Carbon nanotube field-effect transistors (CNTFETs) are becoming a strong competitor for the next generation of high-performance, energy-efficient integrated circuits due to their near-ballistic carrier transport characteristics and excellent suppression of short-channel effects. However, CNT FETs with large diameters and small band gaps exhibit obvious bipolarity, and gate-induced drain leakage (GIDL) contributes significantly to the off-state leakage current. Although the asymmetric gate strategy and feedback gate (FBG) structures proposed so far have shown the potential to suppress CNT FET leakage currents, the devices still lack scalability. Based on the analysis of the conduction mechanism of existing self-aligned gate structures, this study innovatively proposed a design strategy to extend the length of the source–drain epitaxial region (L_ext) under a vertically stacked architecture. While maintaining a high drive current, this structure effectively suppresses the quantum tunneling effect on the drain side, thereby reducing the off-state leakage current (I_off = 10⁻¹⁰ A), and has good scaling characteristics and leakage current suppression characteristics between gate lengths of 200 nm and 25 nm. For the sidewall gate architecture, this work also uses single-walled carbon nanotubes (SWCNTs) as the channel material and uses metal source and drain electrodes with good work function matching to achieve low-resistance ohmic contact. This solution has significant advantages in structural adjustability and contact quality and can significantly reduce the off-state current (I_off = 10⁻¹⁴ A). At the same time, it can solve the problem of off-state current suppression failure when the gate length of the vertical stacking structure is 10 nm (the total channel length is 30 nm) and has good scalability. Full article

This paper elaborates on the proposal of a new analytical model for a non-ballistic transport scenario for Schottky barrier carbon nanotube field effect transistors (SB-CNTFETs). The non-ballistic transport scenario depends on incorporating the effects of acoustic phonon (A-Ph) and optical phonon (O-Ph) electron scattering mechanisms. The analytical model is rooted in the solution of the Landauer integral equation, which is modified to account for non-ballistic transport through a set of approximations applied to the Wentzel–Kramers–Brillouin (WKB) transmission probability and the Fermi–Dirac distribution function. Our proposed model was simulated to evaluate the total current and transconductance, considering scenarios both with and without the electron–phonon scattering effect. The simulation results revealed a substantial decrease of approximately 78.6% in both total current and transconductance due to electron–phonon scattering. In addition, we investigated the impact of acoustic phonon (A-Ph) and optical phonon (O-Ph) scattering on the drain current under various conditions, including different temperatures, gate lengths, and nanotube chiralities. This comprehensive analysis helps in understanding how these parameters influence device performance. Compared with experimental data, the model’s simulation results demonstrate a high degree of agreement. Furthermore, our fully analytical model achieves a significantly faster runtime, clocking in at around 2.726 s. This validation underscores the model’s accuracy and reliability in predicting the behavior of SB-CNTFETs under non-ballistic conditions. Full article

The creation of carbon nanotubes has sparked a paradigm shift in the post-silicon era because of their decent electronic and optical properties. However, interface traps pose an obstacle in the realization of high-performance carbon nanotube field-effect transistors (CNTFETs). Herein, we systematically investigate the C−V characteristics of CNTFETs and propose a small-signal equivalent model to decouple the effects arising from interface traps. Moreover, intrinsic parameters associated with interface traps can be feasibly extracted using this approach. An analytical capacitance model is further developed to be incorporated into the well-established CNTFET virtual source model, and excellent agreement has been achieved between our simulation and the measured results of the as-fabricated MOSCAP. The models developed here help to gain insight into the physical properties of high-κ dielectric interface traps subjected to different processes and inform strategies to achieve high-performance CNTFETs. Full article

Carbon nanotube field-effect transistors (CNT-FETs) have shown great promise in infrared image detection due to their high mobility, low cost, and compatibility with silicon-based technologies. This paper presents the design and simulation of a column-level analog front-end (AFE) circuit tailored for carbon-based short-wave infrared (SWIR) photodetectors. The AFE integrates a Capacitor Trans-impedance Amplifier (CTIA) for current-to-voltage conversion, coupled with Correlated Double Sampling (CDS) for noise reduction and operational amplifier offset suppression. A 10-bit/125 kHz Successive Approximation analog-to-digital converter (SAR ADC) completes the signal processing chain, achieving rail-to-rail input/output with minimized component count. Fabricated using 0.18 μm CMOS technology, the AFE demonstrates a high signal-to-noise ratio (SNR) of 59.27 dB and an Effective Number of Bits (ENOB) of 9.35, with a detectable current range from 500 pA to 100.5 nA and a total power consumption of 7.5 mW. These results confirm the suitability of the proposed AFE for high-precision, low-power SWIR detection systems, with potential applications in medical imaging, night vision, and autonomous driving systems. Full article

