Search Results (7)

Search Parameters:
Keywords = E-plane HPBW

Order results
Result details
Results per page
Select all
Export citation of selected articles as:
16 pages, 12555 KiB
Article
A Dual-Band Low-Profile Microstrip Antenna with Fan-Shaped and Rectangular Beams
by Xue-Ping Li, Meng-Meng Li, Jun-Fei Ji, Qian-Qian Sun, Wei Li and An-Xue Zhang
Electronics 2023, 12(19), 4040; https://doi.org/10.3390/electronics12194040 - 26 Sep 2023
Viewed by 1458
Abstract
In this article, a dual-frequency microstrip antenna capable of radiating sector beams and rectangular beams is designed. Firstly, the characteristic mode of microstrip antennas is analyzed, and the principle of half-power beam width (HPBW) enhancement of microstrip antennas is studied from the mode [...] Read more.
In this article, a dual-frequency microstrip antenna capable of radiating sector beams and rectangular beams is designed. Firstly, the characteristic mode of microstrip antennas is analyzed, and the principle of half-power beam width (HPBW) enhancement of microstrip antennas is studied from the mode combination theory. Studies have shown that when multiple eigenmodes are excited simultaneously at the same frequency point, the radiation modes can be combined to widen the E-plane HPBW. The measurement results indicate that the S11 of the antenna in the two frequency bands is less than −25 dB. In particular, the microstrip antenna E-plane HPBW of the design received a 60° extension. While radiating a wide fan bundle at low frequency points, the HPBW of the E plane extends significantly to 141°. Radiate rectangular beams at high frequency points have an H-plane HPBW beam width of 90° and an E-plane HPBW beam width of 100°. Full article
(This article belongs to the Section Microwave and Wireless Communications)
Show Figures

Figure 1

13 pages, 5399 KiB
Article
A Novel Dual-Polarized Magnetoelectric Dipole Antenna and Its Array for LTE and 5G Sub-6 GHz Base Station Applications
by Zhiwei Song and Junwu Qi
Entropy 2023, 25(2), 274; https://doi.org/10.3390/e25020274 - 2 Feb 2023
Cited by 1 | Viewed by 3114
Abstract
This study presents a novel dual-polarized magnetoelectric dipole antenna and its array with director and rectangular parasitic metal patches for LTE and 5G sub-6 GHz base station applications. This antenna is composed of L-shaped magnetic dipoles, planar electric dipoles, rectangular director, rectangular parasitic [...] Read more.
This study presents a novel dual-polarized magnetoelectric dipole antenna and its array with director and rectangular parasitic metal patches for LTE and 5G sub-6 GHz base station applications. This antenna is composed of L-shaped magnetic dipoles, planar electric dipoles, rectangular director, rectangular parasitic metal patches, and η-shaped feed probes. The gain and bandwidth were enhanced by using the director and parasitic metal patches. The measured impedance bandwidth of the antenna was 82.8% (1.62–3.91 GHz, VSWR < 1.5), and its gain was 10 ± 0.5 dBi. The profile of the antenna unit, operated at 1.7 GHz, was only 42 mm (0.227λ0, where λ0 represents the free space wavelength corresponding to the lowest resonance frequency point). Subsequently, four antenna units were arranged in a line array with 0.6λ0 spacing. Both the antenna and its array were fabricated and measured. The measurement results show that the array has good radiation characteristics, such as broad bandwidth covering 1.65–3.97 GHz (VSWR < 1.5), high gain (its gain was great than 15.2 dBi), and high radiation efficiency (>90%). Its HPBWs were 63° ± 4° and 15° ± 2° for H- and E-planes, respectively. The design can cover TD-LTE and 5G sub-6 GHz NR n78 frequency bands very well, meaning that this is a good candidate antenna for base station applications. Full article
(This article belongs to the Special Issue Progress and Research Challenges to Catalyze B5G and 6G)
Show Figures

