Search Results (96)

This study investigates ground deformations in the southeastern Po Plain (northern Italy), focusing on the Bologna area—a densely populated region affected by natural and anthropogenic subsidence. Ground deformations in the area result from geological processes (e.g., sediment compaction and tectonic activity) and human activities (e.g., ground water production and underground gas storage—UGS). We apply a multidisciplinary approach integrating subsurface geology, ground water production, advanced differential interferometry synthetic aperture radar—DInSAR, gas storage data, and land use information to characterize and analyze the spatial and temporal variations in vertical ground deformations. Seasonal and trend decomposition using loess (STL) and cluster analysis techniques are applied to historical DInSAR vertical time series, targeting three representatives areas close to the city of Bologna. The main contribution of the study is the attempt to correlate the lateral extension of ground water bodies with seasonal ground deformations and water production data; the results are validated via knowledge of the geological characteristics of the uppermost part of the Po Plain area. Distinct seasonal patterns are identified and correlated with ground water production withdrawal and UGS operations. The results highlight the influence of superficial aquifer characteristics—particularly the geometry, lateral extent, and hydraulic properties of sedimentary bodies—on the ground movements behavior. This case study outlines an effective multidisciplinary approach for subsidence characterization providing critical insights for risk assessment and mitigation strategies, relevant for the future development of CO₂ and hydrogen storage in depleted reservoirs and saline aquifers. Full article

Snow water equivalent (SWE) can be estimated using Differential SAR Interferometry (DInSAR), which captures changes in snow depth and density between two SAR acquisitions. However, challenges arise due to SAR signal penetration into the snowpack and the intrinsic limitations of DInSAR measurements. This study addresses these issues and explores the use of multi-band SAR data to derive SWE maps in alpine regions characterized by steep terrain, small spatial extent, and a potentially heterogeneous snowpack. We first conducted a performance analysis to assess SWE estimation precision and the maximum unambiguous SWE variation, considering incidence angle, wavelength, and coherence. Based on these results, we selected C-band Sentinel-1 and L-band SAOCOM data acquired over alpine areas and applied tailored DInSAR processing. Atmospheric artifacts were corrected using zenith total delay maps from the GACOS service. Additionally, sensitivity maps were generated for each interferometric pair to identify pixels suitable for reliable SWE estimation. A comparative analysis of the C- and L-band results revealed several critical issues, including significant atmospheric artifacts, phase decorrelation, and phase unwrapping errors, which impact SWE retrieval accuracy. A comparison between our Sentinel-1-based SWE estimations and independent measurements over an instrumented site shows results fairly in line with previous works exploiting C-band data, with an RSME in the order of a few tens of mm. Full article

Dams are crucial for ensuring water and electricity supply, while also providing significant flood protection. Regular monitoring of dam deformations is of vital socio-economic and ecological significance. In Germany, dams must be constructed and operated according to generally accepted rules of engineering. The safety concept for dams based on these rules relies on structural safety, professional operation and maintenance, safety monitoring, and precautionary measures. Rather time-consuming in situ techniques have been employed for these measurements, which permit monitoring deformations with either high spatial or temporal resolution, but not both. As a means of measuring large-scale deformations in the millimeter range, the Differential Interferometric Synthetic Aperture Radar (DInSAR) technique of Persistent Scatterer Interferometry (PSI) is already being applied in various fields. However, when considering the operational monitoring of dams using PSI, specific characteristics need to be considered. For example, the geographical location of the dam in space, as well as its shape, size, and land cover. All these factors can affect the visibility of the structure for the use with PSI and, in certain cases, limit the applicability of SAR data. The visibility of dams for PSI monitoring is often limited, particularly in cases where observation is typically not feasible due to factors such as geographical and structural characteristics. While corner reflectors can improve visibility, their large size often makes them unsuitable for dam infrastructure and may raise concerns with heritage protection for listed dams. Addressing these challenges, electronic corner reflectors (ECRs) offer an effective alternative due to their small and compact size. In this study, we analyzed the strategic placement of ECRs on dam structures. We developed a new CR Index, which identifies areas where PSI alone is insufficient due to unfavorable geometric or land use conditions. This index categorizes visibility potential into three classes, presented in a ‘traffic light’ map, and is instrumental in selecting optimal installation sites. We furthermore investigated the signal stability of ECRs over an extended observation period, considering the Amplitude Dispersion Index (ADI). It showed values between 0.1 and 0.4 for many dam structures, which is comparable to normal corner reflectors (CRs), confirming the reliability of these signals for PSI analysis. This work underscores the feasibility of using ECRs to enhance monitoring capabilities at dam infrastructure. Full article

