This study investigates the forming process (stamping) of bipolar plates which have applied a novel ultra-thin (0.1 mm) super ferritic stainless steel, i.e., SUS470, whose chromium is sufficiently high for corrosion resistance. A three-dimensional finite element model of the stamping process was developed using the commercial software ABAQUS version 2022. The model incorporated optimized die parameters obtained through Central Composite Design (CCD). This model was used to analyze the effects of key forming parameters, including stamping speed and friction coefficient, on the distribution of stress, strain, and thickness reduction during the stamping process. The finite element modeling (FEM) results disclose that the inner corner of the flow channel is a critical defect-prone region, exhibiting stress concentration, uneven strain distribution, and severe thinning. The optimal forming quality can be achieved at a stamping speed of 100 mm/s and a friction coefficient of 0.185 among all varied options. Further, a comparative study of single-stage, conventional two-stage, and optimized two-stage stamping strategies based on previous investigation demonstrates that the optimized two-stage stamping process can effectively alleviate stress and strain concentrations at the corners, significantly reduce thinning problems, and enhance the uniformity and stability during stamping. In summary, this study provides theoretical support for the design of the forming process (stamping) of high-performance super ferritic stainless steel bipolar plates, which is beneficial to subsequent practical engineering application. Full article

The insufficient corrosion resistance and high interfacial contact resistance (ICR) of 316L stainless steel (316L SS) severely limit its application as bipolar plates (BPs) in proton exchange membrane fuel cells (PEMFCs). In this study, a graphite/carbon black/PVDF composite coating was first developed by hot rolling on the surface of 316L SS to enhance both corrosion resistance and conductivity. By incorporating 5 wt% polyaniline (PANI) as a corrosion inhibitor, the optimized RP5 coating exhibited further improvements in corrosion resistance. The potentiodynamic polarization tests revealed that the RP5 coating achieved a corrosion current density of 0.977 μA·cm⁻², representing a two-orders of magnitude reduction compared to bare 316L SS (34.1 μA·cm⁻²). The coating also exhibits a satisfactory interfacial contact resistance (ICR) of 8.20 mΩ·cm² at 1.5 MPa, meeting the U.S. Department of Energy (DOE) 2025 targets (<10 mΩ·cm²). Additionally, the RP5 coating exhibited superior hydrophobicity with a water contact angle of 96.5°, which is advantageous for water management within PEMFCs. The results confirm that the RP5 coating achieves an optimal balance between high conductivity, excellent corrosion resistance, and improved hydrophobicity, making it a promising solution for advancing PEMFC bipolar plates’ performance. Full article

This study investigates the impact of graphite (GR) concentration and particle size on the performance of conductive polymer composites (CPCs) using polyvinylidene fluoride (PVDF), polypropylene (PP), and polyethylene terephthalate (PET) as matrix materials. Composites were prepared with GR concentrations ranging from 20 to 60 wt. % and particle sizes categorized as G1 (5.9 µm), G2 (17.8 µm), and G3 (561 µm), and evaluated for their electrical, thermal, and mechanical properties. The investigation of the effect of graphite particle size on composite properties represents the main originality of this work. Among all composites, PVDF containing 60 wt. % of medium-sized G2 particles exhibited the lowest electrical resistivity (0.77 ohm·cm through-plane and 0.69 ohm·cm in-plane), along with the highest residual ash content (72%). In PP and PET matrices, incorporating 60 wt. % G2 particles resulted in through-plane resistivities of 11.3 ohm·cm and 1.6 ohm·cm, and in-plane resistivities of 5 ohm·cm and 1.2 ohm·cm, respectively, with thermal decomposition temperatures of 374 °C and 401 °C. Regarding mechanical performance and thermal stability, composites with small-sized G1 particles demonstrated superior performance due to their larger surface area and stronger matrix interactions. The PVDF/G1 (40/60 wt. %) composite achieved the highest flexural modulus (6.8 GPa), flexural strength (38.6 MPa), compressive modulus (0.28 GPa), and decomposition temperature (445 °C), highlighting its exceptional properties. These CPCs show significant promise for energy and electronic applications, particularly in the fabrication of bipolar plates for proton exchange membrane fuel cells, as well as in shielding materials and thermoelectric devices. Full article

