Search Results (21)

To address the limited flexibility of pumped storage power stations (PSPSs) under hierarchical clearing of energy and ancillary service markets, this study proposes a joint clearing mechanism for multi-level electricity markets. A bi-level optimization model based on the Stackelberg game is developed to characterize the strategic interaction between PSPSs and the market operator. Simulation results on the IEEE 30-bus system demonstrate that the proposed mechanism captures the dynamics of nodal supply and demand, as well as time-varying network congestion. It guides PSPSs to operate more flexibly and economically. Additionally, the mechanism increases PSPS profitability, reduces system costs, and improves frequency regulation performance. This game-theoretic framework offers quantitative decision support for PSPS participation in multi-level spot markets and provides insights for optimal storage deployment and market mechanism improvement. Full article

This study analyzed the frequency control challenges within the West Africa Power Pool Interconnected Transmission System (WAPPITS) as it plans to incorporate variable renewable energy (VRE) resources, such as wind and solar energy. Concerns center on the ability of WAPPITS primary frequency control reserves to adapt to high VRE penetration given the synchronization and frequency control problems experienced by the three separate synchronous blocks of WAPPITS. Optimizing solutions requires a better understanding of WAPPITS’ current frequency control approach. This study used questionnaires to understand operators’ practical experience with frequency control and compared these observations to field tests at power plants and frequency response metrics during system events. Eight (8) of ten (10) Transmission System Operators (TSOs) indicated that primary frequency control service was implemented in the TSO, but nine (9) of ten TSOs indicated that the reserves provided were inadequate to meet system needs. Five (5) of ten (10) respondents answered “yes” to the provision of secondary frequency control service, while only one (1) indicated that secondary reserves were adequate. Three (3) TSOs indicated they have AGC (Automatic Generation Control) installed in the control room, but none have implemented it for secondary frequency control. The results indicate a significant deficiency in primary control reserves, resulting in a reliance on under-frequency load shedding for primary frequency control. Additionally, the absence of an AGC system for secondary frequency regulation required manual intervention to restore frequency after events. To ensure the effectiveness of battery energy storage systems (BESSs) and the reliable operation of the WAPPITS with a higher penetration of inverter-based VRE, this paper recommends (a) implementing and enforcing basic primary frequency control structures through regional regulation and (b) establishing an ancillary services market to mobilize secondary frequency control resources. Full article

In view of the frequency regulation (FR) policy in Northeast China, a two-stage real-time rolling optimization model for power plants participating in FR ancillary services is established. The optimization object of the first stage is to maximize the overall profitability of the power plant and to obtain FR performance sub-indicators (K₁, K₂, K₃) and the electric power curve of combined heat and power (CHP) units with energy storage. The second stage of the model performs load distribution with the objective of minimizing operating cost, subject to the constraint of electric and heat power balance for CHP units and energy storage. Meanwhile, rolling optimization combined with dynamic correction is used to ensure the accuracy of the two-stage FR optimization model by updating the operating status of the CHP units and energy storage and reducing the prediction errors of the FR commands. The above models have been validated by actual case studies of a CHP plant in Northeast China. They can ensure the economic and sustainable operation of CHP units and energy storage, enabling the CHP plant to benefit in the FR ancillary services market. The models offer a useful reference for CHP enterprises in terms of FR. Full article

With the transformation of the energy structure, the integration of numerous small-scale, widely distributed renewable energy sources into the power grid has introduced operational safety challenges. To enhance the operational competitiveness, the virtual power plant (VPP) has emerged to aggregate and manage these distributed energy resources (DERs). However, current research on the VPP’s frequency modulation performance and bidding strategy remains insufficient in the joint market of electrical energy and frequency modulation (FM) ancillary services, with inadequate coordination of internally distributed resources. To fully leverage the flexibility of VPPs and incentivize their participation in electricity market operations, this paper investigates game-based bidding strategies and internal distributed resources allocation methods for VPPs in the joint market for electrical energy and frequency ancillary services. Firstly, the regulatory performance indicators of VPPs participating in the joint market and develops the corresponding market-clearing model. Secondly, to address the competition among distributed resources within VPPs, a master-slave game approach is innovatively employed to optimize the VPP’s trading strategies. This method ensures the rational allocation of electricity consumption among distributed energy resources within the VPP and derives the optimized bidding prices and quantities for both the VPP and its internal members. Finally, the case study shows that the proposed trading strategy provides effective bidding strategies for distributed energy resources participating in the joint market for energy and frequency regulation ancillary services. It enhances the regulatory performance of VPPs in the energy-frequency regulation market, ensures the profitability of distributed energy resources, and contributes to the economically stable operation of the market. Full article

