The stability of thermal barrier coating (TBC) materials during service is a prerequisite for the normal operation of aircraft engines. The high-temperature corrosion of CaO–MgO–Al₂O₃–SiO₂ (CMAS) is an important factor that affects the stability of TBCs on turbine blades and causes premature engine failure. For traditional 6-8 YSZ, at temperatures of more than 1200 °C, the thermal insulation performance is significantly reduced, which makes it necessary to find new, alternative materials. La₂Zr₂O₇ has good thermal physical properties; the addition of Ce⁴⁺ improves its mechanical properties, while adding Gd₂O₃ affects its corrosion resistance. Herein, high-temperature corrosion studies of (La_1−xGd_x)₂(Zr_0.7Ce_0.3)₂O₇ (L-GZC) (x = 0, 0.3, 0.5, 0.7) ceramic TBC were conducted using CMAS glass at 1250 °C. The results indicate that CMAS rapidly dissolves L-GZC and separates the (La, Gd)₈Ca₂(SiO₄)₆O₂ apatite phase, ZrO₂, and other crystalline phases. These products form a crystalline layer at the contact boundary, which can inhibit further CMAS reactions. Among the coatings examined, the L-GZC ceramic (x = 0.7) exhibits better corrosion resistance, and the penetration depth is <200 μm after high-temperature corrosion at 1250 °C for 5, 10, and 20 h. The failure mechanism and potential risk of CMAS were also analyzed and discussed. The L-GZC ceramic material has good thermal corrosion resistance and is expected to replace the traditional YSZ to better meet the high-temperature working requirements of gas turbines and aircraft engines. Full article

The main purpose of this work is to suppress the rate of thermal and oxidative corrosion of copper substrates using double-ceramic-layer thermal barrier coatings (TBCs). Herein, the orthogonal spray experiment was employed to optimize the spraying parameters for TBCs consisting of Cu/NiCoCrAlY/8YSZ/(Y_0.5Gd_0.5)TaO₄. The thermal cycling and average mass loss rate of TBCs prepared by atmospheric plasma spraying (APS) with optimum spraying parameters correspond to 20 cycles and 0.56‰, respectively. The thermal conductivity (0.39 W·m⁻¹·K⁻¹ at 900 °C) of (Y_0.5Gd_0.5)TaO₄ is 71.68% and 52.7% lower than that of (Y_0.5Gd_0.5)TaO₄ bulk and 8YSZ, respectively. Meanwhile, the bond strength increased from 8.86 MPa to 14.03 MPa as the heat treatment time increased from 0 h to 24 h, benefiting from the heat treatment to release the residual stresses inside the coating. Additionally, the hardness increased from 5.88 ± 0.56 GPa to 7.9 ± 0.64 GPa as the heat treatment temperature increased from room temperature to 1000 °C, resulting from the healing of pores and increased densification. Lastly, crack growth driven by thermal stress mismatch accumulated during thermal cycling is the main cause of coating failure. The above results demonstrated that 8YSZ/(Y_0.5Gd_0.5)TaO₄ can increase the service span of copper substrate. Full article

Calcium–magnesium–alumina–silicate (CMAS), as an environmental deposit, deposits on engine components and causes serious damage to traditional thermal barrier coatings (TBCs) at high temperatures. The rare-earth silicate apatite dense reaction layer is regarded as a promising strategy to prevent TBCs from molten CMAS penetration and corrosion. The interactions between the Gd₂O₃ ceramic and CMAS are discussed at various temperatures and times in the study. The main reaction products are gadolinium silicate apatite (Ca₂Gd₈(SiO₄)₆O₂, Gd-apatite) and melilite phases. Within the first 15 min of interaction, a thin, continuous and dense reaction layer (DRL) consisting of Gd-apatite comes to form, and it thickens with increasing exposure temperature and time. The thickness of the DRL is ~0.8 μm after 15 min of the reaction at 1250 °C and it slowly increases to ~9.1 μm after a duration of 24 h at 1400 °C. This is attributed to CMAS infiltration along the grain boundaries of the Gd-apatite phases in the DRL. The growing rates of the Gd-apatite DRL decrease with reaction time and are significantly influenced by the temperature and the ability of the DRL to inhibit CMAS infiltration. Full article

The distribution of voids in ceramic topcoats (TC) and the micro-roughness of metallic bond coat (BC) interfaces are important for the structure design and coating life of thermal barrier coating (TBC) systems. In this study, finite elemental (FE) models were built by considering those two structural factors to investigate their influence on the stress distribution in TBCs in quenching processes under thermal shock conditions. According to the simulation analyses, the function of the voids in TCs includes the dilution effect of the stress concentration at the macro-scale, the releasing effect of the tensile stress along the vertical direction above the TC peak, and the “stress trapping” effect bringing higher stress at the horizontal tips of the voids on the micro-scale. The micro-roughness of the TC/BC interface did not have much effect on the stress values in the TC, aside from at the TC peak, but had a significant influence on the stress value along the interface due to the “stress trapping” effect. The TBC samples that were experimentally tested under water-cooling thermal shock conditions were also analyzed in this paper to verify the modelling results. Full article

