Search Results (110)

Search Parameters:
Keywords = all-inorganic perovskite

Order results
Result details
Results per page
Select all
Export citation of selected articles as:
11 pages, 5145 KiB
Article
Island-like Perovskite Photoelectric Synaptic Transistor with ZnO Channel Layer Deposited by Low-Temperature Atomic Layer Deposition
by Jiahui Liu, Yuliang Ye and Zunxian Yang
Materials 2025, 18(12), 2879; https://doi.org/10.3390/ma18122879 - 18 Jun 2025
Viewed by 358
Abstract
Artificial photoelectric synapses exhibit great potential for overcoming the Von Neumann bottleneck in computational systems. All-inorganic halide perovskites hold considerable promise in photoelectric synapses due to their superior photon-harvesting efficiency. In this study, a novel wavy-structured CsPbBr3/ZnO hybrid film was realized [...] Read more.
Artificial photoelectric synapses exhibit great potential for overcoming the Von Neumann bottleneck in computational systems. All-inorganic halide perovskites hold considerable promise in photoelectric synapses due to their superior photon-harvesting efficiency. In this study, a novel wavy-structured CsPbBr3/ZnO hybrid film was realized by depositing zinc oxide (ZnO) onto island-like CsPbBr3 film via atomic layer deposition (ALD) at 70 °C. Due to the capability of ALD to grow high-quality films over small surface areas, dense and thin ZnO film filled the gaps between the island-shaped CsPbBr3 grains, thereby enabling reduced light-absorption losses and efficient charge transport between the CsPbBr3 light absorber and the ZnO electron-transport layer. This ZnO/island-like CsPbBr3 hybrid synaptic transistor could operate at a drain-source voltage of 1.0 V and a gate-source voltage of 0 V triggered by green light (500 nm) pulses with low light intensities of 0.035 mW/cm2. The device exhibited a quiescent current of ~0.5 nA. Notably, after patterning, it achieved a significantly reduced off-state current of 10−11 A and decreased the quiescent current to 0.02 nA. In addition, this transistor was able to mimic fundamental synaptic behaviors, including excitatory postsynaptic currents (EPSCs), paired-pulse facilitation (PPF), short-term to long-term plasticity (STP to LTP) transitions, and learning-experience behaviors. This straightforward strategy demonstrates the possibility of utilizing neuromorphic synaptic device applications under low voltage and weak light conditions. Full article
(This article belongs to the Section Electronic Materials)
Show Figures

Graphical abstract

12 pages, 3483 KiB
Article
A Cascade Bilayer Electron-Transporting Layer for Enhanced Performance and Stability of Self-Powered All-Inorganic Perovskite Photodetectors
by Yu Hyun Kim and Jae Woong Jung
Molecules 2025, 30(10), 2195; https://doi.org/10.3390/molecules30102195 - 17 May 2025
Viewed by 452
Abstract
This study aims to enhance optoelectronic properties of all-inorganic perovskite photodetectors (PDs) by incorporating a bilayer electron transport layer (ETL). The bilayer ETL composed of SnO2 and ZnO effectively optimizes energy level alignment at the interface, facilitating efficient electron extraction from the [...] Read more.
This study aims to enhance optoelectronic properties of all-inorganic perovskite photodetectors (PDs) by incorporating a bilayer electron transport layer (ETL). The bilayer ETL composed of SnO2 and ZnO effectively optimizes energy level alignment at the interface, facilitating efficient electron extraction from the CsPbI2Br perovskite layer while suppressing shunt pathways. Additionally, it enhances interfacial properties by mitigating defects and minimizing dark current leakage, thereby improving overall device performance. As a result, the bilayer ETL-based PDs exhibit broadband photoresponsivity in 300 to 700 nm with a responsivity of 0.45 A W−1 and a specific detectivity of 9 × 1013 Jones, outperforming the single-ETL devices. Additionally, they demonstrate stable cyclic photoresponsivity with fast response times (14 μs for turn-on and 32 μs for turn-off). The bilayer ETL also improves long-term reliability and thermal stability, highlighting its potential for high performance, reliability, and practical applications of all-inorganic perovskite PDs. Full article
(This article belongs to the Special Issue Chemistry Innovatives in Perovskite Based Materials)
Show Figures

