Search Results (71)

Electrochemical formation of ceria (mixed Ce₂O₃ and CeO₂) coatings on different types of screen-printed carbon electrodes (SPCEs) (based on graphite (C110), carbon nanotubes (CNT), single-walled carbon nanotubes (SWCNT), carbon nanofibers (CNF), and mesoporous carbon (MC)) were studied. Their potential applications as catalysts for various redox reactions and electrochemical sensors were investigated. The ceria oxide layers were electrodeposited on SPCEs at various current densities and deposition time. The morphology, structure, and chemical composition in the bulk of the ceria layers were studied by SEM and EDS methods. XRD was used to identify the formed phases. The concentration, chemical composition and chemical state of the elements on the surface of studied samples were characterized by XPS. It was established that the increase of the concentration of CeCl₃ in the solution and the cathode current density strongly affected the surface structure and concentration (relation between Ce³⁺ and Ce⁴⁺, respectively) in the formed ceria layers. At low concentration of CeCl₃ (0.1M) and low values of cathode current density (0.5 mA·cm⁻²), porous samples were obtained, while with their increase, the ceria coatings grew denser. Full article

Organic hybrid materials are gaining traction as electrode candidates for energy storage due to their structural tunability and environmental compatibility. This study investigates polyimide/carbon nanotube/polypyrrole (PI/CNTs/PPy) hybrid nanocomposites, focusing on the correlation between thermal imidization temperature, polypyrrole deposition time, and the resulting electrochemical properties. By modulating PI processing temperatures (90 °C, 180 °C, 250 °C) and PPy deposition durations (60–700 s), this research uncovers critical structure–function relationships governing charge storage behavior. Scanning electron microscopy and electrochemical impedance spectroscopy reveal that low-temperature imidization preserves porosity and enables ion-accessible pathways, while moderate PPy deposition enhances electrical conductivity without blocking pore networks. The optimized composite, processed at 90 °C with 60 s PPy deposition, demonstrates superior specific capacitance (850 F/g), high redox contribution (~70% of total charge), low charge transfer resistance, and enhanced energy/power density. In contrast, high-temperature processing and prolonged PPy deposition result in structural densification, increased resistance, and diminished performance. These findings highlight a synergistic design approach that leverages partial imidization and controlled doping to balance ionic diffusion, electron transport, and redox activity. The results provide a framework for developing scalable, high-performance, and sustainable electrode materials for next-generation lithium-ion batteries and supercapacitors. Full article

One of the challenging problems in the research and development of vibration sensors relates to the formation of Ohmic contacts for the removal of an electrical signal. In some cases, it is proposed to use arrays of carbon nanotubes (CNTs), which can serve as highly elastic electrode materials for vibration sensors. The purpose of this work is to study the effect of a current-collecting layer of CNTs grown over silicon on the properties of a lead zirconate titanate (PZT) film, which is frequently employed in mechanical vibration sensors or energy harvesters. For the experiments, a vibration sensor mock-up was created with the PZT-CNT-Ni-V-SiO₂-Si and PZT-CNT-Ni-V-Si structures where an array of vertically oriented CNTs was grown over an oxidized or high-alloyed silicon substrates by plasma chemical deposition from a gas phase. Then, a thin film of PZT was applied to the CNT layer with a high-frequency reactive plasma spraying. For comparison, the PZT film was applied to silicon without a CNT layer (PZT-Si structure). The calculated average value of the piezoelectric module is 112 pm/V for the Ni-PZT-PT-Ni-Si-SiO₂ sample, and 35 pm/V for PZT-Ni-SiO₂-Si. It can be seen that the contact realized with the help of CNT ensures more than three times the best efficiency in terms of the piezoelectric module. The value of the piezoelectric module of the vibration sensor with the PZT-CNT-Ni-V-Si structure was 186 pm/V, and the value of the residual polarization was 23.2 µC/cm², which is more than eight and three times, respectively, higher than the values of these properties for the vibration sensor with the PZT-Si structure. It is shown that the vibration sensor can operate in the frequency range of 0.1–10 kHz. Full article

