Aerospace, Volume 5, Issue 1 (March 2018)

  • Issues are regarded as officially published after their release is announced to the table of contents alert mailing list.
  • You may sign up for e-mail alerts to receive table of contents of newly released issues.
  • PDF is the official format for papers published in both, html and pdf forms. To view the papers in pdf format, click on the "PDF Full-text" link, and use the free Adobe Readerexternal link to open them.
Cover Story (view full-size image) This turbofan engine is a cooperation between MTU Aero Engines located in Munich and Pratt & [...] Read more.
View options order results:
result details:
Displaying articles 1-32
Export citation of selected articles as:
Open AccessReview Buoyancy-Induced Heat Transfer inside Compressor Rotors: Overview of Theoretical Models
Received: 16 February 2018 / Revised: 12 March 2018 / Accepted: 13 March 2018 / Published: 17 March 2018
PDF Full-text (5917 KB) | HTML Full-text | XML Full-text
Abstract
Increasing pressures in gas-turbine compressors, particularly in aeroengines where the pressure ratios can be above 50:1, require smaller compressor blades and an increasing focus on blade-clearance control. The blade clearance depends on the radial growth of the compressor discs, which in turn depends
[...] Read more.
Increasing pressures in gas-turbine compressors, particularly in aeroengines where the pressure ratios can be above 50:1, require smaller compressor blades and an increasing focus on blade-clearance control. The blade clearance depends on the radial growth of the compressor discs, which in turn depends on the temperature and stress in the discs. As the flow inside the disc cavities is buoyancy-driven, calculation of the disc temperature is a conjugate problem: the heat transfer from the disc is coupled with the air temperature inside the cavity. The flow inside the cavity is three-dimensional, unsteady and unstable, so computational fluid dynamics is not only expensive and time-consuming, it is also unable to achieve accurate solutions at the high Grashof numbers found in modern compressors. Many designers rely on empirical equations based on inappropriate physical models, and recently the authors have produced a series of papers on physically-based theoretical modelling of buoyancy-induced heat transfer in the rotating cavities found inside compressor rotors. Predictions from these models, all of which are for laminar flow, have been validated using measurements made in open and closed compressor rigs for a range of flow parameters representative of those found inside compressor rotors. (The fact that laminar buoyancy models can be used for large Grashof numbers (up to 10 12 ), where most engineers expect the flow to be turbulent, is attributed to the large Coriolis accelerations in the fluid core and to the fact that there is only a small difference between the rotational speed of the core and that of the discs.) As many as 223 separate tests were analysed in the validation of the models, and good agreement between the predictions and measurements was achieved for most of these cases. This overview paper has collected together the equations from these papers, which should be helpful to designers and research workers. The paper also points out the limitations of the models, all of which are for steady flow, and shows where further experimental evidence is needed. Full article
(This article belongs to the Special Issue Secondary Air Systems in Gas Turbine Engines)
Figures

Figure 1

Open AccessArticle CFD Validation and Flow Control of RAE-M2129 S-Duct Diffuser Using CREATETM-AV Kestrel Simulation Tools
Received: 17 January 2018 / Revised: 9 March 2018 / Accepted: 14 March 2018 / Published: 16 March 2018
PDF Full-text (8072 KB) | HTML Full-text | XML Full-text
Abstract
The flow physics modeling and validation of the Royal Aircraft Establishment (RAE) subsonic intake Model 2129 (M2129) are presented. This intake has an 18 inches long S duct with a 5.4 inches offset, an external and an internal lip, forward and rear extended
[...] Read more.
The flow physics modeling and validation of the Royal Aircraft Establishment (RAE) subsonic intake Model 2129 (M2129) are presented. This intake has an 18 inches long S duct with a 5.4 inches offset, an external and an internal lip, forward and rear extended ducts, and a center-positioned bullet before the outlet. Steady-state and unsteady experimental data are available for this duct. The measurements include engine face conditions (pressure recovery, static pressure to free-stream total pressure ratio, and distortion coefficient at the worst 60 sector or DC60), as well as wall static pressure data along the duct. The intake has been modeled with HPCMP CREATE TM -AV Kestrel simulation tools. The validation results are presented including the effects of turbulence models on predictions. In general, very good agreement (difference errors are less than 6%) was found between predictions and measurements. Secondary flow at the first bend and a region of flow separation are predicted at the starboard wall with an averaged DC60 coefficient of 0.2945 at the engine face. Next, a passive and an active flow control method are computationally investigated. The passive one uses vane-type vortex generators and the active one has synthetic jet actuators. The results show that considered passive and active flow control methods reduce the distortion coefficient at the engine face and the worst 60 sector to 0.1361 and 0.0881, respectively. The flow control performance trends agree with those obtained in experiments as well. These results give confidence to apply the Kestrel simulation tools for the intake design studies of new and unconventional vehicles and hence to reduce the uncertainties during their flight testing. Full article
(This article belongs to the Special Issue Computational Aerodynamic Modeling of Aerospace Vehicles)
Figures