Figure 1

13 pages, 2446 KiB
Article
A Novel Pathogen Detection System Combining a Nucleic Acid Extraction Biochip with a Perovskite Photodetector
by Zhuo Gao, Pan Wang, Chang Chen, Jian Duan, Shilun Feng and Bo Liu
Micromachines 2025, 16(5), 581; https://doi.org/10.3390/mi16050581 - 15 May 2025
Viewed by 2622
Abstract
The increasing spread of infectious diseases caused by pathogenic microorganisms underscores the urgent need for highly sensitive, portable, and rapid nucleic acid detection technologies to facilitate early diagnosis and effective prevention. In this study, we developed a fluorescence-based nucleic acid detection platform that [...] Read more.
The increasing spread of infectious diseases caused by pathogenic microorganisms underscores the urgent need for highly sensitive, portable, and rapid nucleic acid detection technologies to facilitate early diagnosis and effective prevention. In this study, we developed a fluorescence-based nucleic acid detection platform that integrates a microfluidic chip with an all-inorganic perovskite photodetector. The system enables integrated operation of nucleic acid extraction, purification, and amplification on a microfluidic chip, combined with real-time electrical signal readout via a CsPbBr3 perovskite photodetector. Experimental results indicate that the photodetector exhibits high responsivity at 530 nm, aligning well with the primary emission peak of FAM. The system demonstrates a strong linear correlation between photocurrent and FAM concentration over the range of 0.01–0.4 μM (R2 = 0.928), with a low detection limit of 0.01 μM and excellent reproducibility across multiple measurements. Validation using FAM standard solutions and Escherichia coli samples confirmed the system’s reliable linearity and signal stability. This platform demonstrates strong potential for rapid pathogen screening and point-of-care diagnostic applications. Full article
(This article belongs to the Special Issue Recent Progress of Lab-on-a-Chip Assays)
Show Figures

Figure 1

13 pages, 5562 KiB
Article
ZrBr4-Mediated Phase Engineering in CsPbBr3 for Enhanced Operational Stability of White-Light-Emitting Diodes
by Muhammad Amin Padhiar, Yongqiang Ji, Jing Wang, Noor Zamin Khan, Mengji Xiong and Shuxin Wang
Nanomaterials 2025, 15(9), 674; https://doi.org/10.3390/nano15090674 - 28 Apr 2025
Viewed by 460
Abstract
The persistent operational instability of all-inorganic cesium lead halide (CsPbX3) perovskite nanocrystals (NCs) has hindered their integration into white-light-emitting diodes (WLEDs). This study introduces a transformative approach by engineering a phase transition from CsPbBr3 NCs to zirconium bromide (ZrBr4 [...] Read more.
The persistent operational instability of all-inorganic cesium lead halide (CsPbX3) perovskite nanocrystals (NCs) has hindered their integration into white-light-emitting diodes (WLEDs). This study introduces a transformative approach by engineering a phase transition from CsPbBr3 NCs to zirconium bromide (ZrBr4)-stabilized hexagonal nanocomposites (HNs) through a modified hot-injection synthesis. Structural analyses revealed that the ZrBr4-mediated phase transformation induced a structurally ordered lattice with minimized defects, significantly enhancing charge carrier confinement and radiative recombination efficiency. The resulting HNs achieved an exceptional photoluminescence quantum yield (PLQY) of 92%, prolonged emission lifetimes, and suppressed nonradiative decay, attributed to effective surface passivation. The WLEDs with HNs enabled a breakthrough luminous efficiency of 158 lm/W and a record color rendering index (CRI) of 98, outperforming conventional CsPbX3-based devices. The WLEDs exhibited robust thermal stability, retaining over 80% of initial emission intensity at 100 °C, and demonstrated exceptional operational stability with negligible PL degradation during 50 h of continuous operation at 100 mA. Commission Internationale de l’Éclairage (CIE) coordinates of (0.35, 0.32) validated pure white-light emission with high chromatic fidelity. This work establishes ZrBr4-mediated HNs as a paradigm-shifting material platform, addressing critical stability and efficiency challenges in perovskite optoelectronics and paving the way for next-generation, high-performance lighting solutions. Full article
(This article belongs to the Special Issue Recent Advances in Halide Perovskite Nanomaterials)
Show Figures