The possibility of directly growing carbon nanofibers (CNFs) and carbon nanotubes (CNTs) on half-Heusler alloys by Chemical Vapour Deposition (CVD) is investigated for the first time, without using additional catalysts, since the half-Heusler alloys per se may function as catalytic substrates, according to the findings of the current study. As a carbon source, acetylene is used in the temperature range of 700–750 °C. The n-type half-Heusler compound ${\left({\mathrm{Z}\mathrm{r}}_{0.4}{\mathrm{T}\mathrm{i}}_{0.6}\right)}_{0.33}{\mathrm{N}\mathrm{i}}_{0.33}{\left({\mathrm{S}\mathrm{n}}_{0.98}{\mathrm{S}\mathrm{b}}_{0.02}\right)}_{0.33}$ is utilized as the catalytic substrate. At first, a computational model is developed for the CVD reactor, aiming to optimize the experimental process design and setup. The experimental process conditions are simulated to investigate the reactive species concentrations within the reactor chamber and the activation of certain reactions. SEM analysis confirms the growth of CNFs with diameters ranging from 450 nm to 1 μm. Raman spectroscopy implies that the formed carbon structures resemble CNFs rather than CNTs, and that amorphous carbon also co-exists in the deposited samples. From the characterization results, it may be concluded that a short reaction time and a low acetylene flow rate lead to the formation of a uniform CNF coating on the surface of half-Heusler alloys. The purpose of depositing carbon nanostructures onto half-Heusler alloys is to improve the current transfer, generated from these thermoelectric compounds, by forming a conductive coating on their surface. Full article

This article presents, for the first time, a comparative analysis of the emission characteristics of large-area field-effect cathodes (LAFE) based on carbon nanotubes (CNTs) of various morphologies according to key parameters using a unique computerized technique. The work presents a description of a technology for creating various CNT arrays and their comprehensive structure characterization. All CNT arrays synthesized by the catalytic PECVD method on a silicon substrate showed a high degree of chemical purity under the presented technological conditions. In some cases, nanoisland films of Fe were used as a catalyst; in others, thin films of NiO were used, which were deposited on a silicon wafer by chemical vapor deposition (CVD) and atomic layer deposition (ALD), respectively. As a result of these studies, it turned out that an array with a thick CNT coating has good resistance to the action of strong electric fields, fairly good uniformity of distribution of emission centers, a fairly high selection current (2.88 mA/cm² at 4.53 V/μm), and compliance with the normal current mode according to the “orthodox” test, which makes the morphology of such structures the most promising for further technological optimization of CNT-based cathodes for various practical applications. Full article

In this study, a multiwalled carbon nanotube (MWCNT) dispersion is used as an ink for a single-nozzle inkjet printing system to produce a planar coil that can be used to determine strain wirelessly. The MWCNT dispersion is non-covalently functionalized by dispersing the CNTs in an anionic surfactant, namely sodium dodecyl sulfate (SDS). The fabrication parameters, such as sonication energy and centrifugation time, are optimized to obtain an aqueous suspension suitable for an inkjet printer. Planar coils with different design parameters are printed on a flexible polyethylene terephthalate (PET) polymer substrate. The design parameters include a different number of windings, inner diameter, outer diameter, and deposited layers. The electrical impedance spectroscopy (EIS) analysis is employed to characterize the printed planar coils, and an equivalent electrical circuit model is derived based on the results. Additionally, the radio frequency identification technique is utilized to wirelessly investigate the read-out mechanism of the printed planar MWCNT coils. The complex impedance of the inductively coupled sensor undergoes a shift under strain, allowing for the monitoring of changes in resonance frequency and bandwidth (i.e., amplitude). The proposed wireless strain sensor exhibits a remarkable gauge factor of 22.5, which is nearly 15 times higher than that of the wireless strain sensors based on conventional metallic strain gauges. The high gauge factor of the proposed sensor suggests its high potential in a wide range of applications, such as structural health monitoring, wearable devices, and soft robotics. Full article

