Shale gas is a low-carbon unconventional natural gas resource. The development of shale gas helps to optimize the energy structure and reduce carbon emissions. However, the needle throttle valves (NTVs) commonly used in shale gas fields are usually severely eroded by solid particles. Based on the method of CFD-DEM coupling calculation, this paper constructs a gas–solid two-phase flow erosion model of the NTV and studies the influence of different placement methods, valve opening degrees, and other factors on particle movement and valve erosion. This research found that the spool is the area of the valve that is most severely eroded, and when placed horizontally, it has a serious ‘bias wear’ phenomenon. The research results herein can provide references for the design optimization and on-site maintenance of valve performance. Full article

To address the issues of low solid–liquid mixing and mass transfer efficiency and difficult real-time regulation in the resource utilization of non-ferrous metal smelting slag, this study constructs a research framework integrating Computational Fluid Dynamics-Discrete Element Method (CFD-DEM) coupling models and machine learning. The framework systematically investigates particle motion characteristics and mass transfer laws in stirred tanks and enables an intelligent prediction of key parameters. Through a CFD-DEM two-way coupling simulation, the study quantifies particle dispersion characteristics using relative standard deviation (RSD) and calculates the mass transfer coefficient (k) based on the Hughmark model, revealing the effects of particle size and impeller speed on mixing and mass transfer efficiency. For parameter prediction, particle motion and mass transfer data are used to train a multi-model prediction library, with model performance evaluated through comparative experiments. The results show that increasing the rotational speed shortens the particle mixing time, reduces RSD values by 25–40%, increases the coupling force, and decreases stability during the circulation phase. Different machine learning (ML) algorithms exhibit varying performances in the time-series prediction of particle motion characteristics and real-time prediction of mass transfer coefficients. Notably, GA-BP achieves a fitting degree R of 0.99 in both predictions, meeting the requirements for the structural optimization and intelligent regulation of stirred tanks. This research provides theoretical support and technical pathways for the structural optimization and intelligent control of stirred tanks, offering engineering application value in fields such as hydrometallurgy and solid waste resource utilization. Full article

Magnetic separation is an important method in the processing process, and its essence is the targeted dispersion of the mineral processing slurry pulp in the magnetic field space. The slurry is a complex multiphase fluid system with continuous phase carrying a large number of discrete phase particles, in which the magnetic particles agglomerate, migrate, and disperse under the dominance of magnetic force. In this process, there is nonlinear and unstable dynamic coupling between the continuous phase (liquid) and the discrete phase (solid particles) and between the discrete phases. In this paper, a dynamic cyclic multi-dipole magnetic moment algorithm with a higher calculation accuracy is innovatively proposed to calculate the magnetic interaction force between particles. Moreover, the P-E magnetization model suitable for a two-dimensional uniform magnetic field is further improved and optimized to make it applicable to a three-dimensional gradient magnetic field. Finally, based on the coupling of the Finite Element Method (FEM), Computational Fluid Dynamics (CFD), and Discrete Element Method (DEM), a dynamic coupling model capable of accurately simulating the magnetic separation process is developed. This model can be used to study the separation behavior of particles under a multiphase flow and multi-force field and to explore the motion behavior of magnetic particles. Full article

The phenomenon of tunnel erosion is quite common in the Loess Plateau. Tunnel erosion can cause disasters such as landslides, mudslides, and ground collapses, resulting in significant economic losses and posing a threat to people’s safety. Therefore, understanding the evolution mechanism of tunnel erosion not only helps to analyze and predict the development law of erosion but also has a certain guiding role in engineering activities. Many scholars (including our team) have conducted field investigations and statistical analysis on the phenomenon of tunnel erosion in loess; however, these studies still have shortcomings in visual quantitative analysis. The combination of the Discrete Element Method (DEM) and Computational Fluid Dynamics (CFD) has significant advantages in studying soil seepage and erosion. Based on existing experimental research, this article combines the Discrete Element Method (DEM) with Computational Fluid Dynamics (CFD) to establish a CFD-DEM coupled model that can simulate tunnel erosion processes. In this model, by changing the working conditions (vertical cracks, horizontal cracks, and circular holes) and erosion water pressure conditions (200 Pa, 400 Pa, 600 Pa), the development process of tunnel erosion and changes in erosion rate are explored. The results indicate that during the process of fluid erosion, the original vertical crack, horizontal crack, and circular hole-shaped tunnels all become a circular cave. The increase in erosion water pressure accelerates the erosion rate of the model, and the attenuation rate of the particle contact force chain also increases, resulting in a decrease in the total erosion time. During the erosion process, the curve of the calculated erosion rate shows a pattern of slow growth at first, then rapid growth, before finally stabilizing. The variation law of the erosion rate curve combined with the process of tunnel erosion can roughly divide the process of tunnel erosion into three stages: the slow erosion stage, the rapid erosion stage, and the uniform erosion stage. Full article

