Search Results (33)

When wind turbines contribute to system frequency support using virtual synchronous generator (VSG) control, conventional VSG methods often fall short of meeting operational demands, particularly in terms of inertia and frequency support. In this study, considering both the frequency regulation and dynamic performance of VSG, a novel parameter design method that enhances frequency modulation capabilities is proposed in this paper. Initially, VSG control is integrated into the grid-side converter of a direct-drive permanent magnet synchronous generator (D-DPMSG) wind turbine. A small-signal model of the D-DPMSG-VSG active power is then formulated to analyze how the moment of inertia and damping coefficient impact system stability. Subsequently, ensuring that system parameter constraints are met, the key parameters of VSG are adaptively designed to dynamically adjust the system’s frequency and output power during transient responses. Finally, simulation results based on D-DPMSG-VSG in MATLAB/Simulink validated the feasibility, effectiveness, and advantages of the proposed parameter-adaptive VSG control strategy for enhancing the frequency modulation (FM) performance of wind turbines. Full article

The captured energy of a wind turbine (WT) can be converted into electricity by a generator. Therefore, to improve the efficiency of this system, both the structures of WTs and generators should be considered for control. But the present challenge is WT uncertainty, while the input signals to the generator should be smooth. In this paper, a permanent magnet synchronous generator (PMSG) is considered. The dynamics of the PMSG can be described using two axes, named d-q reference frameworks, with an input in each framework direction. To obtain the maximum power and to overcome the uncertainty by means of a smooth signal, the dynamic sliding mode controller (D-SMC) is implemented. In the D-SMC, an integrator is placed in the control scheme in order to suppress the chattering, because it acts like a low-pass filter. To estimate the state added by the integrator, a new observer-based neural network (ONN) is proposed. The proof of the stability of the D-SMC and ONN is based on Lyapunov theory. To prove the advantages of the D-SMC, a comparison was also carried out by traditional sliding mode control (T-SMC) with a similar ONN. From this comparison, we know that the advantages of the D-SMC are clear in terms of real implementation, concept, and chattering suppression. Full article

Background: Three-dimensional (3D) printing is becoming increasingly popular around the world not only in engineering but also in the medical industry. This trend is visible, especially in aortic modeling for both training and treatment purposes. As a result of advancements in 3D technology, patients can be offered personalized treatment of aortic lesions via physician-modified stent grafts (PMSG), which can be tailored to the specific vascular conditions of the patient. The objective of this systematic review was to investigate the utility of 3D printing in PMSG in aortic lesion repair by examining procedure time and complications. Methods: The systematic review has been performed using the PRISMA 2020 Checklist and PRISMA 2020 flow diagram and following the Cochrane Handbook. The systematic review has been registered in the International Prospective Register of Systematic Reviews: CRD42024526950. Results: Five studies with a total number of 172 patients were included in the final review. The mean operation time was 249.95± 70.03 min, and the mean modification time was 65.38 ± 10.59 min. The analysis of the results indicated I² of 99% and 100% indicating high heterogeneity among studies. The bias assessment indicated the moderate quality of the included research. Conclusions: The noticeable variance in the reviewed studies’ results marks the need for larger randomized trials as clinical results of 3D printing in PMSG have great potential for patients with aortic lesions in both elective and urgent procedures. Full article

This paper studies the stability of a real-world wind farm, Bison Wind Generation System (BWGS) in the state of North Dakota in the United States. BWGS uses an AC collector grid rated at 34.5 kV and a symmetrical bipolar high-voltage DC (HVDC) transmission grid rated at ±250 kV. The HVDC line transfers a total power of 0.5 GW, while both the HVDC rectifier and inverter substations use line-commuted converters (LCCs). The LCC-based rectifier adopts constant DC current control to regulate HVDC current, while the inverter operates in constant extinction angle control mode to maintain a fixed HVDC voltage. This paper proposes a frequency scan-based approach to obtain the d–q impedance model of (i) BWGS AC collector grids with Type 4 wind turbines that use permanent magnet synchronous generators (PMSGs) and two fully rated converters, and (ii) an LCC-HVDC system. The impedance frequency response of the BWGS is acquired by exciting the AC collector grid and LCC-HVDC with multi-sine voltage perturbations during its steady-state operation. The resulting voltage and current signals are subjected to a fast Fourier transform (FFT) to extract frequency components. By analyzing the impedance frequency response measurement of BWGS, a linear time–invariant (LTI) representation of its dynamics is obtained using the vector fitting (VF) technique. Finally, a Bode plot is applied, considering the impedance of the BWGS and grid to perform stability analyses. This study examines the influence of the short circuit ratio (SCR) of the grid and the phase lock loop (PLL) frequency bandwidth on the stability of the overall system. The findings provide valuable insights for the design and verification of an AC collector and LCC-based HVDC transmission systems. The findings suggest that the extraction of the impedance model of a real-world wind farm, achieved through frequency scanning and subsequent representation as an LTI system using VF, is regarded as a robust, suitable, and accurate methodology for investigating the dynamics, unstable operating conditions, and control interaction of the wind farm and LCC-HVDC system with the AC grid. Full article

