This study seeks to improve the performance of a low-temperature differential free-piston Stirling air conditioner (FPSAC). To achieve this, a novel approach is proposed, which replaces the conventional simple harmonic drive with a multi-harmonic drive. This modification aims to optimize the motion of the driving piston, bringing it closer to the ideal movement pattern. The research involves both thermodynamic and dynamic coupling simulations of the FPSAC, complemented by experimental verification of its key performance parameters. A thermodynamic model for the gas medium, employing a quasi-one-dimensional dynamic approach for compressible fluids, and a nonlinear two-dimensional vibration dynamic model for the solid piston are developed, focusing on the low-temperature differential FPSAC physical model. The finite difference method is employed to numerically simulate the entire system, including the electromagnetic thrust of the multi-harmonic-driven linear oscillating motor, fluid transport equations, and the nonlinear dynamic equations of the power and gas control pistons. Variations in displacement, velocity, and pressure for each control volume at any given time are obtained, along with the indicator and temperature–entropy diagrams after the system stabilizes. The simulation results show that, in cooling mode, assuming no heat loss or mechanical friction, the Stirling cooler operates at a frequency of 80 Hz. Using the COP_sin value for the simple harmonic drive as a baseline, performance is improved by altering the driving method. Under the multi-harmonic drive, the COP_c5 increased by 10.03% and COP_c7 by 14.23%. In heating mode, the COP under the multi-harmonic drive improved by 0.51% for COP_h5 and 2.61% for COP_h7. Performance experiments were conducted on the low-temperature differential FPSAC, and the key parameter test results showed good agreement with the simulation outcomes. The maximum deviation at the trough was found to be less than 2.45%, while at the peak, the maximum error did not exceed 3.61%. When compared to the simple harmonic drive, the application of the multi-harmonic drive significantly enhances the overall efficiency of the FPSAC, demonstrating its superior performance. The simulation analysis and experimental results indicate a significant improvement in the coefficient of performance of the Stirling cooler under the multi-harmonic drive at the same power level, demonstrating that the multi-harmonic drive is an effective approach for enhancing FPSAC performance. Furthermore, it should be noted that the method proposed in this study is applicable to other types of low-temperature differential free-piston Stirling air conditioners. Full article

This paper presents a parametric analysis of a $\beta$-type Stirling engine, focusing on the impact of various rotational speeds. The investigation employs a three-dimensional computational fluid analysis model. The study places emphasis on monitoring and understanding the temperature variations across the primary components of the engine, including the regenerator, heater, and cooler. The full apparatus is designed and simulated, acquiring the results for its energy output and thermal behavior.Using this CFD model, parameterization optimization is presented, aiming to establish the best conditions for the engine and regenerator efficiencies. Utilizing the results of the behavior of the machine, a correlation between the Nusselt and Reynolds numbers with regard to the rotational speeds is produced, giving a further understanding of the conduct of the working medium in the system. Full article

Space nuclear reactor power system (SNRPS) is a priority technical solution to meet the future space power requirement of high-power, low-mass, and long-life. The thermoelectric conversion subsystem is the key component of SNRPS, which greatly affects the performance, quality, and volume of SNRPS. Among all kinds of proposed thermoelectric conversion technologies, the free-piston Stirling power converter (FPSPC) has become a preferred conversion technology for small-scale advanced SNPRS due to its moderate waste heat emission temperature and high conversion efficiency, mainly composed of a linear alternator and free-piston Stirling engine (FPSE). For studying the performance of FPSPC, a quasi-steady flow thermodynamic cycle analysis model considering parasitic heat losses has been developed for FPSE. And then the performance analysis model for FPSPC has been established by coupling the thermodynamic cycle analysis model with the mechanical motion model of the piston and volt-ampere characteristic model of the linear alternator. Furthermore, the analysis model was compared and validated by the GPU-3 Stirling engine’s experimental data. The performance parameters of Component Test Power Converter (CTPT) FPSPC designed by NASA for SNRPS were also analyzed. The results show that the amplitudes position of CTPC displacer and piston are 15.1 mm and 11.2 mm, respectively. The corresponding average electric power output of CTPC is 17.316 kW. The input thermal power to the CTPT heater is 66.1 kW, leading to the converter efficiency of 26.2%. The average current and voltage of the CTPC alternator are 86.38 A and 193.15 V, respectively. Among all kinds of parasitic energy losses, the regenerator heat loss accounts for the largest proportion, with an average of about 12.7 kW. The effects of cooler and heater temperature on the performance of CTPC FPSPC were also studied. Full article

