The non-linear Schrödinger (NLS) equation has often been used as a model equation in the study of quantum states of physical systems. Numerical solution of NLS equation is obtained using cubic B-spline Galerkin method. We have applied the Crank–Nicolson scheme for time discretization and the cubic B-spline basis function for space discretization. Three numerical problems, including single soliton, interaction of two solitons and birth of standing soliton, are demonstrated to evaluate to the performance and accuracy of the method. The error norms and conservation laws are determined and found to be in good agreement with the published results. The obtained results show that the approach is feasible and accurate. The proposed method has almost second order convergence. The linear stability of the method is performed using the Von Neumann method. Full article

To have a safe structural design, an analysis of the dynamic behavior of a Francis turbine runner with consideration of the added mass effects of surrounding water is necessary during design phase. Both in design and at off-design operations, large-scale forms of attached cavitation may appear on runner blades and can change the added mass effects of the surrounding fluid in relation to a single water domain. Consequently, a numerical investigation of the modal response of a Francis runner has been carried out by reproducing the presence of various sizes of leading edge cavitation (LEC) and trailing edge cavitation (TEC). The fluid–structure interaction problem has been solved by means of an acoustic-structural coupling method. The calculated added mass effects with cavitation have been compared with those corresponding to the pure water condition without cavitation. Firstly, a single blade has been investigated to evaluate the level of significance for the proposed cavity shapes and dimensions. Afterwards, based on the results obtained, the complete runner structure has been considered, factoring in similar cavity shapes and locations. The results prove that significant added mass effects are induced on the entire runner by the attached cavitation that increase the natural frequencies of the first modes. Moreover, the added mass effects increase with cavity size and amplitude of blade deformation below the cavity. Full article

The coupled nonlinear Schrödinger equation (CNLSE) is a wave envelope evolution equation applicable to two crossing, narrow-banded wave systems. Modulational instability (MI), a feature of the nonlinear Schrödinger wave equation, is characterized (to first order) by an exponential growth of sideband components and the formation of distinct wave pulses, often containing extreme waves. Linear stability analysis of the CNLSE shows the effect of crossing angle, $\theta$ , on MI, and reveals instabilities between $0^{\circ }<\theta <{35}^{\circ }$ , ${46}^{\circ }<\theta <{143}^{\circ }$ , and ${145}^{\circ }<\theta <{180}^{\circ }$ . Herein, the modulational stability of crossing wavetrains seeded with symmetrical sidebands is determined experimentally from tests in a circular wave basin. Experiments were carried out at 12 crossing angles between $0^{\circ }\le \theta \le {88}^{\circ }$ , and strong unidirectional sideband growth was observed. This growth reduced significantly at angles beyond $\theta \approx {20}^{\circ }$ , reaching complete stability at $\theta$ = 30–40 ${}^{\circ }$ . We find satisfactory agreement between numerical predictions (using a time-marching CNLSE solver) and experimental measurements for all crossing angles. Full article

We explore the theory of isolated vortices in strongly sheared, deep zonal flows and the stability of these banded jets, as occur in Jupiter’s atmosphere This is done using the standard 2-layer quasigeostrophic model with the lower layer depth becoming infinite; however, this model differs from the usual layer model because the lower layer is not assumed to be motionless but has a steady configuration of alternating zonal flows. Steady state vortices are obtained by a simulated annealing computational method as generalized to fluid problems with constraints and also used in the used in the context of magnetohydrodynamics. Various cases of vortices with a constant potential vorticity anomaly atop zonal winds and the stability of the underlying winds are considered using a mix of computational and analytical techniques. Full article

Entropy and entropy generation are abstract and illusive concepts for undergraduate students. In general, students find it difficult to visualize entropy generation in real (irreversible) processes, especially at a mechanistic level. Fluid mechanics laboratory can assist students in making the concepts of entropy and entropy generation more tangible. In flow of real fluids, dissipation of mechanical energy takes place due to friction in fluids. The dissipation of mechanical energy in pipeline flow is reflected in loss of pressure of fluid. The degradation of high quality mechanical energy into low quality frictional heat (internal energy) is simultaneously reflected in the generation of entropy. Thus, experiments involving measurements of pressure gradient as a function of flow rate in pipes offer an opportunity for students to visualize and quantify entropy generation in real processes. In this article, the background in fluid mechanics and thermodynamics relevant to the concepts of mechanical energy dissipation, entropy and entropy generation are reviewed briefly. The link between entropy generation and mechanical energy dissipation in pipe flow experiments is demonstrated both theoretically and experimentally. The rate of entropy generation in pipeline flow of Newtonian fluids is quantified through measurements of pressure gradient as a function of flow rate for a number of test fluids. The factors affecting the rate of entropy generation in pipeline flows are discussed. Full article