Figure 1

Open AccessArticle Numerical Simulation of Heat Transfer and Chemistry in the Wake behind a Hypersonic Slender Body at Angle of Attack
Received: 13 December 2017 / Revised: 22 February 2018 / Accepted: 24 February 2018 / Published: 11 March 2018
PDF Full-text (10415 KB) | HTML Full-text | XML Full-text
Abstract
The effect of thermal and chemical boundary conditions on the structure and chemical composition of the wake behind a 3D Mach 7 sphere-cone at an angle of attack of 5 degrees and an altitude of roughly 30,000 m is explored. A special emphasis
[...] Read more.
The effect of thermal and chemical boundary conditions on the structure and chemical composition of the wake behind a 3D Mach 7 sphere-cone at an angle of attack of 5 degrees and an altitude of roughly 30,000 m is explored. A special emphasis is placed on determining the number density of chemical species which might lead to detection via the electromagnetic spectrum. The use of non-ablating cold-wall, adiabatic, and radiative equilibrium wall boundary conditions are used to simulate extremes in potential thermal protection system designs. Non-ablating, as well as an ablating boundary condition using the “steady-state ablation” assumption to compute a surface energy balance on the wall are used in order to determine the impacts of ablation on wake composition. On-body thermal boundary conditions downstream of an ablating nose are found to significantly affect wake temperature and composition, while the role of catalysis is found to change the composition only marginally except at very high temperatures on the cone’s surface for the flow regime considered. Ablation is found to drive the extensive production of detectable species otherwise unrelated to ablation, whereas if ablation is not present at all, air-species which would otherwise produce detectable spectra are minimal. Studies of afterbody cooling techniques, as well as shape, are recommended for further analysis. Full article
(This article belongs to the Special Issue Computational Aerodynamic Modeling of Aerospace Vehicles)
Figures

Figure 1

Open AccessArticle Prilling and Coating of Ammonium Dinitramide (ADN) Solid Green Propellant in Toluene Mixture Using Ultrasound Sonication
Received: 18 December 2017 / Revised: 6 March 2018 / Accepted: 7 March 2018 / Published: 9 March 2018
PDF Full-text (4743 KB) | HTML Full-text | XML Full-text
Abstract
Ammonium Dinitramide (ADN) in its generic form has a long needle shaped structure, which hinders higher solid loading. Therefore, it is of utmost importance to optimize its crystal morphology into octagonal shapes. Moreover, the low critical humidity level of ADN renders it unusable
[...] Read more.
Ammonium Dinitramide (ADN) in its generic form has a long needle shaped structure, which hinders higher solid loading. Therefore, it is of utmost importance to optimize its crystal morphology into octagonal shapes. Moreover, the low critical humidity level of ADN renders it unusable in a humid climate. Hence, encapsulation with a hydrophobic polymer is necessary. In the present work, ADN was synthesized by nitration of potassium sulfamate with mixed acid nitration. The product was then mixed with toluene, graphene, citryl ammonium butyl, Cab-o-sil, and coating polymer (Polystyrene or HTPB) and treated with ultrasound to obtain semi-spherical ADN-coated particles. The method offers a reduction in operating temperature and elimination of ADN melting in the shape-altering process. In addition, the ADN product has a similar particle size and thermal stability compared to those in a conventional ADN melt-prilling method. The ADN product investigated under SEM confirms the particle morphological change from long needles into semi-spherical shapes. The particle size obtained, in the micrometer range, is ideal for higher theoretical maximum density. Furthermore, the ultrasound-treated ADN particles show significant reduction in moisture absorption, from 68% to 16% at 65% relative humidity. The DSC result shows no degradation of thermal stability of the coated particles. Full article
Figures

