Search Results (96)

The growing global demand for electricity, driven by the development of electromobility, data centers, and smart technologies, necessitates innovative approaches to energy generation. Wind power, as a clean and renewable energy source, plays a pivotal role in the global transition towards low-carbon power systems. This paper presents a comprehensive review of generator technologies used in wind turbine applications, ranging from conventional synchronous and asynchronous machines to advanced concepts such as low-speed direct-drive (DD) generators, axial-flux topologies, and superconducting generators utilizing low-temperature superconductors (LTS) and high-temperature superconductors (HTS). The advantages and limitations of each design are discussed in the context of efficiency, weight, reliability, scalability, and suitability for offshore deployment. Special attention is given to HTS-based generator systems, which offer superior power density and reduced losses, along with challenges related to cryogenic cooling and materials engineering. Furthermore, the paper analyzes selected modern generator designs to provide references for enhancing the performance of grid-synchronized hybrid microgrids integrating solar PV, wind, battery energy storage, and HTS-enhanced generators. This review serves as a valuable resource for researchers and engineers developing next-generation wind energy technologies with improved efficiency and integration potential. Full article

Wireless power transfer systems require not only strong coupling capabilities but also stable output under various misalignment conditions. This paper proposes a hybrid magnetic coupler for autonomous underwater vehicles (AUVs), featuring two identical arc-shaped rectangular transmitting coils and a combination of an arc-shaped rectangular receiving coil and two anti-series connected solenoid coils. The arc-shaped rectangular receiving coil captures the magnetic flux generated by the transmitting coil, which is directed toward the center, while the solenoid coils capture the axial magnetic flux generated by the transmitting coil. The parameters of the proposed magnetic coupler have been optimized to enhance the coupling coefficient and improve the system’s tolerance to misalignments. To verify the feasibility of the proposed magnetic coupler, a 300 W prototype with LCC-S compensation topology is built. Within a 360° rotational misalignment range, the system’s output power maintains around 300 W, with a stable power transmission efficiency of over 92.14%. When axial misalignment of 40 mm occurs, the minimum output power is 282.8 W, and the minimum power transmission efficiency is 91.6%. Full article

This paper presents a novel analytical model of a double-stator single-rotor (DSSR) ironless axial flux machine (IAFM), with no iron either in the rotor or in the stator, that has cylindrical magnets in the rotor. The model is based on sizing equations that include the peak no-load flux density as a determining parameter, and then static simulations using the finite element method show that the 3D magnetic field created by cylindrical magnets can be generally fitted with an empirical function. The analytical model is validated throughout this work with finite element simulations and experiments over a prototype, showing a good agreement. It is stated that the integration of the magnetic field for different rotor positions, using the empirical approach presented here, gives accurate results regarding the back-electromotive force waveform and harmonics, with a reduced computation time and effort compared to the finite element method and avoiding complex formulations of previous analytical models. Moreover, this straightforward approach facilitates the design and comparison of IAFMs with other machine topologies, as sizing equations and magnetic circuits developed for conventional electrical machines are not valid for IAFMs, because, here, the magnetic field circulates entirely through air due to the absence of ferromagnetic materials. Furthermore, the scope of this paper is limited to a DSSR-IAFM, but the method can be directly applied to single-sided IAFMs and could be refined to deal with single-stator double-rotor IAFMs. Full article

This study introduces a novel double dumbbell-shaped flux-switching linear tube generator (DDFSLG) for ocean wave energy conversion. The innovative architecture features a uniquely shaped stator and translator, distinguishing it from conventional linear generators. Unlike traditional systems, the DDFSLG is housed in a cylindrical buoy. The translator oscillates axially within the stator. This eliminates the need for motion rectification and reduces mechanical friction losses in the power take-off (PTO) system. These design advancements result in high power output and improved performance. The DDFSLG’s three-phase coil circuit is another key innovation, improving electrical performance and stability in irregular wave conditions. We conducted comprehensive experimental validation using an MTS-250 kN testing system, which demonstrated strong agreement between theoretical predictions and measured results. We compared star and delta coil connections to assess how circuit configuration affects power output and efficiency. Furthermore, hydrodynamic simulations using the JONSWAP spectrum and ANSYS AQWA software (Ansys 13.0) provide detailed insight into the system’s dynamic response under realistic oceanic conditions. Full article