Figure 1

13 pages, 3476 KiB
Article
Preparation of Highly Efficient and Stable All-Inorganic Perovskite Solar Cells in Atmosphere Environment
by Yufan Jiang, Dongdong Deng and Jingjing Dong
Energies 2025, 18(9), 2162; https://doi.org/10.3390/en18092162 - 23 Apr 2025
Viewed by 393
Abstract
All-inorganic CsPbX3 perovskites have significant potential for applications in the photovoltaic field. However, during their preparation, the slow evaporation rate of the precursor solution limits the extent of solution supersaturation, leading to porous perovskite films that substantially impair device performance. Anti-solvent engineering, [...] Read more.
All-inorganic CsPbX3 perovskites have significant potential for applications in the photovoltaic field. However, during their preparation, the slow evaporation rate of the precursor solution limits the extent of solution supersaturation, leading to porous perovskite films that substantially impair device performance. Anti-solvent engineering, which introduces a secondary solvent to modulate the crystallization process, is a well established technique in perovskite photovoltaic research. This study systematically examines the effects of four different anti-solvents on perovskite films and corresponding devices. It also investigates the optimal dipping-time of (trifluoromethyl)benzene as an anti-solvent, as well as the impact of varying amounts of anti-solvent additive perfluorinated acid. The optimized devices achieved a maximum power conversion efficiency of 12.68%. Full article
Show Figures

Figure 1

10 pages, 1581 KiB
Article
Electronic Characteristics of Layered Heterostructures Based on Graphene and Two-Dimensional Perovskites: First-Principle Study
by Lev Zubkov, Pavel Kulyamin, Konstantin Grishakov, Savaş Kaya, Konstantin Katin and Mikhail Maslov
Colloids Interfaces 2025, 9(2), 23; https://doi.org/10.3390/colloids9020023 - 10 Apr 2025
Cited by 1 | Viewed by 637
Abstract
Layered perovskites have been actively studied due to their outstanding electronic and optical properties as well as kinetic stability. Layered perovskites with hexagonal symmetry have special electronic properties, such as the Dirac cone in the band structure, similar to graphene. In the presented [...] Read more.
Layered perovskites have been actively studied due to their outstanding electronic and optical properties as well as kinetic stability. Layered perovskites with hexagonal symmetry have special electronic properties, such as the Dirac cone in the band structure, similar to graphene. In the presented study, the heterostructure of single-layer all-inorganic lead-free hexagonal perovskite of the A3B2X9 type (A = Cs, Rb, K; B = In, Sb; X = Cl, Br) and graphene (Gr) was studied. The structural and electronic characteristics of A3B2X9 and the A3B2X9/Gr composite were calculated using density functional theory. It was found that graphene is not deformed, while the main deformation is observed only in perovskite. B-X bonds have different sensitivities to stretching or compression. The Fermi level of the A3In2X9/Gr composite can be shifted down from the Dirac point, which can be used to create optoelectronic devices or as spacer layers for graphene-based resonant tunneling nanostructures. Full article
Show Figures

