Search Results (26)

By monitoring the solidification of droplets of plant latices with a fast quartz crystal microbalance with dissipation monitoring (QCM-D), droplets from Campanula glomerata were found to solidify much faster than droplets from Euphorbia characias and also faster than droplets from all technical latices tested. A similar conclusion was drawn from optical videos, where the plants were injured and the milky fluid was stretched (sometimes forming fibers) after the cut. Rapid solidification cannot be explained with physical drying because physical drying is transport-limited and therefore is inherently slow. It can, however, be explained with coagulation being triggered by a sudden decrease in hydrostatic pressure. A mechanism based on a pressure drop is corroborated by optical videos of both plants being injured under water. While the liquid exuded by E. characias keeps streaming away, the liquid exuded by C. glomerata quickly forms a plug even under water. Presumably, the pressure drop causes an influx of serum into the laticifers. The serum, in turn, triggers a transition from a liquid–liquid phase separated state (an LLPS state) of a resin and hardener to a single-phase state. QCM measurements, optical videos, and cryo-SEM images suggest that LLPS plays a role in the solidification of C. glomerata. Full article

With the goal of fast and accurate diagnosis of infectious diseases, this study presents a novel electrochemical biosensor that employs a refined aptamer (C9t) for the detection of spike (S) protein SARS-CoV-2 variants in a flexible multielectrode aptasensor array with PoC capabilities. Two aptamer modifications were employed: removing the primer binding sites and including two dithiol phosphoramidite anchor molecules. Thus, reducing fabrication time from 24 to 3 h and increasing the stability and sparseness for multi-thiol aptasensors compared to a standard aptasensor using single thiols, without a reduction in aptamer density. The biosensor fabrication, optimization, and detection were verified in detail by electrochemistry, QCM-D, SPR, and XPS. The analyte–receptor binding was further confirmed spectroscopically at the level of individual molecules by AFM-IR. The aptasensor possesses a low limit of detection (8.0 fg/mL), the highest sensitivity reported for S protein (209.5 signal per concentration decade), and a wide dynamic detection range (8.0 fg/mL–38 ng/mL) in nasopharyngeal samples, covering the clinically relevant range. Furthermore, the C9t aptasensor showed high selectivity for SARS-CoV-2 S proteins over biomarkers for MERS-CoV, RSV, and Influenza. Even more, it showed a three times higher sensitivity for the Omicron in comparison to the Wuhan strain (wild type), alpha, and beta variants of the SARS-CoV-2 virus. Those results demonstrate the creation of an affordable and variant-selective refined C9t aptasensor that outperformed current rapid diagnosis tests. Full article

In this study, an aptamer biosensor for detecting lactoferrin (LF) was developed using piezoelectric quartz-induced bond rupture sensing technology. The thiol-modified aptamer I was immobilized on the gold electrode surface of the quartz crystal microbalance (QCM) through an Au-S bond to specifically bind LF. It was then combined with aptamer–magnetic beads to amplify the mass signal. The peak excitation voltage was 8 V at the resonance frequency for the 60 MHz gold-plated quartz crystal. When the molecular bond cracking process occurred, the aptamer–magnetic beads combined on the surface of the piezoelectric quartz were removed, which resulted in an increase in quartz crystal resonance frequency. Therefore, the specific detection of LF can be realized. Under optimized experimental conditions, the linear range for LF was 10–500 ng/mL, the detection limit (3σ) was 8.2 ng/mL, and the sample recoveries for actual milk powder samples ranged from 97.2% to 106.0%. Compared with conventional QCM sensing technology, the signal acquisition process of this sensing method is simple, fast, and easy to operate. Full article