In this paper, the ceramic coating of thermal barrier coatings (TBCs) was prepared on the surface of the tube specimens by Electron Beam Physical Vapor Deposition (EB-PVD) process. Subsequently, a service simulation was conducted using a simulation device to analyze the failure behavior of the TBCs. The effects of high-temperature sintering and CaO-MgO-Al₂O₃-SiO₂ (CMAS) corrosion on the microstructural evolution, phase structural changes, and insulation performance of the thermal barrier coatings were investigated. The results indicated that with increasing high-temperature sintering time, the “feather” structures at the boundaries of the columnar grains evolve into the “tentacle” structure that facilitates the fusion of adjacent columnar grains, resulting in increased grain diameter and wider gaps. No transformation from t’-ZrO₂ to the monoclinic phase m-ZrO₂ occurred during the high-temperature sintering process. Over time, CMAS wets the coating surface and infiltrates the interior of the coating, causing corrosion to the Yttria-stabilised zirconia (YSZ) and accelerating sintering. A new phase, ZrSiO₄, was formed after corrosion without inducing the transition. Full article

The Ti-6Al-4V alloy is widely utilized in the aerospace industry for applications such as turbine blades, where it is valued for its mechanical strength at high temperatures, low specific gravity, and resistance to corrosion and oxidation. This alloy provides crucial protection against oxidation and thermal damage. A thermal barrier coating (TBC) typically consists of a metallic substrate, a bond coating (BC), a thermally grown oxide (TGO), and a topcoat ceramic (TC). This study aimed to investigate laser parameters for forming a TBC with a NiCrAlY bond coating and a zirconia ceramic topcoat, which contains 16.0% equimolar yttria and niobia. The coatings were initially deposited in powder form and then irradiated using a CO₂ laser. The parameters of laser power and beam scanning speed were evaluated using scanning electron microscopy and X-ray diffraction. The results indicated that the optimal laser scanning speed and power for achieving the best metallurgical bonding between the substrate/BC and the BC-TGO/TC layers were 70 mm/s at 100 W and 550 mm/s at 70 W, respectively. Laser-based layer formation has proven to be a promising technique for the application of TBC. Full article

A jet flame occurs when the release of flammable gas or liquid ignites, resulting in a long, intense, and highly directional flame. This type of fire is commonly associated with industrial incidents involving pipelines, storage tanks, and other pressurized equipment. Jet fires are a significant concern in the oil and gas industry due to the handling and processing of large volumes of flammable hydrocarbons under pressure. The new computational method presented here includes several aspects of hydrogen jet flame accidents and their mitigation: the CFD simulation of a hydrogen jet flame using the HyRAM code and Fire Dynamics Simulator (FDS) software 5.0 using a large eddy simulation (LES) turbulence model; the calculation of the gaseous mixture’s thermo-physical properties using the GASEQ thermochemical code; the calculation of convective and radiative heat fluxes using empirical correlation; and a heat transfer simulation on the pipe thermal barrier coating (TBC) using COMSOL Multiphysics software 4.2a during the heating phase. This method developed for the ceramic blanket was validated successfully against the previous experimental results obtained by Gravit et al. It was shown that a jet fire’s maximum temperature obtained using FDS software was similar to that obtained using GASEQ thermochemical software 0.79 and HyRAM software. The TBC’s surface temperature reached 1945 °C. The stainless steel’s maximal temperature reached 165.5 °C. There was a slight decrease in UTS at this temperature. Full article