Figure 1

15 pages, 13359 KiB
Article
Miniaturized Parasitic Loaded High-Isolation MIMO Antenna for 5G Applications
by Kiran Chand Ravi and Jayendra Kumar
Sensors 2022, 22(19), 7283; https://doi.org/10.3390/s22197283 - 26 Sep 2022
Cited by 24 | Viewed by 2446
Abstract
In this paper, a multiple-input–multiple-output (MIMO) antenna is reported for 5G frequency range-2 (FR-2), 28 GHz bands. The MIMO antenna is developed in multiple iterations, including single-element design, cross-polarization reduction, and mutual coupling reduction. Initially, a single-element coplanar edge feed rectangular patch antenna [...] Read more.
In this paper, a multiple-input–multiple-output (MIMO) antenna is reported for 5G frequency range-2 (FR-2), 28 GHz bands. The MIMO antenna is developed in multiple iterations, including single-element design, cross-polarization reduction, and mutual coupling reduction. Initially, a single-element coplanar edge feed rectangular patch antenna is designed and the E-plane cross-polarization is reduced by −13 dB by trimming the forward corners of the patch. The ground plane is truncated to improve the −3 dB half-power-beamwidth (HPBW). A multi-wavelength spiral inspired parasitic surrounding the single element antenna is loaded, and performance analysis is performed. This parasitic element is used for self-field cancelation for the MIMO configuration. Two MIMO configurations, one with linear and the second with inverted elements, are developed and investigated. The first configuration is found to have better isolation of less than −25 dB compared to the −20 dB of the second configuration. Similarly, the gain of 4.8 dBi, the bandwidth of 3 GHz, envelope correlation coefficient (ECC) of 0.01, and diversity gain (DG) of 9.99 dB are superior to the second configuration. To validate the work, one of two MIMO configurations is fabricated and good agreement is found between simulation and measurement results. Full article
Show Figures

Figure 1

10 pages, 6503 KiB
Article
Effects of Mutual Coupling on Gain and Beam Width of a Linear Array of a Dielectric Resonator Antenna for Main Beam Scanning Applications
by Jamal Nasir, Aftab Ahmad Khan, Shoaib Khaliq, Muhammad Bilal Qureshi, Irfan Ullah, Leo Liu and Raheel Nawaz
Sensors 2022, 22(18), 6820; https://doi.org/10.3390/s22186820 - 9 Sep 2022
Viewed by 2303
Abstract
The effects of mutual coupling on the scanning characteristics of a four-element linear rectangular dielectric resonator antenna array (RDRA) are investigated for different inter-element spacing in this work. In particular, the gain and half-power beam width (HPBW) of an RDRA are studied for [...] Read more.
The effects of mutual coupling on the scanning characteristics of a four-element linear rectangular dielectric resonator antenna array (RDRA) are investigated for different inter-element spacing in this work. In particular, the gain and half-power beam width (HPBW) of an RDRA are studied for various scan angles in the E- and H-plane configurations. It is shown that for both the E and H planes, mutual coupling has an adverse effect on the performance of both phased array configurations. The H-plane array, however, is more stable than the E-plane array in terms of a gain and beam width performance comparison. The HPBW increases and gain decreases more in the E plane than the H plane when the scan angle is increased. Full article
(This article belongs to the Section Communications)
Show Figures

Figure 1

12 pages, 4428 KiB
Article
High Gain SIW H-Plane Horn Antenna with 3D Printed Parasitic E-Plane Horn
by Sheng Huang, King Yuk Chan, Yu Wang and Rodica Ramer
Electronics 2021, 10(19), 2391; https://doi.org/10.3390/electronics10192391 - 30 Sep 2021
Cited by 8 | Viewed by 4117
Abstract
Substrate integrated waveguide (SIW) technology that combines 3D and 2D structures has been successfully utilized due to its notable advantages, including in its application to H-plane horn antennas. As this type of antenna is commonly constructed on thin substrates, the E-plane radiation pattern [...] Read more.
Substrate integrated waveguide (SIW) technology that combines 3D and 2D structures has been successfully utilized due to its notable advantages, including in its application to H-plane horn antennas. As this type of antenna is commonly constructed on thin substrates, the E-plane radiation pattern is always wide, thereby limiting the achievable gain performance. In this work, we propose an approach that incorporates 3D printed horns on a prefabricated SIW H-plane horn antenna to successfully narrow the E-plane radiation pattern, thereby improving the gain performance. The proposed E-plane horn is designed at the aperture of the original H-plane horn, providing a smooth and continuous wave transition from the thin substrate to the end-fire direction. This approach improves the directional radiation performance significantly and reduces fabrication time and associated difficulties as the parasitic structures are simply attached to the SIW horn, without the requirement of redesigning or refabricating the original antenna. From 20 to 25 GHz, an optimized prototype shows excellent performance. At 22.7 GHz, it exhibits 35° and 33° for the E- and H-plane half-power beamwidths (HPBWs), with corresponding side-lobe levels (SLLs) of −23 dB and −15 dB. The present research reveals that the proposed design presents high feasibility and a reduced demand for high-precision manufacturing processes at a lower cost, concomitantly providing an effective means to further improve on the radiation characteristics. Full article
(This article belongs to the Section Microwave and Wireless Communications)
Show Figures