In this study, we have improved the power factor of conductive polymer nanocomposites by combining layer-by-layer assembly with electrochemical deposition to produce flexible thermoelectric materials based on PEDOT/carbon nanotubes (CNTs)—films. To produce films based on CNTs and PEDOT, a dual approach has been employed: (i) the layer-by-layer method has been utilized for constructing the CNTs layer and (ii) electrochemical polymerization has been used in the synthesis of the conducting polymer. Moreover, the thermoelectric properties were optimized by controlling the experimental conditions including the number of deposition cycles and electropolymerizing time. The electrical characterization of the samples was carried out by measuring the Seebeck voltage produced under a small temperature difference and by measuring the electrical conductivity using the four-point probe method. The resulting values of the Seebeck coefficient S and σ were used to determine the power factor. The structural and morphological analyses of CNTs/PEDOT samples were carried out using scanning electron microscopy (SEM) and Raman spectroscopy. The best power factor achieved was 131.1 (μWm⁻¹K⁻²), a competitive value comparable to some inorganic thermoelectric materials. Since the synthesis of the CNT/PEDOT layers is rather simple and the ingredients used are relatively inexpensive and environmentally friendly, the proposed nanocomposites are a very interesting approach as an application for recycling heat waste. Full article

Low-temperature growth of diamond films using the chemical vapor deposition (CVD) method is not so widely reported and its initial periods of nucleation and growth phenomenon are of particular interest to the researchers. Four sets of substrates were selected for growing diamond films using linear antenna microwave plasma-enhanced CVD (LA-MPCVD). Among them, silicon and sapphire substrates were pre-treated with detonation nanodiamond (DND) seeds before diamond growth, for enhancement of its nucleation. Carbon nanotube (CNT) films on Si substrates were also used as another template for LA-MPCVD diamond growth. To enhance diamond nucleation during CVD growth, some of the CNT films were again pre-treated by the electrophoretic deposition (EPD) of diamond nanoparticles. All these substrates were then put inside the LA-MPCVD chamber to grow diamond films under variable processing conditions. Microwave input powers (1100–2800 W), input power modes (pulse or continuous), antenna-to-stage distances (5–6.5 cm), process gas recipes (with or without CO₂), methane gas percentages (3%–5%), and deposition times (11–120 min) were altered to investigate their effect on the growth of diamond film on the pre-treated substrates. The substrate temperatures were found to vary from as low as 170 °C to a maximum of 307 °C during the alteration of the different processing parameters. Contrary to the conventional MPCVD, it was observed that during the first hour of LA-MPCVD diamond growth, DND seeds and the nucleating structures do not coalesce together to make a continuous film. Deposition time was the most critical factor in fully covering the substrate surfaces with diamond film, since the substrate temperature could not become stable during the first hour of LA-MPCVD. CNTs were found to be oxidized rapidly under LA-MPCVD plasma conditions; therefore, a CO₂-free process gas recipe was used to reduce CNT burning. Moreover, EPD-coated CNTs were found to be less oxidized by the LACVD plasma during diamond growth. Full article

Global energy sources are limited, and energy requirements are ever-increasing due to the demand for developments in human life and technology. The environmentally friendly direct formic acid fuel cell (DFAFC) is an attractive electronic device due to its clean energy. In a DFAFC, an anodic catalyst plays an important role concerning the oxidation pathway and activity. In the present study, palladium (Pd) was synthesized by synchrotron X-ray photoreduction using various irradiation times (0.5–4 min) to control the particle size. An acid-treated carbon nanotube (A-CNT) was used as the template for Pd deposition. The A-CNT and Pd/A-CNT were examined using scanning electron microscopy, X-ray diffraction, Raman spectroscopy, and transmission electron microscopy to reveal the microstructural characteristics. Electrochemical evaluation, electrocatalytic activity, and the DFAFC performance of so-obtained Pd/A-CNT catalysts were investigated. The experiment’s results showed that the Pd/A-CNT-2 (i.e., synchrotron photoreduction for 2 min) underwent a direct formic acid oxidation pathway and possessed a high ECSA value of 62.59 m²/g_Pd and superior electrocatalytic activity of 417.7 mA/mg_Pd. In a single DFAFC examination, the anodic Pd/A-CNT-2 catalyst had a power density of 106.2 mW/mg_Pd and a relatively long lifetime of 2.91 h. Pd/A-CNT-2 anodic catalysts synthesized by surfactant-free synchrotron X-ray photoreduction with a rapid processing time (2 min) are potential candidates for DFAFC applications. Full article

