Unfolding Crease Patterns Inspired by Insect Wings and Variations of the Miura-ori with a Single Vein

1
Department of Biology, The University of Akron, 235 Carroll Street, Akron, OH 44325, USA
2
Eric Gjerde Studio, 1122 Edmund Avenue, Saint Paul, MN 55104, USA
3
Myers School of Art and Department of Biology, The University of Akron, 150 East Exchange Street, Akron, OH 44325, USA
*
Authors to whom correspondence should be addressed.
Biomimetics 2019, 4(3), 45; https://doi.org/10.3390/biomimetics4030045
Received: 27 February 2019 / Revised: 1 July 2019 / Accepted: 1 July 2019 / Published: 5 July 2019
(This article belongs to the Special Issue Proto-Architecture and Unconventional Biomaterials)
In many disciplines, professionals are interested in folding patterns for their packing and shape changing capabilities. Many insects have folded wings fitting to their body morphology that can unfold to fly, support their weight and withstand external forces. This paper focuses on the main characteristics emerging from folding patterns inspired and adapted from both insect wings and Miura-ori patterns, along with the actuation mechanism. Pneumatic actuators, similar to the venations on insect wings, are used to unfold these patterns. Depending on one vein’s placement, its inflation can unfold models with many creases. While a single vein cannot fold the model back, a snapping behavior, observed in some folding patterns, could be used to trigger the folding mechanism of a model. By presenting the characteristics of each folding pattern studied in this work, one could come forth with an application and choose the most efficient folding patterns based on the most suitable characteristics for this application. These folding patterns can then be optimized to address specific requirements by adapting their different parameters. View Full-Text
Keywords: folding; Miura-ori; insect wings; venation system; pneumatic; biomimicry; biomimetics folding; Miura-ori; insect wings; venation system; pneumatic; biomimicry; biomimetics
Show Figures

Figure 1

MDPI and ACS Style

Houette, T.; Gjerde, E.; Gruber, P. Unfolding Crease Patterns Inspired by Insect Wings and Variations of the Miura-ori with a Single Vein. Biomimetics 2019, 4, 45.