Graphical abstract

15 pages, 5983 KiB
Article
Mn2+-Doped CsPbBr2I Quantum Dots Photosensitive Films for High-Performance Photodetectors
by Mengwei Chen, Wei Huang, Chenguang Shen, Yingping Yang and Jie Shen
Nanomaterials 2025, 15(6), 444; https://doi.org/10.3390/nano15060444 - 15 Mar 2025
Viewed by 824
Abstract
The variable bandgap and high absorption coefficient of all-inorganic halide perovskite quantum dots (QDs), particularly CsPbBr2I make them highly promising for photodetector applications. However, their high defect density and poor stability limit their performance. To overcome these problems, Mn2+-doped [...] Read more.
The variable bandgap and high absorption coefficient of all-inorganic halide perovskite quantum dots (QDs), particularly CsPbBr2I make them highly promising for photodetector applications. However, their high defect density and poor stability limit their performance. To overcome these problems, Mn2+-doped CsPbBr2I QDs with varying concentrations were synthesized via the one-pot method in this work. By replacing Pb2+ ions, moderate Mn2+ doping caused lattice contraction and improved crystallinity. At the same time, Mn2+-doping effectively passivated surface defects, reducing the defect density by 33%, and suppressed non-radiative recombination, thereby improving photoluminescence (PL) intensity and carrier mobility. The optimized Mn:CsPbBr2I QDs-based photodetector exhibited superior performance, with a dark current of 1.19 × 10−10 A, a photocurrent of 1.29 × 10−5 A, a responsivity (R) of 0.83 A/W, a specific detectivity (D*) of 3.91 × 1012 Jones, an on/off ratio up to 105, and the response time reduced to less than 10 ms, all outperforming undoped CsPbBr2I QDs devices. Stability tests demonstrated enhanced durability, retaining 80% of the initial photocurrent after 200 s of cycling (compared to 50% for undoped devices) and stable operation over 20 days. This work offers a workable strategy for rational doping and structural optimization in the construction of high-performance perovskite optoelectronic devices. Full article
(This article belongs to the Special Issue Advances in Polymer Nanofilms)
Show Figures

Figure 1

12 pages, 3447 KiB
Article
High Performance Phototransistor Based on 0D-CsPbBr3/2D-MoS2 Heterostructure with Gate Tunable Photo-Response
by Chen Yang, Yangyang Xie, Lei Zheng, Hanqiang Liu, Peng Liu, Fang Wang, Junqing Wei and Kailiang Zhang
Nanomaterials 2025, 15(4), 307; https://doi.org/10.3390/nano15040307 - 17 Feb 2025
Cited by 2 | Viewed by 969
Abstract
Monolayer MoS2 has been widely researched in high performance phototransistors for its high carrier mobility and strong photoelectric conversion ability. However, some defects in MoS2, such as vacancies or impurities, provide more possibilities for carrier recombination; thus, restricting the formation [...] Read more.
Monolayer MoS2 has been widely researched in high performance phototransistors for its high carrier mobility and strong photoelectric conversion ability. However, some defects in MoS2, such as vacancies or impurities, provide more possibilities for carrier recombination; thus, restricting the formation of photocurrents and resulting in decreased responsiveness. Herein, all-inorganic CsPbBr3 perovskite quantum dots (QDs) with high photoelectric conversion efficiency and light absorption coefficients are introduced to enhance the responsivity of a 2D MoS2 phototransistor. The CsPbBr3/MoS2 heterostructure has a type II energy band, and it has a high responsivity of ~1790 A/W and enhanced detectivity of ~2.4 × 1011 Jones. Additionally, the heterostructure CsPbBr3/MoS2 enables the synergistic effect mechanism of photoconduction and photogating effects with the gate tunable photo-response, which could also contribute to an improved performance of the MoS2 phototransistor. This work provides new strategies for performance phototransistors and is expected to play an important role in many fields, such as optical communication, environmental monitoring and biomedical imaging, and promote the development and application of related technologies. Full article
(This article belongs to the Section Nanoelectronics, Nanosensors and Devices)
Show Figures