The conventional Structural Health Monitoring (SHM) framework focuses on individual structures. However, preliminary studies are required at a large territorial scale to effectively identify the most vulnerable elements. This becomes particularly challenging in urban settings, where numerous buildings of varied shapes, ages, and structural conditions are closely spaced from one another. A twofold task is therefore required: the automated identification and differentiation of various structures, coupled with a ranking system based on perceived structural risk, here assumed to be linked to their deformation patterns. It integrates displacement measurements acquired through the Differential Synthetic Aperture Radar Interferometry (DInSAR) technique, specifically employing the full-resolution Small Baseline Subset (SBAS) approach coupled with Hierarchical Clustering. The effectiveness of this method is successfully demonstrated and validated in two selected areas of Rome, Italy, serving as case studies. The results of this vast-area scale monitoring can be used to select the constructions that need a more in-depth assessment. Full article

The LuTan-1 (LT-1) satellite, launched in 2022, is China’s first L-band full-polarimetric Synthetic Aperture Radar (SAR) constellation, boasting interferometry capabilities. However, given its limited use in subsidence monitoring to date, a comprehensive evaluation of LT-1’s interferometric quality and capabilities is necessary. In this study, we utilized the Differential Interferometric Synthetic Aperture Radar (DInSAR) technique to analyze mining-induced subsidence results near Shenmu City (China) with LT-1 data, revealing nine subsidence areas with a maximum subsidence of −19.6 mm within 32 days. Furthermore, a comparative analysis between LT-1 and Sentinel-1 data was conducted focusing on the aspects of subsidence results, interferometric phase, scattering intensity, and interferometric coherence. Notably, LT-1 detected some subsidence areas larger than those identified by Sentinel-1, attributed to LT-1’s high resolution, which significantly enhances the detectability of deformation gradients. Additionally, the coherence of LT-1 data exceeded that of Sentinel-1 due to LT-1’s L-band long wavelength compared to Sentinel-1’s C-band. This higher coherence facilitated more accurate capturing of differential interferometric phases, particularly in areas with large-gradient subsidence. Moreover, the quality of LT-1’s monitoring results surpassed that of Sentinel-1 in root mean square error (RMSE), standard deviation (SD), and signal-to-noise ratio (SNR). In conclusion, these findings provide valuable insights for future subsidence-monitoring tasks utilizing LT-1 data. Ultimately, the systematic differences between LT-1 and Sentinel-1 satellites confirm that LT-1 is well-suited for detailed and accurate subsidence monitoring in complex environments. Full article

The goal of this study was to develop a model describing the relationship between the ground-displacement-caused tremors induced by underground mining, and mining and geological factors using the Random Forest Regression machine learning method. The Rudna mine (Poland) was selected as the research area, which is one of the largest deep copper ore mines in the world. The SAR Interferometry methods, Differential Interferometric Synthetic Aperture Radar (DInSAR) and Small Baseline Subset (SBAS), were used in the first case to detect line-of-sight (LOS) displacements, and in the second case to detect cumulative LOS displacements caused by mining tremors. The best-prediction LOS displacement model was characterized by R² = 0.93 and RMSE = 5 mm, which proved the high effectiveness and a high degree of explanation of the variation of the dependent variable. The identified statistically significant driving variables included duration of exploitation, the area of the exploitation field, energy, goaf area, and the average depth of field exploitation. The results of the research indicate the great potential of the proposed solutions due to the availability of data (found in the resources of each mine), and the effectiveness of the methods used. Full article