Graphical abstract

Open AccessArticle Multi-UAV Doppler Information Fusion for Target Tracking Based on Distributed High Degrees Information Filters
Received: 1 January 2018 / Revised: 14 February 2018 / Accepted: 22 February 2018 / Published: 8 March 2018
PDF Full-text (1641 KB) | HTML Full-text | XML Full-text
Abstract
Multi-Unmanned Aerial Vehicle (UAV) Doppler-based target tracking has not been widely investigated, specifically when using modern nonlinear information filters. A high-degree Gauss–Hermite information filter, as well as a seventh-degree cubature information filter (CIF), is developed to improve the fifth-degree and third-degree CIFs proposed
[...] Read more.
Multi-Unmanned Aerial Vehicle (UAV) Doppler-based target tracking has not been widely investigated, specifically when using modern nonlinear information filters. A high-degree Gauss–Hermite information filter, as well as a seventh-degree cubature information filter (CIF), is developed to improve the fifth-degree and third-degree CIFs proposed in the most recent related literature. These algorithms are applied to maneuvering target tracking based on Radar Doppler range/range rate signals. To achieve this purpose, different measurement models such as range-only, range rate, and bearing-only tracking are used in the simulations. In this paper, the mobile sensor target tracking problem is addressed and solved by a higher-degree class of quadrature information filters (HQIFs). A centralized fusion architecture based on distributed information filtering is proposed, and yielded excellent results. Three high dynamic UAVs are simulated with synchronized Doppler measurement broadcasted in parallel channels to the control center for global information fusion. Interesting results are obtained, with the superiority of certain classes of higher-degree quadrature information filters. Full article
(This article belongs to the collection Unmanned Aerial Systems)
Figures

Graphical abstract

Open AccessArticle Field Trial Measurements to Validate a Stochastic Aircraft Boarding Model
Received: 2 February 2018 / Revised: 1 March 2018 / Accepted: 5 March 2018 / Published: 7 March 2018
Cited by 2 | PDF Full-text (3547 KB) | HTML Full-text | XML Full-text
Abstract
Efficient boarding procedures have to consider both operational constraints and the individual passenger behavior. In contrast to the aircraft handling processes of fueling, catering and cleaning, the boarding process is more driven by passengers than by airport or airline operators. This paper delivers
[...] Read more.
Efficient boarding procedures have to consider both operational constraints and the individual passenger behavior. In contrast to the aircraft handling processes of fueling, catering and cleaning, the boarding process is more driven by passengers than by airport or airline operators. This paper delivers a comprehensive set of operational data including classification of boarding times, passenger arrival times, times to store hand luggage, and passenger interactions in the aircraft cabin as a reliable basis for calibrating models for aircraft boarding. In this paper, a microscopic approach is used to model the passenger behavior, where the passenger movement is defined as a one-dimensional, stochastic, and time/space discrete transition process. This model is used to compare measurements from field trials of boarding procedures with simulation results and demonstrates a deviation smaller than 5%. Full article
Figures

