All-Printed Microfluidic–Electrochemical Devices for Glucose Detection
by Zexi Wang, Zhiyi Zhang and Changqing Xu
Biosensors 2024, 14(12), 569; https://doi.org/10.3390/bios14120569 - 24 Nov 2024
Viewed by 1690
Abstract
Free-standing capillary microfluidic channels were directly printed over printed electrodes using a particle/polymer mixture to fabricate microfluidic–electrochemical devices on polyethylene terephthalate (PET) films. Printed devices with no electrode modification were demonstrated to have the lowest limit of detection (LOD) of 7 μM for [...] Read more.
Free-standing capillary microfluidic channels were directly printed over printed electrodes using a particle/polymer mixture to fabricate microfluidic–electrochemical devices on polyethylene terephthalate (PET) films. Printed devices with no electrode modification were demonstrated to have the lowest limit of detection (LOD) of 7 μM for sensing glucose. The study shows that both a low polymer concentration in the mixture for printing the microfluidic channels and surface modification of the printed microfluidic channels using 3-aminopropyltrimethoxysilane can substantially boost the device’s performance. It also shows that both device structure and enzyme doping level of the devices play an important role in ensuring the best performance of the devices under various testing conditions. Full article
(This article belongs to the Special Issue Micro-/Nano Biomedical Point-of-Care Devices)
Show Figures

Figure 1

18 pages, 28128 KB
Article
All Screen Printed and Flexible Silicon Carbide NTC Thermistors for Temperature Sensing Applications
by Arjun Wadhwa, Jaime Benavides-Guerrero, Mathieu Gratuze, Martin Bolduc and Sylvain G. Cloutier
Materials 2024, 17(11), 2489; https://doi.org/10.3390/ma17112489 - 22 May 2024
Cited by 6 | Viewed by 3551
Abstract
In this study, Silicon Carbide (SiC) nanoparticle-based serigraphic printing inks were formulated to fabricate highly sensitive and wide temperature range printed thermistors. Inter-digitated electrodes (IDEs) were screen printed onto Kapton® substrate using commercially avaiable silver ink. Thermistor inks with different weight ratios [...] Read more.
In this study, Silicon Carbide (SiC) nanoparticle-based serigraphic printing inks were formulated to fabricate highly sensitive and wide temperature range printed thermistors. Inter-digitated electrodes (IDEs) were screen printed onto Kapton® substrate using commercially avaiable silver ink. Thermistor inks with different weight ratios of SiC nanoparticles were printed atop the IDE structures to form fully printed thermistors. The thermistors were tested over a wide temperature range form 25 °C to 170 °C, exhibiting excellent repeatability and stability over 15 h of continuous operation. Optimal device performance was achieved with 30 wt.% SiC-polyimide ink. We report highly sensitive devices with a TCR of −0.556%/°C, a thermal coefficient of 502 K (β-index) and an activation energy of 0.08 eV. Further, the thermistor demonstrates an accuracy of ±1.35 °C, which is well within the range offered by commercially available high sensitivity thermistors. SiC thermistors exhibit a small 6.5% drift due to changes in relative humidity between 10 and 90%RH and a 4.2% drift in baseline resistance after 100 cycles of aggressive bend testing at a 40° angle. The use of commercially available low-cost materials, simplicity of design and fabrication techniques coupled with the chemical inertness of the Kapton® substrate and SiC nanoparticles paves the way to use all-printed SiC thermistors towards a wide range of applications where temperature monitoring is vital for optimal system performance. Full article
Show Figures