Composite bipolar plates are a new class of material bipolar plates for PEMFCs. However, their application is limited by problems such as the difficulty of balancing their strength/conductivity properties. In this paper, by using surface-modified carboxylated short-cut carbon fibers and hydroxylated carbon nanotubes as well as PI resin, the interfacial bonding between the carbon-based filler and the resin is effectively improved under the premise of ensuring electrical conductivity, which enhances the flexural strength. The effect of the surface modification of the filler on the interfacial bonding between the filler and the PI resin is thoroughly investigated through molecular dynamics simulations. The mechanism for this improved bonding was also studied. Through the surface modification of the filler, the composite bipolar plates possessed a flexural strength of 49.06 MPa and a planar conductivity of 228.52 S/cm with the addition of 6% MWCNT-OH as well as 12% CCFs, which has the potential to be an optional substrate for composite bipolar plates. Full article

The increasing demand for sustainable agricultural practices aimed at reducing carbon dioxide emissions has driven the exploration of converting viticulture residues into biochar. This study investigates the potential technological applications of biochar as a filler for the production of electrically conductive composite materials, suitable to Bipolar Plate (BP) manufacturing. Grape seeds (GSs), defatted grape seeds (DGSs), wood stems (WSs), and whole grape seeds (WGSs) were converted into biochar samples through low-temperature (300 °C) pyrolysis for 3 or 24 h. The composition and thermal stability of biochar were evaluated through thermogravimetric analysis (TG), which provided valuable insights into interpreting the in-plane conductivity (IPC) values of the BP samples. Pyrolyzed GS and DGS biochar samples demonstrated enhanced thermal stability and conferred higher IPC values compared to WS counterparts. This indicates a clear correlation between the formation of carbon-rich structures during pyrolysis and overall electrical conductivity. In contrast, pyrolyzed WGSs produced BP samples with lower IPC values due to the presence of lipids, which were not effectively degraded by the low-temperature pyrolysis. Full article

To improve the conductivity and flexural strength of bipolar plates for proton-exchange membrane fuel cells, multi-filler-reinforced composites were prepared using graphite, multiwalled carbon nanotubes (MWCNTs), chopped carbon fibers (CCFs), and phenolic resin (PF). The effects of CCF content (0–6 wt.%) and MWCNT content (0–8 wt.%) on the flexural strength, electrical conductivity, interfacial contact resistance (ICR), density, hydrophobicity, and corrosion behavior of the composites were investigated. Results showed that the addition of a small number of CCFs (≤4 wt.%) effectively improved the flexural strength but slightly reduced the electrical conductivity and increased the ICR of the graphite/PF/CCF composites. Further addition of MWCNTs (≤6 wt.%) significantly improved the electrical conductivity and ICR of the graphite/PF/CCF/MWCNT composites, while maintaining high flexural strength. When the composites were filled with 4 wt.% CCFs and 2 wt.% MWCNTs, their electrical conductivity, flexural strength, ICR under 1.38 MPa, and contact angle were 272.8 S/cm, 43.1 MPa, 1.19 mΩ·cm², and 101.5°, respectively. Compared to unreinforced composites, the electrical conductivity was reduced by 27.2%, the flexural strength was increased by 65.1%, and the composite possessed favorable hydrophobicity as well as corrosion behavior. This work reveals that CCFs and MWCNTs can effectively cooperate to improve composites’ electrical and flexural strength properties. Full article

As one core component in hydrogen fuel cells and water electrolysis cells, bipolar plates (BPs) perform multiple important functions, such as separating the fuel and oxidant flow, providing mechanical support, conducting electricity and heat, connecting the cell units into a stack, etc. On the path toward commercialization, the manufacturing costs of bipolar plates have to be substantially reduced by adopting low-cost and easy-to-process metallic materials (e.g., stainless steel, aluminum or copper). However, these materials are susceptible to electrochemical corrosion under harsh operating conditions, resulting in long-term performance degradation. By means of advanced thermal spraying technologies, protective coatings can be prepared on bipolar plates so as to inhibit oxidation and corrosion. This paper reviews several typical thermal spraying technologies, including atmospheric plasma spraying (APS), vacuum plasma spraying (VPS) and high-velocity oxygen fuel (HVOF) spraying for preparing coatings of bipolar plates, particularly emphasizing the effect of spraying processes on coating effectiveness. The performance of coatings relies not only on the materials as selected or designed but also on the composition and microstructure practically obtained in the spraying process. The temperature and velocity of in-flight particles have a significant impact on coating quality; therefore, precise control over these factors is demanded. Full article