Polymeric rubber and organic semiconductor H₂Pc-CNT-composite-based surface- and sandwich-type shockproof deformable infrared radiation (IR) sensors were fabricated using a rubbing-in technique. CNT and CNT-H₂Pc (30:70 wt.%) composite layers were deposited on a polymeric rubber substrate as electrodes and active layers, respectively. Under the effect of IR irradiation (0 to 3700 W/m²), the resistance and the impedance of the surface-type sensors decreased up to 1.49 and 1.36 times, respectively. In the same conditions, the resistance and the impedance of the sandwich-type sensors decreased up to 1.46 and 1.35 times, respectively. The temperature coefficients of resistance (TCR) of the surface- and sandwich-type sensors are 1.2 and 1.1, respectively. The novel ratio of the H₂Pc-CNT composite ingredients and comparably high value of the TCR make the devices attractive for bolometric applications meant to measure the intensity of infrared radiation. Moreover, given their easy fabrication and low-cost materials, the fabricated devices have great potential for commercialization. Full article

The substitution of traditional copper power transmission cables with lightweight copper–carbon nanotube (Cu–CNT) composite fibers is critical for reducing the weight, fuel consumption, and CO₂ emissions of automobiles and aircrafts. Such a replacement will also allow for lowering the transmission power loss in copper cables resulting in a decrease in coal and gas consumption, and ultimately diminishing the carbon footprint. In this work, we created a lightweight Cu–CNT composite fiber through a multistep scalable process, including spinning, densification, functionalization, and double-layer copper deposition. The characterization and testing of the fabricated fiber included surface morphology, electrical conductivity, mechanical strength, crystallinity, and ampacity (current density). The electrical conductivity of the resultant composite fiber was measured to be 0.5 × 10⁶ S/m with an ampacity of 0.18 × 10⁵ A/cm². The copper-coated CNT fibers were 16 times lighter and 2.7 times stronger than copper wire, as they revealed a gravimetric density of 0.4 g/cm³ and a mechanical strength of 0.68 GPa, suggesting a great potential in future applications as lightweight power transmission cables. Full article

Lithium (Li) metal has been regarded as the "Holy Grail" of Li battery anodes thanks to its high theoretic specific capacity and low reduction potential, but uneven formation of Li dendrites and uncontrollable Li volume changes hinder the practical applications of Li metal anodes. A three-dimensional (3D) current collector is one of the promising strategies to address the above issues if it can be compatible with current industrialized process. Here, Au-decorated carbon nanotubes (Au@CNTs) are electrophoretically deposited on commercial Cu foil as a 3D lithiophilic skeleton to regulate Li deposition. The thickness of the as-prepared 3D skeleton can be accurately controlled by adjusting the deposition time. Benefitting from the reduced localized current density and improved Li affinity, the Au@CNTs-deposited Cu foil (Au@CNTs@Cu foil) achieves uniform Li nucleation and dendrite-free Li deposition. Compared with bare Cu foil and CNTs deposited Cu foil (CNTs@Cu foil), the Au@CNTs@Cu foil exhibits enhanced Coulombic efficiency and better cycling stability. In the full-cell configuration, the Au@CNTs@Cu foil with predeposited Li shows superior stability and rate performance. This work provides a facial strategy to directly construct a 3D skeleton on commercial Cu foils with lithiophilic building blocks for stable and practical Li metal anodes. Full article