The Upper Silesian coal basin (USCB) in Poland faces significant ground deformation issues resulting from mining activities conducted without backfill, which can persist for years. These activities can cause damage to surface structures and phenomena such as induced seismicity. Ground deformations can be monitored using differential synthetic aperture radar interferometry (DInSAR). However, various DInSAR approaches have their own advantages and limitations, particularly regarding accuracy and atmospheric filtering. This is especially important for high-frequency displacement signals associated with seismic activity, which can be filtered out. Therefore, this study aims to assess the detectability of mining-induced seismic events using interferometric techniques, focusing on the USCB area. In this experiment, we tested two InSAR approaches: conventional DInSAR without atmospheric filtering and the small baseline subset (SBAS) approach, where the atmospheric phase screen was estimated and removed using high-pass and low-pass filtering. The results indicate that, in most cases, post-seismic ground displacement is not detectable using both methods. This suggests that mining-related seismic events typically do not cause significant post-seismic ground displacement. Out of the 17 selected seismic events, only two were clearly visible in the DInSAR estimated deformation, while for four other events, some displacement signals could neither be definitively confirmed nor negated. Conversely, only one seismic event was clearly detectable in the SBAS displacement time series, with no evidence of induced tremors found for the other events. DInSAR proved to be more effective in capturing displacement signals compared to SBAS. This could be attributed to the small magnitude of the tremors and, consequently, the small size of the seismic sources. Throughout the investigated period, all registered events had magnitudes less than 4.0. This highlights the challenge of identifying any significant influence of low-magnitude tremors on ground deformation, necessitating further investigations. Moreover, SBAS techniques tend to underestimate mining displacement rates, leading to smoothed deformation estimates, which may render post-seismic effects invisible for events with low magnitudes. However, after an in-depth analysis of the 17 seismic events in the USCB, DInSAR was found to be more effective in capturing displacement signals compared to SBAS. This indicates the need for significant caution when applying atmospheric filtering to high-frequency displacement signals. Full article

Long-term ground subsidence (LTGS) is a relatively slow process. However, the accumulation of long-term subsidence has an adverse impact on the normal operation and safety of a subway, hindering sustainable urban development. A wide gap exists between early warning theory and its application in the control of LTGS during subway operation due to time span limitation. Providing decision support for LTGS in high-density urban areas during subway operation is difficult, and a collaborative decision system for real-time early warning and intelligent control is currently lacking. This study establishes the functional components of an intelligent early warning and decision platform, proposes a software system module, constructs an overall software framework structure, and develops a mobile intelligent early warning and decision platform. Moreover, this study introduces an early warning method for LTGS in high-density urban areas during subway operation. This method integrates an intelligent early warning decision-making platform, namely Differential Synthetic Aperture Radar Interferometry (DInSAR), land subsidence monitoring, operation tunnel subsidence monitoring, and other multisource data coupling. The method is applied to sections of the Hangzhou Metro Line 4 Phase I Project (Chengxing Road Station (CRS)–Civic Center Station (CCS)–Jiangjin Road Station (JRS) and Xinfeng Station (XS)–East Railway Station (ERS)–Pengbu Station (PS)). This work can serve as a reference for ensuring urban safety and promoting sustainable development. Full article

The analysis of the degree of surface deformation can be a relevant aspect in the study of surface stability conditions, as it provides added value in the construction of risk management plans. This analysis provides the opportunity to establish the behaviors of the internal dynamics of the earth and its effects on the surface as a prediction tool for possible future effects. To this end, this study was approached through the analysis of Synthetic Aperture Radar (SAR) images using the Differential Interferometry (DInSAR) technique, which, in turn, is supported by the Small Baseline Subset (SBAS) technique to take advantage of the orbital separation of the Sentinel-1 satellite images in ascending and descending trajectory between the years 2014 and 2021. As a result, a time series was obtained in which there is a maximum uplift of 117.5 mm (LOS-ascending) or 49.3 mm (LOS-descending) and a maximum subsidence of −86.2 mm (LOS-ascending) or −71.5 mm (LOS-descending), with an oscillating behavior. These deformation conditions are largely associated with the kinematics of the Bucaramanga Fault, but a recurrent action of deep seismic activity from the Bucaramanga Seismic Nest was also observed, generating a surface deformation of ±20 mm for the period evaluated. These deformations have a certain degree of impact on the generation of mass movements, evaluated by the correlation with the LOS-descending images. However, their action is more focused as an inherent factor of great weight, which makes it possible to respond to early care and allows real-time follow-up, giving positive feedback to the system. Full article