Software-Defined Networking (SDN) revolutionizes network management by decoupling control plane functionality from data plane devices, enabling the centralized control and programmability of network behavior. This paper uses the ternary system to improve the Central Processing Unit (CPU) inside the SDN controller to enhance network management. The Multiple-Valued Logic (MVL) circuit shows remarkable improvement compared to the binary circuit regarding the chip area, propagation delay, and energy consumption. Moreover, the Carbon Nanotube Field-Effect Transistor (CNTFET) shows improvement compared to other transistor technologies regarding energy efficiency and circuit speed. To the best of our knowledge, this is the first time that a ternary design has been applied inside the CPU of an SDN controller. Earlier studies focused on Ternary Content-Addressable Memory (TCAM) in SDN. This paper proposes a new 1-trit Ternary Full Adder (TFA) to decrease the propagation delay and the Power–Delay Product (PDP). The proposed design is compared to the latest 17 designs, including 15 designs that are 1-trit TFA CNTFET-based, 2-bit binary FA FinFET-based, and 2-bit binary FA CMOS-based, using the HSPICE simulator, to optimize the CPU utilization in SDN environments, thereby enhancing programmability. The results show the success of the proposed design in reducing the propagation delays by over 99% compared to the 2-bit binary FA CMOS-based design, over 78% compared to the 2-bit binary FA FinFET-based design, over 91% compared to the worst-case TFA, and over 49% compared to the best-case TFAs. Full article

As the traditional silicon-based CMOS technology advances into the nanoscale stage, approaching its physical limits, the Carbon Nanotube Field-effect Transistor (CNTFET) is considered to be the most significant transistor technology beyond Moore’s era. The CNTFET has a quasi-one-dimensional structure so that the carrier can realize ballistic transport and has very high mobility. At the same time, a single CNTFET can integrate hundreds of nanowires as the conductive channels, enabling significant current transport capabilities even in low supply voltage, thereby providing a foundational basis for achieving nanoscale ultra-large-scale analog/logic circuits. This paper summarizes the development status of the CNTFET compact model and digital/analog/RF integrated circuits. The challenges faced by SPICE modeling and circuit design are analyzed. Meanwhile, solutions to these challenges and development trends of carbon-based transistors are discussed. Finally, the future application prospects of carbon-based integrated circuits are presented. Full article

Carbon nanotubes have excellent electrical properties and can be used as a new generation of semiconductor materials. This paper presents a compact model for carbon nanotube field-effect transistors (CNTFETs). The model uses a semi-empirical approach to model the current–voltage properties of CNTFETs with gate lengths exceeding 100 nm. This study introduces an innovative approach by proposing physical parametric reference lengths ($L_{ref}$), which facilitate the integration of devices of varying sizes into a unified modeling framework. Furthermore, this paper develops models for the bipolar properties of carbon nanotube devices, employing two distinct sets of model parameters for enhanced accuracy. The model offers a comprehensive analysis of the different capacitances occurring between the electrodes within the device. The simulation of the model shows good agreement with the experimental measurements, confirming the model’s validity. The model is implemented in the Verilog-A hardware description language, with the circuit being subsequently constructed and subjected to simulations via the HSPICE tool. The CNTFET-based inverter exhibits a gain of 7.022 and a delay time of 16.23 ps when operated at a voltage of 1.2 V. Full article

Compared to single-gate CNTFET, dual-gate structures have better electrostatic control over nanowire conductive channels. However, currently, there is insufficient research on the back-gate effect in a compact model of dual-gate CNTFET. This paper presents an improved dual-gate carbon nanotube field effect transistor (CNTFET) compact model. The functional relationship between the back-gate voltage (V_bg) and threshold voltage (V_th) is derived. And a voltage reference regulation mechanism is adopted so that the back-gate effect can be accurately reflected in the DC transfer characteristics. The influence of gate voltage and drain voltage on transmission probability is analyzed. Meanwhile, the drain current is optimized by modifying the mobility equation. This compact model is built based on Verilog-A hardware language and supports the Hspice simulation tool. Within the supply voltage of 2 V, the simulation results of the proposed compact model are in good agreement with the measurement results. Finally, based on the compact model, an operational amplifier is designed to verify its correctness and feasibility in analog integrated circuits. When the power supply voltage is 1.8 V, and the load capacitance is 2 pF, the gain is 11.8 dB, and the unit-gain-bandwidth (UGB) is 214 kHz, which proves the efficiency of our compact model. Full article

