This study presents an analytical and experimental approach to enhance cantilever-based piezoelectric energy harvesters by optimizing thickness distribution. Using a gradient projection algorithm within a state-space framework, the unimorph beam’s geometry is tailored while constraining the first natural frequency. The objective is to amplify axial strain within the piezoelectric layers, thereby increasing electric polarization and maximizing the conversion efficiency of mechanical vibrations into electrical energy. The steady-state response under harmonic base excitation at resonance was modeled to evaluate the harvester’s dynamic behavior against uniform-thickness counterparts. Results show that the optimized beam achieves significantly higher output voltage and energy harvesting efficiency. Simulations reveal effective strain concentration in regions of high piezoelectric sensitivity, enhancing power generation under resonant conditions. Two independent experimental setups were employed for empirical validation: a non-contact laser vibrometry system (Polytec 3D) and a first resonant base excitation setup. Eigenfrequencies matched within 5% using a Polytec multipath interferometry system, and constant excitation tests showed approximately 30% higher in optimal shapes electrical potential value generation. The outcome of this study highlights the efficacy of geometric tailoring—specifically, non-linear thickness shaping—as a key strategy in achieving enhanced energy output from piezoelectric harvesters operating at their fundamental frequency. This work establishes a practical route for optimizing unimorph structures in real-world applications requiring efficient energy capture from low-frequency ambient vibrations. Full article

In the current electromechanical model of cantilevered piezoelectric energy harvesters, the assumption of uniform electric field strength within the piezoelectric layer is commonly made. This uniform electric field assumption seems reasonable since the piezoelectric layer looks like a parallel-plate capacitor. However, for a piezoelectric bender, the strain distribution along the thickness direction is not uniform, which means the internal electric field generated by the spontaneous polarization cannot be uniform. In the present study, a non-uniform electric field in the piezoelectric layer is resolved using electrostatic equilibrium equations. Based on these, the traditional distributed parameter electromechanical model is corrected and simplified to a practical single mode one. Compared with a traditional model adopting a uniform electric field, the bending stiffness term involved in the electromechanical governing equations is explicitly corrected. Through comparisons of predicted power output with two-dimensional finite element analysis, the results show that the present model can better predict the power output performance compared with the traditional model. It is found that the relative corrections to traditional model have nothing to do with the absolute dimensions of the harvesters, but only relate to three dimensionless parameters, i.e., the ratio of the elastic layer’s to the piezoelectric layer’s thickness; the ratio of the elastic modulus of the elastic layer to the piezoelectric layer; and the piezoelectric materials’ electromechanical coupling coefficient squared, ${k_{31}}^2$. It is also found that the upper-limit relative corrections are only related to ${k_{31}}^2$, i.e., the higher ${k_{31}}^2$ is, the larger the upper-limit relative corrections will be. For a PZT-5 unimorph harvester, the relative corrections of bending stiffness and corresponding resonant frequency are up to 17.8% and 8.5%, respectively. An inverse problem to identify the material parameters based on experimentally obtained power output performance is also investigated. The results show that the accuracy of material parameters identification is improved when considering a non-uniform electric field. Full article

The subject of this article is an experimental analysis of the control system of a composite-based piezoelectric actuator and an aluminum-based piezoelectric actuator. Analysis was performed for both the unimorph and bimorph structures. To carry out laboratory research, two piezoelectric actuators with a cantilever sandwich beam structure were manufactured. In the first beam, the carrier layer was made of glass-reinforced epoxy composite (FR4), and in the second beam, it was made of 1050 aluminum. A linear mathematical model of both actuators was also developed. A modification of the method of selecting weights in the LQR control algorithm for a cantilever-type piezoelectric actuator was proposed. The weights in the R matrix for the actuator containing a carrier layer made of stiffer material should be smaller than those for the actuator containing a carrier layer made of less stiff material. Additionally, regardless of the carrier layer material, in the case of a bimorph, the weight in the R matrix that corresponds to the control voltage of the compressing MFC patch should be smaller than the weight corresponding to the control voltage of the stretching MFC patch. Full article

