling cutters. Full article

Surface quality of machined wood-based panels plays a key role in subsequent processing and product performance; however, its formation during CNC edge milling remains insufficiently understood, particularly for materials with different structural characteristics, including recycled content. This study investigates the influence of feed per tooth, milling strategy, and material structure on surface quality during CNC edge milling of particleboards manufactured from alternative lignocellulosic resources. Six board variants were experimentally produced and machined on a five-axis CNC machining center Morbidelli m100 using a single-edge milling cutter, with feed per tooth varied at three levels and both climb and conventional milling strategies applied. Surface quality was evaluated using a non-contact 3D optical profilometer Keyence VR-6000, and roughness (R_a) and waviness (W_z) parameters were analyzed. The results showed that surface roughness increased with increasing feed per tooth for all materials, with an increase of approximately 30%–70%. Statistical analysis confirmed a significant effect of feed per tooth and material type, while milling strategy and its interaction with material were not statistically significant. Materials with higher surface heterogeneity (CVR_a) showed increased roughness and greater sensitivity to feed. A statistically significant positive relationship was found between surface heterogeneity (CVR_a) and roughness sensitivity (ΔR_a), indicating that materials with higher surface heterogeneity (CVR_a), which likely reflects variability in their internal structure, are more sensitive to changes in feed per tooth. Full article

The present work examines methods for enhancing dimensional accuracy and circularity in CNC circular end milling processes. While conventional optimization often focuses solely on mechanical cutting parameters, this research integrates the Taguchi method, Response Surface Methodology (RSM), and Analysis of Variance (ANOVA) to explicitly quantify the impact of thermal equilibrium alongside cutting mechanics. The results reveal a novel finding: warm-up time is the dominant factor, contributing 41.01% to dimensional accuracy and 49.97% to circularity variation, significantly outweighing spindle speed and feed rate. The optimized parameter combination—comprising a specific warm-up protocol, depth of cut, and feed per tooth—improved dimensional accuracy by approximately 38% and circularity by 33%. This study provides a critical operational guideline for precision manufacturing: implementing a thermal stability protocol is a prerequisite for realizing the benefits of mechanical parameter optimization. Full article

The paper explores the use of artificial neural networks for surface roughness parameter Ra prediction when milling the finishing of flat surfaces with toroidal milling on C45 steel. The experiments were conducted on a 5-axis CNC center, varying three main parameters: cutting speed, feed per tooth, and tool axis tilt angle. In total, 70 surfaces were processed, with multiple measurements of Ra roughness. The data were preprocessed in MATLAB (noise reduction by Z-score and augmentation to 630 values) and used to train an artificial feedforward neural network with Bayesian regularization. The resulting model showed good performance on the dataset and was experimentally validated on three new parameter combinations, processed and measured independently with a 3D scanner. The results confirm the network’s ability to estimate Ra roughness based on varying process parameters. The paper proposes the model as a useful tool for assessing surface quality in finishing milling and recommends extending the experimental base as the main direction of continuation. Full article

This study examines how variations in cutting parameters and end mill rake-angle affect chip-temperature in the cutting zone. This study describes a method involving end mills with varying rake angles to measure the temperature of chips in the cutting zone during the dry rough milling of magnesium alloys. The chip temperature is determined by infrared spectroscopy. The influence of milling parameters (i.e., cutting speed, feed per tooth, and depth-of-cut) on the maximum chip temperature was analyzed. Box plots, bar charts, and 2D graphs are used to display the chip temperatures. We address issues that come up while recording a signal with an average emissivity coefficient value and how to resolve them. The tests yielded chip temperatures that were not higher than 366 °C. Thus, for a variety of machining parameters, the dry roughing milling procedure using carbide tools with different rake angles can be deemed safe. The proposed approach to detecting the chip temperature and processing findings constitutes a novel and efficient way for evaluating safety in the dry milling of magnesium alloys. Full article