MXenes, as a typical graphene-like material, excels in the realm of humidity sensing owing to its two-dimensional layer structure, high electrical conductivity, tunable chemical properties, hydrophilicity, and large specific surface area. This study proposed a quartz crystal microbalance (QCM) humidity sensor using a nanochitin/Ti₃C₂T_x MXene composite as a humidity-sensing material. The morphology, nanostructure, and elemental composition of nanochitin, Ti₃C₂T_x MXene, and nanochitin/Ti₃C₂T_x MXene composite materials were characterized using transmission electron microscopy, Fourier transform infrared spectroscopy, and X-ray diffraction. Compared to the pure Ti₃C₂T_x MXene-coated QCM humidity sensor, the nanochitin/Ti₃C₂T_x MXene-coated QCM humidity sensor exhibited a higher sensitivity (20.54 Hz/%RH) in the humidity range of 11.3% to 97.3%. The nanochitin/Ti₃C₂T_x Mxene-coated QCM humidity sensor also demonstrated low humidity hysteresis (2.12%RH), very fast response/recovery times (4.4/4.1 s), a high quality factor (37 k), and excellent repeatability and sustained stability over time. Eventually, a bimodal exponential kinetics adsorption model was utilized for the analysis of the response mechanism of the nanochitin/Ti₃C₂T_x MXene composite material-based QCM humidity sensor. This study provides new ideas for optimizing the moisture-sensitive performance of MXene-based QCM humidity sensors. Full article

The interactions that nanoparticles have with blood proteins are crucial for their fate in vivo. Such interactions result in the formation of the protein corona around the nanoparticles, and studying them aids in nanoparticle optimization. Quartz crystal microbalance with dissipation monitoring (QCM-D) can be used for this study. The present work proposes a QCM-D method to study the interactions on polymeric nanoparticles with three different human blood proteins (albumin, fibrinogen and γ-globulin) by monitoring the frequency shifts of sensors immobilizing the selected proteins. Bare PEGylated and surfactant-coated poly-(D,L-lactide-co-glycolide) nanoparticles are tested. The QCM-D data are validated with DLS and UV-Vis experiments in which changes in the size and optical density of nanoparticle/protein blends are monitored. We find that the bare nanoparticles have a high affinity towards fibrinogen and γ-globulin, with measured frequency shifts around −210 Hz and −50 Hz, respectively. PEGylation greatly reduces these interactions (frequency shifts around −5 Hz and −10 Hz for fibrinogen and γ-globulin, respectively), while the surfactant appears to increase them (around −240 Hz and −100 Hz and −30 Hz for albumin). The QCM-D data are confirmed by the increase in the nanoparticle size over time (up to 3300% in surfactant-coated nanoparticles), measured by DLS in protein-incubated samples, and by the trends of the optical densities, measured by UV-Vis. The results indicate that the proposed approach is valid for studying the interactions between nanoparticles and blood proteins, and the study paves the way for a more comprehensive analysis of the whole protein corona. Full article

In this work, a facile synthesis method was adopted to synthesize MOF-14 with mesoporous structure. The physical properties of the samples were characterized by PXRD, FESEM, TEM and FT-IR spectrometry. By coating the mesoporous-structure MOF-14 on the surface of a quartz crystal microbalance (QCM), the fabricated gravimetric sensor exhibits high sensitivity to p-toluene vapor even at trace levels. Additionally, the limit of detection (LOD) of the sensor obtained experimentally is lower than 100 ppb, and the theoretical detection limit is 57 ppb. Furthermore, good gas selectivity and fast response (15 s) and recovery (20 s) abilities are also illustrated along with high sensitivity. These sensing data indicate the excellent performance of the fabricated mesoporous-structure MOF-14-based p-xylene QCM sensor. On the basis of temperature-varying experiments, an adsorption enthalpy of −59.88 kJ/mol was obtained, implying the existence of moderate and reversible chemisorption between MOF-14 and p-xylene molecules. This is the crucial factor that endows MOF-14 with exceptional p-xylene-sensing abilities. This work has proved that MOF materials such as MOF-14 are promising in gravimetric-type gas-sensing applications and worthy of future study. Full article