A PCB stator axial flux permanent magnet (AFPM) motor is presented that overcomes the manufacturing challenges associated with the complex geometry of conventional stators by employing a PCB substrate. Traditionally, AFPM motors are produced by winding coils around the stator teeth, a process that requires specialized winding machinery and is both labor intensive and time consuming, ultimately incurring considerable manufacturing costs and delays. In contrast, PCB substrates offer significant advantages in manufacturability and mass production, effectively resolving these issues. Furthermore, the primary material used in PCB substrates, FR-4, exhibits a permeability similar to that of air, resulting in negligible electromagnetic cogging torque. Cogging torque arises from the attraction between permanent magnets and stator teeth, creating forces that interfere with motor rotation and generate unwanted vibration, noise, and potential mechanical collisions between the rotor and stator. In the PCB stator design, the conventional PCB circuit pattern is replaced by the motor’s coil configuration, and the absence of stator teeth eliminates these interference issues. Consequently, a slotless motor configuration with minimal vibration and noise is achieved. The PCB AFPM motor has been applied to a vehicle-mounted electric water pump (EWP), where mass production and space efficiency are critical. In an EWP, which integrates the impeller with the motor, it is essential that vibrations are minimized since excessive vibration could compromise impeller operation and, due to fluid resistance, require high power input. Moreover, the AFPM configuration facilitates higher torque generation compared to a conventional radial flux permanent magnet synchronous motor (RFPM). In a slotless AFPM motor, the absence of stator teeth prevents core flux saturation, thereby further enhancing torque performance. AC losses occur in the conductors as a result of the magnetic flux produced by the permanent magnets, and similar losses arise within the PCB circuits. Therefore, an optimized PCB circuit design is essential to reduce these losses. The Constant Trace Conductor (CTC) PCB circuit design process is proposed as a viable solution to mitigate AC losses. A 3D finite element analysis (3D FEA) model was developed, analyzed, fabricated, and validated to verify the proposed solution. Full article

Currently, electric machines predominantly rely on costly rare-earth NdFeB magnets, which pose both economic and environmental challenges due to rising demand. This research explores recent advancements in machine topologies and magnetic materials to identify and assess promising solutions to this issue. The study investigates two alternative machine topologies to the conventional permanent magnet synchronous machine (PMSM): the permanent magnet-assisted synchronous reluctance machine (PMaSynRM), which reduces magnet usage, and the wound-field synchronous machine (WFSM), which eliminates magnets entirely. Additionally, the potential of ferrite and recycled NdFeB magnets as substitutes for primary NdFeB magnets is evaluated. Through detailed simulations, the study compares the performance and cost-effectiveness of these solutions against a reference permanent magnet synchronous machine (PMSM). Given their promising performance characteristics and potential to reduce or eliminate the use of rare-earth materials in next-generation electric machines, it is recommended that future research should focus on novel topologies like hybrid-excitation, axial-flux, and switched reluctance machines with an emphasis on manufacturability and also novel magnetic materials such as FeN and MnBi that are currently seeing synthesis challenges. Full article

Wind energy is a vital pillar of modern sustainable power generation, yet wind turbine generators remain vulnerable to incipient inter-turn short-circuit (ITSC) faults in their stator windings. These faults can cause fluctuations in the output voltage, frequency, and power of wind turbines, eventually leading to overheating, equipment damage, and rising maintenance costs if not detected early. Although significant progress has been made in condition monitoring, the current methods still fall short of the robustness required for early fault diagnosis in complex operational settings. To address this gap, this study presents a novel deep learning framework that involves traditional baseline machine-learning algorithms and advanced deep network architectures to diagnose seven distinct ITSC fault types using signals from current, vibration, and axial magnetic flux sensors. Our approach is rigorously evaluated using metrics such as confusion matrices, accuracy, recall, average precision (AP), mean average precision (mAP), hypothesis testing, and feature visualization. The experimental results demonstrate that deep learning models outperform machine learning algorithms in terms of precision and stability, achieving an mAP of 99.25% in fault identification, with three-phase current signals emerging as the most reliable indicator of generator faults compared to vibration and electromagnetic data. It is recommended to combine three-phase current sensors with deep learning frameworks for the precise identification of various types of incipient ITSC faults. This study offers a robust and efficient pipeline for condition monitoring and ITSC fault diagnosis, enabling the intelligent operation of wind turbines and maintenance of their operating states. Ultimately, it contributes to providing a practical way forward in enhancing turbine reliability and lifespan. Full article