This paper reports two piezoelectric materials of lead zirconium titanate (PZT) and aluminum nitride (AlN) used to simulate microelectromechanical system (MEMS) speakers, which inevitably suffered deflections as induced via the stress gradient during the fabrication processes. The main issue is the vibrated deflection from the diaphragm that influences the sound pressure level (SPL) of MEMS speakers. To comprehend the correlation between the geometry of the diaphragm and vibration deflection in cantilevers with the same condition of activated voltage and frequency, we compared four types of geometries of cantilevers including square, hexagon, octagon, and decagon in triangular membranes with unimorphic and bimorphic composition by utilizing finite element method (FEM) for physical and structural analyses. The size of different geometric speakers did not exceed 10.39 mm²; the simulation results reveal that under the same condition of activated voltage, the associated acoustic performance, such as SPL for AlN, is in good comparison with the simulation results of the published literature. These FEM simulation results of different types of cantilever geometries provide a methodology design toward practical applications of piezoelectric MEMS speakers in the acoustic performance of stress gradient-induced deflection in triangular bimorphic membranes. Full article

This work presents a novel development of the impact-based mechanism for piezoelectric vibration energy harvesters. More precisely, the effect of an impacting mass on a cantilever piezoelectric transducer is studied both in terms of the tip mass value attached to the cantilever and impact position to find an optimal condition for power extraction. At first, the study is carried out by means of parametric analyses at varying tip mass and impact position on a unimorph MEMS cantilever, and a suitable physical interpretation of the associated electromechanical response is given. The effect of multiple impacts is also considered. From the analysis, it emerges that the most effective configuration, in terms of power output, is an impact at the cantilever tip without a tip mass. By changing the value of the tip mass, a sub-optimal impact position along the beam axis can also be identified. Moreover, the effect of a tip mass is deleterious on the power performance, contrary to the well-known case of a resonant energy harvester. A mesoscale prototype with a bimorph transducer is fabricated and tested to validate the computational models. The comparison shows a good agreement between numerical models and the experiments. The proposed approach is promising in the field of consumer electronics, such as wearable devices, in which the impact-based device moves at the frequencies of human movement and is much lower than those of microsystems. Full article

This paper presents a piezoelectric heterostructure for extracting mechanical energy from human foot strikes based on the impact of a moving block on the tips of the piezoelectric unimorph cantilevers. The use of the magnetic springs allows low-frequency and high-amplitude movements of the device. The piezoelectric unimorph cantilevers deform under a human foot strike on the pedal, and the piezoelectric elements in d₃₁-mode produce output voltages. An analysis was conducted, and the working principle was stated. A prototype was fabricated to validate the feasibility of the proposed design. The experimental results show that the generated RMS voltage increases with human walking (running) speed. At the walking speed of 6 km/h, an average power of 36.26 μW is produced across a matching resistive load of 4 MΩ with an initial separating distance of 9 mm. Improvements of the device are possible, allowing an increase in the average power by increasing the number of piezoelectric unimorph cantilevers and using the piezoelectric materials with higher piezoelectric constants. Full article

Based on the multi-chamber series structure, a piezoelectric micropump with high output performance is proposed in this paper. The proposed micropump is composed of the circular unimorph piezoelectric vibrator, the cantilever check valve, and the pump body. First, the working process of the piezoelectric micropump was analyzed in detail. Then, the effect of the key dimension parameters on the output performance of the micropump was explored. The key dimension parameters mainly refer to the height of the pump chamber and valve opening (the deformation size of the valve). Finally, experimental prototypes with different parameters were fabricated for the evaluation of the output performance of the micropump. The experimental results show that when the pump chamber height is 0.1 mm and the valve opening is 0.4 mm, the piezoelectric micropump has a good comprehensive output performance. In particular, at 170 V and 120 Hz, the maximum flow rate of the dual-chamber series pump is 65.5 mL/min, and at 100 Hz, the maximum output pressure reaches 59.1 kPa. Moreover, at a certain voltage of 170 V, when the drive frequency is 450 Hz and 550 Hz, the output flow rate and pressure of the four-chamber series pump reach a maximum of 110 mL/min and exceed 140 kPa, respectively. In addition, the volumes of the proposed single-chamber, dual-chamber series, and four-chamber series micropumps are 22 mm × 22 mm × 5 mm, 32.6 mm × 22 mm × 5 mm, and 53.8 mm × 22 mm × 5 mm, respectively. The proposed piezoelectric micropump has the advantages of simple structure, low cost, miniaturization, and high output performance, thus gaining potential practicality for biomedical applications, cooling systems, fuel supply, chemical applications, etc. Full article