Graphical abstract

Open AccessArticle Experimental Study and Neural Network Modeling of Aerodynamic Characteristics of Canard Aircraft at High Angles of Attack
Received: 29 December 2017 / Revised: 18 February 2018 / Accepted: 28 February 2018 / Published: 2 March 2018
PDF Full-text (9437 KB) | HTML Full-text | XML Full-text
Abstract
Flow over an aircraft at high angles of attack is characterized by a combination of separated and vortical flows that interact with each other and with the airframe. As a result, there is a set of phenomena negatively affecting the aircraft’s performance, stability
[...] Read more.
Flow over an aircraft at high angles of attack is characterized by a combination of separated and vortical flows that interact with each other and with the airframe. As a result, there is a set of phenomena negatively affecting the aircraft’s performance, stability and control, namely, degradation of lifting force, nonlinear variation of pitching moment, positive damping, etc. Wind tunnel study of aerodynamic characteristics of a prospective transonic aircraft, which is in a canard configuration, is discussed in the paper. A three-stage experimental campaign was undertaken. In the first stage, a steady aerodynamic experiment was conducted. The influence of a reduced oscillation frequency and angle of attack on unsteady aerodynamic characteristics was studied in the second stage. In the third stage, forced large-amplitude oscillation tests were carried out for the detailed investigation of the unsteady aerodynamics in the extended flight envelope. The experimental results demonstrate the strongly nonlinear behavior of the aerodynamic characteristics because of canard vortex effects on the wing. The obtained data are used to design and test mathematical models of unsteady aerodynamics via different popular approaches, namely the Neural Network (NN) technique and the phenomenological state space modeling technique. Different NN architectures, namely feed-forward and recurrent, are considered and compared. Thorough analysis of the performance of the models revealed that the Recurrent Neural Network (RNN) is a universal approximation tool for modeling of dynamic processes with high generalization abilities. Full article
(This article belongs to the Special Issue Computational Aerodynamic Modeling of Aerospace Vehicles)
Figures

Graphical abstract

Open AccessArticle Design of a Facility for Studying Shock-Cell Noise on Single and Coaxial Jets
Received: 12 January 2018 / Revised: 24 February 2018 / Accepted: 25 February 2018 / Published: 1 March 2018
PDF Full-text (21169 KB) | HTML Full-text | XML Full-text
Abstract
Shock-cell noise occurs in aero-engines when the nozzle exhaust is supersonic and shock-cells are present in the jet. In commercial turbofan engines, at cruise, the secondary flow is often supersonic underexpanded, with the formation of annular shock-cells in the jet and consequent onset
[...] Read more.
Shock-cell noise occurs in aero-engines when the nozzle exhaust is supersonic and shock-cells are present in the jet. In commercial turbofan engines, at cruise, the secondary flow is often supersonic underexpanded, with the formation of annular shock-cells in the jet and consequent onset of shock-cell noise. This paper aims at describing the design process of the new facility FAST (Free jet AeroacouSTic laboratory) at the von Karman Institute, aimed at the investigation of the shock-cell noise phenomenon on a dual stream jet. The rig consists of a coaxial open jet, with supersonic capability for both the primary and secondary flow. A coaxial silencer was designed to suppress the spurious noise coming from the feeding lines. Computational fluid dynamics (CFD) simulations of the coaxial jet and acoustic simulations of the silencer have been carried out to support the design choices. Finally, the rig has been validated by performing experimental measurements on a supersonic single stream jet and comparing the results with the literature. Fine-scale PIV (Particle Image Velocimetry) coupled with a microphone array in the far field have been used in this scope. Preliminary results of the dual stream jet are also shown. Full article
(This article belongs to the Special Issue Under-Expanded Jets)
Figures