Figure 1

12 pages, 6486 KiB
Article
Few-Layered Black Phosphorene as Hole Transport Layer for Novel All-Inorganic Perovskite Solar Cells
by Shihui Xu, Lin Yang, Zhe Wang, Fuyun Li, Xiaoping Zhang, Juan Zhou, Dongdong Lv, Yunfeng Ding and Wei Sun
Materials 2025, 18(2), 415; https://doi.org/10.3390/ma18020415 - 17 Jan 2025
Cited by 1 | Viewed by 1008
Abstract
The CsPbBr3 perovskite exhibits strong environmental stability under light, humidity, temperature, and oxygen conditions. However, in all-inorganic perovskite solar cells (PSCs), interface defects between the carbon electrode and CsPbBr3 limit the carrier separation and transfer rates. We used black phosphorus (BP) [...] Read more.
The CsPbBr3 perovskite exhibits strong environmental stability under light, humidity, temperature, and oxygen conditions. However, in all-inorganic perovskite solar cells (PSCs), interface defects between the carbon electrode and CsPbBr3 limit the carrier separation and transfer rates. We used black phosphorus (BP) nanosheets as the hole transport layer (HTL) to construct an all-inorganic carbon-based CsPbBr3 perovskite (FTO/c-TiO2/m-TiO2/CsPbBr3/BP/C) solar cell. BP can enhance hole extraction capabilities and reduce carrier recombination by adjusting the interface contact between the perovskite and the carbon layer. Due to the coordination of the energy structure related to interface charge extraction and transfer, BP, as a new type of hole transport layer for all-inorganic CsPbBr3 solar cells, achieves a power conversion efficiency (PCE) that is 1.43% higher than that of all-inorganic carbon-based CsPbBr3 perovskite solar cells without a hole transport layer, reaching 2.7% (Voc = 1.29 V, Jsc = 4.60 mA/cm2, FF = 48.58%). In contrast, the PCE of the all-inorganic carbon-based CsPbBr3 perovskite solar cells without a hole transport layer was only 1.27% (Voc = 1.22 V, Jsc = 2.65 mA/cm2, FF = 39.51%). The unencapsulated BP-based PSCs device maintained 69% of its initial efficiency after being placed in the air for 500 h. In contrast, the efficiency of the PSC without HTL significantly decreased to only 52% of its initial efficiency. This indicates that BP can effectively enhance the PCE and stability of PSCs, demonstrating its great potential as a hole transport material in all-inorganic perovskite solar cells. BP as the HTL for CsPbBr3 PSCs can passivate the perovskite interface, enhance the hole extraction capability, and improve the optoelectronic performance of the device. The subsequent doping and compounding of the BP hole transport layer can further enhance its photovoltaic conversion efficiency in PSCs. Full article
Show Figures

Figure 1

28 pages, 7320 KiB
Review
Recent Advances in Lead-Free All-Inorganic Perovskite CsCdCl3 Crystals for Anti-Counterfeiting Applications
by Nankai Wang, Zhaojie Zhu, Jianfu Li, Chaoyang Tu, Weidong Chen and Yan Wang
Crystals 2024, 14(12), 1077; https://doi.org/10.3390/cryst14121077 - 13 Dec 2024
Cited by 1 | Viewed by 1289
Abstract
This study reviews the advanced anti-counterfeiting applications of CsCdCl3, a lead-free all-inorganic perovskite crystal exhibiting dynamic luminescent properties responsive to temperature and UV light. Using synthesis methods such as Bridgman and hydrothermal techniques and incorporating dopants like bromine and tellurium, this [...] Read more.
This study reviews the advanced anti-counterfeiting applications of CsCdCl3, a lead-free all-inorganic perovskite crystal exhibiting dynamic luminescent properties responsive to temperature and UV light. Using synthesis methods such as Bridgman and hydrothermal techniques and incorporating dopants like bromine and tellurium, this research achieves improved luminescent stability, spectral diversity, and afterglow characteristics in CsCdCl3. The crystal demonstrates extended afterglow, photochromic shifts, and temperature-sensitive luminescence, enabling applications in 4D encoding for secure data encryption and in cold-chain temperature monitoring for pharmaceuticals. Despite these promising attributes, the challenges related to photostability, batch consistency, and environmental resilience persist, necessitating further exploration into the optimized synthesis and doping strategies to enhance material stability. These findings underscore the potential of CsCdCl3 for high-security information storage, pharmaceutical anti-counterfeiting, and real-time environmental sensing, positioning it as a valuable material for the next generation of secure, intelligent packaging solutions. Full article
(This article belongs to the Special Issue Recent Development and Research Trend of Laser Crystals)
Show Figures

