This article describes an innovative thermal insulation barrier in the form of a sandwich panel manufactured using 3D FDM printing technology. The internal structure (core structure) of the barrier is based on the Kelvin foam model. This paper presents the influence of the parameters (the height h and the porosity P of a single core cell) of the barrier on its properties (thermal conductivity, thermal resistance, compressive strength, and quasi-static indentation strength). The dominant influence of the porosity of the structure on the determined physical properties of the fabricated samples was demonstrated. The best insulation results were obtained for single-layer composites with a cell height of 4 mm and a porosity of 90%, where the thermal conductivity coefficient was 0.038 W/(m·K) and the thermal resistance 0.537 (m²·K)/W. In contrast, the best compressive strength properties were obtained for the 50% porosity samples and amounted to about 350 MPa, while the moduli for the 90% porosity samples were 14 times lower and amounted to about 26 MPa. The porosity (P) of the composite structure also had a significant effect on the punch shear strength of the samples produced, and the values obtained for the 90% porosity samples did not exceed 1 MPa. In conclusion, the test showed that the resulting 3D cellular composites offer an innovative and environmentally friendly approach to thermal insulation. Full article

This work investigated the impact and piercing load resistance (energy absorption capabilities) of 3D-printed composites plates manufactured by means of the Fused-Filament-Fabrication (FFF) technique. Two sets of reinforced composite plates were produced. The first set of plates was printed with short-carbon-fiber-reinforced polyamide-12, while the second set was reinforced with continuous fibers. The plates were tested with quasi-static indentation tests at various Span-to-Punch ratios and with three different indenter nose shapes (blunt, hemispherical, and conical). The quasi-static measurements were subsequently elaborated to estimate the energy absorption capability of the plates during a ballistic impact. The addition of continuous fibers increased the quasi-static energy absorption capability by 20–185% with respect to the short-fiber-reinforced plates. The quasi-static results showed that by including the continuous reinforcement in the plates, the normalized energy absorbed increased by an order of magnitude. Finally, a comparison with data from the literature concerning continuous-reinforced composite plates manufactured by means of traditional techniques was carried out. The comparison revealed that FFF-printed composite plates can compete with traditional composite ones in terms of both ballistic and quasi-static penetrating load conditions, even if limited by the lower fiber volume fraction. Thus, these findings confirm that this novel Additive Manufacturing technique is promising and worth investigating further. Full article

The possibility of controlling the porosity and, as a result, the permeability of fibrous non-woven fabrics was studied. Modification of experimental samples was performed on equipment with adjustable heating and compression. It was found that the modification regimes affected the formation of the porous structure. We found that there was a relationship between the permeability coefficient and the porosity coefficient of the materials when the modification speed and temperature were varied. A model is proposed for predicting the permeability for modified material with a given porosity. As the result, a new hybrid composite material with reversible dynamic color characteristics that changed under the influence of ultraviolet and/or thermal exposure was produced. The developed technology consists of: manufacture of the non-woven needle-punched fabrics, surface structuring, material extrusion, additive manufacturing (FFF technology) and the stencil technique of ink-layer adding. In our investigation, we (a) obtained fibrous polymer materials with a porosity gradient in thickness, (b) determined the dependence of the material’s porosity coefficient on the speed and temperature of the modification and (c) developed a model for calculating the porosity coefficient of the materials with specified technological parameters. Full article

Small specimen technologies, such as the small punch test, the indentation test, and the in situ Scanning Electron Microscope (SEM)/Electron Back Scatter Diffraction (EBSD) test, provide important data support for understanding mechanical properties when the size of testing materials is limited, such as for alloys, 3D printing metals, and welding joints, as illustrated in Figure 1 [...] Full article

Natural fibres are the preferred options for garment, technical and medical textiles, nonwovens and composites. Their sustainability is a considerable advantage, though the nature of silk production and processing involves a large amount of waste. The present review explores the current issues of recycling silk waste into nonwovens for various purposes. The article proposes obtaining nonwovens from short fibres using electrospinning of fibroin solutions in volatile solvents. Longer fibres are proposed to be processed into needle-punched nonwoven materials with a selection of an effective antistatic treatment. Full article

