Progressive Damage Numerical Modelling and Simulation of Aircraft Composite Bolted Joints Bearing Response
1
Jiangsu Key Laboratory of Precision and Micro-Manufacturing Technology, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China
2
Centre of Aeronautics, School of Aerospace, Transport and Manufacturing, Cranfield University, Cranfield MK43 0AL, UK
3
Institute of Aeronautical Manufacturing Technology, Shanghai Aircraft Manufacturing Co. Ltd., Shanghai 200126, China
4
AECC Hunan Aviation Powerplant Research Institute, Zhuzhou 412002, China
*
Authors to whom correspondence should be addressed.
Materials 2020, 13(24), 5606; https://doi.org/10.3390/ma13245606
Received: 14 November 2020
/
Revised: 4 December 2020
/
Accepted: 4 December 2020
/
Published: 8 December 2020
(This article belongs to the Section Advanced Materials Characterization)
Finite element numerical progressive damage modelling and simulations applied to the strength prediction of airframe bolted joints on composite laminates can lead to shorter and more efficient product cycles in terms of design, analysis and certification, while benefiting the economic manufacturing of composite structures. In the study herein, experimental bolted joint bearing tests were carried out to study the strength and failure modes of fastened composite plates under static tensile loads. The experimental results were subsequently benchmarked against various progressive damage numerical modelling simulations where the effects of different failure criteria, damage variables and subroutines were considered. Evidence was produced that indicated that both the accuracy of the simulation results and the speed of calculation were affected by the choice of user input and numerical scheme.
View Full-Text
Keywords:
structural joints; mechanical testing; strength; numerical modelling
▼