Figure 1

14 pages, 3831 KiB
Article
A-Site Ion Doping in Cs2AgBiBr6 Double Perovskite Films for Improved Optical and Photodetector Performance
by Yuejia Wu, Yanpeng Meng, Qirun Hu, Songchao Shen, Chengxi Zhang, Ang Bian and Jun Dai
Crystals 2024, 14(12), 1068; https://doi.org/10.3390/cryst14121068 - 12 Dec 2024
Cited by 2 | Viewed by 1533
Abstract
Perovskite materials, as emerging semiconductors, have attracted significant attention for their exceptional optoelectronic properties, tunable bandgaps, ease of fabrication, and cost-effectiveness, making them promising candidates for next-generation optoelectronic devices. The all-inorganic perovskite Cs2AgBiBr6 distinguishes itself from other perovskite materials due [...] Read more.
Perovskite materials, as emerging semiconductors, have attracted significant attention for their exceptional optoelectronic properties, tunable bandgaps, ease of fabrication, and cost-effectiveness, making them promising candidates for next-generation optoelectronic devices. The all-inorganic perovskite Cs2AgBiBr6 distinguishes itself from other perovskite materials due to its remarkable optical absorption and emission properties, excellent stability, prolonged carrier recombination lifetime, and nontoxic characteristics. However, a deeper understanding of its unique luminescent properties and a further optimization of its structure and performance are still necessary. This study systematically investigates the optimization of Cs2AgBiBr6 double perovskite films through A-site Na+ doping. At an optimal Na+ doping concentration of 3.5% (Na0.07Cs1.93AgBiBr6), the film shows 1.4 times and 2.7 times enhancement in light absorption and photoluminescence intensity, compared to the undoped film. Low-temperature spectroscopy measurements indicate that Na0.07Cs1.93AgBiBr6 exhibits higher exciton binding energy and phonon energy. Based on Na0.07Cs1.93AgBiBr6, the photodetectors demonstrate significant performance improvements, with a high photocurrent response of 10−2 A, a photo-to-dark current ratio (PDCR) of 7.57 × 104, a responsivity (R) of 16.23 A/W, a detectivity (D*) of 2.92 × 1012 Jones, a linear dynamic range (LDR) of 98.75 dB, and a fast response time of 943 ms. This work provides a promising strategy for optimizing all-inorganic perovskite materials through doping and offers guidance for enhancing high-performance photodetectors. Full article
(This article belongs to the Special Issue Novel Photoelectric Materials and Their Photophysical Processes)
Show Figures