Alumina is one of the most popular ceramic materials widely used in both tooling and construction applications due to its low production cost, and high properties. However, the final properties of the product depend not only on the purity of the powder, but also, e.g., on its particle size, specific surface area, and the production technology used. These parameters are particularly important in the case of choosing additive techniques for the production of details. Therefore, the article presents the results of comparing five grades of Al₂O₃ ceramic powder. Their specific surface area (via Brunauer–Emmett–Teller (BET) and Barrett–Joyner–Halenda (BJH) methods), particle size distribution, and phase composition by X-ray diffraction (XRD) were determined. Moreover, the surface morphology was characterized by the scanning electron microscopy (SEM) technique. The discrepancy between generally available data and the results obtained from measurements has been indicated. Moreover, the method of spark plasma sintering (SPS), equipped with the registration system of the position of the pressing punch during the process, was used to determine the sinterability curves of each of the tested grades of Al₂O₃ powder. Based on the obtained results, a significant influence of the specific surface area, particle size, and the width of their distribution at the beginning of the Al₂O₃ powder sintering process was confirmed. Furthermore, the possibility of using the analyzed variants of powders for binder jetting technology was assessed. The dependence of the particle size of the powder used on the quality of the printed parts was demonstrated. The procedure presented in this paper, which involves analyzing the properties of alumina varieties, was used to optimize the Al₂O₃ powder material for binder jetting printing. The selection of the best powder in terms of technological properties and good sinterability makes it possible to reduce the number of 3D printing processes, which makes it more economical and less time-consuming. Full article

Self-adaptive mechanisms are gaining momentum in industrial processes. It is understandable that as the complexity increases, the human work must be augmented. Considering this, the authors have developed one such solution for the punch-forming process, using additive manufacturing, i.e., a 3D-printed punch, to draw into shape 6061-T6 aluminum sheets. This paper aims to highlight the topological study used to optimize the punch form shape, the methodology of the 3D printing process, and the material used. For the adaptive algorithm, a complex Python-to-C++ bridge was created. It was necessary as the script has computer vision (used for calculating stroke and speed), punch force, and hydraulic pressure measurement capabilities. The algorithm uses the input data to control its subsequent actions. Two approaches are used in this experimental paper, a pre-programmed direction and an adaptive one, for comparison purposes. The results, namely the drawing radius and flange angle, were statistically analyzed using the ANOVA methodology for significance. The results indicate significant improvements when using the adaptive algorithm. Full article

The main objective of this research is to identify optimal printing strategies and PLA (polylactic acid) filament materials to produce rapid prototype deep drawing tools. Additive 3D printing technologies have been applied for a long time to produce tools, but the research is unique in that it uses conventional and various reinforced PLA materials with conventional FDM (Fused Deposition Modeling) printers. The advantage of this method is that PLA is easy to print and recycle and does not require expensive or special printers, this also gives the article its novelty. A further aim was to produce the tools using commercially available low-end printers. DX53D 0.8 mm thick body steel and AlMg3 2.5 mm thick sheet were the materials to be molded for the tests. The test tool was an Erichsen deep drawing punch. Tool wear was tested using the GOM ATOS measuring system, an optical coordinate measuring machine based on the DIC (Digital Image Correlation) principle, which is also popular in the automotive industry. The study aims to determine the 3D printing and material parameters that can safely produce a minimum batch of 100 parts. Full article

The additive manufacturing (3D printing) of metallic materials is a relatively new technology and its use is quickly increasing. Although it is of interest to many researchers, there are still areas which are not fully explored. One of those areas is the behavior of large components and/or semi-products processed by 3D printing. This work is focused on the study of material properties of additive manufactured large block made of AISI 316L steel in two heat treatment conditions (as-printed and solution annealed) and their comparison with the properties of hot-rolled plate performed by tensile tests, Charpy V-notch tests, small punch tests and stress rupture tests. Mechanical tests were complemented by microstructural investigation and the fractographic analysis of fracture surfaces. We found out that mechanical and long-term properties of large 3D printed blocks of this steel are excellent and comparable with other published results obtained on small-sized and intentionally produced test pieces. The observed lower ductility is the result of printing imperfections in microstructure. The results of small punch tests confirmed the possibility of exploiting the existing database and using the correlation between small punch tests and tensile tests results even for 3D-printed AISI 316L steel. Full article