High-feed face milling is widely adopted in industry for its productivity advantages, especially when machining medium carbon steels. However, the combined effects of lubrication regimes on both the cutting forces and surface quality remain insufficiently explored, creating a research gap in optimizing process parameters for improved performance. This study presents an experimental investigation into the effects of lubrication on cutting forces and surface topography during the high-feed face milling of C45 steel. Using a design of experiments (DOE) approach, eight distinct machining setups were developed by varying the cutting speed, depth of cut, and feed per tooth. Each setup was tested under two lubrication conditions: with flood coolant and under dry machining. Cutting forces in the X, Y, and Z directions were recorded using a dynamometer, while the post-machining surface quality was evaluated using 3D areal surface topography measurements. The results revealed that feed per tooth was the primary factor affecting both the cutting forces and surface roughness, with depth of cut having a moderate effect and cutting speed a minor influence. Flood lubrication reduced the peak forces, stabilized force fluctuations, and improved surface uniformity, particularly in the valley depths and skewness parameters. This work provides (i) a combined analysis of cutting forces and surface topography under high-feed milling, (ii) quantitative evidence of lubrication effects on force and surface consistency, and (iii) identification of dominant process parameters for optimization, offering practical guidance for enhancing productivity, surface quality, and tribological performance in high-feed milling operations. Full article

Due to the unique microstructure and mechanical heterogeneity of austenitic stainless steel made via wire arc additive manufacturing (WAAM), its machinability differs significantly from that of rolled material. Accordingly, this study systematically investigates the influence of milling strategies on key process responses (cutting forces, surface roughness, vibration displacement, and temperature) to reveal the mechanisms of machining parameters during the milling of WAAM-fabricated austenitic stainless steel. The material used in this study is ER321 austenitic stainless steel. During deposition, the fusion zone cools more slowly than the transition zone; consequently, the fusion zone exhibits a hardness approximately 20 HV_0.1 lower than that of the transition zone. Surface roughness is primarily reduced by decreasing the primary feed per tooth. However, when the primary feed per tooth is small, ploughing is induced, which not only increases surface roughness by 25% but also causes abnormal increases in temperature and vibration displacement. Nevertheless, ploughing has little effect on the total milling force, and the feed per tooth shows a positive correlation with the total milling force. Tool run-out and an increase in the uncut chip thickness lead to a positive correlation between the radial depth of cut and the key process responses. Moreover, ploughing also occurs when the radial depth of cut is small. The axial depth of cut has almost no effect on the machining process. Moreover, a small-diameter mill leads to severe ploughing, and at a high table feed, climb milling leads to cutter offset. Full article

Milling force is a parameter affecting wood processing quality, tool life, and energy consumption, and its variation is influenced by the multi-factor coupling of cutting parameters and tool geometric factors. This study systematically investigates milling forces during the processing of pine wood (Pinus sylvestris var. mongholica Litv.) using a hybrid modeling approach combining principal component analysis (PCA) and multiple linear regression (MLR). Firstly, PCA was employed to reduce the dimensionality of the tool rake angle (γ), helix angle (λ), cutting depth (h), feed per tooth (U_z), and triaxial milling forces (F_x, F_y, F_z); this eliminated the multicollinearity among variables and extracted the integrated features. Subsequently, an MLR model was constructed using the principal components as independent variables to quantitatively evaluate the contribution of each factor to milling forces. The results support the conclusion that PCA successfully extracted the first four principal components (cumulative variance contribution rate: 92.78%), with PC1 (49.16%) characterizing the comprehensive milling force effect and PC2 (15.03%) primarily reflecting the characteristics of the tool geometric parameters. The established MLR model demonstrated a high significance (R²: F_x = 0.915, F_y = 0.907, F_z = 0.852). The cutting depth exerted a significant positive driving effect on the triaxial milling forces via PC1 (each 1 mm increase in depth increased the PC1 score by 0.64 units, resulting in increases of 27.2%, 26.6%, and 21.8% for F_x, F_y, and F_z, respectively). The helix angle significantly suppressed F_y through PC2 (β = −0.090, p < 0.001), whereas the rake angle exhibited a weak negative effect on F_x via PC3 (β = −0.015). Parameter optimization identified the combination γ = 25°, λ = 30°, h = 0.5 mm, and U_z = 0.1 mm∙z⁻¹ as optimal, which reduced the triaxial milling forces by 62.3% compared to the experimental maximum. This study provides a theoretical foundation and novel parameter optimization strategy for the efficient, low-damage processing of wood materials. Full article