Environmental energy harvesting is a major operation in research and industries. Currently, researchers have started analyzing small-scale energy scavengers for the supply of energy in low-power electrical appliances. One area of interest is the use of piezoelectric materials, especially in the presence of mechanical vibrations. This study analyzed a unimorph cantilever beam in different modes by evaluating the effects of various parameters, such as geometry, piezoelectric material, lengths of layers, and the proof mass to the energy harvesting process. The finite element method was employed for analysis. The proposed model was designed and simulated in COMSOL Multiphysics, and the output parameters, i.e., natural frequencies and the output voltage, were then evaluated. The results suggested a considerable effect of geometrical and physical parameters on the energy harvesters and could lead to designing devices with a higher functional efficiency. Full article

This paper deals with analytical modelling of piezoelectric energy harvesting systems for generating useful electricity from ambient vibrations and comparing the usefulness of materials commonly used in designing such harvesters for energy harvesting applications. The kinetic energy harvesters have the potential to be used as an autonomous source of energy for wireless applications. Here in this paper, the considered energy harvesting device is designed as a piezoelectric cantilever beam with different piezoelectric materials in both bimorph and unimorph configurations. For both these configurations a single degree-of-freedom model of a kinematically excited cantilever with a full and partial electrode length respecting the dimensions of added tip mass is derived. The analytical model is based on Euler-Bernoulli beam theory and its output is successfully verified with available experimental results of piezoelectric energy harvesters in three different configurations. The electrical output of the derived model for the three different materials (PZT-5A, PZZN-PLZT and PVDF) and design configurations is in accordance with lab measurements which are presented in the paper. Therefore, this model can be used for predicting the amount of harvested power in a particular vibratory environment. Finally, the derived analytical model was used to compare the energy harvesting effectiveness of the three considered materials for both simple harmonic excitation and random vibrations of the corresponding harvesters. The comparison revealed that both PZT-5A and PZZN-PLZT are an excellent choice for energy harvesting purposes thanks to high electrical power output, whereas PVDF should be used only for sensing applications due to low harvested electrical power output. Full article

In renewable energy technology development, piezoelectric material has electro-mechanical converted capability and the advantages of simple construction and compact size, it has potential development since the environment vibration can be transferred into an electrical energy in daily harvesting applications. To improve the electro-mechanical converted efficiency of a piezoelectric harvester at low-frequency environment, a free vibration type of piezoelectric cantilever harvesting structure was proposed, which can generate a resonant oscillation by releasing an initial deformed displacement, and was uninfluenced from the effects of external environment. To analyze the harvesting behaviors, an equivalent circuit with voltage source was provided, and the parameters in theoretical model can be determined by the dimensions of the piezoelectric unimorph plate and its initial deformation. From the comparison of measurement and simulation, it reveals a significant efficient theoretical model where 8% error occurrence for storage energy was found. Finally, the proposed free-vibration generation method was developed in a piezoelectric harvesting floor design, which can transfer human walking motion into electric energy, and store in an external storage capacitor. From the testing result, one time of footstep motion can cause the charging energy in a 33 μF of storage capacitor achieve to 0.278 mJ, which was larger than the driven power of the wireless transmitter module, and then the wireless transmitter can be driven to send a RF signal without external power supply. Therefore, the designed piezoelectric harvesting floor has potential development to locate the user’s current position, which can provide users with future appropriate service for intelligent building application. Full article