This study presents a flywheel energy storage system utilizing a new multi-axial flux permanent magnet (MAFPM) motor–generator for coil launchers. The traditional winding structure of the flywheel is effective for energy recovery over several minutes. However, because the projectile is launched from coil launchers in less than one second, the traditional winding structure experiences insulation deterioration and winding damage due to the high current. This study proposes a winding structure made of an 8 × 0.5 mm conductor with eight turns to meet the energy requirements of coil launchers. Furthermore, the motor winding was divided into two sections, which were compared using both series and parallel connection methods as described in the literature. The proposed system produces energy that is 29.96%, 85.63%, and 81.11% lower than the A winding (where A and B are identical), the A + B winding (series connected), and A//B winding (parallel connected) at the same speed. However, as the speed increases by 258.26%, the energy output rises by 215.88%. The flywheel motor–generator’s series-parallel winding structure reaches its current carrying capacity at 1188 rpm. By utilizing a separate winding instead of the traditional motor–generator winding, a current of 38.4 A is achieved, ensuring that the winding’s current carrying capacity remains within the design parameters. Experimental data have proven that the proposed multi-wire winding structure is an innovative solution for coil launchers, surpassing various combinations of motor–generator windings found in the literature. Furthermore, the placement of the proposed winding in a single slot in the design ensures a compact structure. Full article

This work introduces a systematic method for identifying analytical and semi-analytical solutions of force-free magnetic fields with plane-parallel and axial symmetry. The method of separation of variables is used, allowing the transformation of the non-linear partial differential equation, corresponding to force-free magnetic fields, to a system of decoupled ordinary differential equations, which nevertheless, are in general non-linear. It is then shown that such solutions are feasible for configurations where the electric current has a logarithmic dependence to the magnetic field flux. The properties of the magnetic fields are studied for a variety of physical parameters, through solution of the systems of the ordinary differential equations for various values of the parameters. It is demonstrated that this new logarithmic family of solutions has properties that are highly distinct from the known linear and non-linear equations, as it allows for bounded solutions of magnetic fields, for periodic solutions and for solutions that extend to infinity. Possible applications to astrophysical fields and plasmas are discussed as well as their use in numerical studies, and the overall enrichment of our understanding of force-free configurations. Full article

An axial field hybrid excitation synchronous generator (AF-HESG) is proposed for an independent power supply system, and its electromagnetic performance is studied in this paper. The distinguishing feature of the proposed generator is the addition of static magnetic bridges at both ends to place the field windings and the use of a sloping surface to increase the additional air-gap cross-sectional area. The advantage of the structure is that it achieves brushless excitation and improves the flux-regulation range. The structure and magnetic circuit characteristics are introduced in detail. Theoretical analysis of the flux-regulation principle is conducted by studying the relationship between field magnetomotive force, rotor reluctance, and air-gap flux density. Quantitative calculation is performed using a magnetomotive force (MMF)-specific permeance model, and the influence of the main parameters on the air-gap flux density and flux-regulation range is analyzed. Subsequently, magnetic field, no-load, and load characteristics are investigated through three-dimensional finite element analysis. The loss distribution is analyzed, and the temperature of the generator under rated conditions is simulated. Finally, a 30 kW, 1500 r/min prototype is developed and tested. The test results show good flux-regulation capability and stable voltage output performance of the proposed generator. Full article

The study demonstrates an application of actual technologies and tools for the development of an axial-flux electricity generator. The specifics of its application—a run-of-river sited power station—predefine some of the design parameters that are close to a wind turbine generator. An extensive study of available solutions is used as a starting point for further concept development. The study aims to provide a viable solution for a large-scale electrical machine. A step-based methodology is defined for concept parameters’ assessment and a feasibility study. It demonstrates the advantages of virtual prototyping when assessing various design parameters such as air gaps, coil thickness, and the number of rotor disks. Several simulations over different virtual prototypes provide sufficient information to elaborate an improved design concept. The major result is a ready-for-detailed design concept, with defined major parameters and studied work behavior for a specific, large structure of an electrical machine. Another important result is the presentation of the application of virtual prototyping in the assessment of large structures, for which physical prototyping is an expensive and time-consuming approach. The application of virtual prototyping at a very early product development stage is an effective way to undertake efficient solutions involving the concept of the product. Full article