Vuilleumier machines are a promising technology for heating. Respective performances of Vuilleumier’s engine and cooler are generally unclear. In Stirling machines, performances can be determined based on PV power flow and heat flow methods. In this work, respective performances based on two methods in current Vuilleumier models were investigated. It was found that PV power flow and heat flow methods in current Vuilleumier models were ineffective for analysis of respective performances due to there being no piston as a boundary between Vuilleumier’s engine and cooler. Then, a virtual piston was assumed, and a virtual piston based Vuilleumier model (VPBVM) was developed. The relative Carnot efficiencies of the obtained engine and cooler were 53~64% and 43~49%, respectively, at conditions of 550 °C hot temperature, 50~70 °C warm temperature, and −20~10 °C cold temperature. The results indicated that respective performances obtained in VPBVM were reasonable. Moreover, the engine’s compression ratios could be obtained in VPBVM and were 1.2~1.24. Thus, VPBVM could be effective for the analysis of the Vuilleumier machine’s engine and cooler. Full article

In this paper, an evaluation of the performance and operating parameters of a hybrid compression/absorption chiller coupled with a low-capacity solar concentrator is presented. The study was carried out using energy and mass balances applied to each component of each system. The variables evaluated in the hybrid chiller were the cooling power, the supply power, the Coefficient of Performance (COP) of both cooling systems and the ratio between heat and power. The diameter and temperature of the hot spot as well as the performance of the dish collector were evaluated. The changed parameters were the heat removed by each refrigeration system, the condenser temperature, the evaporator temperature, the concentration ratio and the irradiance. Results have shown that the compression system can produce up to 53% more cooling power than the heat supplied to the hybrid system. Meanwhile, the absorption system produces approximately 20% less cooling power than the supplied heat. It has also been found that, for the cooling power produced by the hybrid cooler to be always greater than the heat supplied, the cooling power provided by the absorption system should preferably be between 20% and 60% of the total, with a Stirling engine efficiency between 0.2 and 0.3 and a condensation temperature from 28 to 37 °C. Likewise, it has been found that the compression system can produce cooling power up to 3 times higher than the heat of the Stirling engine hot source, with T_h = 200 °C and η_s = 0.3. Finally, it has been found that, in a low-capacity solar concentrator, on a typical day in Mexico City, temperatures in the hot spot between 200 and 400 °C can be reached with measured irradiance values from 200 to 1200 W/m². Full article

There is an increasing request in energy recovery systems that are more efficient, environmentally friendly and economical. The free piston Stirling engine has been investigated due to its structural simplicity and high efficiency, coupled with its cogeneration ability. This study presents the numerical investigation of quasi-steady model of a gamma type free piston Stirling engine (FPSE), including the thermodynamic analysis of the heat exchangers. Advanced thermodynamic models are employed to derive the initial set of operational parameters of the FPSE due to the coupling of the piston’s (displacer and piston) dynamics and the working process. The proximity effect of the heater and cooler on the regenerator effectiveness in relation to the heat losses, output power, net work and thermal efficiency of the FPSE are also observed and presented in this study. It can be observed that at temperatures of 541.3 °C and 49.8 °C of the heater and cooler, respectively, with heater volume of 0.004 m³, regenerator volume of 0.003 m³ and cooler volume of 0.005 m³, the FPSE produced an output performance of 996.7 W with a thermal efficiency of 23% at a frequency of 30 Hz. This approach can be employed to design effective high performance FPSE due to their complexity and also predict a satisfactory performance. Full article