Figure 1

11 pages, 3900 KiB
Communication
Analysis of Patch Antenna with Broadband Using Octagon Parasitic Patch
by Sun-Woong Kim, Ho-Gyun Yu and Dong-You Choi
Sensors 2021, 21(14), 4908; https://doi.org/10.3390/s21144908 - 19 Jul 2021
Cited by 11 | Viewed by 4701
Abstract
This paper proposes a novel broadband octagonal patch antenna with parasitic patches. The proposed patch antenna is constructed with four parasitic patches around a central radiating octagonal element. It is illustrated that this arrangement can be used to improve the antenna bandwidth and [...] Read more.
This paper proposes a novel broadband octagonal patch antenna with parasitic patches. The proposed patch antenna is constructed with four parasitic patches around a central radiating octagonal element. It is illustrated that this arrangement can be used to improve the antenna bandwidth and gain when compared with that of conventional antennas. The proposed patch antenna is very simple, low-profile, and economical. The typical analysis of the proposed antenna is analyzed by the S11(S-parameter), the radiation pattern, and the realized gain. It can achieve an impedance bandwidth of 1.44 GHz and a high gain of 8.56 dBi in the 8.5 GHz band. Furthermore, the proposed antenna shows that the directional pattern and HPBW measurement results of E and H-plane were 70° and 74° at 8.5 GHz, and 74° and 83° at 9 GHz, and 47° and 42° at 9.5 GHz, respectively. Full article
(This article belongs to the Section Communications)
Show Figures

Figure 1

14 pages, 1514 KiB
Article
Triangular Slot-Loaded Wideband Planar Rectangular Antenna Array for Millimeter-Wave 5G Applications
by Iftikhar Ahmad, Houjun Sun, Umair Rafique and Zhang Yi
Electronics 2021, 10(7), 778; https://doi.org/10.3390/electronics10070778 - 25 Mar 2021
Cited by 12 | Viewed by 3187
Abstract
This paper presents a design of a triangular slot-loaded planar rectangular antenna array for wideband millimeter-wave (mm-wave) 5G communication systems. The proposed array realizes an overall size of 35.5 × 14.85 mm2. To excite the array elements, a four-way broadband corporate [...] Read more.
This paper presents a design of a triangular slot-loaded planar rectangular antenna array for wideband millimeter-wave (mm-wave) 5G communication systems. The proposed array realizes an overall size of 35.5 × 14.85 mm2. To excite the array elements, a four-way broadband corporate feeding network was designed and analyzed. The proposed array offered a measured impedance bandwidth in two different frequency ranges, i.e., from 23 to 24.6 GHz and from 26 to 45 GHz. The single-antenna element of the array consists of a rectangular patch radiator with a triangular slot. The partial ground plane was used at the bottom side of the substrate to obtain a wide impedance bandwidth. The peak gain in the proposed array is ≈12 dBi with a radiation efficiency of >90%. Furthermore, the array gives a half-power beamwidth (HPBW) of as low as 12.5°. The proposed array has been fabricated and measured, and it has been observed that the measured results are in agreement with the simulated data. Full article
(This article belongs to the Section Microwave and Wireless Communications)
Show Figures

Figure 1