At present, most studies use the direct method to analyze the oscillation problem of modern power systems. However, these studies often only simplify the external characteristics of the wind turbine and lack an in-depth understanding of its internal refined energy structure. In this paper, based on the direct-drive permanent magnetic synchronous generator’s detailed model (D-PMSG), combined with the dynamic energy of its port, layers of analysis are performed on the wind turbine’s internal connections, and a detailed model of the energy structure is created. Then, the interaction mechanism of each control link in the wind turbine is analyzed by combining the energy function of the wind turbine with the improved perturbation method. Finally, this paper constructs a sub-synchronous oscillation (SSO) scenario of weak damping and a forcing type and proves the accuracy and effectiveness of the traceability method based on the refined energy of D-PMSG. This traceability method based on refined energy is expected to provide a new solution to the stability problem caused by the integration of new energy. Full article

Integrating wind power generators, whose frequency varies in a wide range due to varying wind speeds, into a grid is a formidable problem. At present, the use of permanent magnet synchronous generators (PMSG) and doubly fed induction generators (DFIG) as wind generators with suitable control is the best possible solution. However, a dual-field excited synchronous generator (DESG), which has two windings on the rotor, can also be used for the same purpose with appropriate control. A new control strategy, which essentially employs the d-axis and q-axis components of the alternator terminal voltage, is suggested here. This strategy essentially results in exciting the two field windings with a slip frequency. This eventually holds the stator frequency constant, irrespective of the rotor speed of the wind generator. The difference between the required frequency and the natural frequency, analogous to the rotor speed of the wind power generator, is the slip frequency. The ring modulator automatically adjusts the slip frequency depending on the actual speed of the generator’s rotor. This paper uses the ANSYS MAXWELL 2022 R1 software to design a DESG and uses a ring modulator as the control function generator for feedback with ANSYS TWIN BUILDER 2022 R1. Simulations are carried out using transient–transient co-simulation by combining both of these software tools for cases of both a constant-speed input and of a variable-speed input to the rotor of the machine. Moreover, a mathematical model of the DESG as a wind generator with the proposed controlled strategy is used to perform the stability analysis of a nine-bus three-machine system, and the results are compared with those of conventional wind generators. Full article

Ensuring the quality and stability of the electrical grid is of utmost importance during the phase of electrical energy production. As wind energy plays an increasingly significant role in a country’s energy composition, maintaining stability and optimal quality has emerged as a prerequisite for the generated electricity. This article aims to devise a dynamic nonlinear algorithm that can be implemented in the wind energy conversion system (WECS) featuring a direct-drive permanent magnet synchronous generator (PMSG). Notably, the adaptive backstepping control relies on the nonlinear model of the controlled system. It harnesses the principles of the Lyapunov stability theory to regulate various parameters and uphold the overall system’s stability. Employing simulation analysis through the Matlab–Simulink environment, the proposed control strategy is evaluated using a 1.5 MW wind turbine. The results showcase the robust capability of the suggested control algorithm: it effectively maintains the DC bus voltage and produces high-quality electrical energy with a total harmonic distortion (THD) below 0.38%. Moreover, the algorithm demonstrates added resilience. The practical viability of the adaptive control algorithm is validated through an experimental study on the dSPACE DS1104 prototyping platform. This study underscores the algorithm’s proficiency in achieving all control objectives under diverse wind scenarios. Full article