A pair of punch and die was often fabricated using subtractive manufacturing processes such as milling and other machining processes. However, additive manufacturing could be used to perform the same processes. This study explored this possibility. In particular, this study fabricated a pair of T-shaped punch and die made of AISI316L austenitic stainless steel using an additive manufacturing process called plasma-assisted 3D printing. Accordingly, T-shaped negative and positive 2D patterns were screen-printed onto the mirror-polished surfaces of the substrates made of AISI316L austenitic stainless steel. The printed film worked like a mask to prevent the printed substrate surfaces from nitriding. In order to form a thick nitrided layer, the unprinted substrate surfaces were selectively nitrided at 673 K for 14.4 ks. The un-nitrided segments of the substrates were uniformly removed by sand-blasting that involved shooting silica particles on the substrate’s surfaces. As a result, the substrates printed with negative and positive T-shaped patterns were transformed into the punch head and die cavity. In order to see the efficacy of the fabricated punch and die pair, this pair was used for piercing the electrical steel sheets under a controlled clearance. Scanning Electron Microscopy with Energy Dispersive X-ray (SEM-EDX) was used to measure surface topography after piercing. In addition, SEM and a 3D profilometer were used to measure the punch and die profiles after piercing. The abovementioned measurement results showed that the fabricated punch and die exhibited highly accurate piercing behavior. Thus, the plasma-assisted 3D printing was useful for punch and die fabrication. Full article

The post-processing (punching or trimming) of high-strength parts reinforced by hot stamping requires punch molds with improved mechanical properties in hardness, resistance to wear, and toughness. In this study, a semi-additive manufacturing (semi-AM) method of heterogeneous materials was proposed to strengthen these properties using high wear resistance steel (HWS) powder and directed energy deposition (DED) technology. To verify these mechanical properties as a material for the punch mold for cutting, specimens were prepared and tested by a semi-AM method of heterogeneous material. The test results of the HWS additive material by the semi-AM method proposed in this study are as follows: the hardness was 60.59–62.0 HRc, which was like the Bulk D2 specimen. The wear resistance was about 4.2 times compared to that of the D2 specimen; the toughness was about 4.0 times that of the bulk D2 specimen; the compressive strength was about 1.45 times that of the bulk D2 specimen; the true density showed 100% with no porosity. Moreover, the absorption energy was 59.0 J in a multi-semi-AM specimen of heterogeneous materials having an intermediate buffer layer (P21 powder material). The semi-AM method of heterogeneous materials presented in this study could be applied as a method to strengthen the punch mold for cutting. In addition, the multi-semi-AM method of heterogeneous materials will be able to control the mechanical properties of the additive material. Full article

Additive manufacturing is becoming a technique with great prospects for the production of components with new designs or shapes that are difficult to obtain by conventional manufacturing methods. One of the most promising techniques for printing metallic components is binder jetting, due to its time efficiency and its ability to generate complex parts. In this process, a liquid binding agent is selectively deposited to adhere the powder particles of the printing material. Once the metallic piece is generated, it undergoes a subsequent process of curing and sintering to increase its density (hot isostatic pressing). In this work, we propose subjecting the manufactured component to an additional post-processing treatment involving the application of a high hydrostatic pressure (5000 bar) at room temperature. This post-processing technique, so-called cold isostatic pressing (CIP), is shown to increase the yield load and the maximum carrying capacity of an additively manufactured AISI 316L stainless steel. The mechanical properties, with and without CIP processing, are estimated by means of the small punch test, a suitable experimental technique to assess the mechanical response of small samples. In addition, we investigate the porosity and microstructure of the material according to the orientations of layer deposition during the manufacturing process. Our observations reveal a homogeneous distribution independent of these orientations, evidencing thus an isotropic behaviour of the material. Full article

Advanced manufacturing encompasses the wide range of processes that consist of “3D printing” of metallic materials. One such method is Electron Beam Melting (EBM), a modern build technology that offers significant potential for lean manufacture and a capability to produce fully dense near-net shaped components. However, the manufacture of intricate geometries will result in variable thermal cycles and thus a transient microstructure throughout, leading to a highly textured structure. As such, successful implementation of these technologies requires a comprehensive assessment of the relationships of the key process variables, geometries, resultant microstructures and mechanical properties. The nature of this process suggests that it is often difficult to produce representative test specimens necessary to achieve a full mechanical property characterisation. Therefore, the use of small scale test techniques may be exploited, specifically the small punch (SP) test. The SP test offers a capability for sampling miniaturised test specimens from various discrete locations in a thin-walled component, allowing a full characterisation across a complex geometry. This paper provides support in working towards development and validation strategies in order for advanced manufactured components to be safely implemented into future gas turbine applications. This has been achieved by applying the SP test to a series of Ti-6Al-4V variants that have been manufactured through a variety of processing routes including EBM and investigating the structural integrity of each material and how this controls the mechanical response. Full article
