We report a 2.8 μm all-fiber high-power and high-energy gain-switched Er³⁺:ZBLAN laser based on dielectric fiber mirror and fiber-tip protection. The fiber pigtail mirror, specifically designed for dichroic operation (i.e., anti-reflection at 976 nm pump wavelength and high-reflection around 2.8 μm laser wavelength), shows high damage density of >10 MW/cm². An anti-reflection protective film is coated on the input tip of Er³⁺:ZBLAN fiber and an AlF₃ endcap is spliced to the output tip of Er³⁺:ZBLAN fiber for mitigating the fiber-tip photodegradation and high-power catastrophic failure at 2.8 μm. The compact all-fiber cavity is formed by efficiently connecting the Er³⁺:ZBLAN fiber with dielectric fiber mirror using the standard FC/PC fiber adaptor. When the 976 nm pump operates in pulsed regime, the all-fiber mid-infrared gain-switched laser can be attained with two states of single-pulse and pulse-burst output. The extracted maximum pulse energy is 4.8 μJ in the single-pulse state, and the shortest pulse width is 426 ns. The pulse-burst mode can generate a maximum average power of 5.291 W and burst energy of 264.55 μJ. This work may offer a promising way to realize the low-cost, all-fiber, high-power and high-energy gain-switched laser at MIR wavelengths. Full article

Mid-infrared optics require optical coatings composed of high- and low-refractive-index dielectric layers for the design of optical mirrors, filters, and anti-reflection coatings. However, there are not many technologies for depositing a material with a refractive index of less than 2 and a low loss in the mid-infrared region. Here, we present a unique deposition method of crosslinked polyethylene thin film for mid-IR optical filter design. Polyethylene has a refractive index of 1.52 in the mid-infrared region and a small number of absorption peaks, so it is useful for making optical filters in the mid-infrared region. Only 1 keV of energy is required to crosslink the entire film by irradiating an electron beam while depositing polyethylene. In addition, crosslinked polyethylene thin film has high mechanical strength, so there is no cracking or peeling when used with germanium. This allows for the use of crosslinked polyethylene as a low refractive index for mid-infrared optical coating. Full article

We present a novel terahertz (THz) Fabry–Perot (FP) microcavity biosensor that uses a porous polytetrafluoroethylene (PTFE) supporting film to improve microorganism detection. The THz FP microcavity confines and enhances fields in the middle of the cavity, where the target microbial film is placed with the aid of a PTFE film having a dielectric constant close to unity in the THz range. The resonant frequency shift increased linearly with increasing amount of yeasts, without showing saturation behavior under our experimental conditions. These results agree well with finite-difference time-domain (FDTD) simulations. The sensor’s sensitivity was 11.7 GHz/μm, close to the optimal condition of 12.5 GHz/μm, when yeast was placed at the cavity’s center, but no frequency shift was observed when the yeast was coated on the mirror side. We derived an explicit relation for the frequency shift as a function of the index, amount, and location of the substances that is consistent with the electric field distribution across the cavity. We also produced THz transmission images of yeast-coated PTFE, mapping the frequency shift of the FP resonance and revealing the spatial distribution of yeast. Full article

This paper presents the fabrication and characterization of a biaxial MEMS (MicroElectroMechanical System) scanner based on PZT (Lead Zirconate Titanate) which incorporates a low-absorption dielectric multilayer coating, i.e., a Bragg reflector. These 2 mm square MEMS mirrors, developed on 8-inch silicon wafers using VLSI (Very Large Scale Integration) technology are intended for long-range (>100 m) LIDAR (LIght Detection And Ranging) applications using a 2 W (average power) pulsed laser at 1550 nm. For this laser power, the use of a standard metal reflector leads to damaging overheating. To solve this problem, we have developed and optimised a physical sputtering (PVD) Bragg reflector deposition process compatible with our sol-gel piezoelectric motor. Experimental absorption measurements, performed at 1550 nm and show up to 24 times lower incident power absorption than the best metallic reflective coating (Au). Furthermore, we validated that the characteristics of the PZT, as well as the performance of the Bragg mirrors in terms of optical scanning angles, were identical to those of the Au reflector. These results open up the possibility of increasing the laser power beyond 2W for LIDAR applications or other applications requiring high optical power. Finally, a packaged 2D scanner was integrated into a LIDAR system and three-dimensional point cloud images were obtained, demonstrating the scanning stability and operability of these 2D MEMS mirrors. Full article