A new type of power system with a high proportion of renewable energy sources (RES) penetration has become a global development trend. Meanwhile, the marketization reforms of the electricity market pose challenges to traditional energy. A multi-energy model including a wind turbine (WT), photovoltaic (PV) energy, energy storage (ES), and a thermal power system is proposed in this paper, participating in a joint market mechanism for energy and frequency regulation ancillary services. Unlike existing joint markets, this paper considers the market coupling clearing of various energy sources and the uncertainty of RES generation. Specially, a mechanism for the participation of storage and thermal power units in the frequency regulation ancillary service market is designed. Finally, a practical 118-node case study is provided to validate the impact of renewable generation uncertainty on the participation of multi-energy coupled systems in joint and single energy markets. Compared to the single electricity energy market, the simulation results show that the model can reduce the impact of RES uncertainty on ES generation and increase the cleared electricity quantity of thermal power units by 16%. Moreover, the model also increases the market revenue of thermal power units and storage by 30% and 44%, respectively. Full article

In recent years, the escalating electricity demand in Taiwan has heightened the prominence and discourse surrounding the issue of power supply. With the enactment of the European climate law, global commitment to achieving net-zero emissions has gained momentum. Concurrently, the Taiwanese government has articulated the Taiwan 2050 net-zero emissions policy. To realize this objective, Taiwan has vigorously promoted renewable energy in recent years, increasing the proportion of renewable energy in its energy mix. However, confronted with the intermittent and unpredictable nature of renewable energy generation, challenges arise concerning the stability and quality of power supply. In response to the impact of integrating renewable energy into the grid, the Taiwan Power Company (Taipower) has introduced the day-ahead ancillary service market. Through this platform, power generation and battery energy storage systems (BESSs) engage in competitive bidding, fostering the integration of diverse distributed energy resources into the system. These resources serve as dispatchable assets for Taipower, contributing to grid stability by providing ancillary services. This study has developed an advanced dynamic regulation reserve controller by employing an industrial PC (IPC) in conjunction with a multifunctional power meter. Through real-time measurement of the power grid frequency by the multifunctional power meter, a sophisticated dynamic frequency reserve control strategy has been devised, taking into account the charging state of energy storage systems. This strategy exhibits high operational quality, effectively regulating the charging and discharging of energy storage systems. In addition to swiftly adjusting the current grid frequency, it encompasses the capability to facilitate the transfer of peak electrical energy. This effectively stabilizes the power grid, alleviating supply pressures during nighttime peaks and enhancing the overall supply stability of the power system. Full article

In recent years, energy challenges such as grid congestion and imbalances have emerged from conventional electric grids. Furthermore, the unpredictable nature of these systems poses many challenges in meeting various users’ demands. The Battery Energy Storage System is a potential key for grid instability with improved power quality. The present study investigates the global trend towards integrating battery technology as an energy storage system with renewable energy production and utility grid systems. An extensive review of battery systems such as Lithium-Ion, Lead–Acid, Zinc–Bromide, Nickel–Cadmium, Sodium–Sulphur, and the Vanadium redox flow battery is conducted. Furthermore, a comparative analysis of their working principles, control strategies, optimizations, and technical characteristics is presented. The review findings show that Lead–Acid, Lithium-Ion, Sodium-based, and flow redox batteries have seen increased breakthroughs in the energy storage market. Furthermore, the use of the BESS as an ancillary service and control technique enhances the performance of microgrids and utility grid systems. These control techniques provide potential solutions such as peak load shaving, the smoothing of photovoltaic ramp rates, voltage fluctuation reduction, a large grid, power supply backup, microgrids, renewable energy sources time shift, spinning reserve for industrial consumers, and frequency regulation. Conclusively, a cost summary of the various battery technologies is presented. Full article