Figure 1

Open AccessReview Testing-Based Approach to Determining the Divergence Speed of Slung Loads
Received: 15 December 2017 / Revised: 19 February 2018 / Accepted: 25 February 2018 / Published: 28 February 2018
PDF Full-text (11670 KB) | HTML Full-text | XML Full-text
Abstract
When a rotorcraft carries an external slung load, flight speed is often limited by the fear of divergent oscillations, rather than vehicle performance. Since slung objects can be of any shape, incorporating the aerodynamics with sufficient accuracy to predict safe speed has been
[...] Read more.
When a rotorcraft carries an external slung load, flight speed is often limited by the fear of divergent oscillations, rather than vehicle performance. Since slung objects can be of any shape, incorporating the aerodynamics with sufficient accuracy to predict safe speed has been a problem. The uncertainty forces certifying authorities to set conservative limits on speed to avoid divergence. Obtaining the aerodynamic coefficients of bluff bodies was excessively time-consuming in experiments, and impractical in computations. This review traces the evolution of progress in the area. Prior thinking was to use computations for prediction, with the computational codes validated using a few samples of experiments. This approach has not led to valid general predictions. Data were sparse and a-priori predictions were rarer. A continuous rotation approach has enabled swift measurements of 6-degrees-of-freedom aerodynamic load maps with high resolution about several axes of rotation. The resulting knowledge base in turn permits a swift determination of dynamics up to divergence, with wind tunnel tests where necessary to fill interpolation gaps in the knowledge base. The essence of efficient and swift dynamics simulation with a few well-tested assumptions is described. Under many relevant conditions, the vehicle flight dynamics can be safely decoupled from those of the slung load. While rotor wake swirl causes the payload to rotate at liftoff and landing, this effect can be incorporated into the simulation. Recent success in explaining two well-documented flight test cases provides strong evidence that predictions can be made for most missions swiftly. Full article
(This article belongs to the Special Issue Aircraft Dynamics & Control)
Figures

Figure 1

Open AccessArticle Experimental and Numerical Investigation of the Outer Ring Cooling Concept in a Hybrid and in an All-Steel Ball Bearing Used in Aero-Engines by the Introduction of a Helical Duct
Received: 27 November 2017 / Revised: 14 February 2018 / Accepted: 18 February 2018 / Published: 28 February 2018
PDF Full-text (11767 KB) | HTML Full-text | XML Full-text
Abstract
Rolling element bearings for aero engine applications have to withstand very challenging operating conditions because of the high thermal impact due to elevated rotational speeds and loads. The high rate of heat generation in the bearing has to be sustained by the materials,
[...] Read more.
Rolling element bearings for aero engine applications have to withstand very challenging operating conditions because of the high thermal impact due to elevated rotational speeds and loads. The high rate of heat generation in the bearing has to be sustained by the materials, and in the absence of lubrication these will fail within seconds. For this reason, aero engine bearings have to be lubricated and cooled by a continuous oil stream. When the oil has reached the outer ring it has already been heated up, thus its capability to remove extra heat from the outer ring is considerably reduced. Increasing the mass flow of oil to the bearing is not a solution since excess oil quantity would cause high parasitic losses (churning) in the bearing chamber and also increase the demands in the oil system for oil storage, scavenging, cooling, hardware weight, etc. A method has been developed for actively cooling the outer ring of the bearing. The idea behind the outer ring cooling concept was adopted from fins that are used for cooling electronic devices. A spiral groove engraved in the outer ring material of the bearing would function as a fin body with oil instead of air as the cooling medium. The method was first evaluated in an all steel ball bearing and the results were a 50% reduction in the lubricating oil flow with an additional reduction in heat generation by more than 25%. It was then applied on a Hybrid ball bearing of the same size and the former results were reconfirmed. Hybrid bearings are a combination of steel made parts, like the outer ring, the inner ring, and the cage and of ceramic rolling elements. This paper describes the work done to-date as a follow up of the work described in, and demonstrates the potential of the outer ring cooling for a bearing. Friction loss coefficient, Nusselt number, and efficiency correlations have been developed on the basis of the test results and have been compared to correlations from other authors. Computational Fluid Dynamics (CFD) analysis with ANSYS CFX has been used to verify test results and also for parametric studies. Full article
(This article belongs to the Special Issue Aeroengine)
Figures