Figure 1

10 pages, 3818 KiB
Article
Single CsPbBr3 Perovskite Microcrystals: From Microcubes to Microrods with Improved Crystallinity and Green Emission
by Khouloud Abiedh, Marco Salerno, Fredj Hassen and Zouhour Zaaboub
Materials 2024, 17(16), 4043; https://doi.org/10.3390/ma17164043 - 14 Aug 2024
Cited by 1 | Viewed by 1236
Abstract
All-inorganic perovskite materials are promising in optoelectronics, but their morphology is a key parameter for achieving high device efficiency. We prepared CsPbBr3 perovskite microcrystals with different shapes grown directly on planar substrate by conventional drop casting. We observed the formation of CsPbBr [...] Read more.
All-inorganic perovskite materials are promising in optoelectronics, but their morphology is a key parameter for achieving high device efficiency. We prepared CsPbBr3 perovskite microcrystals with different shapes grown directly on planar substrate by conventional drop casting. We observed the formation of CsPbBr3 microcubes on bare indium tin oxide (ITO)-coated glass. Interestingly, with the same technique, CsPbBr3 microrods were obtained on (3-Aminopropyl) triethoxysilane (APTES)-modified ITO-glass, which we ascribe to the modification of formation kinetics. The obtained microcrystals exhibit an orthorhombic structure. A green photoluminescence (PL) emission is revealed from the CsPbBr3 microrods. Contact angle measurements, Fourier-transform infrared and PL spectroscopies confirmed that APTES linked successfully to the ITO-glass substrate. We propose a qualitative mechanism to explain the anisotropic growth. The microrods exhibited improved PL and a slower PL lifetime compared to the microcubes, likely due to the diminished occurrence of defects. This work demonstrates the importance of the substrate surface to control the growth of perovskite single crystals and to boost the radiative recombination in view of high-performance optoelectronic devices. Full article
Show Figures

Figure 1

11 pages, 3988 KiB
Article
Preparation of Highly Efficient and Stable All-Inorganic CsPbBr3 Perovskite Solar Cells Using Pre-Crystallization Multi-Step Spin-Coating Method
by Yulong Zhang, Zhaoyi Jiang, Jincheng Li, Guanxiong Meng, Jiajun Guo and Weijia Zhang
Coatings 2024, 14(7), 918; https://doi.org/10.3390/coatings14070918 - 22 Jul 2024
Cited by 5 | Viewed by 2210
Abstract
All-inorganic CsPbBr3 perovskite solar cells have garnered extensive attention in the photovoltaic domain due to their remarkable environmental stability. Nevertheless, CsPbBr3 prepared using the conventional sequential deposition method suffers from issues such as inferior crystallinity, low phase purity, and poor film [...] Read more.
All-inorganic CsPbBr3 perovskite solar cells have garnered extensive attention in the photovoltaic domain due to their remarkable environmental stability. Nevertheless, CsPbBr3 prepared using the conventional sequential deposition method suffers from issues such as inferior crystallinity, low phase purity, and poor film morphology. Herein, we propose a pre-crystallization methodology by introducing a minute quantity of CsBr into the PbBr2 precursor solution to generate a small amount of CsPb2Br5 crystals within the PbBr2 film, leading to a porous PbBr2 film with enhanced crystallinity. Under the influence of more pores and CsPb2Br5 crystals as nucleation sites for inducing growth, a CsPbBr3 film with a larger crystal size, lower grain boundary density, stronger crystallinity, and higher phase purity is formed. Compared with untreated devices, photovoltaic devices prepared using the pre-crystallization method achieved a champion photovoltaic conversion efficiency (PCE) of 8.62%. Furthermore, pre-crystallized devices demonstrate higher stability than untreated ones and can still retain 94% of the original PCE after being exposed to air for 1000 h without encapsulating. Full article
Show Figures