In this study, Gd₂O₃ and Yb₂O₃ co-doped YSZ (GYYSZ) ceramic coatings were prepared via atmospheric plasma spraying (APS). The GYYSZ ceramic coatings were subjected to heat treatment at different temperatures for 5 h to analyze their high-temperature phase stability and sintering resistance. The thermophysical properties of GYYSZ, YSZ, and composite coatings were compared. Three types of thermal barrier coatings (TBCs) were designed: GYYSZ (TBC-1), YSZ/GYYSZ (TBC-2), and YSZ/Composite/GYYSZ (TBC-3). The failure mechanisms of these three TBCs were investigated. The results indicate that both the powder and the sprayed GYYSZ primarily maintain a homogeneous cubic phase c-ZrO₂, remaining stable at 1500 °C after annealing. The sintering and densification of the coatings are influenced by the annealing temperature; higher temperatures lead to faster sintering rates. At 1500 °C, the grain size and porosity of GYYSZ are 4.66 μm and 9.9%, respectively. At 1000 °C, the thermal conductivity of GYYSZ is 1.35 W·m⁻¹ K⁻¹, which is 44% lower than that of YSZ. The thermal conductivity of the composite material remains between 1.79 W·m⁻¹ K⁻¹ and 1.99 W·m⁻¹ K⁻¹ from room temperature to 1000 °C, positioned between GYYSZ and YSZ. In the TBC thermal shock water quenching experiment, TBC-3 demonstrated an exceptionally long thermal shock lifetime of 246.3 cycles, which is 5.8 times that of TBC-1 and 1.8 times that of TBC-2. The gradient coating structure effectively reduces the thermal mismatch stress between layers, while the dense surface microcracks provide a certain toughening effect. Failure analysis of the TBC reveals that TBC-3 exhibits a mixed failure mode characterized by both spallation and localized peeling. The ultimate failure was attributed to the propagation of transverse cracks during the final stage of water quenching, which led to the eventual spallation of the ceramic blocks. Full article

Grit particles remaining on the substrate surface after grit blasting are generally considered to impair the thermal performance of thermal barrier coatings (TBCs). However, the specific mechanisms by which these particles degrade the multilayer structure of TBCs during thermal cycling have not yet been fully elucidated. In this study, the superalloy substrate was grit-blasted using various processing parameters, followed by the deposition of thermal barrier coatings (TBCs) consisting of a metallic bond coat (BC) and a ceramic top coat (TC). After thermal shock tests, local thinning or discontinuities in the thermally grown oxide (TGO) layer were observed in TBCs where large grit particles were embedded at the BC/substrate interface. Moreover, cracks originated at the concave positions of the TGO layer and propagated vertically towards BC; these cracks may be associated with additional stress imposed by the foreign grit particles during thermal cycling. At the BC/substrate interface, crack origins were observed in the vicinity of large grit particles (~50 μm). Full article

Thermal barrier coatings (TBCs) are effective protective and insulative coatings on hot section components of turbine engines. The quality and subsequent performance of the TBCs are strongly dependent on the adhesion between the coating and the metal substrate. The adhesion strength of TBCs varies depending on the substrate materials and coating, the coating technique used, the coating application parameters, the substrate surface treatments, and environmental conditions. Therefore, the roughness of the substrate surface has a significant effect on the performance of the TBC system. In this work, the roughness and microstructure of the 7YSZ (7 wt.% yttria-stabilised zirconia) top coat under different bond coat roughness treatments were studied. The purpose of this paper was to investigate the influence of the roughness of the bond coat on the adhesion of 7YSZ TBCs prepared by the electron beam–physical vapour deposition (EB-PVD) process. The VPA (vapour phase aluminium) bond coat was deposited on Inconel 718 nickel superalloy substrate using the above-the-pack technique. The ceramic top coat was applied to the bond coat using the EB-PVD process. The dependence between the TBC coating roughness and the bond coat roughness was determined. Adhesion strength measurements were performed according to the ASTM C 633 standard test method. The highest adhesion value observed in the tensile adhesion tests was 105 MPa. However, it was not determined whether the surface roughness of the bond coat affects the adhesion of the 7YSZ top coat. Full article

Higher operating temperatures for gas turbine engines require highly durable thermal barrier coatings (TBCs) with improved insulation properties. A suspension plasma spray process (SPS) had been developed for the deposition of columnar-structured TBCs. SPS columnar TBCs are normally achieved at a short standoff distance (50.0 mm–75.0 mm), which is not practical when coating complex-shaped engine hardware since the plasma torch may collide with the components being sprayed. Therefore, it is critical to develop SPS columnar TBCs at longer standoff distances. In this work, a commercially available pressure-based suspension delivery system was used to deliver the suspension to the plasma jet, and a high-enthalpy TriplexPro-210 plasma torch was used for the SPS coating deposition. Suspension injection pressure was optimized to maximize the number of droplets injected into the hot plasma core and achieving the best particle-melting states and deposition efficiency. The highest deposition efficiency of 51% was achieved at 0.34 MPa injection pressure with a suspension flow rate of 31.0 g/min. With the optimized process parameters, 1000 μm thick columnar-structured SPS 8 wt% Y₂O₃-stabilized ZrO₂ (8YSZ) TBCs were successfully developed at a standoff distance of 100.0 mm. The SPS TBCs have a columnar width between 100 μm and 300 μm with a porosity of ~22%. Furnace cycling tests at 1125 °C showed the SPS columnar TBCs had an average life of 1012 cycles, which is ~2.5 times that of reference air-plasma-sprayed dense vertically cracked TBCs with the same coating thickness. The superior durability of the SPS columnar TBCs can be attributed to the high-strain-tolerant microstructure. SEM cross-section characterization indicated the failure of the SPS TBCs occurred at the ceramic top coat and thermally grown oxide (TGO) interface. Full article