Bipolar plates (BPs) are one of the most important components of polymer electrolyte membrane fuel cells (PEMFCs) because of their important role in gas and water management, electrical performance, and mechanical stability. Therefore, promising materials for use as BPs should meet several technical targets established by the United States Department of Energy (DOE). Thus far, in the literature, many materials have been reported for possible applications in BPs. Of these, polymer composites reinforced with carbon allotropes are one of the most prominent. Therefore, in this review article, we present the progress and critical analysis on the use of carbon material-reinforced polymer composites as BPs materials in PEMFCs. Based on this review, it is observed that numerous polymer composites reinforced with carbon allotropes have been produced in the literature, and most of the composites synthesized and characterized for their possible application in BPs meet the DOE requirements. However, these composites can still be improved before their use for BPs in PEMFCs. Full article

The demand for polymer composite solutions in bipolar plates for polymer electrolyte membrane fuel cells (PEMFCs) has risen due to advantages over metal plates such as longer lifetime, weight reduction, corrosion resistance, flexible manufacturing, freedom of design, and cost-effectiveness. The challenge with polymer composites is achieving both sufficient electrical conductivity and mechanical stability with high filler content. A carbon fiber fleece as reinforcement in a graphite-filled polypropylene (PP) matrix was investigated for use as bipolar plate material with increased mechanical and sufficient conductive properties. Plates with a thickness of 1 mm containing four layers of fleece impregnated in the PP-graphite compound were produced in a compression molding process. Particle and fiber interactions were investigated via microscopy. The plates were characterized with respect to the electrical conductivity and mechanical stability. High electric conductivity was reached for fiber-reinforced and plain PP-graphite compound plates, with increased filler content leading to a higher conductivity. The contact resistance remained largely unaffected by surface etching as no polymeric skin layer formed during compression molding. Fiber-reinforced plates exhibit twice the tensile strength, a significantly higher tensile modulus, and an increased elongation at break, compared to PP filled only with graphite. Full article

In this research, polypropylene (PP)–graphite composites were prepared using the melt mixing technique in a twin-screw extruder. Graphite, multi-walled carbon nanotubes (MWCNT), carbon black (CB), and expanded graphite (EG) were added to the PP in binary, ternary, and quaternary formations. The graphite was used as a primary filler, and MWCNT, CB, and EG were added to the PP–graphite composites as secondary fillers at different compositions. The secondary filler compositions were considered the control input factors of the optimization study. A full factorial design of the L-27 Orthogonal Array (OA) was used as a Design of Experiment (DOE). The through-plane electrical conductivity and flexural strength were considered the output responses. The experimental data were interpreted via Analysis of Variance (ANOVA) to evaluate the significance of each secondary filler. Furthermore, statistical modeling was performed using response surface methodology (RSM) to predict the properties of the composites as a function of filler composition. The empirical model for the filler formulation demonstrated an average accuracy of 83.9% and 93.4% for predicting the values of electrical conductivity and flexural strength, respectively. This comprehensive experimental study offers potential guidelines for producing electrically conductive thermoplastic composites for the manufacturing of bipolar fuel cell plates. Full article

Composite bipolar plates (BPs) hinder their application in proton exchange membrane fuel cells (PEMFC) because of their poor conductivity and mechanical properties. Nanofillers can effectively solve this problem but often have a limited effect due to their easy agglomeration. In this work, a continuous mesh carboxylated multi-walled carbon nanotube (MWCNT) coating on the surface of graphite was synthesized by chemical vapor deposition (CVD) and carboxylation modification, and the composite BPs were prepared by molding using prepared reticulated carboxylated MWCNTs, expanded graphite, and resin. By optimizing the carboxylation treatment time and the content of the nano-filler, the composite BPs had the best performance at a 15 min carboxylation treatment time and 2.4% filler content. The planar conductivity reached up to 243.52 S/cm, while the flexural strength increased to 61.9 MPa. The thermal conductivity and hydrophobicity were improved compared with the conventional graphite/resin composite BPs, and good corrosion resistance has been demonstrated under the PEMFC operating environment. This work provides a novel nanofiller modification paradigm for PBs. Full article