Landslide geological disasters, occurring globally, often result in significant loss of life and extensive economic damage. In recent years, the severity of these disasters has increased, likely due to the frequent occurrence of extreme rainstorms associated with global warming. This escalating trend emphasizes the urgent need for a simple and efficient method to identify hidden dangers related to landslide geological disasters. Areas experiencing seasonal heavy rainfall are particularly susceptible to such disasters, posing a serious threat to the lives and property of local residents. In response to the challenging characteristics of landslide geological hazards, such as their strong concealment and the high vegetation coverage in the Liupan Mountain area of the Loess Plateau, this study focuses on the integrated remote sensing identification and research of hidden landslide dangers in Longde County. The methodology combines differential interferometric synthetic aperture radar technology (D-InSAR) and high-resolution optical remote sensing. Surface deformation information of Longde County was obtained by analyzing 85 Sentinel-1A data from 2019 to mid-2020 using Stacking-InSAR, in conjunction with high-resolution optical remote sensing image data from GF-2 in 2019. Furthermore, the study conducted integrated remote sensing identification and field verification of landslide hazards throughout the entire county. This involved interpreting the shape and deformation marks of landslide hazards, identifying the disaster-bearing bodies, and expertly interpreting the environmental factors contributing to the hazards. As a result, 47 suspected landslide hazards and 21 field investigation points were identified, with 16 hazards verified with an accuracy of 76.19%. This outcome directly confirms the applicability and accuracy of the integrated remote sensing identification technology in the study area. The research results presented in this paper provide an effective scientific and theoretical basis for the monitoring and treatment of landslide geological disasters in the future stages. They also play a pivotal role in the prevention of such disasters. Full article

Differential SAR Interferometry is a largely exploited technique to study ground deformations. A key application is the detection of the effects promoted by earthquakes, including detailed variations in ground deformations at different scales. In this work, an implemented Python script (Snap2DQuake) based on the “snappy” module by SNAP software 9.0.8 (ESA) for the processing of satellite imagery is proposed. Snap2DQuake is aimed at producing detailed coseismic deformation maps using Sentinel-1 C-band data by the DInSAR technique. With this alternative approach, the processing is simplified, and several issues that may occur using the software are solved. The proposed tool has been tested on two case studies: the M_w 6.4 Petrinja earthquake (Croatia, December 2020) and the M_w 5.7 to M_w 6.3 earthquakes, which occurred near Tyrnavós (Greece, March 2021). The earthquakes, which occurred in two different tectonic contexts, are used to test and verify the validity of Snap2DQuake. Snap2DQuake allows us to provide detailed deformation maps along the vertical and E-W directions in perfect agreement with observations reported in previous works. These maps offer new insights into the deformation pattern linked to earthquakes, demonstrating the reliability of Snap2DQuake as an alternative tool for users working on different applications, even with basic coding skills. Full article

The Essential Climate Variable (ECV) Permafrost is currently undergoing strong changes due to rising ground and air temperatures. Surface movement, forming characteristic landforms such as rock glaciers, is one key indicator for mountain permafrost. Monitoring this movement can indicate ongoing changes in permafrost; therefore, rock glacier velocity (RGV) has recently been added as an ECV product. Despite the increased understanding of rock glacier dynamics in recent years, most observations are either limited in terms of the spatial coverage or temporal resolution. According to recent studies, Sentinel-1 (C-band) Differential SAR Interferometry (DInSAR) has potential for monitoring RGVs at high spatial and temporal resolutions. However, the suitability of DInSAR for the detection of heterogeneous small-scale spatial patterns of rock glacier velocities was never at the center of these studies. We address this shortcoming by generating and analyzing Sentinel-1 DInSAR time series over five years to detect small-scale displacement patterns of five high alpine permafrost environments located in the Central European Alps on a weekly basis at a range of a few millimeters. Our approach is based on a semi-automated procedure using open-source programs (SNAP, pyrate) and provides East-West displacement and elevation change with a ground sampling distance of 5 m. Comparison with annual movement derived from orthophotos and unpiloted aerial vehicle (UAV) data shows that DInSAR covers about one third of the total movement, which represents the proportion of the year suited for DInSAR, and shows good spatial agreement (Pearson R: 0.42–0.74, RMSE: 4.7–11.6 cm/a) except for areas with phase unwrapping errors. Moreover, the DInSAR time series unveils spatio-temporal variations and distinct seasonal movement dynamics related to different drivers and processes as well as internal structures. Combining our approach with in situ observations could help to achieve a more holistic understanding of rock glacier dynamics and to assess the future evolution of permafrost under changing climatic conditions. Full article

