A frequency domain imaging algorithm, featured as joint two-dimensional (2D) time and frequency domain resampling, used for high-resolution high-squint large-scene (HHL) spaceborne sliding spotlight synthetic aperture radar (SAR) processing is proposed in this paper. Due to the nonlinear beam rotation during HHL data acquisition, the Doppler centroid varies nonlinearly with azimuth time and traditional sub-aperture approaches and two step approach fail to remove the inertial Doppler aliasing of spaceborne sliding spotlight SAR data. In addition, curved orbit effect and long synthetic aperture time make the range histories difficult to model and introduce space-variants in both range and azimuth. In this paper, we use the azimuth deramping and 2D time-domain azimuth resampling, collectively referred to as preprocessing, to eliminate the aliasing in Doppler domain and correct the range-dependent azimuth-variants of range histories. After preprocessing, the squint sliding spotlight SAR data could be considered as equivalent broadside strip-map SAR during processing. Frequency domain focusing, mainly involves phase multiplication and resampling in 2D frequency and RD domain, is then applied to compensate for the residual space-variants and achieve the focusing of SAR data. Moreover, in order to adapt higher resolution and larger scene cases, the combination of the proposed algorithm and partitioning strategy is also discussed in this paper. Processing results of simulation data and Gaofen-3 experimental data are presented to demonstrate the feasibility of the proposed methods. Full article

The spotlight image acquired by the Gaofen-3 satellite has a resolution of 1 m, which has great potential for 3-D localization. However, there have been no public reports on the 3-D localization accuracy evaluation of Gaofen-3 spotlight synthetic aperture radar (SAR) images. Here, three study areas were selected from this perspective, and the SAR spotlight stereo images of the study area were acquired using Gaofen-3. In the case of no ground control points (GCPs), based on the Rational Polynomial Coefficient (RPC) model, these images were used for initial 3-D localization; the plane accuracy was better than 10 m in general, and the elevation accuracy was worse than 37 m in general. Subsequently, the RPC model was optimized using geometric calibration technology, and the 3-D localization accuracy was assessed again. The elevation accuracy was significantly improved, which was generally better than 5 m. The plan accuracy was also improved, and it was generally better than 6 m. It can be seen that Gaofen-3 spotlight stereo images are of good quality, and high plane accuracy can be obtained even without GCPs. Geometric calibration technology improves the 3-D localization accuracy, and the elevation accuracy optimization effect is remarkable. Moreover, the optimization effect of plane accuracy is affected by the properties of stereo-image pairs. The optimization effect of plane accuracy is obvious for asymmetric stereo-image pairs, and the optimization effect of plane accuracy is general for symmetric stereo-image pairs. Full article

GaoFen-3 was the first Chinese civilian C-band synthetic aperture radar (SAR) satellite, launched in August 2016. The need for monitoring the satellite’s image quality has been boosted by its widespread applications in various fields. The efficient and scientific assessment of the system’s radiometric and polarimetric performance has been essential in its more than five years of service. The authors collected 90 images of the Inner Mongolia calibration site, 888 images of the Amazon rainforest, and 39,929 images of the Chinese mainland from 2017 to 2021. This was achieved whilst covering the leading imaging modes, such as the spotlight mode, stripmap mode, ultra-fine mode, wave imaging mode, etc. In this study, we derive a framework that incorporates the man-made corner reflectors (CRs) in Mongolia, the traditional Amazon rainforest datasets, and even the long-strip data in the Chinese mainland (known as CRAS) for the purposes of GaoFen-3 radiometric quality analysis and polarimetric validation over its five years of operation. Polarimetric calibration without recourse to the CRs is utilized to measure the polarimetric distortions regardless of the region, and thus requires a higher calibration accuracy for the GaoFen-3 polarimetric monitoring task. Consequently, the modified Quegan method is developed by relaxing the target azimuth symmetry constraint with the Amazon forest datasets. The experiments based on the CRAS demonstrate that the main radiometric characteristics could reach the international level, with an estimated noise-equivalent sigma zero of approximately −30 dB, a radiometric resolution that is better than 2.9 dB, and a single-imagery relative radiation accuracy that is better than 0.51 dB. For polarimetric validation, the modified Quegan method was utilized to measure the crosstalk for quad-pol products to ensure that it was than −40 dB. Meanwhile, non-negligible channel imbalance errors were found in the QPSII and WAV modes, and they were effectively well-calibrated with strip estimators to satisfy the system design. Full article