Acute toxicity data are a necessary component of the general analysis of gaseous environments and the prediction of the possible consequences of exposure to a chemical substance on living organisms. One of the fastest ways to obtain such information is to use gas-phase chemical sensors with sensitive layers of biological origin. Here we report an experimental study of complex loadings for classical quartz crystal microbalances arising in closely packed protein layers of ovalbumin (OVA) on the surface of polycrystalline silver, silver coated with rigid carbon fullerene C₆₀, or a soft molecular-organic crystal of copper phthalocyanine (CuPc). OVA molecules are similarly immobilized on the silver and fullerene-decorated surfaces, while the response of the OVA-CuPc layer indicates an insignificant amount of protein on the surface. A systematic study of the kinetics of the responses of these layers to saturated vapors of volatile solvents shows that the QCM resonant frequency change correlates well with the toxicity of gaseous analytes. It has been observed that saturated vapors of water, ethanol, and their mixtures are classically adsorbed with a high adsorption capacity. Benzene and isobutanol showed only a non-monotonic anti-Sauerbrey behavior, while acetone and cyclohexane had a 10-fold smaller quasi-classical response. The possibility of a gaseous analyte changing not only the QCM loading but also the mechanical behavior of the protein mass associated with the surface opens up the possibility of observing nonspecific conformational changes in proteins, which can be the cause of general cytotoxicity. This effect, combined with the native conformation of OVA in densely packed protein films, allows the use of ovalbumin in creating sensitive bio-sniffer layers for fast toxicological assays—a new class of express tests for biosafety and environmental control. Full article

Methylene blue (MB) dye is a common colorant used in numerous industries, particularly the textile industry. When methylene blue is discharged into water bodies without being properly treated, it may seriously damage aquatic and human life. As a result, a variety of methods have been established to remove dyes from aqueous systems. Thanks to their distinguishing features e.g., rapid responsiveness, cost-effectiveness, potential selectivity, portability, and simplicity, the electrochemical methods provided promising techniques. Considering these aspects, a novel quartz crystal microbalance nanosensors based on green synthesized magnesium ferrite nanoparticles (QCM-Based MgFe₂O₄ NPs) and magnesium ferrite nanoparticles coated alginate hydrogel nanocomposite (QCM-Based MgFe₂O₄@CaAlg NCs) were designed for real-time detection of high concentrations of MB dye in the aqueous streams at different temperatures. The characterization results of MgFe₂O₄ NPs and MgFe₂O₄@CaAlg NCs showed that the MgFe₂O₄ NPs have synthesized in good crystallinity, spherical shape, and successfully coated by the alginate hydrogel. The performance of the designed QCM-Based MgFe₂O₄ NPs and MgFe₂O₄@CaAlg NCs nanosensors were examined by the QCM technique, where the developed nanosensors showed great potential for dealing with continuous feed, very small volumes, high concentrations of MB, and providing an instantaneous response. In addition, the alginate coating offered more significant attributes to MgFe₂O₄ NPs and enhanced the sensor work toward MB monitoring. The sensitivity of designed nanosensors was evaluated at different MB concentrations (100 mg/L, 400 mg/L, and 800 mg/L), and temperatures (25 °C, 35 °C, and 45 °C). Where a real-time detection of 400 mg/L MB was achieved using the developed sensing platforms at different temperatures within an effective time of about 5 min. The results revealed that increasing the temperature from 25 °C to 45 °C has improved the detection of MB using the MgFe₂O₄@CaAlg NCs nanosensor and the MgFe₂O₄@CaAlg NCs nanosensor exhibited high sensitivity for different MB concentrations with more efficiency than the MgFe₂O₄ NPs nanosensor. Full article