Landslides pose significant risks to towns and villages in Southern Italy, including the San Marco dei Cavoti hamlet (Benevento, Campania), where settlements have expanded into areas threatened by landslides, leading to property damage, disruption to the social fabric and loss of life. This study aims to investigate the surface deformations in the area using Differential Interferometry SAR (DInSAR) analysis on COSMO-SkyMed radar imagery and to assess the potential implications for landslide activity. The DInSAR analysis methodology allowed us to obtain high-precision results presented as time series diagrams and maps of cumulative displacement for the study area. Furthermore, the displacement rates derived from the DInSAR analysis were decomposed into vertical and horizontal components to provide better insights into the slope processes and their potential impacts on the San Marco dei Cavoti hamlet. Our significant findings revealed active slope movements and the uphill enlargement of previously inventoried landslides threatening the San Marco dei Cavoti hamlet. These insights contribute to a better understanding of the landslide dynamics in the region and highlight the areas that may require further investigation or intervention measures. In conclusion, this study demonstrates the effectiveness of DInSAR analysis in providing valuable insights into landslide dynamics and informing potential mitigation measures for at-risk communities. This technique could be applied to other landslide-prone regions to support informed decision-making and enhance the safety and resilience of affected communities. Full article

In the application of synthetic aperture radar differential interferometry in urban environments, it is easy to regard the phase change in the deformation band of buildings under construction as noise that requires filtering. This introduces an error into the surrounding area while over-filtering, resulting in an error in the magnitude of the deformation measurement results for the entire region and the loss of deformation details in the surrounding area. Based on the traditional DInSAR workflow, this study added a deformation magnitude identification step, determined the deformation magnitude by using enhanced offset tracking technology, supplemented the filtering quality map and removed the construction areas that affect the interferometry in the filtering stage. The enhanced offset tracking technique adjusted the ratio of contrast saliency and coherence via the contrast consistency peak in the radar intensity image, which was used as the basis for adjusting the adaptive window size. The method proposed in this paper was evaluated in an experiment on a stable region using simulated data and in an experiment on a large deformation region using Sentinel-1 data. The experimental results show that the enhanced method has a better anti-noise ability than the traditional method, and the accuracy rate is improved by about 12%. The supplemented quality map can effectively remove the large deformation area to prevent over-filtering while ensuring the filtering quality, and it can achieve better filtering results. Full article

This manuscript presents the results of the study of snow covers’ influence on the interferometric measurements of the stability of industrial infrastructure in the vicinity of Norilsk city, Russia. Fuel tanks of the Norilsk thermal power plant (TPP) were selected as an object of study due to a well-known accident when about 20,000 tons of diesel fuel spilled from one of the tanks. Sentinel-1 synthetic aperture radar data acquired over the territory of Norilsk TPP were used in the DInSAR study of the possible displacements of the tanks that could be the cause of the tank’s damage. For twelve days, radar interferograms that were generated in the study covered the cold and warm seasons of 2018–2020, including the catastrophic event—the rupture of the tank with diesel fuel—in order to shed light on the possible impact of the area subsidence because of permafrost thaw under the tanks. As the tank walls and adjacent concrete base constituted the virtual dihedral corner reflector, the accumulation of snow on the surface near the tanks created a distorting effect on the results of monitoring the stability of the tank’s location. Three models of snow layer within the dihedral proposed could help explain the deviations in the signal amplitude and phase in the case of snowfalls occurring between radar observations. We propose three ways to minimize the influence of snow on interferometric measurements. One of them, the selection of the radar data acquired in proper observation conditions, made it possible to assess the stability of the mutual location of the tanks. Among the most important processing and analysis results in the paper is a conclusion about the high stability of the fuel tank’s location on the yearly time interval, including the troubleshooting tank. Full article
