Open AccessArticle
J. Compos. Sci. 2018, 2(2), 18;

Preparation and Performance of Ecofriendly Epoxy/Multilayer Graphene Oxide Composites with Flame-Retardant Functional Groups

Green Flame Retardant Material Research Laboratory, Department of Safety, Health and Environmental Engineering, Hung-Kuang University, Taichung 433, Taiwan
Author to whom correspondence should be addressed.
Received: 23 January 2018 / Revised: 16 March 2018 / Accepted: 21 March 2018 / Published: 23 March 2018
Full-Text   |   PDF [67392 KB, uploaded 3 May 2018]   |


This study aimed to prepare ecofriendly flame retardants. Using the –OH and –COOH functional groups of multilayer graphene oxide (GO) for the hydrolytic condensation of tetraethoxysilane (TEOS), TEOS was grafted onto GO to form Si-GO. Subsequently, p-aminophenol (AP) was grafted onto Si-GO to produce Si-GA, forming composite materials with epoxy (EP). The structures and properties of the composite materials were examined with Fourier-transform infrared spectroscopy (FTIR), thermogravimetric analysis (TGA), and the limiting oxygen index (LOI). In terms of structure, FTIR observed two characteristic peaks of Si-GO, namely Si–O–C and Si-O-Si, indicating that TEOS was successfully grafted onto GO. TGA was used to determine the thermal stability of the epoxy/Si-GA composites; with the increase in Si-GA, the char yield of the materials increased from 15.6 wt % (pure epoxy) to 25 wt % (epoxy/10 wt % Si-GA), indicating that Si-GA effectively enhanced the thermal stability of the epoxy matrix. Lastly, the flame retardant tests determined that the LOI value rose from 19% (pure epoxy) to 26% (epoxy/10 wt % Si-GA), proving that graphene with modified silicon can be used to enhance the flame retardancy of epoxy. View Full-Text
Keywords: epoxy; graphene oxide; silicon; composite; flame retardant epoxy; graphene oxide; silicon; composite; flame retardant

Figure 1

This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited. (CC BY 4.0).
