In the electric vehicle wireless power transmission system, the high-frequency alternating magnetic field between the transmitter and receiver can have a certain impact on the health of living organisms and may even lead to lesions. In addition, metal foreign objects in an alternating magnetic field can cause their own heating or even cause fires due to the eddy current effect, so foreign object detection is an essential function in the wireless power transmission system of electric vehicles. In order to prevent metals and living organisms from entering the charging area and causing harm to the charging system and living organisms, this paper proposes a method for detecting living organisms and metal foreign objects. Firstly, the equivalent circuits for the detection systems of the living organism foreign objects and metal foreign objects are established, respectively, and the working theory of the detection system is analyzed by deriving equations. Secondly, the comb capacitor simulation model was constructed, and the comb capacitor electrode spacing, wire thickness, and capacitor spacing were designed based on the scale factor γ to explore the effects of the height and bottom area of the living organism’s foreign object on the comb capacitor. We constructed a simulation model of the detection coil and designed the inner diameter D, the number of turns N, and the wire spacing S of the detection coil according to the scale factor β. An arrayed detection coil and comb capacitor combination mode is proposed to realize the function of the simultaneous detection of metal and living organism foreign objects, and a compensation capacitor is introduced to keep the detection system in a resonant state. Lastly, a platform for foreign object detection experiments was set up to detect metal screws and beef chunks compared to the detection area without foreign objects. Metal screws entering the detection area cause a 20% voltage drop in the detection circuit resistor, and beef chunks entering the detection area cause a 30% voltage drop in the detection circuit resistor, so the detection method is effective in detecting both metals and living organisms. The feasibility of the combined mode of arrayed detection coils and comb capacitors was verified. Full article

This paper designs two DC-DC converter configurations integrated with solar PV renewable energy resource. Its focuses on comparing two converter topologies: the conventional boost converter and the switched capacitor boost converter. The Perturb and Observe (P&O), Incremental Conductance (INC), Genetic Algorithm (GA), and Particle Swarm Optimization (PSO) algorithms are employed to dynamically enhance the Maximum Power Point Tracking (MPPT) performance for both converters. The simulation results demonstrate that both converter topologies, when integrated with appropriate MPPT algorithms, can effectively harvest maximum power from the solar PV. However, the switched capacitor topology converter exhibits advantages in terms of current capabilities and voltage performance. In addition, combing the switched capacitor boost converter with the GA-MPPT algorithm improved the output voltage profile. The switched capacitor topology demonstrates distinct advantages by exhibiting enhanced current control, enabling improved handling of dynamic load changes and varying irradiance conditions. It shows voltage regulation, resulting in reduced output voltage fluctuations and enhanced stability, thereby optimizing energy extraction. The GA-MPPT simulation demonstrates a substantial increase in maximized output current for the switched capacitor boost configuration (70 A) when compared to the conventional type (10 A). The validation and implementation of the system models are carried out using MATLAB/Simulink. Full article

Microelectromechanical systems (MEMS) are nowadays widespread in the sensor market, with several different applications. New production techniques and ever smaller device geometries require a continuous investigation of potential failure mechanisms in such devices. This work presents an experimental on-chip setup to assess the geometry- and material-dependent strength of stoppers adopted to limit the deformation of movable parts, using an electrostatically actuated device. A series of comb-finger and parallel plate capacitors are used to provide a rather large stroke to a shuttle, connected to the anchors through flexible springs. Upon application of a varying voltage, failure of stoppers of variable size is observed and confirmed by post-mortem $\mathsf{\Delta }C–V$ curves. The results of the experimental campaign are collected to infer the stochastic property of the strength of polycrystalline, columnar silicon films. Full article

Hafnia-based ferroelectric (FE) thin films have received extensive attention in both academia and industry, benefitting from their outstanding scalability and excellent CMOS compatibility. Hafnia-based FE capacitors in particular have the potential to be used in dynamic random-access memory (DRAM) applications. Obtaining fine structure characterization at ultra-high spatial resolution is helpful for device performance optimization. Hence, sample preparation by the focused ion beam (FIB) system is an essential step, especially for in situ biasing experiments in a transmission electron microscope (TEM). In this work, we put forward three tips to improve the success rate of in situ biasing experiments: depositing a carbon protective layer to position the interface, welding the sample on the top of the Cu column of the TEM grid, and cutting the sample into a comb-like shape. By these means, in situ biasing of the FE capacitor was realized in TEM, and electric-field-induced tetragonal (t-) to monoclinic (m-) structure transitions in Hf_0.5Zr_0.5O₂ FE film were observed. The improvement of FIB sample preparation technology can greatly enhance the quality of in situ biasing TEM samples, improve the success rate, and extend from capacitor sample preparation to other types. Full article

Multilevel inverters have been widely used in various industrial applications such as renewable energy generation and electric vehicles. An improved circuit of symmetrical cascaded switched-capacitor multilevel inverter is proposed so that the reactive power is absorbed by its power supply instead of capacitors. Then, a special hybrid pulse width modulation strategy combing level-shifted pulse width modulation (LS-PWM) and phase-shifted pulse width modulation (PS-PWM) was developed for the inverter. With this modulation algorithm, the power between cascaded units is automatically balanced, and the voltage of the capacitor in each unit is also automatically balanced to the dc input voltage. In addition, the optimized capacitor voltage ripple makes it possible to use a smaller capacitor to produce a better output voltage waveform. Theoretical analysis, simulation and experimental results show that the equivalent switching frequency of the cascaded multilevel inverter is twice the original frequency so that the output voltage harmonics are only distributed near even multiples of the carrier frequency. Full article

