Minerals 2018, 8(3), 93; https://doi.org/10.3390/min8030093

Platy Galena from the Viburnum Trend, Southeast Missouri: Character, Mine Distribution, Paragenetic Position, Trace Element Content, Nature of Twinning, and Conditions of Formation

Department of Geological Sciences and Geological and Petroleum Engineering, Missouri University of Science and Technology, Rolla, MO 65401, USA
Received: 15 December 2017 / Revised: 11 February 2018 / Accepted: 23 February 2018 / Published: 2 March 2018
(This article belongs to the Special Issue Fundamentals and Frontiers in Mineralogy)
Full-Text   |   PDF [6672 KB, uploaded 2 March 2018]   |

Abstract

The Viburnum Trend of southeast Missouri is one of the world’s largest producers of lead. The lead occurs as galena, predominantly in two crystallographic forms, octahedrons and cubes. Many studies have shown that octahedral galena is paragentically early, the more abundant of the two crystal forms, and is commonly modified in the cube. Those studies also have shown that the cubic form is paragenetically later, less abundant than the octahedrons, and may exhibit minor octahedral modifications. Viburnum Trend galena crystals that exhibit a platy form have received almost no study. The reason for their lack of study is the rarity of their occurrence. This communication discusses their character, mine distribution, paragenetic position, trace element contents, nature of twinning, and speculated conditions of formation. It also compares their character to similar platy galena occurrences in Germany, Bulgaria, Russia, Mexico, and notes their occurrence at the Pine Point District in the Northwest Territories of Canada and at the Black Cloud mine in Colorado. Flat, platy galena crystals have been recognized to occur in very small amounts in the Magmont, Buick, Fletcher, Brushy Creek, and Sweetwater mines in the Viburnum Trend. In contrast, platy galena has never been observed to occur at the Casteel, West Fork, #27, #28, and #29 mines in the Trend. The platy crystals have formed early in the paragenetic sequence of the ores, prior to and coated by subsequently deposited druzy quartz and cubic galena. Spinel twinning of the octahedron produces flat platy crystals. The platy galena crystals of the Viburnum Trend are very similar in crystal morphology to platy galena crystals interpreted to be spinel twins in the Gonderbach Ag mine in NW Germany, the Dalnegorsk Pb-Zn (skarn deposit) mine in SE Russia, the Madan ore field of skarn Pb-Zn-Ag deposits of southern Bulgaria, and the large Naica skarn Pb mine of northern Mexico. The crystallization of certain crystal forms of galena has been ascribed to the incorporation of elevated contents of trace elements in some lead districts. Analysis of Viburnum platy galena crystals shows that they contain very low levels of trace elements: 3.1 ppm Ag, <2 ppm Bi, <2 ppm Sb, and <2 ppm As. Thus, elevated trace element content is not the cause for the development of Viburnum platy galena. It is speculated that the Viburnum spinel-twinned galena crystals were the result of rapid crystallization from oversaturated hydrothermal ore fluids. View Full-Text
Keywords: galena; morphology; spinel twins; trace elements; paragenesis; Viburnum Trend; Missouri galena; morphology; spinel twins; trace elements; paragenesis; Viburnum Trend; Missouri