Figure 1

13 pages, 4662 KiB
Article
In Situ Synthesis of CsPbX3/Polyacrylonitrile Nanofibers with Water-Stability and Color-Tunability for Anti-Counterfeiting and LEDs
by Yinbiao Shi, Xiaojia Su, Xiaoyan Wang and Mingye Ding
Polymers 2024, 16(11), 1568; https://doi.org/10.3390/polym16111568 - 1 Jun 2024
Cited by 3 | Viewed by 1488
Abstract
Inorganic CsPbX3 (X = Cl, Br, I) perovskite quantum dots (PQDs) have attracted widespread attention due to their excellent optical properties and extensive application prospects. However, their inherent structural instability significantly hinders their practical application despite their outstanding optical performance. To enhance [...] Read more.
Inorganic CsPbX3 (X = Cl, Br, I) perovskite quantum dots (PQDs) have attracted widespread attention due to their excellent optical properties and extensive application prospects. However, their inherent structural instability significantly hinders their practical application despite their outstanding optical performance. To enhance stability, an in situ electrospinning strategy was used to synthesize CsPbX3/polyacrylonitrile composite nanofibers. By optimizing process parameters (e.g., halide ratio, electrospinning voltage, and heat treatment temperature), all-inorganic CsPbX3 PQDs have been successfully grown in a polyacrylonitrile (PAN) matrix. During the electrospinning process, the rapid solidification of electrospun fibers not only effectively constrained the formation of large-sized PQDs but also provided effective physical protection for PQDs, resulting in the improvement in the water stability of PQDs by minimizing external environmental interference. Even after storage in water for over 100 days, the PQDs maintained approximately 93.5% of their photoluminescence intensity. Through the adjustment of halogen elements, the as-obtained composite nanofibers exhibited color-tunable luminescence in the visible light region, and based on this, a series of multicolor anti-counterfeiting patterns were fabricated. Additionally, benefiting from the excellent water stability and optical performance, the CsPbBr3/PAN composite film was combined with red-emitting K2SiF6:Mn4+ (KSF) on a blue LED (460 nm), producing a stable and efficient WLED device with a color temperature of around 6000 K and CIE coordinates of (0.318, 0.322). These results provide a general approach to synthesizing PQDs/polymer nanocomposites with excellent water stability and multicolor emission, thereby promoting their practical applications in multifunctional optoelectronic devices and advanced anti-counterfeiting. Full article
(This article belongs to the Special Issue New Advances in Polymer Electrospun Fibers)
Show Figures

Figure 1

18 pages, 4400 KiB
Article
Theoretical Study and Analysis of CsSnX3 (X = Cl, Br, I) All-Inorganic Perovskite Solar Cells with Different X-Site Elements
by Shiyu Yuan, Zhenzhen Li, Yitong Wang and Hang Zhao
Molecules 2024, 29(11), 2599; https://doi.org/10.3390/molecules29112599 - 31 May 2024
Cited by 9 | Viewed by 1794
Abstract
In this research, SCAPS-1D simulation software (Version: 3.3.10) was employed to enhance the efficiency of CsSnX3 (X = Cl, Br, I) all-inorganic perovskite solar cells. By fine-tuning essential parameters like the work function of the conductive glass, the back contact point, defect [...] Read more.
In this research, SCAPS-1D simulation software (Version: 3.3.10) was employed to enhance the efficiency of CsSnX3 (X = Cl, Br, I) all-inorganic perovskite solar cells. By fine-tuning essential parameters like the work function of the conductive glass, the back contact point, defect density, and the thickness of the light absorption layer, we effectively simulated the optimal performance of CsSnX3 (X = Cl, Br, I) all-inorganic perovskite solar cells under identical conditions. The effects of different X-site elements on the overall performance of the device were also explored. The theoretical photoelectric conversion efficiency of the device gradually increases with the successive substitution of halogen elements (Cl, Br, I), reaching 6.09%, 17.02%, and 26.74%, respectively. This trend is primarily attributed to the increasing size of the halogen atoms, which leads to better light absorption and charge transport properties, with iodine (I) yielding the highest theoretical conversion efficiency. These findings suggest that optimizing the halogen element in CsSnX3 can significantly enhance device performance, providing valuable theoretical guidance for the development of high-efficiency all-inorganic perovskite solar cells. Full article
(This article belongs to the Special Issue Chemical Properties of Photoelectric Materials)
Show Figures

Figure 1