On 23 November 2021, the Gaofen-3-02 (GF3-02) satellite was successfully launched in the Jiuquan Satellite Launch Center of China. The primary payload is C-band Synthetic Aperture Radar (SAR), with a maximum resolution of 1 m, and includes 12 imaging modes such as Spotlight, Strip, and TOPSAR, which will play an essential role in marine environment monitoring. As an important marine environmental parameter, the wind speed accuracy retrieved by GF3-02 SAR directly reflects its performance and effectiveness as an operational product. Therefore, based on the wind data of buoys of the National Data Buoy Center (NDBC), ECMWF reanalysis V5 (ERA5), and HY-2B Scatterometer (SCA), a preliminary accuracy assessment of the wind speed retrieved by GF3-02 SAR is carried out in this paper. The wind speed retrieval accuracy of GF3-02 SAR in the co-polarization (HH+VV) data under different Geophysical Model Functions (GMFs) is discussed by using 478 level-1A Single Look Complex (SLC) ocean products acquired in Quad-Polarization Strip I (QPSI) and produced by the National Satellite Ocean Application Service (NSOAS) from January to March 2022. The results show that the optimal root mean square errors (RMSE) are 1.40 m/s, 1.18 m/s, and 1.24 m/s for the VV polarization and 1.39 m/s, 1.19 m/s, and 1.52 m/s for the HH polarization compared to the NDBC wind speed, the ERA5 wind speed, and the HY-2B SCA wind speed, respectively. The preliminary results show that GF3-02 SAR has good wind speed retrieval ability and can meet the needs of operational products. Full article

High resolution synthetic aperture radar (SAR) imaging has extensive application value especially in military reconnaissance and disaster monitoring. The motion of the satellite during the transmission and reception of the signal introduces notable errors in the high resolution SAR spotlight mode, which will lead to a defocused SAR image if not handled. To address this problem, an accurate correct echo model based on non-start-stop model is derived to describe the property of the SAR signal in the paper. Then, in the imaging processing, an azimuth-time-varying range frequency modulation rate is used for range compression. The range history and compensation phase are also derived based on the correct echo model. Then, combining the correct echo model and Cartesian factorized backprojection (CFBP) algorithm, a modified CFBP algorithm is proposed for SAR imaging to improve the accuracy and efficiency of processing. Besides, the influence of residual error due to mismatch is analyzed in detail. In the end, the simulation experiment and Gaofen-3 (GF-3) data experiment are carried out to demonstrate the feasibility of the proposed algorithm. Full article

Due to self-motion and sea waves, moving ships are typically defocused in synthetic aperture radar (SAR) images. To focus non-cooperative targets, the inverse SAR (ISAR) technique is commonly used with motion compensation. The hybrid SAR/ISAR approach allows a long coherent processing interval (CPI), in which SAR targets are processed with ISAR processing, and exploits the advantages of both SAR and ISAR to generate well-focused images of moving targets. In this paper, based on hybrid SAR/ISAR processing, we propose an improved rank-one phase estimation method (IROPE). By using an iterative two-step convergence approach in the IROPE, the proposed method achieves accurate phase error, maintains robustness to noise and performs well in estimating various phase errors. The performance of the proposed method is analyzed by comparing it with other focusing algorithms in terms of processing simulated data and real complex image data acquired by Gaofen-3 (GF-3) in spotlight mode. The results demonstrate the effectiveness of the proposed method. Full article