Figure 1

12 pages, 2460 KB
Article
All-Printed Flexible Memristor with Metal–Non-Metal-Doped TiO2 Nanoparticle Thin Films
by Maryam Khan, Hafiz Mohammad Mutee Ur Rehman, Rida Tehreem, Muhammad Saqib, Muhammad Muqeet Rehman and Woo-Young Kim
Nanomaterials 2022, 12(13), 2289; https://doi.org/10.3390/nano12132289 - 3 Jul 2022
Cited by 28 | Viewed by 4480
Abstract
A memristor is a fundamental electronic device that operates like a biological synapse and is considered as the solution of classical von Neumann computers. Here, a fully printed and flexible memristor is fabricated by depositing a thin film of metal–non-metal (chromium-nitrogen)-doped titanium dioxide [...] Read more.
A memristor is a fundamental electronic device that operates like a biological synapse and is considered as the solution of classical von Neumann computers. Here, a fully printed and flexible memristor is fabricated by depositing a thin film of metal–non-metal (chromium-nitrogen)-doped titanium dioxide (TiO2). The resulting device exhibited enhanced performance with self-rectifying and forming free bipolar switching behavior. Doping was performed to bring stability in the performance of the memristor by controlling the defects and impurity levels. The forming free memristor exhibited characteristic behavior of bipolar resistive switching with a high on/off ratio (2.5 × 103), high endurance (500 cycles), long retention time (5 × 103 s) and low operating voltage (±1 V). Doping the thin film of TiO2 with metal–non-metal had a significant effect on the switching properties and conduction mechanism as it directly affected the energy bandgap by lowering it from 3.2 eV to 2.76 eV. Doping enhanced the mobility of charge carriers and eased the process of filament formation by suppressing its randomness between electrodes under the applied electric field. Furthermore, metal–non-metal-doped TiO2 thin film exhibited less switching current and improved non-linearity by controlling the surface defects. Full article
(This article belongs to the Special Issue Nanomaterials for Electron Devices)
Show Figures

Figure 1

12 pages, 2769 KB
Article
Portable Photovoltaic-Self-Powered Flexible Electrochromic Windows for Adaptive Envelopes
by Antonio Cánovas-Saura, Ramón Ruiz, Rodolfo López-Vicente, José Abad, Antonio Urbina and Javier Padilla
Electron. Mater. 2021, 2(2), 174-185; https://doi.org/10.3390/electronicmat2020014 - 2 Jun 2021
Cited by 5 | Viewed by 3887
Abstract
Variable transmission applications for light control or energy saving based on electrochromic materials have been successfully applied in the past in the building, sports, or automotive fields, although lower costs and ease of fabrication, installation, and maintenance are still needed for deeper market [...] Read more.
Variable transmission applications for light control or energy saving based on electrochromic materials have been successfully applied in the past in the building, sports, or automotive fields, although lower costs and ease of fabrication, installation, and maintenance are still needed for deeper market integration. In this study, all-printed large area (900 cm2 active area) flexible electrochromic devices were fabricated, and an autoregulating self-power supply was implemented through the use of organic solar cells. A new perspective was applied for automotive light transmission function, where portability and mechanical flexibility added new features for successful market implementation. Special emphasis was placed in applying solution-based scalable deposition techniques and commercially available materials (PEDOT-PSS as an electrochromic material; vanadium oxide, V2O5, as a transparent ion-storage counter electrode; and organic solar modules as the power supply). A straightforward electronic control method was designed and successfully implemented allowing for easy user control. We describe a step-by-step route following the design, materials optimization, electronic control simulation, in-solution fabrication, and scaling-up of fully functional self-powered portable electrochromic devices. Full article
(This article belongs to the Special Issue Feature Papers of Electronic Materials)
Show Figures

Graphical abstract

13 pages, 3274 KB
Article
Inkjet-Printed Molybdenum Disulfide and Nitrogen-Doped Graphene Active Layer High On/Off Ratio Transistors
by Mohi Uddin Jewel, Mahmuda Akter Monne, Bhagyashree Mishra and Maggie Yihong Chen
Molecules 2020, 25(5), 1081; https://doi.org/10.3390/molecules25051081 - 28 Feb 2020
Cited by 22 | Viewed by 4277
Abstract
Fully inkjet-printed device fabrication is a crucial goal to enable large-area printed electronics. The limited number of two-dimensional (2D) material inks, the bottom-gated structures, and the low current on/off ratio of thin-film transistors (TFTs) has impeded the practical applications of the printed 2D [...] Read more.
Fully inkjet-printed device fabrication is a crucial goal to enable large-area printed electronics. The limited number of two-dimensional (2D) material inks, the bottom-gated structures, and the low current on/off ratio of thin-film transistors (TFTs) has impeded the practical applications of the printed 2D material TFTs. In the search for TFTs with high current ratios, we introduce a stable and efficient method of nitrogen-doped graphene (NDG) ink preparation for inkjet printing by liquid-phase exfoliation. The NDG thin film is print-stacked with molybdenum disulfide (MoS2) by multiple printing passes to construct a MoS2–NDG stack. We demonstrate top-gated fully inkjet-printed MoS2–NDG transistors with silver drain, source, and gate electrodes, and a barium titanate (BaTiO3) dielectric. A 100% inkjet-printed MoS2–NDG vertical 2D active heterostructure layer transistor with a current on/off ratio of 1200 is exhibited. The results may lead towards the development of all-printed 2D material-based transistor switches. Full article
(This article belongs to the Special Issue Optical Properties of Nanomaterials)
Show Figures