As the semiconductor industry enters the post-Moore era, the carbon nanotube field-effect transistor (CNTFET) has become a powerful substitute for silicon-based transistors beyond 5 nm process nodes due to its high mobility, low power consumption, and ultra-thin-body electrical advantages. Carbon-based transistor technology has made significant progress in device manufacture and preparation, but carbon-based process design kits (PDKs) that meet the standards of commercial design tools are still an important bottleneck hindering the development of carbon-based integrated circuits. For the first time, a complete full-custom 90 nm CNTFET PDK is proposed in this paper, which includes Pcells for transistors, resistors, and capacitors; a compact model; DRC/LVS/PEX rules; and a standard cell and timing library. It can support the entire design flow of analog, digital, and mixed-signal carbon-based integrated circuits. To achieve an accurate compact model, the back-gate effect of CNTFETs and the influence of gate/drain voltage on transport probability are analyzed. Then the theoretical formulas for mobility and channel current are established. The comparison of the simulation and test results of CNTFET characteristics proves the accuracy of the compact model. Using this PDK, combined with standard IC design tools and design flow, the circuit and layout of an operational amplifier, SRAM, and 8-bit counter are completed. The simulation results verify the correctness and effectiveness of the PDK, laying a solid foundation for the large-scale industrialization of carbon-based integrated circuits. Full article

In this paper, a new carbon nanotube field effect transistor (CNTFET)-based second-order fully differential all-pass filter circuit is presented. The realized filter uses CNTFET-based transconductors and grounded capacitors. An active-only second-order fully differential all-pass filter circuit topology is also presented by replacing the grounded capacitance with a CNTFET-based varactor to achieve filter tunability. By controlling the varactor capacitance, active-only second-order fully differential all-pass filter tunability in the range of 15 GHz to 27.5 GHz is achieved. The proposed active-only circuit works on -oltage, low-power dissipation and high tunable pole frequency. The realized circuit operations are verified through the HPSPICE simulation tool. Deng’s CNTFET model is utilized to verify the filter performances at the 16 nm technology node. It is seen that the proposed filter simulation justifies the theoretical predictions and works efficiently in the deep-submicron technology. Full article

One-dimensional carbon nanotubes (CNTs) are promising for future nanoelectronics and optoelectronics, and an understanding of electrical contacts is essential for developing these technologies. Although significant efforts have been made in this direction, the quantitative behavior of electrical contacts remains poorly understood. Here, we investigate the effect of metal deformations on the gate voltage dependence of the conductance of metallic armchair and zigzag CNT field effect transistors (FETs). We employ density functional theory calculations of deformed CNTs under metal contacts to demonstrate that the current-voltage characteristics of the FET devices are qualitatively different from those expected for metallic CNT. We predict that, in the case of armchair CNT, the gate-voltage dependence of the conductance shows an ON/OFF ratio of about a factor of two, nearly independent of temperature. We attribute the simulated behavior to modification of the band structure under the metals caused by deformation. Our comprehensive model predicts a distinct feature of conductance modulation in armchair CNTFETs induced by the deformation of the CNT band structure. At the same time, the deformation in zigzag metallic CNTs leads to a band crossing but not to a bandgap opening. Full article