This paper presents an analytical model to determine a closed form mathematical representation for the output displacement of a displacement amplification compliant mechanism used for energy harvesting. A symmetric five-bar compliant mechanism with right-circular and corner-filleted flexure hinges was mathematically modeled and its displacement was determined using the Castigliano energy theorem. The stresses within the flexure joints, the weakest points in the mechanism body, were calculated. The mathematical model expresses both the displacement amplification and the stresses as functions of the design parameters and the load caused by the harvester. The developed model can be used to optimize the mechanism dimensions for maximum harvested power, while minimizing its structural stresses. The mechanism was also modeled numerically using finite element methods; both the analytical and numerical models were verified experimentally. The mathematical model of the mechanism was integrated with a model representing a piezoelectric energy harvester to calculate the open-circuit voltage. As a proof of concept, experiments were performed using an unimorph piezoelectric cantilever at low-frequency (less than 1 Hz) harmonic excitation inputs. The measured open-circuit voltage was found to be in agreement with that calculated using the proposed model, when integrated with the model representing the piezoelectric beam. The power generated by the piezoelectric harvester, equipped with the proposed displacement amplification mechanism, was more than a hundred times that without amplification. Full article

Heat generation in active/passive layer-based piezoelectric actuators is unavoidable due to the mechanical, dielectric, and resistive losses in the material. In this work, a polyvinylidene fluoride (PVDF)-based unimorph cantilever actuator is developed with simulation and experimental studies on the effect of DC high voltages on heat production in the PVDF layer. A layer of one-way shape memory polymers (1W-SMPs) is integrated in the actuator to exploit the heat produced to increase the bending angle. The length and mounting location of the SMP layer impacts the bending of the actuator; by using an SMP layer with a length equal to half of the PVDF layer at the center of the unimorph actuator, the absolute bending angle is increased to 40° compared to the base piezo bending angle of 4° at 20 V/µm. Full article

Layered piezo-composite unimorph actuators have been studied by many research teams to provide active vibration control of thin-walled aerospace structures, control the shapes of aircraft wing airfoils, and control the fins of small missiles, because they require less space and provide better frequency responses than conventional electro-magnetic motor actuator systems. However, due to the limited actuation strains of conventional piezo-composite unimorph actuators with poly-crystalline piezoelectric ceramic layers, they have not been implemented effectively as actuators for small aerospace vehicles. In this study, a lightweight piezo-composite unimorph actuator (LIPCA-S2) was manufactured and analyzed to predict its flexural actuation displacement. It was found that the actuated tip displacement of a piezo-composite cantilever could be predicted accurately using the proposed prediction model based on the nonlinear properties of the piezoelectric strain coefficient and elastic modulus of a piezoelectric single crystal. Full article

The overall performance of an electrostrictive polymer is rated by characteristic numbers, such as its transverse strain, blocking force, and energy density, which are clearly limited by several parameters. Besides the geometrical impact, intrinsic material parameters, such as the permittivity coefficient as well as the Young’s modulus and the breakdown electric field, have strong influences on the actuation properties of an electroactive polymer and thus on the device’s overall behavior. As a result, an analysis of the figures of merit (FOMs) involving all relevant material parameters for the transverse strain, the blocking force, and the energy density was carried out, making it possible to determine the choice of polymer matrix in order to achieve a high actuator performance. Another purpose of this work was to demonstrate the possibility of accurately measuring the free deflection without the application of an external force and inversely measuring the blocking force under quasi-static displacement. The experimental results show good electrostrictive characteristics of the plasticized terpolymer under relatively low electric fields. Full article

This paper presents the design and fabrication of a piezoelectric MEMS cantilever harvester of optimized shape able to generate a usable amount of power from low frequency vibrations for moderate cantilever deflection. The corresponding harvester design, obtained by means of FEM simulations, comprises a trapezoidal unimorph silicon cantilever beam with a piezoelectric PZT film and a rectangular silicon tip mass. This device was fabricated by wafer-level micro-fabrication processes. The harvester provided 2 μW generated power at 123 Hz resonant frequency. Full article