In this article, a simple and practical magnetic equivalent charge model is proposed to predict the torque of a slotted-type axial-flux magnetic coupler (SAMC) under conditions of radial misalignment, angle misalignment, and synthetic misalignment. The magnetic field generated by the permanent magnet (PM) disk and the induced magnetic field generated by the slotted conductor sheet (CS) are equivalent to the surface magnetic charge, respectively. Particularly, the induced magnetic field produced by eddy current considering skin depth in the conductor sheet is introduced into the magnetic equivalent charge model. Combined with Coulomb’s law of magnetic field, the formulas of torque and axial force are both derived. Using this method, the torques in three cases of misalignment are calculated. Finally, the effectiveness of the model is verified by the finite element method (FEM) and experiment; the results calculated by the magnetic equivalent charge model are basically consistent with those from the finite element method and experiment. The derived formula is suitable for small air gaps, small slip rates, and small radial deflection distances. Additionally, the limitations of the method proposed are discussed, which is of great help for understanding the torque transmission of the magnetic coupler in the misalignment state. Full article

Flux transfer events (FTEs) are magnetic structures generally believed to originate from time-varying magnetic reconnection at the Earth’s magnetopause. Despite years of research, the mechanism of how FTEs are formed through reconnection remains controversial. In various models, FTEs exhibit different global configurations. Studying the FTE axial orientation can provide insights into their global shape, thereby helping to distinguish the generation mechanisms. In this paper, taking advantage of the orbital characteristics of the four Cluster spacecraft, we devised a multi-spacecraft timing method to determine the axes of a total of 57 FTEs observed sequentially by Cluster during a high-latitude duskside magnetopause crossing. During the nearly five-hour observation, the interplanetary magnetic field (IMF) experienced a large rotation, leading to a substantial rotation of the magnetosheath magnetic field. The analysis results show two new features of the FTE axis that have not been reported before: (1) the axes of the FTEs gradually rotate in response to the turning of the IMF and the magnetosheath magnetic field; (2) the axes of the FTEs vary between the direction of the magnetosheath magnetic field and the direction of the reconnection X-line. These features indicate that FTEs may have a more complex global configuration than depicted by traditional FTE models. Full article

In this study, we evaluated the nonlinear dynamics of convection flow using the thermodynamic variational principle, focusing on scenarios where multiple external forces, such as a thermal gradient and rotational field, are applied to a shallow annular pool. We observed that with the increase in the thermal gradient, the flow changed from an axial flow to a rotational oscillatory flow with the wave amplitudes aligned. Further increasing the temperature difference led to a rotational oscillatory flow characterized by alternating wave generation and annihilation. Our analysis of the flow, considering heat fluxes orthogonal to the thermal gradient, allowed us to describe the flow state as a phase at equilibrium. The state transition of the flow was accompanied by a discontinuous jump in the heat flux, which occurred at the intersection of the entropy production curves. The first transition occurred at a temperature difference $\Delta T=12.4 \mathrm{K} \left(\mathrm{M}\mathrm{a}\mathrm{r}\mathrm{a}\mathrm{n}\mathrm{g}\mathrm{o}\mathrm{n}\mathrm{i} \mathrm{n}\mathrm{u}\mathrm{m}\mathrm{b}\mathrm{e}\mathrm{r},\mathrm{M}\mathrm{a}=1716\right)$ and the second at ΔT = 16.3 K $\left(\mathrm{M}\mathrm{a}=2255\right)$. Analysis based on entropy production could accurately predict the observed transition points. Full article

Switched reluctance motors (SRMs) are highly advantageous electric motors for various industrial applications, particularly in electric vehicles (EVs), due to their winding-free rotor, magnet-free design, simplicity, and ease of manufacturing. The growing interest in axial flux SRMs (AFSRMs) is particularly noticeable, as axial flux electric motors with a flat shape and high aspect ratio have become commonly used in various industrial applications, including in-wheel motors for EVs. Structurally, AFSRMs significantly differ from radial flux SRMs (RFSRMs), but share the same electromagnetic operating principles. When compared to RFSRMs, AFSRMs generate higher torque per unit volume due to their more effective utilization of their air gap. In this study, the axial force on the rotor and torque ripple of a 6/4 pole fully pitched axial flux SRM (FP-AFSRM) were minimized by combining the advantages of “single-stator and single-rotor AFSRM” and “double-stator and single-rotor AFSRM” models. The proposed FP-AFSRM model, which has a “double-stator and single-rotor AFSRM” design and has the operating logic of a “single-stator and single-rotor AFSRM”, was analyzed using 3D finite element analysis. The results show that the torque ripple decreased (Δ % T_rip) between (−30.42) and (−41.14), and the axial force on the rotor decreased between 17.61% and 25.4%. Full article