The fabrication of multi-dimensional nanocomposites has been extensively attempted to achieve synergistic performance through the uniform mixing of functional constituents. Herein, we report a one-pot fabrication of nanocomposites composed of carbon nanotubes (CNTs) and Al₂O₃ powder. Our strategy involves a synthesis of CNTs on the entire Al₂O₃ surface using a rotatable chemical vapor deposition system (RCVD). Ehylene and ferritin-induced nanoparticles were used as the carbon source and wet catalyst, respectively. The RCVD was composed of a quartz reaction tube, 5.08 cm in diameter and 150 cm in length, with a rotation speed controller. Ferritin dissolved in deionized water was uniformly dispersed on the Al₂O₃ surface and calcinated to obtain iron nanoparticles. The synthesis temperature, time, and rotation speed of the chamber were the main parameters used to investigate the growth behavior of CNTs. We found that the CNTs can be grown at least around 600 °C, and the number of tubes increases with increasing growth time. A faster rotation of the chamber allows for the uniform growth of CNT by the tip-growth mechanism. Our results are preliminary at present but show that the RCVD process is sufficient for the fabrication of powder-based nanocomposites. Full article

In this study, carbon nanotubes (CNTs) were grown under the same conditions as those of carbon fibers and glass fibers, and a comparative analysis was performed to confirm the potential of glass fibers with grown CNTs as electromagnetic interference (EMI) shielding materials. The CNTs were grown directly on the two fiber surfaces by a chemical vapor deposition process, with the aid of Ni particles loaded on them via a Ni-P plating process followed by heat treatment. The morphology and structural characteristics of the carbon and glass fibers with grown CNTs were analyzed using scanning electron microscopy–energy dispersive X-ray spectroscopy (SEM–EDS), X-ray diffraction (XRD), and X-ray photoelectron spectrometry (XPS), and the EMI shielding efficiency (EMI SE) of the directly grown CNT/carbon and glass fiber-reinforced epoxy matrix composites was determined using a vector-network analyzer. As the plating time increased, a plating layer serving as a catalyst formed on the fiber surface, confirming the growth of numerous nanowire-shaped CNTs. The average EMI SE_T values of the carbon fiber-reinforced plastic (CFRP) and glass fiber-reinforced plastic (GFRP) with grown CNTs maximized at approximately 81 and 40 dB, respectively. Carbon fibers with grown CNTs exhibited a significantly higher EMI SE_T value than the glass fiber-based sample, but the latter showed a higher EMI SE_T increase rate. This indicates that low-cost, high-quality EMI-shielding materials can be developed through the growth of CNTs on the surface of glass fibers. Full article

The discovery of piezoelectricity inspired several sensing applications. For these applications, the thinness and flexibility of the device increase the range of implementations. A thin lead zirconate titanate (PZT) ceramic piezoelectric sensor is advantageous compared with bulk PZT or a polymer when it comes to having minimal impacts on dynamics and high-frequency bandwidth provided by low mass or high stiffness, while satisfying constraints regarding tight spaces. PZT devices have traditionally been thermally sintered inside a furnace and this process consumes large amounts of time and energy. To overcome such challenges, we employed laser sintering of PZT that focused the power onto selected areas of interest. Furthermore, non-equilibrium heating offers the opportunity to use low-melting-point substrates. Additionally, carbon nanotubes (CNTs) were mixed with PZT particles and laser sintered to utilize the high mechanical and thermal properties of CNTs. Laser processing was optimized for the control parameters, raw materials and deposition height. A multi-physics model of laser sintering was created to simulate the processing environment. Sintered films were obtained and electrically poled to enhance the piezoelectric property. The piezoelectric coefficient of laser-sintered PZT increased by approximately 10-fold compared with unsintered PZT. Moreover, CNT/PZT film displayed higher strength compared with PZT film without CNTs after the laser sintering while using less sintering energy. Thus, laser sintering can be effectively used to enhance the piezoelectric and mechanical properties of CNT/PZT films, which can be used in various sensing applications. Full article