In order to solve the current fluctuation problem in microgrids, a suppression method called the Direct-driven Permanent Magnet Synchronous Generator (DPMSG)-based Wind Power System (WPS) based on an adaptive enhanced moving average filter algorithm is proposed. Firstly, the mathematical model of the WPS is established. On this basis, the suppression method under unbalanced conditions is derived by the instantaneous power equation to ensure the stable operation of the microgrid. In order to improve the dynamic compensation capability of the DPMSG-based WPS, an enhanced moving average filtering algorithm with frequency adaptability is proposed. The positive and negative sequence components are obtained in the dq frame by this filtering algorithm. Subsequently, the angular frequency of the microgrid is obtained according to the changing phase, which realizes the high-performance control of the WPS and avoids the complicated parameter adjustment of traditional methods. The correctness of this method is verified by the simulation results. The DPMSG-based WPS with the proposed method can improve the stability of the microgrid. Full article

The equine chorionic girdle is comprised of specialized invasive trophoblast cells that begin formation approximately 25 days after ovulation (day 0) and invade the endometrium to become endometrial cups. These specialized trophoblast cells transition from uninucleate to differentiated binucleate trophoblast cells that secrete the glycoprotein hormone equine chorionic gonadotropin (eCG; formerly known as pregnant mare serum gonadotropin or PMSG). This eCG has LH-like activity in the horse but variable LH- and FSH-like activity in other species and has been utilized for these properties both in vivo and in vitro. To produce eCG commercially, large volumes of whole blood must be collected from pregnant mares, which negatively impacts equine welfare due to repeated blood collections and the birth of an unwanted foal. Attempts to produce eCG in vitro using long-term culture of chorionic girdle explants have not been successful beyond 180 days, with peak eCG production at 30 days of culture. Organoids are three-dimensional cell clusters that self-organize and can remain genetically and phenotypically stable throughout long-term culture (i.e., months). Human trophoblast organoids have been reported to successfully produce human chorionic gonadotropin (hCG) and proliferate long-term (>1 year). The objective of this study was to evaluate whether organoids derived from equine chorionic girdle maintain physiological functionality. Here we show generation of chorionic girdle organoids for the first time and demonstrate in vitro production of eCG for up to 6 weeks in culture. Therefore, equine chorionic girdle organoids provide a physiologically representative 3D in vitro model for chorionic girdle development of early equine pregnancy. Full article

This paper proposes a model predictive controller (MPC) design based on the optimal tip-speed ratio method for maximum power point tracking (MPPT) of a direct-driven permanent magnet synchronous generator (D-PMSG)-based wind energy conversion system (WECS). To eliminate system nonlinearity and time-varying characteristics, a control variable was added at the wind turbine and the system model was feedback-linearized to create a linear time-invariant system, reducing the computational burden of the MPC and improving system performance. MATLAB/Simulink simulations were performed and the results show that the linearized system has high fidelity. Compared to traditional MPC that use an operating point to linearize the system, it has better adaptability to turbulent wind speeds, improving the stability and rapidity of the system. Full article

The synergetic control technique (SCT) has the solution for understanding the symmetry inherent in the non-linear properties of wind turbines (WTs); therefore, they achieve excellent performance and enhance the operation of the WT. Small-scale WTs are efficient and cost-effective; they are usually installed close to where the generated electricity is used. This technology is gaining popularity worldwide for off-grid electricity generation, such as in rural homes, farms, small factories, and commercial properties. To enhance the efficiency of the WT, it is vital to operate the WT at its maximum power. This work proposes an efficient and fast maximum power point tracking (MPPT) technique based on the SCT to eradicate the drawbacks of the conventional methods and enhance the operation of the WT at the MPP regardless of wind speed and load changes. The SCT has advantages, such as robustness, simplified design, fast response, no requirement for knowledge of WT characteristics, no need for wind sensors or intricate power electronics, and straightforward implementation. Furthermore, it improves speed convergence with minimal steady-state oscillations at the MPP. The investigated configuration involves a wind-driven permanent magnet synchronous generator (PMSG), uncontrolled rectifier, boost converter, and variable load. The two converters are used to integrate the PMSG with the load. Three scenarios (step changes in wind speed, stochastic changes in wind speed, and variable electrical load) are studied to assess the SCT. The results prove a high performance of the suggested MPPT control method for a fast convergence speed, boosted WT efficacy, low oscillation levels, and applicability under a variety of environmental situations. This work used the MATLAB/Simulink program and was then implemented on a dSPACE 1104 control board to assess the efficacy of the SCT. Furthermore, experimental validation on a 1 kW Darrieus-type WT driving a PMSG was performed. Full article