Ground collapse is one of the common geological hazards in modern cities. With the development of urbanization, the risk of ground collapse increases, which has a great impact on urban public safety. Ground collapse accidents typically occur due to the presence of unstable cavities under the surface, or the generation and expansion of cavities induced by triggering factors. Investigating the stability of cavities in the strata is significant for identifying subsidence risks and mitigating the consequences of subsidence. This study proposed a method for predicting ground subsidence settlement based on the ARMA model. Firstly, CFD-DEM coupled simulation is employed to simulate the mechanism of cavity changes in the soil layers under the influence of triggering factors and to calculate the safety coefficient for ground subsidence stability. Subsequently, the safety coefficient data at different time points are fitted to predict the subsequent stability of the subsidence. We selected a subway permeable collapse accident in Foshan City, Guangdong Province for experimental verification, and compared the predicted results with the actual situation. The result shows that this method can effectively predict the changes in ground collapse safety factor and the collapse time point. With 40% of the data, high accuracy prediction can be achieved, improving the efficiency of collapse evolution prediction and providing strong support for ground collapse risk prevention and control. Full article

Frazil ice is the foundation for all other ice phenomena, and its spatiotemporal evolution is critical for regulating ice conditions in rivers and channels, as well as for preventing and controlling ice damage. This paper investigates the dynamic transport pattern of frazil ice during the early stages of winter freezing in water conveyance channels based on a CFD-DEM coupled numerical model, and derives predictive formulae for the spatiotemporal evolution of frazil ice and floating ice. First, static repose angle simulations and slope sliding simulations were used to calibrate the contact parameters between frazil ice particles and between frazil ice and the channel bed, ensuring the accurate calculation of contact forces in the model. On this basis, the processes of frazil ice transport, aggregation, and upward movement in water transfer channels were simulated, and the influence of contact parameters on simulation results was analyzed, showing a significant effect when the ice concentration was high. Numerical results indicate that the amount of suspended frazil ice is positively correlated with the frazil ice generation rate and water depth, with minimal influence from the flow velocity; the amount of floating ice increases linearly along the channel, with growth positively correlated with the frazil ice generation rate and water depth, and negatively correlated with the flow velocity. Predictive formulae correlating frazil ice and floating ice amounts with the flow velocity, water depth, and other factors were proposed based on numerical results. There is good agreement between the predictive and numerical results: the maximum APE between the predicted and simulated values of suspended frazil ice is 13.24%, and the MAPE is 6.32%; the maximum APE between the predicted and simulated values of floating ice increment is 7.80%, and the MAPE is 2.89%. The proposed prediction formulae can provide a theoretical basis for accurately predicting ice conditions during the early stages of winter freezing in rivers and channels. Full article

Ore collection devices are important for the collection of deep-sea polymetallic nodules. Based on the CFD-DEM solid–liquid two-phase flow coupling calculation method, this paper simulated the rise and transport phases of polymetallic nodules using the Coanda effect ore collection device. The validity of the numerical simulation method was confirmed through experimental testing. On this basis, the effects of different working and structural parameters on the collection rate were studied. The results indicate that the flow rate of the collection jet and the bottom clearance were the primary factors affecting the collection rate of the polymetallic nodules. An increase in the collection jet flow rate leads to a substantial rise in the collection rate of polymetallic nodules. Conversely, an increase in bottom clearance results in a decrease in the collection rate. A collection rate exceeding 90% can be achieved in both scenarios: a 10 mm bottom clearance with an 8 m/s collection jet flow rate, and a 30 mm bottom clearance with a 10 m/s collection jet flow rate. The collection nozzle slant angle has no substantial impact on the collection rate, and the recommended collection nozzle slant angle is 35° to reduce energy loss. Full article

The reliability and accuracy of numerical models and computer simulations to study aerosol deposition in the human respiratory system is investigated for a patient-specific tracheobronchial tree geometry. A computational fluid dynamics (CFD) model coupled with discrete elements methods (DEM) is used to predict the transport and deposition of the aerosol. The results are compared to experimental and numerical data available in the literature to study and quantify the impact of the modeling parameters and numerical assumptions. Even if the total deposition compares very well with the reference data, it is clear from the present work how local deposition results can depend significantly upon spatial discretization and boundary conditions adopted to represent the respiratory act. The modeling of turbulent fluctuations in the airflow is also found to impact the local deposition and, to a minor extent, the flow characteristics at the inlet of the computational domain. Using the CFD-DEM model, it was also possible to calculate the airflow and particles splitting at bifurcations, which were found to depart from the assumption of being equally distributed among branches adopted by some of the simplified deposition models. The results thus suggest the need for further studies towards improving the quantitative prediction of aerosol transport and deposition in the human airways. Full article