Graphical abstract

Open AccessArticle Predicting Non-Linear Flow Phenomena through Different Characteristics-Based Schemes
Received: 18 November 2017 / Revised: 7 January 2018 / Accepted: 18 February 2018 / Published: 24 February 2018
PDF Full-text (1110 KB) | HTML Full-text | XML Full-text
Abstract
The present work investigates the bifurcation properties of the Navier–Stokes equations using characteristics-based schemes and Riemann solvers to test their suitability to predict non-linear flow phenomena encountered in aerospace applications. We make use of a single- and multi-directional characteristics-based scheme and Rusanov’s Riemann
[...] Read more.
The present work investigates the bifurcation properties of the Navier–Stokes equations using characteristics-based schemes and Riemann solvers to test their suitability to predict non-linear flow phenomena encountered in aerospace applications. We make use of a single- and multi-directional characteristics-based scheme and Rusanov’s Riemann solver to treat the convective term through a Godunov-type method. We use the Artificial Compressibility (AC) method and a unified Fractional-Step, Artificial Compressibility with Pressure-Projection (FSAC-PP) method for all considered schemes in a channel with a sudden expansion which provides highly non-linear flow features at low Reynolds numbers that produces a non-symmetrical flow field. Using the AC method, our results show that the multi-directional characteristics-based scheme is capable of predicting these phenomena while the single-directional counterpart does not predict the correct flow field. Both schemes and also Riemann solver approaches produce accurate results when the FSAC-PP method is used, showing that the incompressible method plays a dominant role in determining the behaviour of the flow. This also means that it is not just the numerical interpolation scheme which is responsible for the overall accuracy. Furthermore, we show that the FSAC-PP method provides faster convergence and higher level of accuracy, making it a prime candidate for aerospace applications. Full article
(This article belongs to the Special Issue Computational Aerodynamic Modeling of Aerospace Vehicles)
Figures

Figure 1

Open AccessArticle Modeling and Dynamics of HTS Motors for Aircraft Electric Propulsion
Received: 15 December 2017 / Revised: 6 February 2018 / Accepted: 12 February 2018 / Published: 22 February 2018
PDF Full-text (1140 KB) | HTML Full-text | XML Full-text
Abstract
In this paper, the methodology of how a dynamic model of a conventional permanent magnet synchronous motor (PMSM) may be modified to model the dynamics of a high-temperature superconductor (HTS) machine is illustrated. Simulations of a typical PMSM operating under room temperature conditions
[...] Read more.
In this paper, the methodology of how a dynamic model of a conventional permanent magnet synchronous motor (PMSM) may be modified to model the dynamics of a high-temperature superconductor (HTS) machine is illustrated. Simulations of a typical PMSM operating under room temperature conditions and also at temperatures when the stator windings are superconducting are compared. Given a matching set of values for the stator resistance at superconducting temperature and flux-trapped rotor field, it is shown that the performance of the HTS PMSM is quite comparable to a PMSM under normal room temperature operating conditions, provided the parameters of the motor are appropriately related to each other. From these simulations, a number of strategies for operating the motor so as to get the propeller to deliver thrust with maximum propulsive efficiency are discussed. It is concluded that the motor–propeller system must be operated so as to deliver thrust at the maximum propulsive efficiency point. This, in turn, necessitates continuous tracking of the maximum propulsive efficiency point and consequently it is essential that the controller requires a maximum propulsive efficiency point tracking (MPEPT) outer loop. Full article
(This article belongs to the Special Issue Electric Aircraft)
Figures

Figure 1

Open AccessArticle Rupture of a Cryogenic Composite Overwrapped Pressure Vessel Following a High-Speed Particle Impact
Received: 2 January 2018 / Revised: 8 February 2018 / Accepted: 14 February 2018 / Published: 18 February 2018
Cited by 1 | PDF Full-text (2398 KB) | HTML Full-text | XML Full-text
Abstract
A primary spacecraft design consideration is the anticipation and mitigation of the possible damage that might occur in the event of an on-orbit micro-meteoroid or orbital debris (MMOD) particle impact. While considerable effort has been expended in the study of non-pressurized spacecraft components
[...] Read more.
A primary spacecraft design consideration is the anticipation and mitigation of the possible damage that might occur in the event of an on-orbit micro-meteoroid or orbital debris (MMOD) particle impact. While considerable effort has been expended in the study of non-pressurized spacecraft components under room temperature conditions to MMOD impacts, technical and safety challenges have limited the number of tests that have been conducted on pressurized elements of such spacecraft, especially under cryogenic conditions. This paper presents the development of a data-driven equation for composite material pressure vessels under cryogenic operating conditions that differentiate between impact conditions that, given a tank wall perforation, would result in only a small hole or crack from those that would cause catastrophic tank failure. This equation would be useful to a spacecraft designer who might be able to tailor the design parameters and operating conditions of, for example, a fuel tank so that if such a tank were to be struck and perforated by the impact of an MMOD particle, then only a hole would occur and neither catastrophic spacecraft failure nor additional sizable debris would be created as a result of that impact. Full article
(This article belongs to the Special Issue Space Debris: Impact and Remediation)
Figures