This paper presents a novel and accurate method to implement the Kutta condition in solving subsonic (subcritical) inviscid isentropic compressible flow over isolated airfoils using the stream function equation. The proposed method relies on body-fitted grid generation and solving the stream function equation for compressible flows in computational domain using finite-difference method. An expression is derived for implementing the Kutta condition for the airfoils with both finite angles and cusped trailing edges. A comparison of the results obtained from the proposed numerical method and the results from experimental and other numerical methods reveals that they are in excellent agreement, which confirms the accuracy and correctness of the proposed method. Full article

We investigate the flow structure and dynamics of moderate-Rayleigh-number ( $Ra$ ) thermal convection in a two-dimensional inclined porous layer. High-resolution numerical simulations confirm the emergence of $O\left(1\right)$ aspect-ratio large-scale convective rolls, with one ‘natural’ roll rotating in the counterclockwise direction and one ‘antinatural’ roll rotating in the clockwise direction. As the inclination angle $\varphi$ is increased, the background mean shear flow intensifies the natural-roll motion, while suppressing the antinatural-roll motion. Our numerical simulations also reveal—for the first time in single-species porous medium convection—the existence of spatially-localized convective states at large $\varphi$ , which we suggest are enabled by subcritical instability of the base state at sufficiently large inclination angles. To better understand the physics of inclined porous medium convection at different $\varphi$ , we numerically compute steady convective solutions using Newton iteration and then perform secondary stability analysis of these nonlinear states using Floquet theory. Our analysis indicates that the inclination of the porous layer stabilizes the boundary layers of the natural roll, but intensifies the boundary-layer instability of the antinatural roll. These results facilitate physical understanding of the large-scale cellular flows observed in the numerical simulations at different values of $\varphi$ . Full article

This paper presents experimental results on the vortex shedding frequency measured behind a bent cylinder. Experiments were conducted in a wind tunnel covering Reynolds numbers between 50 and 500, a range of interest for flow sensing, flow control, and energy harvesting applications. The bent cylinder comprised a vertical leg always oriented at normal incidence with respect to the free-stream flow, and an inclined leg whose inclination was varied during the tests between 90° and 15°. The bent cylinder was oriented in the wind tunnel with the vertical leg upstream and the inclined leg downstream, and the vortex shedding frequency was measured with hot-wire anemometry at several locations behind the inclined leg. The present bent cylinder design improves upon those previously considered by providing a finer control on the upstream boundary condition acting upon the inclined leg, which in the present design is not affected by the yaw angle of the inclined leg. With the exception of free-end effects, only noticeable for certain inclinations and Reynolds number values, inclination effects were surprisingly not observed, and the frequency of vortex shedding measured behind the inclined leg of the bent cylinder was consistent (within a few percent) with the cross-flow vortex shedding frequency at the same flow velocity. The present results corroborate and significantly extend the limited observations on bent cylinders available in the literature, further highlighting the importance of the upstream boundary condition on the vortex shedding process with inclined cylinders. Full article

The formation mechanism of extreme waves in the coastal areas is still an open contemporary problem in fluid mechanics and ocean engineering. Previous studies have shown that the transition of water depth from a deeper to a shallower zone increases the occurrence probability of large waves. Indeed, more efforts are required to improve the understanding of extreme wave statistics variations in such conditions. To achieve this goal, large scale experiments of unidirectional irregular waves propagating over a variable bottom profile considering different transition water depths were performed. The validation of two highly nonlinear numerical models was performed for one representative case. The collected data were examined and interpreted by using spectral or bispectral analysis as well as statistical analysis. The higher probability of occurrence of large waves was confirmed by the statistical distributions built from the measured free surface elevation time series as well as by the local maximum values of skewness and kurtosis around the end of the slope. Strong second-order nonlinear effects were highlighted as waves propagate into the shallower region. A significant amount of wave energy was transmitted to low-frequency modes. Based on the experimental data, we conclude that the formation of extreme waves is mainly related to the second-order effect, which is also responsible for the generation of long waves. It is shown that higher-order nonlinearities are negligible in these sets of experiments. Several existing models for wave height distributions were compared and analysed. It appears that the generalised Boccotti’s distribution can predict the exceedance of large wave heights with good confidence. Full article

We present dimensionally reduced Reynolds type equations for steady lubricating flows of incompressible non-Newtonian fluids with shear-dependent viscosity by employing a rigorous perturbation analysis on the governing equations of motion. Our analysis shows that, depending on the strength of the power-law character of the fluid, the novel equation can either present itself as a higher-order correction to the classical Reynolds equation or as a completely new nonlinear Reynolds type equation. Both equations are applied to two classic problems: the flow between a rolling rigid cylinder and a rigid plane and the flow in an eccentric journal bearing. Full article