In this study, three randomly packed beds with varying tube-to-particle diameter ratios (D/d) are constructed using the discrete element method (DEM) and simulated via CFD under low pore Reynolds numbers (Re_p < 100). An innovation of this research lies in the application of hydrogen in randomly packed beds, coupled with the consideration of its temperature-dependent thermal properties. The axial analysis of the heat transfer characteristics shows that PB−5 and PB−6 achieve thermal equilibrium 44% and 58% faster than PB−4, respectively, demonstrating enhanced heat transfer efficiency. However, at higher flow rates (0.8 m/s), the large-sized fluid channels in PB−6 severely impact the heat transfer efficiency, slightly reducing it compared to PB−5. Additionally, this study introduces a localized segmentation method for calculating the axial local Nusselt number, showing that the axial local Nusselt number (Nu) not only exhibits an inverse relationship with the axial porosity distribution, but also matches its amplitude fluctuations. The wall effect significantly impacts the flow and temperature distribution in the packed bed, causing notable velocity and temperature oscillations in the near-wall region. In the near-wall region, the average temperature is lower than in the core region, and the axial temperature profile exhibits more intense oscillations. These findings may provide insights into the use of hydrogen in randomly packed beds, which are vital for enhancing industrial applications such as hydrogen storage and utilization. Full article

With the continuous depletion of fossil fuels, all countries attach importance to clean and sustainable development. The real-time state monitoring of multiphase flows is vital for enhancing hydropower station energy conversion. However, the material mass transfer mechanism and flow field disturbance regulation strategy faces significant challenges. To solve these problems, a computational fluid mechanics and discrete element method (CFD-DEM) coupling modeling and solution method based on a particle porosity model was proposed, and the mass transfer mechanism of gas–liquid–solid mixing flows was obtained under dynamic whirl intensity regulations. Combined with the user-defined function (UDF), the interphase forces and void ratios of fluids and particles were calculated to obtain the material mass transfer laws under dynamic disturbance regulations. The evolution characteristics of the particle flow pattern were tracked during the material mixing process. The results show that the mixed flow field had a high material transport efficiency under intensive whirl regulation, especially for the particle aggregation in the center of the reaction vessel. The maximum peak velocity and energy values of the particle transport process were 3.30 m/s and 0.27 × 10⁻³ m²·s⁻². The higher whirl regulation improved the material transport process and conveying efficiency and enhanced the particle mixing effect in the reaction space. Relevant research results can provide theoretical references for material mass transfer mechanisms, dynamic regulation strategies, and particle flow pattern identifications and can also provide technical support for hydropower energy conversion. Full article

Tee pipes are widely utilized in pipeline transportation, especially in subsea production systems and the chemical industry. The purpose of this research is to study the influences of gravity direction, conveying parameters and particle properties on the erosion distribution in tee junctions. Investigation using the CFD-DEM coupled method is conducted on the flow mechanisms and erosion characteristics in a tee junction under different flow conditions. Firstly, numerical calculations of liquid–solid two-phase flow in a vertical cylindrical pipe are performed, and the comparison between simulation results and experimental results is carried out. Then, the verified lift and erosion models are used for the numerical calculations of tee pipes. Flow mechanisms and erosion characteristics are numerically investigated through analysis of the velocity profiles, streamlines, and erosion contours. The results indicate that the gravity direction has a nonnegligible influence on the cross-sectional velocity profiles, particularly under the condition of high velocity and high particle concentration. The region with the maximum erosion rate occurred at the branch pipes, about three fourths of the pipe diameter away from the tee junction. Full article

Flow pattern monitoring of gas–liquid–solid mixed flow has great significance to enhance the quality and efficiency of material mixing, and the material transport mechanism and dynamic control strategy are faced with significant challenges. To solve these problems, a computational fluid mechanics and discrete element method (CFD-DEM) coupling modeling and solving approach based on soft sphere and porous models is presented to explore material transport mechanisms. The user-defined function (UDF) is adopted to perform data communication, and the porosity of the porous model is calculated to achieve the bidirectional calculation of Eulerian fluid and Lagrange particle phases. Material transport processes of gas–liquid–solid mixed flows are discussed to explore material transport mechanisms of particle flow and the flow pattern evolution laws under the inflation control are obtained. The results show that the particles are not evenly distributed under the synergistic action of impeller rotation and inflation. The particles in the upper and lower impeller have similar characteristics along the radial direction, and there is an aggregation phenomenon in the impeller center. A certain degree of inflation enhances the macroscopic mixing process of turbulent vortices, promotes the particle suspension effect inside the container, and improves the material transport efficiency inside the mixing space. Relevant research results can provide theoretical references for the material transport mechanism, flow pattern tracking models, and energy transfer and can also provide technical support for chemical process separation, food processing, battery homogenate mixing, and other production processes. Full article

