Fibers 2017, 5(2), 21; doi:10.3390/fib5020021

Compact Narrow Linewidth Actively Q-Switched Er–Yb Double-Clad Fiber Laser

1
Instituto Nacional de Astrofísica, Óptica y Electrónica, Luis Enrique Erro 1, Sta. María Tonantzintla, Puebla 72824, Mexico
2
CONACyT—Instituto Nacional de Astrofísica, Óptica y Electrónica, Luis Enrique Erro 1, Sta. María Tonantzintla, Puebla 72824, Mexico
3
CONACyT—Universidad Autónoma de Nuevo León, Av. Universidad S/N San Nicolás de los Garza, Nuevo León 66451, Mexico
4
Universidad Autónoma de Nuevo León, Av. Universidad S/N San Nicolás de los Garza, Nuevo León 66451, Mexico
*
Author to whom correspondence should be addressed.
Academic Editors: Giancarlo C. Righini, Shibin Jiang and Francesco Prudenzano
Received: 30 March 2017 / Revised: 13 May 2017 / Accepted: 29 May 2017 / Published: 3 June 2017
(This article belongs to the Special Issue Advances in Optical Fibers II)
View Full-Text   |   Download PDF [2361 KB, uploaded 6 June 2017]   |

Abstract

Actively Q-switched laser operation of a narrow linewidth compact fiber laser based on an Er–Yb double-clad fiber is presented. The laser linewidth as a function of the repetition rate and the Q-switched pulses characteristics for different pump powers are experimentally analyzed. Stable Q-switched laser operation with spectral laser linewidth of 73 pm in a repetition rate range from 90 to 270 kHz is obtained. The minimum pulse duration of 178 ns, maximum peak power of 30.5 W, and maximum pulse energy of 5.4 µJ are observed. The maximum average power reached is 1.1 W. View Full-Text
Keywords: fiber lasers; Q-switched lasers; Er–Yb double-clad fiber; fiber Bragg gratings fiber lasers; Q-switched lasers; Er–Yb double-clad fiber; fiber Bragg gratings
Figures

Figure 1