Oxidation of the bond coat during turbine operation leads to additional stresses in the thermal barrier coating (TBC) system that promotes spalling of the thermal insulation. Therefore, the oxidation behavior of a TBC system plays an important role in the thermal cycling of a TBC system. To delay the loss of thermal insulation, research has typically focused for a long time on the composition and microstructure of the ceramic topcoats and metallic bond coats. More recently, heat treatment for the diffusion annealing of the bond coat has also become a focus of research. Several studies have shown that pre-oxidation of the bond coat prior to the application of the ceramic topcoat slows down the subsequent oxidation of the bond coat in service. The improved thermal cyclability has been demonstrated in studies for systems with atmospheric plasma-sprayed (APS), suspension plasma-sprayed (SPS) or electron beam physical vapor deposition (EB-PVD) top coatings. However, no study has directly compared the effects of pre-oxidation on different topcoats. Therefore, this study compared the effect of pre-oxidation on APS and SPS coatings with the same bond coat. For both topcoats, pre-oxidation slowed the subsequent TGO growth and thus increased the lifetime of the coatings. The improvement in lifetime was particularly pronounced for the systems with an SPS topcoat. Overall, the lifetime of the coatings with an APS topcoat was higher as the critical energy release rate within the coating was not exceeded in these coatings. Full article

HfO₂ has become a promising thermal barrier coating material due to its similarity in structure and chemical properties with ZrO₂ and its higher phase structure transition temperature. However, the fracture toughness of HfO₂ is not ideal, greatly limiting its application. In this report, we find a special sandwich structure of ceramics, comprising a cubic (C) phase /monoclinic (M) phase/cubic (C) phase. The microstructural evolution and mechanical properties of these ceramics were investigated under annealing at 1500 °C. The results indicate that, with an increase in annealing duration, there was a gradual augmentation in the proportion of the monoclinic (M) phase and the fracture toughness increased from 2.18 MPa·m^0.5 to 2.83 MPa·m^0.5 after 48 h of annealing, which is higher than many potential TBC materials. The residual compressive stress present in the M phases during the progression of crack propagation served to facilitate the bridging and deflection of cracks. As such, this process led to the alleviation of stress concentration at the crack tip, ultimately enhancing the toughening effect. Full article

The high toughness of zirconia is paving the way for the development of new materials for application in TBC for gas turbine blades. The main aim of this work was the obtainment of tetragonal zirconia polycrystalline (TZP) with high density, from mixtures of high-purity powder of zirconia, yttria, and niobia with different compositions (14.5 to 21 mol%), through the processes of cold pressing by uniaxial pressing and by isostatic pressing, followed by air sintering processes at 1550 °C for 1 h. The samples were characterized for phase composition by X-ray diffraction, Rietveld analysis, and morphology by transmission electron microscopy and energy dispersive spectroscopy analyses. Mechanical and tribological resistance was evaluated by fracture toughness and nanoindentation tests as well as Weibull statistics. The incorporation of yttria and niobia resulted in relatively denser ceramics with stabilization of the tetragonal phase which was confirmed by detailed X-ray diffraction analysis. Modified ceramics for TBC with 17.5 mol% of yttria and niobia showed higher hardness and fracture toughness, 16.16 GPa and 173.38 GPa, respectively. Through nano hardness measurements, it was possible to verify the effect of the samples’ ferroelasticity. Thus, the addition of niobia and yttria to zirconia represents an opportunity for the development of new materials with increasing mechanical and tribological resistance for TBC application. Full article

The uncertain service life of thermal barrier coatings (TBCs) imposes constraints on their secure application. In addressing this uncertainty, this study employs the Monte Carlo simulation method for reliability evaluation, quantifying the risk of TBC peeling. For reliability evaluation, the failure mode needs to be studied to determine failure criteria. The failure mode of high-speed rotating TBCs under gas thermal shock was studied by combining fluid dynamics simulations and experiments. Based on the main failure mode, the corresponding failure criterion was established using the energy release rate, and its limit state equation was derived. After considering the dispersion of parameters, the reliability of TBCs was quantitatively evaluated using failure probability and sensitivity analysis methods. The results show that the main mode is the fracture of the ceramic layer itself, exhibiting a distinctive top-down “step-like” thinning and peeling morphology. The centrifugal force emerges as the main driving force for this failure mode. The failure probability value on the top side of the blade is higher, signifying that coating failure is more likely at this location, aligning with the experimental findings. The key parameters influencing the reliability of TBCs are rotation speed, temperature, and the thermal expansion coefficient. This study offers a valuable strategy for the secure and reliable application of TBCs on aeroengine turbine blades. Full article