Here, potential metallic bipolar plate (BP) materials were manufactured by laser coating NiCr-based alloys with different Ti additions on low carbon steel substrates. The titanium content within the coating varied between 1.5 and 12.5 wt%. Our present study focussed on electrochemically testing the laser cladded samples in a milder solution. The electrolyte used for all of the electrochemical tests consisted of a 0.1 M Na₂SO₄ solution (acidulated with H₂SO₄ at pH = 5) with the addition of 0.1 ppm F⁻. The corrosion resistance properties of the laser-cladded samples was evaluated using an electrochemical protocol, which consisted of the open circuit potential (OCP), electrochemical impedance spectroscopy (EIS) measurements, and potentiodynamic polarization, followed by potentiostatic polarization under simulated proton exchange membrane fuel cell (PEMFC) anodic and cathodic environments for 6 h each. After the samples were subjected to potentiostatic polarization, the EIS measurements and potentiodynamic polarization were repeated. The microstructure and chemical composition of the laser cladded samples were investigated by scanning electron microscopy (SEM) combined with energy-dispersive X-ray spectroscopy (EDX) analysis. Full article

Cost reduction in bipolar plates in proton exchange membrane water electrolyzers has previously been attempted by substituting bulk titanium with austenitic stainless steels protected with highly conductive and corrosion-resistant coatings. However, austenitic steels are more expensive than ferritic steels due to their high nickel content. Herein we report on the corrosion resistance of two high chromium ferritic stainless steels, AISI 442 and AISI 446, as an alternative material to manufacture bipolar plates. Electrochemical corrosion tests have shown that AISI 442 and AISI 446 have similar corrosion resistance, while AISI 446 reveals more noble corrosion potential and performs better during potentiostatic stress tests. The current density obtained during polarization at 2 V versus the standard hydrogen electrode (SHE) is 3.3 mA cm⁻², which is more than two times lower than on AISI 442. Additionally, surface morphology characterization demonstrates that in contrast to AISI 442, AISI 446 is not sensitive to intercrystalline or pitting corrosion. Moreover, EDX energy dispersion analysis of AISI 446 reveals no differences in the chemical composition of the surface layer compared to the base material, as a confirmation of its high corrosion resistance. The results of this work open up the perspective of replacing austenitic stainless steels with less expensive ferritic stainless steels for the production of components such as bipolar plates in proton exchange membrane water electrolyzers. Full article

Composite bipolar plates with excellent performance play a crucial role in improving the overall performance of proton-exchange-membrane fuel cells. However, for graphite/resin composite bipolar plates, their electrical conductivity and mechanical properties are often too complex to meet the needs of users at the same time. Although nanoconductive fillers can alleviate this problem, the performance improvement for composite bipolar plates is often limited due to problems such as agglomeration. In this study, a uniformly dispersed multi-walled carbon nanotube network was prepared by in situ vapor deposition on the surface and pores of expanded graphite, which effectively avoided the problem of agglomeration and effectively improved the various properties of the composite BPs through the synergistic effect with graphite. With the addition of 2% in situ deposited carbon nanotubes, the modified composite bipolar plate has the best conductivity (334.53 S/cm) and flexural strength (50.24 MPa), and all the properties can meet the DOE requirements in 2025. Using the in situ deposition of carbon nanotubes to modify composite bipolar plates is a feasible route because it can result in multi-walled carbon nanotubes in large quantities and avoid the agglomeration phenomenon caused by adding nanofillers. It can also significantly improve the performance of composite bipolar plates, achieving the high performance of composite bipolar plates at a lower cost. Full article

Stainless steel, which is used in metallic bipolar plates, is generally known to have excellent corrosion resistance, which is achieved by forming oxide films. However, localized corrosion occurs when the oxide films are destroyed by pH and chloride ions. Particularly, since the operating condition of polymer electrolyte membrane fuel cells (PEMFCs) is strongly acidic, the reduced stability of the oxide films leads to the corrosion of the stainless steel. In this research, the electrochemical characteristics of 304L and 316L stainless steels were investigated in an accelerating solution that simulated the cathode condition of PEMFCs with chloride concentrations. Results under all experimental conditions showed that the corrosion current density of 304L stainless steel was at least four times higher than that of 316L stainless steel. Maximum damage depth was measured at 6.136 μm and 9.192 μm for 304L stainless steel and 3.403 μm and 5.631 μm for 316L stainless steel for chloride concentrations of 0 and 1000 ppm, respectively. Furthermore, 304L and 316L stainless steels were found to have uniform and localized corrosion, respectively. The differences in the electrochemical characteristics of 304L and 316L stainless steel are considered to be due to the molybdenum contained in the chemical composition of 316L stainless steel. Full article