Although one-dimensional non-linear diffusion equations are commonly used to model flow dynamics in aquifers and fissures, they disregard multiple effects of real-life flows. Similarity analysis may allow further analytical reduction of these equations, but it is often difficult to provide applicable initial and boundary conditions in practice, or know the magnitude of effects neglected by the 1D model. Furthermore, when multiple simplifying assumptions are made, the sources of discrepancy between modeled and observed data are difficult to identify. We derive one such model of viscous flow in a parabolic fissure from first principals. The parabolic fissure is formed by extruding an upward opening parabola in a horizontal direction. In this setting, permeability is a power law function of height, resulting in a generalized Boussinesq equation. To gauge the effects neglected by this model, 3D Navier-Stokes multiphase flow simulations are conducted for the same geometry. Parameter variations are performed to assess the nature of errors induced by applying the 1D model to a realistic scenario, where the initial and boundary conditions can not be matched exactly. Numerical simulations reveal an undercutting effect observed in laboratory experiments, but not modeled when the Dupuit-Forchheimer assumption is applied. By selectively controlling the effects placed on the free surface in 3D simulations, we are able to demonstrate that free surface slope is the primary driver of the undercutting effect. A consistent lag and overshoot flow regime is observed in the 3D simulations as compared to the 1D model, based on the choice of initial condition. This implies that the undercutting effect is partially induced by the initial condition. Additionally, the presented numerical evidence shows that some of the flow behavior unaccounted for in the 1D model scales with the 1D model parameters. Full article

We present the theoretical models and review the most recent results of a class of experiments in the field of surface gravity waves. These experiments serve as demonstration of an analogy to a broad variety of phenomena in optics and quantum mechanics. In particular, experiments involving Airy water-wave packets were carried out. The Airy wave packets have attracted tremendous attention in optics and quantum mechanics owing to their unique properties, spanning from an ability to propagate along parabolic trajectories without spreading, and to accumulating a phase that scales with the cubic power of time. Non-dispersive Cosine-Gauss wave packets and self-similar Hermite-Gauss wave packets, also well known in the field of optics and quantum mechanics, were recently studied using surface gravity waves as well. These wave packets demonstrated self-healing properties in water wave pulses as well, preserving their width despite being dispersive. Finally, this new approach also allows to observe diffractive focusing from a temporal slit with finite width. Full article

We study the steady free convective flow of a Bingham fluid in a porous channel where heat is supplied by both differential heating of the sidewalls and by means of a uniform internal heat generation. The detailed temperature profile is governing by an external and an internal Darcy-Rayleigh number. The presence of the Bingham fluid is characterised by means of a body force threshold as given by the Rees-Bingham number. The resulting flow field may then exhibit between two and four yield surfaces depending on the balance of magnitudes of the three nondimensional parameters. Some indication is given of how the locations of the yield surfaces evolve with the relative strength of the Darcy-Rayleigh numbers and the Rees-Bingham number. Finally, parameter space is delimited into those regions within which the different types of flow and stagnation patterns arise. Full article

A monolithic semi-implicit method is presented for three-dimensional simulation of fluid–structure interaction problems. The updated Lagrangian framework is used for the structure modeled by linear elasticity equation and, for the fluid governed by the Navier–Stokes equations, we employ the Arbitrary Lagrangian Eulerian method. We use a global mesh for the fluid–structure domain where the fluid–structure interface is an interior boundary. The continuity of velocity at the interface is automatically satisfied by using globally continuous finite element for the velocity in the fluid–structure mesh. The method is fast because we solve only a linear system at each time step. Three-dimensional numerical tests are presented. Full article

In this paper, the static interaction of a train of three cylinders in a Bingham fluid is studied numerically using Computational Fluid Dynamics. The variation of drag forces for the cylinders in several configurations is investigated. Positions of the particles in relation to the reference particle are recognized by the separation distance between the cylinders. A steady state field is considered, with Bingham numbers between 5 and 150. Several separation distances (d) were considered, such that 2.0D ≤ d ≤ 6.0D where D is the cylinder diameter. The Reynolds number was chosen in the range of 5 ≤ Re ≤ 40. In particular, the effect of the separation distance, Reynolds number and Bingham number on the shape and size of the unyielded regions was investigated. The functional dependence of this region and the drag coefficient is explored. The present results reveal the significant influence of the gap between the cylinders on the drag force and the shape of the unyielded regions surrounding the cylinders. It was found that there are several configurations in which the drag forces over the first and the third cylinders are almost equal depending on variation of the Bi, Re and the separation distance. Full article