Figure 1

10 pages, 3839 KB
Letter
Printing the Ultra-Long Ag Nanowires Inks onto the Flexible Textile Substrate for Stretchable Electronics
by Sheng-Hai Ke, Qing-Wen Xue, Chuan-Yuan Pang, Pan-Wang Guo, Wei-Jing Yao, He-Ping Zhu and Wei Wu
Nanomaterials 2019, 9(5), 686; https://doi.org/10.3390/nano9050686 - 2 May 2019
Cited by 31 | Viewed by 4959
Abstract
Printing technology offers a simple and cost-effective opportunity to develop all-printed stretchable circuits and electronic devices, possibly providing ubiquitous, low-cost, and flexible devices. To successfully prepare high-aspect-ratio Ag nanowires (NWs), we used water and anhydrous ethanol as the solvent and polyvinylpyrrolidone (PVP) as [...] Read more.
Printing technology offers a simple and cost-effective opportunity to develop all-printed stretchable circuits and electronic devices, possibly providing ubiquitous, low-cost, and flexible devices. To successfully prepare high-aspect-ratio Ag nanowires (NWs), we used water and anhydrous ethanol as the solvent and polyvinylpyrrolidone (PVP) as the viscosity regulator to obtain a water-soluble Ag NWs conductive ink with good printability. Flexible and stretchable fabric electrodes were directly fabricated through screen printing. After curing at room temperature, the sheet resistance of the Ag NW fabric electrode was 1.5 Ω/sq. Under a tensile strain of 0–80% and with 20% strains applied for 200 cycles, good conductivity was maintained, which was attributed to the inherent flexibility of the Ag NWs and the intrinsic structure of the interlocked texture. Full article
Show Figures

Figure 1

9 pages, 4683 KB
Article
All-Printed Human Activity Monitoring and Energy Harvesting Device for Internet of Thing Applications
by Shawkat Ali, Saleem Khan and Amine Bermak
Sensors 2019, 19(5), 1197; https://doi.org/10.3390/s19051197 - 8 Mar 2019
Cited by 15 | Viewed by 4253
Abstract
A self-powered device for human activity monitoring and energy harvesting for Internet of Things (IoT) devices is proposed. The self-powered device utilizes flexible Nano-generators (NGs), flexible diodes and off-the-shelf capacitors. During footsteps the NGs generate an AC voltage then it is converted into [...] Read more.
A self-powered device for human activity monitoring and energy harvesting for Internet of Things (IoT) devices is proposed. The self-powered device utilizes flexible Nano-generators (NGs), flexible diodes and off-the-shelf capacitors. During footsteps the NGs generate an AC voltage then it is converted into DC using rectifiers and the DC power is stored in a capacitor for powering the IoT devices. Polydimethylsiloxane (PDMS) and zinc stannate (ZnSnO3) composite is utilized for the NG active layer, indium tin oxide (ITO) and aluminum (Al) are used as the bottom and top electrodes, respectively. Four diodes are fabricated on the bottom electrode of the NG and connected in bridge rectifier configuration. A generated voltage of 18 Vpeak was achieved with a human footstep. The self-powered smart device also showed excellent robustness and stable energy scavenger from human footsteps. As an application we demonstrate human activity detection and energy harvesting for IoT devices. Full article