The milled surface topography of NiTi SMA critically affects its frictional behavior, corrosion resistance, and biocompatibility, which are essential for biomedical and aerospace applications. This study combines simulation and single-factor experiments to investigate the coupling behavior among surface topography evolution, work hardening, plastic deformation, and residual stress evolution. Results showed that increasing feed per tooth led to a significant rise in surface residual height and an improvement in surface isotropy. With the increase in feed per tooth, the error between the experimental and simulated heights gradually decreased from 105.6% to 30.9%, indicating that both material properties and feed per tooth strongly affect residual profile formation in the feed direction. In addition, larger feed per tooth intensifies work hardening and plastic deformation but reduces surface residual stress, thereby increasing microhardness. These effects can mitigate material rebound and improve surface profile accuracy. The results provide a direct basis for controlling the surface integrity of NiTi SMA components through machining parameter optimization, enabling precise tailoring of functional surface characteristics, such as wear performance, chemical stability, and biological response, which is of critical importance for high-end biomedical implants and aerospace systems. Full article

High-quality drilled holes are critical in thin fabric-reinforced composites used in many industrial applications; however, the influence of woven architecture on drilling performance without a backup plate remains insufficiently defined. This paper introduces the first comprehensive experimental and statistical framework for evaluating unsupported drilling of thin woven glass fiber-reinforced polymer (GFRP) laminates. The framework integrates the effect of support opening width, fiber weight fraction (wf), feed per tooth, and fabric architecture to quantify their combined effects on delamination, cutting forces, and surface roughness. The samples consisted of vacuum mold-pressed GFRP laminates. Drilling tests were conducted on plain and twill-woven plates, and hole quality was evaluated using thrust force, delamination factor, and surface roughness (Sa). A statistical DOE and multifactorial ANOVA were applied to quantify the effects of the main parameters. For plain-woven GFRP, the best results were obtained with a 65 mm support opening width, 45% fiber wf, and 0.04 mm/tooth feed. Plain-woven laminates exhibited lower average surface roughness (Sa ≈ 5.0–6.5 µm) than twill-woven laminates (Sa ≈ 6.0–7.0 µm). The study demonstrates how fabric architecture and drilling parameters jointly influence hole quality in thin GFRP composites, providing practical guidance for manufacturing applications. Full article

Symmetry and asymmetry jointly govern the dynamics and surface integrity of thin-wall AA7075 end milling. In this work, a symmetry-aware simulation and experimental framework is developed to connect process parameters with milling forces, dynamic response, surface quality, and through-thickness residual stress. A mechanistic milling-force model is first established for multi-tooth end milling, where the periodically repeated tooth-order excitation provides a nominally symmetric load pattern along the tool path. The predicted forces are then used as input for finite-element modal and harmonic-response analysis of a thin-walled component, revealing how symmetric and anti-symmetric mode shapes interact with the tooth-order excitation to generate locally amplified, asymmetric vibration of the compliant wall. Orthogonal and single-factor milling experiments on AA7075 thin-wall specimens are performed to calibrate and validate the force model, and to quantify the influence of feed per tooth, axial depth of cut, spindle speed, and radial width of cut on deformation, surface roughness, and geometric accuracy. Finally, a thermo-mechanically coupled finite-element model is employed to evaluate the residual-stress field, showing a characteristic pattern in which an initially symmetric thermal–mechanical loading produces depth-wise symmetry breaking between tensile surface layers and compressive subsurface zones. The proposed symmetry-aware framework, which combines milling-force theory, finite-element simulation, and systematic experiments, provides practical guidance for selecting parameter windows that suppress vibration, control residual stress, and improve the machining quality of thin-wall AA7075 components. Full article

