Fabrication and Characterization of Inhomogeneous Curved Artificial Compound Eye

1
Department of Mechanical Engineering, Shenyang Ligong University, Shenyang 110159, Liaoning, China
2
Technology Center of CAD/CAM, Shenyang Ligong University, Shenyang 110159, Liaoning, China
3
Lovol Heavy Industry Co., Ltd., Weifang 261206, Shandong, China
*
Author to whom correspondence should be addressed.
Received: 2 April 2018 / Revised: 27 April 2018 / Accepted: 14 May 2018 / Published: 15 May 2018
Full-Text   |   PDF [2919 KB, uploaded 15 May 2018]   |

Abstract

Compared with the conventional compound eye processing method, a new fabrication method—namely, a mold casting method—was presented. This method is simple, low-cost, easy to implement, and can be reused. A bionic compound eye array model with 61 ommatidia arranged inhomogeneously onto a curved surface was fabricated. The curved surface had a radius of 9 mm and a thickness of 0.5 mm. The margin imaging quality was improved significantly by the analysis of light beam focus and the optical imaging properties of the fabricated compound eye. The sub-image of each ommatidium had a high resolution. There was 5% error between the collecting spot brightness and simulation analysis results, which proved that the production method is feasible. View Full-Text
Keywords: microfabrication; compound eye; polydimethylsiloxane (PDMS); mold microfabrication; compound eye; polydimethylsiloxane (PDMS); mold
