Open AccessArticle
Appl. Sci. 2018, 8(2), 175; doi:10.3390/app8020175

Application of an Artificial Fish Swarm Algorithm in an Optimum Tuned Mass Damper Design for a Pedestrian Bridge

1
Research Institute of Structural Engineering and Disaster Reduction, Tongji University, Shanghai 200092, China
2
State Key Laboratory of Disaster Reduction in Civil Engineering, Tongji University, Shanghai 200092, China
3
Shanghai Zhili Vibration Technology Co., Ltd., Shanghai 200092, China
*
Author to whom correspondence should be addressed.
Received: 26 December 2017 / Revised: 15 January 2018 / Accepted: 24 January 2018 / Published: 25 January 2018
View Full-Text   |   Download PDF [2829 KB, uploaded 25 January 2018]   |

Abstract

Tuned mass damper (TMD) has a wide application in the human-induced vibration control of pedestrian bridges and its parameters have great influence on the control effects, hence it should be well designed. A new optimization method for a TMD system is proposed in this paper, based on the artificial fish swarm algorithm (AFSA), and the primary structural damping is taken into consideration. The optimization goal is to minimize the maximum dynamic amplification factor of the primary structure under external harmonic excitations. As a result, the optimized TMD has a smaller maximum dynamic amplification factor and better robustness. The optimum TMD parameters for a damped primary structure with different damping ratios and different TMD mass ratios are summarized in a table for simple, practical design, and the fitting equation is also provided. The TMD configuration optimized by the proposed method was shown to be superior to that optimized by other classical optimization methods. Finally, the application of an optimized TMD based on AFSA for a pedestrian bridge is proposed as a case study. The results show that the TMD designed based on AFSA has a smaller maximum dynamic amplification factor than the TMD designed based on the classic Den Hartog method and the TMD designed based on the Ioi Toshihiro method, and the optimized TMD has a good effect in controlling human-induced vibrations at different frequencies. View Full-Text
Keywords: tuned mass damper; human-induced vibrations; pedestrian bridge; artificial fish swarm algorithm; passive control tuned mass damper; human-induced vibrations; pedestrian bridge; artificial fish swarm algorithm; passive control
Figures

Figure 1

This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited. (CC BY 4.0).