Anticholinesterase pesticides are a main cause of the intentional or accidental poisoning of animals. Anticholinesterases include several substances that cause the overstimulation of both central and peripheral acetylcholine-dependent neurotransmission. Forensic analyses of poisoning cases require high levels of expertise, are costly, and often do not provide reliable quantitative information for unambiguous conclusions. The purpose of the present study was to develop and validate a method of high-performance liquid chromatography with diode array detector (HPLC–DAD) for the identification and quantitation of n-methyl carbamates, organophosphates and respective metabolites from biological samples of animals that were suspected of poisoning. HPLC–DAD is reliable, fast, simplistic and cost-effective. The method was validated for biological samples obtained from stomach contents, liver, vitreous humor and blood from four different animal species. The validation of the method was achieved using the following analytical parameters: linearity, precision, accuracy, selectivity, recovery, and matrix effect. The method showed linearity at the range of 25–500 μg/mL, and the correlation coefficient (r2) values were >0.99 for all matrices. Precision and accuracy were determined by the (a) coefficient of variation (CV), (b) relative standard deviation low-quality control (LQC), (c) medium-quality control (QCM), and (d) high-quality control (QCA). The indicated parameters were all less than 15%. The recovery of analytes ranged from 31 to 71%. The analysis of results showed no significant interfering peaks due to common xenobiotics or matrix effects. The abovementioned method was used to positively identify pesticide analytes in 44 of the 51 animal samples that were suspected of poisoning, demonstrating its usefulness as a forensic tool. Full article

Technological evolution has allowed impedance analysis to become a versatile and efficient method for the precise measurement of the equivalent electrical parameters of the quartz crystal microbalance (QCM). By measuring the dissipation factor, or another equivalent electrical parameter, the QCM sensor provides access to the sample mass per unit area and its physical parameters, thus ensuring a detailed analysis. This paper aims to demonstrate the benefits of advanced impedance spectroscopy concerning the Butterworth–van Dyke (BVD) model for QCM sensors immersed with an electrode in a liquid medium. The support instrument in this study is a fast and accurate software-defined virtual impedance analyzer (VIA) with real-time computing capabilities of the QCM sensor’s electric model. Advanced software methods of self-calibration, real-time compensation, innovative post-compensation, and simultaneous calculation by several methods are the experimental resources of the results presented in this paper. The experimental results validate the theoretical concepts and demonstrate both the capabilities of VIA as an instrument and the significant improvements brought by the advanced software methods of impedance spectroscopy analysis related to the BVD model. Full article

The impedance quartz crystal microbalance (QCMI) is a versatile and simple method for making accurate measurements of the QCM sensor electrical parameters. The QCM sensor provides access to the physical parameters of the sample beyond the mass per unit area by measuring the dissipation factor, or another equivalent, ensuring a detailed analysis of the surface. By establishing a cooperative relationship between custom software and modular configurable hardware we obtain a user-defined measurement system that is called a virtual instrument. This paper aims primarily to improve and adapt existing concepts to new electronics technologies to obtain a fast and accurate virtual impedance analyzer (VIA). The second is the implementation of a VIA by software to cover a wide range of measurements for the impedance of the QCM sensor, followed by the calculation of the value of lumped electrical elements in real time. A method for software compensation of the parallel and stray capacitance is also described. The development of a compact VIA with a decent measurement rate (192 frequency points per second) aims, in the next development steps, to create an accurate impedance analyzer for QCM sensors. The experimental results show the good working capacity of QCMI based on VIA. Full article

In environments polluted by mercury vapors that are potentially harmful to human health, there is a need to perform rapid surveys in order to promptly identify the sources of emission. With this aim, in this work, a low cost, pocket-sized portable mercury measurement system, with a fast response signal is presented. It consists of a preconcentrator, able to adsorb and subsequently release the mercury vapour detected by a quartz crystal microbalance (QCM) sensor. The preconcentrator is based on an adsorbing layer of titania/gold nanoparticles (TiO₂NP/AuNPs), deposited on a micro-heater that acts as mercury thermal desorption. For the detection of the released mercury vapour, gold electrodes QCM (20 MHz) have been used. The experimental results, performed in simulated polluted mercury-vapour environments, showed a detection capability with a prompt response. In particular, frequency shifts (−118 Hz ± 2 Hz and −30 Hz ± 2 Hz) were detected at concentrations of 65 µg/m³ Hg⁰ and 30 µg/m³ Hg⁰, with sampling times of 60 min and 30 min, respectively. A system limit of detection (LOD) of 5 µg/m³ was evaluated for the 30 min sampling time. Full article