Safety in human–machine cooperation is the current challenge in robotics. Safe human–robot interaction requires the development of sensors that detect human presence in the robot’s workspace. Detection of this presence should occur before the physical collision of the robot with the human. Human to robot proximity detection should be very fast, allowing machine elements deceleration to velocities safe for human–machine collision. The paper presents a new, low-cost design of distributed robotic skin, which allows real-time measurements of the human body parts proximity. The main advantages of the proposed solution are low cost of its implementation based on comb electrodes matrix and real-time operation due to fast and simple electronic design. The main contribution is the new idea of measuring the distance to human body parts by measuring the operating frequency of a rectangular signal generator, which depends on the capacity of the open capacitor. This capacitor is formed between the comb electrodes matrix and a reference plate located next to the matrix. The capacitance of the open capacitor changes if a human body part is in vicinity. The application of the developed device can be very wide. For example, in the field of cooperative robots, it can lead to the improvement of human–machine interfaces and increased safety of human–machine cooperation. The proposed construction can help to meet the increasing requirements for cooperative robots. Full article

The capacitance and rotor angle of a MEMS top-drive electrostatic rotary actuator do not have a linear relationship due to the non-ignorable fringe effect and low aspect ratio of the electrodes. Therefore, the position estimation is not as straightforward as that for a comb-drive linear actuator or a side-drive rotary actuator. The reason is that the capacitance is a nonlinear and periodic function of the rotor angle and is affected by the three-phase input voltages. Therefore, it cannot be approximated as a simple two-plate capacitor. Sensing the capacitance between a rotor and a stator is another challenge. The capacitance can be measured in the electrodes (stators), but the electrodes also have to perform actuation, so a method is needed to combine actuation and sensing. In this study, a nonlinear capacitance model was derived as a data-driven model that effectively represents the nonlinear capacitance with sufficient accuracy. To measure the capacitance accurately, the stator parts for actuation and those for sensing are separated. Using the nonlinear model and the capacitance measurement, an unscented Kalman filter was designed to mitigate the large estimation error due to the periodic nonlinearity. The proposed method shows stable and accurate estimation that cannot be achieved with a simple two-plate capacitor model. The proposed approach can be applied to a similar system with highly nonlinear capacitance. Full article

In this work, microelectromechanical systems (MEMS)-based directional acoustic sensors operating in an underwater environment are explored. The studied sensors consist of a free-standing single wing or two wings pivoted to a substrate. The sensors operate in a narrow frequency band determined by the resonant frequency of the mechanical structure. The electronic readout of the mechanical response is obtained using interdigitated comb finger capacitors attached to the wings. The characteristics of MEMS sensors immersed in silicone oil are simulated using finite element modeling. The performance of the sensors is evaluated both in air and underwater. For underwater testing and operation, the sensors are packaged in a housing containing silicone oil, which was specially developed to present near unity acoustic transmission. The measurements show that the resonant frequency of the sensors obtained in air shifts to a lower frequency when immersed in silicone oil, which is primarily due to the mass loading of the liquid. The peak sensitivity of the MEMS sensors is approximately 6 mV/Pa or −165 dB re 1 V/μPa, and the directional response shows a dipole pattern. The signal-to-noise ratio was found to be about 200 or 23 dB at 1 Pa incident sound pressure. The results show the potential of MEMS sensors to be used in underwater applications for sound source localization. Full article

Research, design, fabrication and results of various screen printed capacitive humidity sensors is presented in this paper. Two types of capacitive humidity sensors have been designed and fabricated via screen printing on recycled paper and cardboard, obtained from the regional paper and cardboard industry. As printing ink, commercially available silver nanoparticle-based conductive ink was used. A considerable amount of work has been devoted to the humidity measurement methods using paper as a dielectric material. Performances of different structures have been tested in a humidity chamber. Relative humidity in the chamber was varied in the range of 35%–80% relative humidity (RH) at a constant temperature of 23 °C. Parameters of interest were capacitance and conductance of each sensor material, as well as long term behaviour. Process reversibility has also been considered. The results obtained show a mainly logarithmic response of the paper sensors, with the only exception being cardboard-based sensors. Recycled paper-based sensors exhibit a change in value of three orders of magnitude, whereas cardboard-based sensors have a change in value of few 10s over the entire scope of relative humidity range (RH 35%–90%). Two different types of capacitor sensors have been investigated: lateral (comb) type sensors and modified, perforated flat plate type sensors. The objective of the present work was to identify the most important factors affecting the material performances with humidity, and to contribute to the development of a sensor system supported with a Radio Frequency Identification (RFID) chip directly on the material, for use in smart packaging applications. Therefore, the authors built a passive and a battery-supported wireless module based on SL900A smart sensory tag’s IC to achieve UHF-RFID functionality with data logging capability. Full article

The article offers a comparison of the sensitivities for vapour trace detection of Trinitrotoluene (TNT) explosives of two different sensor systems: a chemo-mechanical sensor based on chemically modified Atomic Force Microscope (AFM) cantilevers based on Micro Electro Mechanical System (MEMS) technology with optical detection (CMO), and a miniature system based on capacitive detection of chemically functionalized planar capacitors with interdigitated electrodes with a comb-like structure with electronic detection (CE). In both cases (either CMO or CE), the sensor surfaces are chemically functionalized with a layer of APhS (trimethoxyphenylsilane) molecules, which give the strongest sensor response for TNT. The construction and calibration of a vapour generator is also presented. The measurements of the sensor response to TNT are performed under equal conditions for both systems, and the results show that CE system with ultrasensitive electronics is far superior to optical detection using MEMS. Using CMO system, we can detect 300 molecules of TNT in 10⁺¹² molecules of N₂ carrier gas, whereas the CE system can detect three molecules of TNT in 10⁺¹² molecules of carrier N₂. Full article