The suspension velocity is the core of the cleaning and sorting mechanisms that utilize a combination of a fan and vibrating sieve. To investigate this, various experimental subjects, such as peanuts with different kernels and clay-heavy clods in different states, were used. The experiment involved simulating the suspension velocity of materials through numerical calculations using fluid dynamics and particle discrete element coupling. The Eularian model was employed to study the coupled gas-solid two-phase flow. The experiment measured the suspension velocities of single and double kernel peanuts, which were found to be 8.34~9.40 m/s and 8.13~9.51 m/s, respectively. Under 20.4% water content and lumpy conditions, the suspension velocities of smaller clods, side by side clods, and larger clods were 12.61~14.30 m/s, 14.16~15.76 m/s and 16.44~18.72 m/s, respectively; under 20.4% water content and smaller clods, the suspension velocities of lumpy and strip of clods were 12.61~14.30 m/s, 11.90~14.13 m/s, respectively; under lumpy and smaller clods, the suspension velocity at 17.6%, 20.4%, and 23.9% water content ranged from 12.38 to 14.20 m/s, 12.61 to 14.30 m/s, and 12.62 to 14.49 m/s, respectively. The simulations showed that the suspension velocity for different types of peanuts, clod sizes, shapes, and water contents was less different from the actual experiments. Specifically, the relative errors in suspension velocity for single-kernel peanuts, double-kernel peanuts, smaller clods, side-by-side clods, larger clods, lumpy clods, strips of clods, and clods with 17.3%, 20.4%, and 23.9% water content were 1.2%, 4.1%, 0.4%, 2.0%, 4.4%, 0.4%, 5.1%, 5.4%, 0.4%, and 1.9%, respectively, compared to actual experiment measurements. The results indicate a significant difference in the suspension velocity between peanuts and clay-heavy clods, which can be distinguished from each other based on this difference. Furthermore, the simulation results have been found to be consistent with the experimental results, thus verifying the feasibility of measuring the material suspension velocity using CFD-DEM gas-solid coupling. Full article

The movement of particles caused by erosion is one of the main reasons for the destruction of projects, such as dams, tunnels, and foundation pits. This study highlights a theoretical model to assess the occurrence of erosion in gap-graded, sand-gravel soils under variable seepage direction based on the critical hydraulic conditions of particle initiation. The model introduced the effects of relative exposure degree, relative hidden degree, and seepage direction by considering the difference in particle initiation conditions. On the basis of the variable-section capillary tube model formed by the skeletal pores, the mechanical analysis of the movable particles in the pores was performed, and the formulas for the critical hydraulic conditions were obtained according to the moment balance equation. Subsequently, the coupled CFD-DEM method and the available experimental data were used for validation. The comparison revealed a deviation of 0.0268 for the mean of the ratio between the calculated and simulated values compared to 1, with a covariance (COV) of 0.0344. Further, the mean value of the ratio between the calculated and test values compared to 1 had a maximum deviation of 0.095 and a covariance (COV) of 0.0143. The high degree of agreement between the data proved that the theoretical model can assess the occurrence of erosion more accurately. Finally, based on the theoretical model, the study further explored the effects of seepage direction and relative particle position on the variability in particle initiation conditions, thus finding that, unlike in other studies, the effect of seepage direction was not linear. Full article

The discrete element method coupled with the computational fluid dynamic (CFD-DEM) method is effective for studying the micro-flow process of lignin particles in ceramic membranes. Lignin particles may exhibit various shapes in industry, so it is difficult to model their real shapes in CFD-DEM coupled solutions. Meanwhile, the solution of non-spherical particles requires a very small time-step, which significantly lowers the computational efficiency. Based on this, we proposed a method to simplify the shape of lignin particles into spheres. However, the rolling friction coefficient during the replacement was hard to be obtained. Therefore, the CFD-DEM method was employed to simulate the deposition of lignin particles on a ceramic membrane. Impacts of the rolling friction coefficient on the deposition morphology of the lignin particles were analyzed. The coordination number and porosity of the lignin particles after deposition were calculated, based on which the rolling friction coefficient was calibrated. The results indicated that the deposition morphology, coordination number, and porosity of the lignin particles can be significantly affected by the rolling friction coefficient and slightly influenced by that between the lignin particles and membranes. When the rolling friction coefficient among different particles increased from 0.1 to 3.0, the average coordination number decreased from 3.96 to 2.73, and the porosity increased from 0.65 to 0.73. Besides, when the rolling friction coefficient among the lignin particles was set to 0.6–2.4, the spherical lignin particles could replace the non-spherical particles. Full article