Emerging research in biosensors has attracted much attention worldwide, particularly in response to the recent pandemic outbreak of coronavirus disease 2019 (COVID-19). Nevertheless, initiating research in biosensing applied to the diagnosis of diseases is still challenging for researchers, be it in the preferences of biosensor platforms, selection of biomarkers, detection strategies, or other aspects (e.g., cutoff values) to fulfill the clinical purpose. There are two sides to the development of a diagnostic tool: the biosensor development side and the clinical side. From the development side, the research engineers seek the typical characteristics of a biosensor: sensitivity, selectivity, linearity, stability, and reproducibility. On the other side are the physicians that expect a diagnostic tool that provides fast acquisition of patient information to obtain an early diagnosis or an efficient patient stratification, which consequently allows for making assertive and efficient clinical decisions. The development of diagnostic devices always involves assay developer researchers working as pivots to bridge both sides whose role is to find detection strategies suitable to the clinical needs by understanding (1) the intended use of the technology and its basic principle and (2) the preferable type of test: qualitative or quantitative, sample matrix challenges, biomarker(s) threshold (cutoff value), and if the system requires a mono- or multiplex assay format. This review highlights the challenges for the development of biosensors for clinical assessment and its broad application in multidisciplinary fields. This review paper highlights the following biosensor technologies: magnetoresistive (MR)-based, transistor-based, quartz crystal microbalance (QCM), and optical-based biosensors. Its working mechanisms are discussed with their pros and cons. The article also gives an overview of the most critical parameters that are optimized by developing a diagnostic tool. Full article

Lamiaceae belong to the species-richest family of flowering plants and harbor many species that are used as herbs or in medicinal applications such as basils or mints. The evolution of this group has been driven by chemical speciation, mainly volatile organic compounds (VOCs). The commercial use of these plants is characterized by adulteration and surrogation to a large extent. Authenticating and discerning this species is thus relevant for consumer safety but usually requires cumbersome analytics, such as gas chromatography, often coupled with mass spectroscopy. Here, we demonstrate that quartz-crystal microbalance (QCM)-based electronic noses provide a very cost-efficient alternative, allowing for fast, automated discrimination of scents emitted from the leaves of different plants. To explore the range of this strategy, we used leaf material from four genera of Lamiaceae along with lemongrass, which is similarly scented but from an unrelated outgroup. To differentiate the scents from different plants unambiguously, the output of the six different SURMOF/QCM sensors was analyzed using machine learning (ML) methods together with a thorough statistical analysis. The exposure and purging of data sets (four cycles) obtained from a QCM-based, low-cost homemade portable e-Nose were analyzed using a linear discriminant analysis (LDA) classification model. Prediction accuracy with repeated test measurements reached values of up to 0%. We show that it is possible not only to discern and identify plants at the genus level but also to discriminate closely related sister clades within a genus (basil), demonstrating that an e-Nose is a powerful device that can safeguard consumer safety against dangers posed by globalized trade. Full article

Monolithic quartz crystal microbalance (MQCM) has recently emerged as a very promising technology suitable for biosensing applications. These devices consist of an array of miniaturized QCM sensors integrated within the same quartz substrate capable of detecting multiple target analytes simultaneously. Their relevant benefits include high throughput, low cost per sensor unit, low sample/reagent consumption and fast sensing response. Despite the great potential of MQCM, unwanted environmental factors (e.g., temperature, humidity, vibrations, or pressure) and perturbations intrinsic to the sensor setup (e.g., mechanical stress exerted by the measurement cell or electronic noise of the characterization system) can affect sensor stability, masking the signal of interest and degrading the limit of detection (LoD). Here, we present a method based on the discrete wavelet transform (DWT) to improve the stability of the resonance frequency and dissipation signals in real time. The method takes advantage of the similarity among the noise patterns of the resonators integrated in an MQCM device to mitigate disturbing factors that impact on sensor response. Performance of the method is validated by studying the adsorption of proteins (neutravidin and biotinylated albumin) under external controlled factors (temperature and pressure/flow rate) that simulate unwanted disturbances. Full article
