Industrial ball milling circuits usually include hydrocyclones in a closed configuration to achieve a specified grinding size. Although hydrocyclones are relatively simple to operate, their classification performance is generally low, leading to significant fines recirculation within the circuit, consequently overgrinding the product. Conversely, high-frequency screening potentially shows a relatively higher separation efficiency, as the entrainment of fines to the coarse product is significantly reduced. The present work compares the performance of hydrocyclones—HC and high-frequency screens—HFS based on four surveys conducted in Nexa’s Vazante Zinc ore industrial grinding circuit in Vazante, Brazil, which processes zinc silicate ore. The comparisons included the partition of solids, water split, and particle size distributions. Whiten’s partition curve model was adopted to obtain the selected performance parameters through mass balancing the experimental data. The industrial surveys comprised three different size separation configurations, i.e., HC-Only, HFS-Only, and a combined HC-HFS setup. In all cases, the assessments consistently indicated higher separation performances with HFS compared to the HC operation. The final product associated with the HC+HFS configuration showed a narrower size distribution around the grinding size. Full article

This paper presents a modular hardware control system tailored for industrial applications. The system presented is designed with electrical protection, guaranteeing the reliable operation of its modules in the presence of various field noises and external disturbances. The modular architecture comprises a principal module (mP) and dedicated expansion modules (mEXs). The principal module serves as the network administrator and facilitates interaction with production and control processes. The mEXs are equipped with sensors, conditioning circuits, analog-to-digital converters, and digital signal processing capabilities. The mEX’s primary function is to acquire local processing field signals and ensure their reliable transmission to the mP. Two specific mEXs were developed for industrial environments: an electrical signal expansion module (mSE) and the vibration signals expansion module (mSV). The EtherCAT protocol serves as a means of communication between the modules, fostering deterministic and real-time interactions while also simplifying the integration and replacement of modules within the modular architecture. The proposed system incorporates local and distributed processing in which data acquisition, processing, and data analysis are carried out closer to where data are generated. Locally processing the acquired data close to the production in the mEX increases the mP availability and network reliability. For the local processing, feature extraction algorithms were developed on the mEX based on a Fast Fourier Transform (FFT) algorithm and a curve-fitting algorithm that accurately represents a given FFT curve by significantly reducing the amount of data that needs to be transmitted over the mP. The proposed system offers a promising solution to use computational intelligence methodologies and meet the growing need for a modular industrial control system with reliable local data processing to reach a smart industry. The case study of acquiring and processing vibration signals from a real cement ball mill showed a good capacity for processing data and reducing the amount of data. Full article

This paper compares two deconvolution methodologies used to estimate residence time distributions (RTD) in industrial closed-circuit ball mills. Parametric and non-parametric deconvolution techniques were evaluated. Both techniques allowed for direct RTD estimates from inlet and outlet tracer measurements in the mills, with no need for mass balances nor assumptions to correct the effect of the tracer recirculation in the grinding circuits. Measurements of inlet and outlet concentrations were conducted by radioactive solid tracers and on-stream detectors. The parametric deconvolution was applied assuming the N-perfectly-mixed-reactors-in-series model, whereas the non-parametric deconvolution consisted of a constrained least squares estimation subject to non-negativity. The shapes of the estimated RTDs were consistent between these methodologies, showing mound-shaped distributions in all cases. From the parametric approach, mixing regimes described by 2–4 perfect mixers in series were observed, which indicated significant differences regarding perfect mixing. The mean (τ_mean) and median (τ₅₀) residence times were more consistent with the RTD shapes when applying the parametric deconvolution. The non-parametric approach was more sensitive to noise, a disadvantage leading to mean residence times significantly higher than the median, and less consistent with the RTD locations. From the comparisons, the estimation strategies proved to be applicable in industrial closed-circuit ball mills. The parametric deconvolution led to better overall performances for τ₅₀ = 1.7–8.3 min, given a suitable model structure for the RTDs. Full article