Graphical abstract

Open AccessArticle Thrust Augmentation by Airframe-Integrated Linear-Spike Nozzle Concept for High-Speed Aircraft
Received: 8 December 2017 / Revised: 2 February 2018 / Accepted: 6 February 2018 / Published: 9 February 2018
PDF Full-text (11675 KB) | HTML Full-text | XML Full-text
Abstract
The airframe-integrated linear-spike nozzle concept applied to an external nozzle for high-speed aircraft was evaluated with regard to the thrust augmentation capability and the trim balance. The main focus was on the vehicle aftbody. The baseline airframe geometry was first premised to be
[...] Read more.
The airframe-integrated linear-spike nozzle concept applied to an external nozzle for high-speed aircraft was evaluated with regard to the thrust augmentation capability and the trim balance. The main focus was on the vehicle aftbody. The baseline airframe geometry was first premised to be a hypersonic waverider design. The baseline aftbody case had an external nozzle comprised of a simple divergent nozzle and was hypothetically replaced with linear-spike external nozzle configurations. Performance evaluation was mainly conducted by considering the nozzle thrust generated by the pressure distribution on the external nozzle surface at the aftbody portion calculated by computer simulation at a given cruise condition with zero angle of attack. The thrust performance showed that the proposed linear-spike external nozzle concept was beneficial in thrust enhancement compared to the baseline geometry because the design of the proposed concept had a compression wall for the exhaust flow, which resulted in increasing the wall pressure. The configuration with the boattail and the angled inner nozzle exhibited further improvement in thrust performance. The trim balance evaluation showed that the aerodynamic center location appeared as acceptable. Thus, benefits were obtained by employing the airframe-integrated linear-spike external nozzle concept. Full article
(This article belongs to the Special Issue Propulsion/Airframe Integration)
Figures

Figure 1

Open AccessArticle Robust Autoland Design by Multi-Model ℋ Synthesis with a Focus on the Flare Phase
Received: 29 November 2017 / Revised: 26 January 2018 / Accepted: 7 February 2018 / Published: 9 February 2018
PDF Full-text (1580 KB) | HTML Full-text | XML Full-text
Abstract
Recent advances in the resolution of multi-model and multi-objective control problems via non-smooth optimization are exploited to provide a novel methodology in the challenging context of autoland design. Based on the structured H control framework, this paper focuses on the demanding flare
[...] Read more.
Recent advances in the resolution of multi-model and multi-objective control problems via non-smooth optimization are exploited to provide a novel methodology in the challenging context of autoland design. Based on the structured H control framework, this paper focuses on the demanding flare phase under strong wind conditions and parametric uncertainties. More precisely, the objective is to control the vertical speed of the aircraft before touchdown while minimizing the impact of windshear, ground effects, and airspeed variations. The latter is indeed no longer controlled accurately during flare and strongly affected by wind. In addition, parametric uncertainties are to be considered when designing the control laws. To this purpose, extending previous results published by the authors in a conference paper, a specific multi-model strategy taking into account variations of mass and center-of-gravity location is considered. The methodology is illustrated on a realistic aircraft benchmark proposed by the authors, which is fully described in this paper and freely available from the SMAC (Systems Modeling Analysis & Control) toolbox website (http://w3.onera.fr/smac). Full article
(This article belongs to the Special Issue Aircraft Dynamics & Control)
Figures

Figure 1