We compare the pH sensing performance of non-functionalized carbon nanotubes (CNT) field-effect transistors (p-CNTFET) and CNTFET functionalized with a conjugated polyfluorene polymer (labeled FF-UR) bearing urea-based moieties (f-CNTFET). The devices are electrolyte-gated, PMMA-passivated, 5 µm-channel FETs with unsorted, inkjet-printed single-walled CNT. In phosphate (PBS) and borate (BBS) buffer solutions, the p-CNTFETs exhibit a p-type operation while f-CNTFETs exhibit p-type behavior in BBS and ambipolarity in PBS. The sensitivity to pH is evaluated by measuring the drain current at a gate and drain voltage of −0.8 V. In PBS, p-CNTFETs show a linear, reversible pH response between pH 3 and pH 9 with a sensitivity of 26 ± 2.2%/pH unit; while f-CNTFETs have a much stronger, reversible pH response (373%/pH unit), but only over the range of pH 7 to pH 9. In BBS, both p-CNTFET and f-CNTFET show a linear pH response between pH 5 and 9, with sensitivities of 56%/pH and 96%/pH, respectively. Analysis of the I–V curves as a function of pH suggests that the increased pH sensitivity of f-CNTFET is consistent with interactions of FF-UR with phosphate ions in PBS and boric acid in BBS, with the ratio and charge of the complexed species depending on pH. The complexation affects the efficiency of electrolyte gating and the surface charge around the CNT, both of which modify the I–V response of the CNTFET, leading to the observed current sensitivity as a function of pH. The performances of p-CNTFET in PBS are comparable to the best results in the literature, while the performances of the f-CNTFET far exceed the current state-of-the-art by a factor of four in BBS and more than 10 over a limited range of pH in BBS. This is the first time that a functionalization other than carboxylate moieties has significantly improved the state-of-the-art of pH sensing with CNTFET or CNT chemistors. On the other hand, this study also highlights the challenge of transferring this performance to a real water matrix, where many different species may compete for interactions with FF-UR. Full article

The excellent performance and radiation-hardness potential of carbon nanotube (CNT) field effect transistors (CNTFETs) have attracted wide attention. However, top-gate structure CNTFETs, which are often used to make high-performance devices, have not been studied enough. In this paper, the total ionizing dose (TID) effect of the top-gate structure CNTFETs and the influence of the substrate on top-gate during irradiation are studied. The parameter degradation caused by the irradiation- and radiation-damage mechanisms of the top-gate P-type CNTFET were obtained by performing a Co-60 γ-ray irradiation test. The results indicate that the transfer curves of the top-gate P-type CNTFETs shift negatively, the threshold voltage and the transconductance decrease when TID increases, and the subthreshold swing decreases first and then increases with the increase in TID. The back-gate transistor is constructed by using the substrate as a back-gate, and the influence of back-gate bias on the characteristics of the top-gate transistor is tested. We also test the influence of TID irradiation on the characteristics of back-gate transistors, and reveal the effect of trapped charge introduced by radiation on the characteristics of top-gate transistors. In addition, the CNTFETs that we used have obvious hysteresis characteristics. After irradiation, the radiation-induced trapped charges generated in oxide and the OH groups generated by ionization of the CNT adsorbates aggravate the hysteresis characteristics of CNTFET, and the hysteresis window increases with the increase in TID. Full article

One-dimensional (1D) and two-dimensional (2D) materials represent the emerging technologies for transistor electronics in view of their attractive electrical (high power gain, high cut-off frequency, low power dissipation) and mechanical properties. This work investigates the integration of carbon-nanotube-based field-effect transistors (CNT-FETs) and molybdenum disulphide (MoS₂)-based FETs with standard CMOS technology for designing a simple analog system integrating a power switching circuit for the supply management of a 10 GHz transmitting/receiving (T/R) module that embeds a low-noise amplifier (LNA) and a high-power amplifier (HPA), both of which loaded by nanocrystalline graphene (NCG)-based patch antennas. Verilog-A models, tuned to the technology that will be used to manufacture the FETs, were implemented to perform electrical simulations of the MoS₂ and CNT devices using a commercial integrated circuit software simulator. The obtained simulation results prove the potential of hybrid CNT-MoS₂-FET circuits as building blocks for next-generation integrated circuits for radio frequency (RF) applications, such as radars or IoT systems. Full article

Nano biochemical sensors play an important role in detecting the biomarkers related to human diseases, and carbon nanotubes (CNTs) have become an important factor in promoting the vigorous development of this field due to their special structure and excellent electronic properties. This paper focuses on applying carbon nanotube field-effect transistor (CNT-FET) biochemical sensors to detect biomarkers. Firstly, the preparation method, physical and electronic properties and functional modification of CNTs are introduced. Then, the configuration and sensing mechanism of CNT-FETs are introduced. Finally, the latest progress in detecting nucleic acids, proteins, cells, gases and ions based on CNT-FET sensors is summarized. Full article