The electric power system is rapidly transforming to address the urgent need for decarbonization and combat climate change. Integration of renewable energy sources into the power grid is accelerating, creating new challenges such as intermittency and uncertainty. To address these challenges, this paper proposes a new design of automatic generation control (AGC) ancillary service cost allocation based on the causer-pays rule. The proposed design treats reserves as inventory and aims to minimize them by allocating costs among consumers based on the causative factors for AGC operation. Two cost-allocation methods based on the causer-pays principle are introduced. The first method distributes costs according to the changes in loads causing ancillary service operation, while the second method considers opportunity costs. The case study on the IEEE 39 Bus System demonstrates that the proposed methods incentivize consumers to minimize volatility, resulting in reduced reserve requirements for system operation. In particular, the opportunity cost-based approach encourages loads and variable renewable energy (VRE) to actively reduce volatility, resulting in more efficient power system operation. In conclusion, the novel AGC ancillary service cost allocation methods offer a promising strategy for minimizing spinning reserves, increasing the power system’s efficiency, and incentivizing consumers to actively participate in frequency regulation for a more sustainable and reliable electricity market. Full article

In pursuit of Finland’s carbon neutrality objective by 2035, integrating renewable energy sources into the power grid is essential. To address the stochastic nature of these resources, additional sources of flexibility are required to maintain grid stability. Meanwhile, district heating network (DHN) operators in Finland are decommissioning fossil fuel-based combined heat and power plants (CHPs) and electrifying heating systems with heat pumps (HPs) and electric boilers. A techno-economic assessment and the optimized operation of DHN-connected HPs and electric boilers in providing ancillary balancing services were explored in this study. The primary goal was to maximize the potential revenue for DHN operators through participation in the day-ahead electricity market and frequency containment reserve (FCR) balancing markets. Three interconnected DHNs in the Helsinki metropolitan area were optimized based on 2019 data and each operator’s decarbonization strategies for 2025. HPs are expected to achieve the highest profit margins in the FCR-D up-regulation market, while electric boilers could generate substantial profits from the FCR-D down-regulation market. In contrast to other balancing markets studied, the FCR-N market exhibited limited profit potential. Sensitivity analysis indicated that spot electricity prices and CO₂ emission allowance prices significantly influence the profitability derived from balancing markets. Full article

With the promotion of carbon peaking and carbon neutrality goals and the construction of renewable-dominated electric power systems, renewable energy will become the main power source of power systems in China. Therefore, ensuring frequency stability and system security will emerge as pivotal challenges in the future development process. Created by combining a Li-ion battery and a supercapacitor, a hybrid energy storage system (HESS), which possesses robust power regulation capabilities and rapid response capabilities, holds promise for supporting the frequency stability of power systems. In this context, the assessment of the economic viability of HESSs providing multitype frequency response services becomes a critical factor in their deployment and promotion. In this paper, an economic analysis approach for a Li-ion battery–supercapacitor HESS towards a multitype frequency response is presented. First, a multitype frequency response-oriented operational mode for the HESS is designed, outlining the roles and functions of the Li-ion battery and the supercapacitor in delivering distinct services. Moreover, building upon the analysis of the power trajectory of Li-ion batteries, a lifetime model for the HESS is proposed based on the rain-flow counting method. Furthermore, considering the competitive landscape for the HESS in the frequency regulation ancillary service market, a full lifecycle economic assessment model is proposed. Finally, case studies on actual power system frequency data and PJM market data are performed to verify the effectiveness of the proposed method, and the simulation results confirm that the HESS exhibits robust performance and a competitive advantage in providing multitype frequency response services. Additionally, it demonstrates commendable economic benefits, establishing its potential as a valuable contributor to frequency response services. Full article

Regulating the frequencies of power grids by controlling electric vehicle charging and discharging, known as vehicle-to-grid (V2G) ancillary services, is a promising and profitable means of providing flexibility that integrates variable renewable energy (VRE) into traditional power systems. However, the ancillary services market is a niche, and the scale, saturation, and time-dependency are unclear when assuming future changes in the power system structure. We studied the marginal value of V2G ancillary services as a balancing capacity of the power system operation on the load-frequency control (LFC) timescale and evaluated the reasonable maximum capacity of the LFC provided by V2G. As a case study, we assumed that the Japanese power system would be used under various VRE penetration scenarios and considered the limited availability time of V2G, based on the daily commuter cycle. The power system operation was modeled by considering pumped storage, interconnection lines, and thermal power–partial load operations. The results show that the marginal value of V2G was greater during the daytime than overnight, and the maximum cost saving (USD 705.6/EV/year) occurred during the daytime under the high-VRE scenario. Improving the value and size of V2G ancillary services required coordination with energy storage and excess VRE generation. Full article