High-quality hole machining of Ti-6Al-4V is critical for precision aerospace components but remains challenging due to the alloy’s poor machinability. In this study, the influence of cutting parameters on milling force, burr formation and the hole quality of Ti-6Al-4V was investigated. The mechanical properties and microstructure of the milled holes were analyzed. The research results show that milling depth is the primary factor governing variations in milling force and burr formation. The minimum milling force of 3.61 N is achieved at a milling depth of 60 μm, a feed per tooth of 2 μm/z and a cutting speed of 31 m/min. Compared to pre-optimization parameters, the milling force is decreased by 91.74%. Correspondingly, entrance burr width and hole-axis deviation were substantially reduced, indicating marked improvement in hole quality and geometrical accuracy. Microstructural observations show no deleterious phase transformations or excessive work-hardening under the optimized regime. The results deliver quantitative guidelines for parameter selection and tool application in micro-hole milling of Ti-6Al-4V and provide a foundation for further process modelling and optimization for aerospace manufacturing. Full article

This study focuses on the prediction and analysis of temperature distribution during end milling of AISI 4340 steel. The influence of cutting parameters—cutting speed, feed per tooth, and depth of cut—on temperature generation in the cutting zone was investigated using a CCD experimental plan. Temperature was measured with a thermal imaging camera, while the milling process was simulated using Third Wave AdvantEdge 7.1 FEM software. The obtained temperatures ranged from 74 °C to 200 °C, depending on the cutting conditions. A second-order regression model with three factors was developed and showed an average prediction error of 8.62%, while the alternative fitted model had an average error of 10.91%. FEM simulations using AdvantEdge 7.1 demonstrated a somewhat higher deviation, with an average error of 14.75% relative to experiments. The highest deviations for all approaches occurred at extreme cutting parameters (very low or very high depth of cut). The study demonstrates that FEM simulations are an effective tool for predicting thermal behavior in milling and optimizing cutting parameters. Accurate prediction of cutting zone temperatures can improve tool life, enhance process efficiency, and support the selection of optimal machining conditions, which is very important from an industry point of view. Full article

This study investigates vibration signals generated during end milling of thin-walled EN AW-7075 aluminum alloy components using a set of 24 tools with distinct cutting edge microgeometries. Five characteristic parameters describing the dynamic response of the process, including both energy-related and statistical indicators, were extracted and analyzed. The results clearly demonstrate the critical influence of tool microgeometry on process dynamics. In particular, the introduction of an additional zero-clearance flank land at the cutting edge proved decisive in suppressing vibrations. For the most favorable geometries, the root mean square (RMS) value of vibration was reduced by more than 50%, while the spectral power density (PSD) decreased by up to 70–75% compared with the least favorable configurations. Simultaneously, both time- and frequency-domain responses exhibited complex and irregular patterns, highlighting the limitations of intuitive interpretation and the need for multi-parameter evaluation. To enable a synthetic comparison of tools, the Vibration Severity Index (VSI), which integrates RMS and kurtosis into a single composite metric, was introduced. VSI-based ranking allowed the clear identification of the most dynamically stable geometry. For the selected tool, additional analysis was conducted to evaluate the influence of cutting parameters, namely feed per tooth and radial depth of cut. The results showed that the most favorable dynamic behavior was achieved at a feed of 0.08 mm/tooth and a radial depth of cut of 1.0 mm, whereas boundary conditions resulted in higher kurtosis and a more impulsive signal structure. Overall, the findings confirm that properly engineered cutting-edge microgeometry, especially the formation of additional zero-clearance flank land significantly enhances the dynamic of thin-wall milling, demonstrating its potential as an effective strategy for vibration suppression and process optimization in precision machining of lightweight structural materials. Full article