Ambient humidity is an important factor to consider when maintaining dielectric films’ component performance. Herein, humidity-influenced experiments were conducted on complex spectral dielectric films based on SiO₂ and K9 substrates. Firstly, complex spectral dielectric films’ spectral and surface stresses in different humidity environments were measured. Subsequently, laser-induced damage threshold measurements were carried out on these components. The experimental results indicate that the environmental humidity will induce the evolution of the internal structure of the dielectric films on the mirror, resulting in the deformation of the coating surface and a slight shift of the reflection spectrum. At the same time, the environmental humidity also greatly influences the anti-laser damage performance of the dielectric film mirror. Dielectric films based on SiO₂ have excellent damage resistance in high-humidity environments. Conversely, K9-based dielectric films have better damage resistance in low-humidity environments. Full article

The lifetime of mirrors in outdoor conditions is crucial in the correct operation of any concentrating solar power (CSP) installation. In this work, the corrosion behavior of two types of metallized surfaces was studied. The first was made of a flexible polymer having a deposited reflective silver metallic film. The second was made of the same surface type with a dielectric SiO₂ protection coating by an atmospheric pressure plasma jet. Polycarbonate sheets were used as substrates on which metallic silver was deposited by the Dynamic Chemical Deposit technique. This electroless technique allowed producing the mirror finishing under environmental conditions by sequentially spraying; as aerosols projected towards the substrate surface, the activation and reducing-oxidizing solutions with rinsing after each one. The silver coatings were about 100 nm thick. Environmental and accelerated weathering degradation and salt and sulfide fogs were carried out. XPS analyses show that the corrosion products formed were Ag₂S, AgCl, and Ag₂O. It was observed that the tarnishing was initiated locally by the formation of Ag₂S columns as eruptions on the surface. Subsequently, the ions diffused through the protective layer and into the silver reflective layer, chemically reacting with the silver. The main atmospheric agents were H₂S, chloride particles, and HCl. High reflectance was initially obtained of about 95%. The obtained results suggest mechanisms for the degradation of exposed silver surfaces to moisturized atmospheres with corrosive compounds. Full article

The recent severe acute respiratory syndrome coronavirus 2 (SARS-CoV-2) infection has posed a great challenge for the development of ultra-fast methods for virus identification based on sensor principles. We created a structure modeling surface and size of the SARS-CoV-2 virus and used it in comparison with the standard antigen SARS-CoV-2—the receptor-binding domain (RBD) of the S-protein of the envelope of the SARS-CoV-2 virus from the Wuhan strain—for the development of detection of coronaviruses using a DNA-modified, surface-enhanced Raman scattering (SERS)-based aptasensor in sandwich mode: a primary aptamer attached to the plasmonic surface—RBD-covered Ag nanoparticle—the Cy3-labeled secondary aptamer. Fabricated novel hybrid plasmonic structures based on “Ag mirror-SiO₂-nanostructured Ag” demonstrate sensitivity for the detection of investigated analytes due to the combination of localized surface plasmons in nanostructured silver surface and the gap surface plasmons in a thin dielectric layer of SiO₂ between silver layers. A specific SERS signal has been obtained from SERS-active compounds with RBD-specific DNA aptamers that selectively bind to the S protein of synthetic virion (dissociation constants of DNA-aptamer complexes with protein in the range of 10 nM). The purpose of the study is to systematically analyze the combination of components in an aptamer-based sandwich system. A developed virus size simulating silver particles adsorbed on an aptamer-coated sensor provided a signal different from free RBD. The data obtained are consistent with the theory of signal amplification depending on the distance of the active compound from the amplifying surface and the nature of such a compound. The ability to detect the target virus due to specific interaction with such DNA is quantitatively controlled by the degree of the quenching SERS signal from the labeled compound. Developed indicator sandwich-type systems demonstrate high stability. Such a platform does not require special permissions to work with viruses. Therefore, our approach creates the promising basis for fostering the practical application of ultra-fast, amplification-free methods for detecting coronaviruses based on SARS-CoV-2. Full article