Spaceborne spotlight SAR mode has drawn attention due to its high-resolution capability, however, the studies about moving target detection with this mode are less. The paper proposes an image sequence-based method entitled modified logarithm background subtraction to detect ground moving targets with Gaofen-3 Single Look Complex (SLC) spotlight SAR images. The original logarithm background subtraction method is designed by our team for airborne SAR. It uses the subaperture image sequence to generate a background image, then detects moving targets by using image sequence to subtract background. When we apply the original algorithm to the spaceborne spotlight SAR data, a high false alarm problem occurs. To tackle the high false alarm problem due to the target’s low signal-to-noise-ratio (SNR) in spaceborne cases, several improvements are made. First, to preserve most of the moving target signatures, a low threshold CFAR (constant false alarm rate) detector is used to get the coarse detection. Second, because the moving target signatures have higher density than false detections in the coarse detection, a modified DBSCAN (density-based spatial-clustering-of-applications-with-noise) clustering method is then adopted to reduce false alarms. Third, the Kalman tracker is used to exclude the residual false detections, due to the real moving target signature having dynamic behavior. The proposed method is validated by real data, the shown results also prove the feasibility of the proposed method for both Gaofen-3 and other spaceborne systems. Full article

Spotlight synthetic aperture radar (SAR) is a proven technique, which can provide high-resolution images as compared to those produced by traditional stripmap SAR. This paper addresses a high-resolution SAR focusing experiment based on Gaofen-3 satellite (GF-3) staring data with about 55 cm azimuth resolution and 240 MHz range bandwidth. In staring spotlight (ST) mode, the antenna always illuminates the same scene on the ground, which can extend the synthetic aperture. Based on a two-step processing algorithm, some special aspects such as curved-orbit model error correction, stop-and-go correction, and antenna pattern demodulation must be considered in image focusing. We provide detailed descriptions of all these aspects and put forward corresponding solutions. Using these suggested methods directly in an imaging module without any modification for other data processing software can make the most of the existing ground data processor. Finally, actual data acquired in GF-3 ST mode is used to validate these methodologies, and a well-focused, high-resolution image is obtained as a result of this focusing experiment. Full article

Gaofen-3 (GF-3) is China’ first C-band multi-polarization synthetic aperture radar (SAR) satellite, which also provides the sliding spotlight mode for the first time. Sliding-spotlight mode is a novel mode to realize imaging with not only high resolution, but also wide swath. Several key technologies for sliding spotlight mode in spaceborne SAR with high resolution are investigated in this paper, mainly including the imaging parameters, the methods of velocity estimation and ambiguity elimination, and the imaging algorithms. Based on the chosen Convolution BackProjection (CBP) and PFA (Polar Format Algorithm) imaging algorithms, a fast implementation method of CBP and a modified PFA method suitable for sliding spotlight mode are proposed, and the processing flows are derived in detail. Finally, the algorithms are validated by simulations and measured data. Full article

Synthetic aperture radar (SAR) sliding spotlight work mode can achieve high resolutions and wide swath (HRWS) simultaneously by steering the radar antenna beam. This paper aims to obtain well focused images using sliding spotlight mode with the Chinese Gaofen-3 SAR sensor. We proposed an integrated imaging scheme with sliding spotlight echoes. In the imaging scheme, the two-step approach is applied to the spaceborne sliding spotlight SAR imaging algorithm, followed by the Doppler parameter estimation algorithm. The azimuth spectral folding phenomenon is overcome by the two-step approach. The results demonstrate a high Doppler parameter estimation accuracy. The proposed imaging process is accurate and highly efficient for sliding spotlight SAR mode. Full article

The GaoFen-3 (GF-3) satellite is the first C-band multi-polarization synthetic aperture radar (SAR) imaging satellite with a resolution up to 1 m in China. It is also the only SAR satellite of the High-Resolution Earth Observation System designed for civilian use. There are 12 different imaging models to meet the needs of different industry users. However, to use SAR satellite images for related applications, they must possess high geometric accuracy. In order to verify the geometric accuracy achieved by the different modes of GF-3 images, we analyze the SAR geometric error source and perform geometric correction tests based on the RPC model with and without ground control points (GCPs) for five imaging modes. These include the spotlight (SL), ultra-fine strip (UFS), Fine Strip I (FSI), Full polarized Strip I (QPSI), and standard strip (SS) modes. Experimental results show that the check point residuals are large and consistent without GCPs, but the root mean square error of the independent checkpoints for the case of four corner control points is better than 1.5 pixels, achieving a similar level of geometric positioning accuracy to that of international satellites. We conclude that the GF-3 satellite can be used for high-accuracy geometric processing and related industry applications. Full article