Due to the intense penetration of wind energy into the power grid, grid quality and stability have become a crucial necessity in this type of power generation. It is in this context that this article has just designed an Adaptive Nonlinear Control strategy applied to the Permanent Magnet Synchronous Generator (PMSG) of 1.5 MW power, in order to generate good quality and cleanly usable energy. Interestingly, this robust control algorithm mainly uses the Lyapunov stability theory, which ensures the stability of the Wind Energy Conversion System (WECS), and therefore offers excellent results in the presence of system parametric uncertainties and changes in the elements of the external environment. To this end, the methodology followed in this in-depth study focuses on the application of the Adaptive Backstepping Control algorithm for WECS by exploiting the MATLAB/Simulink toolbox. The theoretical study and simulation of the WECS was supported by the Processor-in-the-Loop (PIL) implantation of the control in the dSPACE DS1104 embedded board to approve the effect of the control in terms of robustness against different wind profiles and parametric changes. ST-LINK communication is used to connect the embedded board and the host computer. The results obtained revealed a fast response of the different signals, a practically low ripple rate of the order of 0.1% and minor overshoots for the different electrical quantities. Operation with a unity power factor is well ensured via this control strategy. Therefore, the adaptive control applied to the WECS has verified the high performance offered and benefits from additional robustness properties. Full article

Renewable energy will play a vital role in greenhouse gas emissions reduction. However, renewable energy is located far away from the load center. Modular multilevel converter-(MMC) based VSC-HVDC systems became competitive for remotely located renewable energy grid integration. Unlike the average model for MMC and renewable energy side converter, this paper presents a detailed model-based control and analysis of the MMC-HVDC system for solar and wind energy integration. Furthermore, it optimally tracks PV energy employing the modified incremental conductance method and wind energy using field-oriented control. Instead of decoupled control, a feedforward controller is utilized to establish a standalone AC voltage for renewable energy grid integration. This work considers a doubly fed induction generator (DFIG), permanent magnet synchronous generator (PMSG), and squirrel cage induction generator (SCIG) for wind energy integration. The results from MATLAB/SIMULINK platform agree with the controller hardware in the loop results from RTDS-dSPACE platform. The results confirmed the optimum solar and wind energy tracking during wind speed, irradiance, and temperature variations. However, it improved the fault ride-through capability during balanced and unbalanced low voltage disturbances at the point of common coupling (PCC) of AC grid. Full article

The dynamics of wind power generation cannot be neglected in the modern power system and could have a great impact on the system dynamics, even raising the risk of a blackout. Because of this, power system simulation has to include the model of wind power generation. However, due to the high order of the full model of the wind power generator, it is impossible to model them in detail in the use of the power system dynamic simulation considering the thousands of wind generators in the grid. In this context, a simplified model is normally used with the trade-off in lower accuracy. As a direct-drive permanent magnet synchronous wind power generation system (D-PMSG) would take up a certain occupation in the modern power system, a proper D-PMSG simplified model is needed in the power system simulation. For a different research purpose in a different timescale, a different complexity of the model can be used to maximize the accuracy, in the meantime speeding up the simulation. This paper proposes a set of simplified models of the direct-drive permanent magnet synchronous wind power generation system (D-PMSG) and classifies them according to the timescale of the dynamics and the use cases, i.e., faults (transient stability analysis), system contingencies (voltage and frequency stability analysis) and wind speed variations (energy transformation). The accuracy of the proposed simplified models is verified by comparing them with the detailed D-PMSG electromagnetic transient mode in Matlab/Simulink, and their use case of the power system simulation is validated based on the case study of the IEEE 39-bus system considering the above scenarios. Full article

This study deals with the characteristic analysis of a permanent magnet synchronous generator (PMSG) with a bolting and an overhang structure. Bolting is applied to a PMSG to prevent the defects caused by scattering. To compensate the flux reduction caused by the end effect and bolting material, an overhang structure is used for the permanent magnet machine. Therefore, an overhang structure must be considered in the three-dimensional (3D) analysis of a PMSG; however, such an analysis is time-intensive. To reduce the initial analysis time, we performed a semi-3D analysis of a PMSG considering a bolting and an overhang structure. Subsequently, we compared the output results of the characteristic analysis with a 3D finite element method and experimental results under loading. Full article