In this paper, we explore the behavior of several optimization methods for reducing coating Brownian noise in the mirrors of gravitational wave detectors. We will refer to cryogenic operating temperatures, where the low refractive index material has mechanical losses higher than those of the high refractive index material. This situation is the exact opposite of that which occurs at room temperature, which is already widely known. The optimal design of the dielectric mirror (without a priori assumptions on thicknesses) can be obtained through the combined multi-objective optimization of transmittance and thermal noise. In the following, we apply several multi-objective meta-heuristics to compute the Pareto front related to the optimization problem of dielectric mirror thicknesses made of two materials (binary coatings). This approach gives us more certainty about the structure of the final result. We find strong evidence that all meta-heuristics converge to the same solution. The final result can be interpreted with simple physical considerations, providing useful rules to simplify the thicknesses of the optimization algorithm. Full article

The chirped pulse amplification technique has enabled the generation of pulses of a few femtosecond duration with peak powers multi-Tera and Peta–Watt in the near infrared. Its implementation to realize even shorter pulse duration, higher energy, and higher repetition rate laser systems relies on overcoming the limitations imposed by laser damage of critical components. In particular, the laser damage of coatings in the amplifiers and in post-compression optics have become a bottleneck. The robustness of optical coatings is typically evaluated numerically through steady-state simulations of electric field enhancement in multilayer stacks. However, this approach cannot capture crucial characteristics of femtosecond laser induced damage (LID), as it only considers the geometry of the multilayer stack and the optical properties of the materials composing the stack. This approach neglects that in the interaction of an ultrashort pulse and the materials there is plasma generation and associated material modifications. Here, we present a numerical approach to estimate the LID threshold of dielectric multilayer coatings based on strong field electronic dynamics. In this dynamic scheme, the electric field propagation, photoionization, impact ionization, and electron heating are incorporated through a finite-difference time-domain algorithm. We applied our method to simulate the LID threshold of bulk fused silica, and of multilayer dielectric mirrors and gratings. The results are then compared with experimental measurements. The salient aspects of our model, such as the implementation of the Keldysh photoionization model, the impact ionization model, the electron collision model for ‘low’-temperature, dense plasma, and the LID threshold criterion for few-cycle pulses are discussed. Full article

Highly reflective metal coatings are essential for manufacturing reflecting telescope mirrors to achieve the highest reflectivity with broad spectral bandwidth. Among metallic materials, enhanced silver-based coatings can provide higher reflectivity in the 400–500 nm spectral range to better performance from visible to near IR. Moreover, over-coating a dielectric protective layer on the mirror’s front side attains additional hardness and oxidation stability. In this paper, we study a combination of thermal and electron beam evaporation as a technology to form protected enhanced high reflective Ag coatings. A newly designed multiplayer film can pass ASTM 5B adhesive performance testing and give sulfurization inhibition. The average specular reflectivity for the enhancement coating is about 98% in wavelengths across the spectral range from 400–1000 nm. This innovation has been demonstrated on a Newtonian type telescope, with storage in an ambiance humidity H = 60–85%, and temperature T = 10–35 °C, for more than six months without degradation in coating performance. Full article