This article examines the mechanisms for cross-border interchange of the regulating reserves (RRs), i.e., the imbalance-netting process (INP) and the cross-border activation of the RRs (CBRR). Both mechanisms are an additional service of frequency restoration reserves in the power system and connect different control areas (CAs) via virtual tie-lines to release RRs and reduce balancing energy. The primary objective of the INP is to net the demand for RRs between the cooperating CAs with different signs of interchange power variation. In contrast, the primary objective of the CBRR is to activate the RRs in the cooperating CAs with matching signs of interchange power variation. In this way, the ancillary services market and the European balancing system should be improved. However, both the INP and CBRR include a frequency term and thus impact the frequency response of the cooperating CAs. Therefore, the impact of the simultaneous operation of the INP and CBRR on the load-frequency control (LFC) and performance is comprehensively evaluated with dynamic simulations of a three-CA testing system, which no previous studies investigated before. In addition, a function for correction power adjustment is proposed to prevent the undesirable simultaneous activation of the INP and CBRR. In this way, area control error (ACE) and scheduled control power are decreased since undesired correction is prevented. The dynamic simulations confirmed that the simultaneous operation of the INP and CBRR reduced the balancing energy and decreased the unintended exchange of energy. Consequently, the LFC and performance were improved in this way. However, the impact of the INP and CBRR on the frequency quality has no unambiguous conclusions. Full article

This study focuses on strategic development for incorporating distributed energy resources into the electrical off-grid power system operator, or isolated microgrids, to guarantee sustainability and energy transition by an adapted business model. A business model canvas was adapted to allow sustainability in an off-grid Colombian microgrid by integrating distributed energy resources with voltage and frequency control as ancillary services; support services that maintain the stability and security of energy supply in isolated rural electrification. The business model canvas was studied with government funds, who cover all the costs associated with making the model attractive and sustainable in a Colombian context, and some proposed technical incentives to analyze the profitability and guarantee the sustainability of rural electrification. The proposed modified business model canvas offers a useful tool for supporting microgrid market scheme development to include distributed energy resources in a Colombian case. The model showed the importance of motivating investors and increasing profitability by including a value proposition based on technical contributions that benefit the microgrid operation; by around 80%. These benefits can solve some stability problems, including ancillary services, like frequency and voltage support, using distributed energy resources. Finally, integrating rural electrification in off-grid zones into the national energy regulation system is vital for incentivizing sustainable projects in rural zones, such as microgrids. Full article

As a consequence of the exponential growth of the electric vehicle (EV) market, DC fast-charging infrastructure is being rapidly deployed all around the world. Ultra-fast charging (UFC) stations are starting to pose serious challenges to the electric power system operation, mostly due to their high peak power demand and unregulated discontinuous operation. To address these issues, local energy storage can be installed, ensuring a smoother grid power absorption profile and allowing to provide grid-supporting features. In this work, a control solution for the grid-side AC/DC converter of next-generation EV UFC stations is proposed. A virtual synchronous compensator (VSC) control algorithm is implemented, in order to lessen the impact of the charging station on the utility and to provide the full spectrum of grid ancillary services (i.e., frequency regulation, reactive power compensation, harmonic reduction, short circuit current generation, etc.). The proposed control strategy is verified experimentally on a downscaled 15 kVA three-phase inverter, emulating the grid front-end of the charging station. Full article

The gradual displacement of synchronous generators driven by conventional power plants, due to the increasing penetration of distributed renewable energy sources (DRES) in distribution grids, is creating a shortage of crucial ancillary services (AS) which are vital for the frequency and voltage stability of the grid. These AS, and some new ones, could now be offered by the DRES, particularly those that are converter interfaced, in a coordinated way in order to preserve the grid stability and resilience. Although recent standards and grid codes specify that the DRES exhibit some system support functions, there are no specifications on how to measure and quantify (M & Q) them both at DRES level and in aggregated form. The M & Q of AS is crucial, since it would allow the AS to be treated as tradable AS in the current and future AS markets. This paper attempts to define a number of AS that can be offered by converter-interfaced DRES and suggests methods for their M & Q. The new AS addressed are: (1) inertial response; (2) primary frequency response; (3) active power smoothing (ramp-rate limitation); (4) exchange of reactive power for voltage regulation; (5) fault-ride-through (FRT) and contribution to fault clearing; (6) voltage harmonic mitigation. Additionally, a rough estimation of the additional investment and operational cost, as well as the financial benefits associated with each AS is provided in order to form the basis for the development of business models around each AS in the near future. Full article
