Open AccessReview
Appl. Sci. 2017, 7(3), 246; doi:10.3390/app7030246

Metal-Insulator-Metal Single Electron Transistors with Tunnel Barriers Prepared by Atomic Layer Deposition

1
Department of Electrical Engineering, University of Notre Dame, Notre Dame, IN 46556, USA
2
Lashkaryov Institute of Semiconductor Physics, 03028 Kyiv, Ukraine
3
Present address: Electrical Engineering and Computer Sciences, University of California, Berkeley, Berkeley, CA 94720-1770, USA
4
Present address: Intel Corp, 2501 NW 229th Ave., Hillsboro, OR 97124, USA
5
Present address: Cypress Semiconductor Corp, 2401 East 86th St., Bloomington, MN 55425, USA
*
Author to whom correspondence should be addressed.
Academic Editor: Antonio Ficarella
Received: 16 January 2017 / Accepted: 27 February 2017 / Published: 3 March 2017
(This article belongs to the Special Issue Applied Single-Electron Transistors)
View Full-Text   |   Download PDF [5024 KB, uploaded 6 March 2017]   |

Abstract

Single electron transistors are nanoscale electron devices that require thin, high-quality tunnel barriers to operate and have potential applications in sensing, metrology and beyond-CMOS computing schemes. Given that atomic layer deposition is used to form CMOS gate stacks with low trap densities and excellent thickness control, it is well-suited as a technique to form a variety of tunnel barriers. This work is a review of our recent research on atomic layer deposition and post-fabrication treatments to fabricate metallic single electron transistors with a variety of metals and dielectrics. View Full-Text
Keywords: single electron transistor; atomic layer deposition; tunnel barrier single electron transistor; atomic layer deposition; tunnel barrier
Figures

Figure 1

This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited. (CC BY 4.0).