In this paper, an analytical solution to the problem of optimal dielectric coating design of mirrors for gravitational wave detectors is found. The technique used to solve this problem is based on Herpin’s equivalent layers, which provide a simple, constructive, and analytical solution. The performance of the Herpin-type design exceeds that of the periodic design and is almost equal to the performance of the numerical, non-constructive optimized design obtained by brute force. Note that the existence of explicit analytic constructive solutions of a constrained optimization problem is not guaranteed in general, when such a solution is found, we speak of turbo optimal solutions. Full article

The laser-induced damage threshold (LIDT) of optical components is one of the major constraints in developing high-power ultrafast laser systems. Multi-layer dielectric (MLD) coatings-based optical components are key parts of high-power laser systems because of their high damage resistance. Therefore, understanding and characterizing the laser-induced damage of MLD coatings are of paramount importance for developing ultrahigh-intensity laser systems. In this article, we overview the possible femtosecond laser damage mechanisms through damage morphologies in various MLD optical coatings tested in our facility. To evaluate the major contributions to the coating failure, different LIDT test methods (R-on-1, ISO S-on-1 and Raster Scan) were carried out for a high reflective hybrid Ta₂O₅/HfO₂/SiO₂ MLD mirror coating at a pulse duration of 37 fs. Different LIDT test methods were compared due to the fact that each test method exposes the different underlying damage mechanisms. For instance, the ISO S-on-1 test at a higher number of laser pulses can bring out the fatigue effects, whereas the Raster Scan method can reveal the non-uniform defect clusters in the optical coating. The measured LIDT values on the sample surface for the tested coating in three test methods are 1.1 J/cm² (R-on-1), 0.9 J/cm² (100k-on-1) and 0.6 J/cm² (Raster Scan) at an angle of incidence of 45 deg. The presented results reveal that the performance of the tested sample is limited by coating defects rather than fatigue effects. Hence, the Raster Scan method is found to be most accurate for the tested coating in evaluating the damage threshold for practical applications. Importantly, this study demonstrates that the testing of different LIDT test protocols is necessary in femtosecond regime to assess the key mechanisms to the coating failure. Full article

Integration of metamaterial and nonvolatile memory devices with tunable characteristics is an enthusing area of research. Designing a unique nanoscale prototype to achieve a metasurface with reliable resistive switching properties is an elusive goal. We demonstrate a method to exploit the advantages of a phase-change material (PCM) as a metamaterial light absorber and a nanoscale data storage device. We designed and simulated a metamaterial perfect absorber (MPA) that can be reconfigured by adjusting the visible light properties of a chalcogenide-based PCM. The suggested perfect absorber is based on a Ge₂Sb₂Te₅ (GST) film, and is tuned between two distinct states by heat treatment. Furthermore, we fabricated and characterized a resistive switching memory (ReRAM) device with the same features. The MPA/ReRAM device with a conventional metal/dielectric/metal structure (Ag/GST/Al₂O₃/Pt) consisted of arrays of Ag squares patterned on a GST thin film and an alumina-coated Pt mirror on a glass substrate. Based on the numerical data, amorphous GST showed perfect absorbance in the visible spectrum, whereas, crystalline GST showed broadband perfect absorbance. The fabricated ReRAM device exhibited uniform, bidirectional, and programmable memory characteristics with a high ON/OFF ratio for nonvolatile memory applications. The elucidated origin of the bipolar resistive switching behavior is assigned to the formation and rupture of conductive filaments. Full article

This study aims to determine the necessity of applying a mirror coating on the side of a truncated solid dielectric CPC (compound parabolic concentrator) since ray tracing analysis has revealed that part of the incoming rays do not undergo total internal reflection, even within the half acceptance angle of the CPC. An experiment was designed and conducted indoors and outdoors to study the effect of mirror coating on the optical performance of a solid dielectric CPC. Ray tracing was also employed for the detailed analysis and its results are compared with the measurements. Based on these, a concept of partial coating is proposed and verified through simulation. The results show that a partly coated solid dielectric CPC may have a better optical efficiency than a solid CPC without coating for a certain range of incidence angles. Full article
