Open AccessArticle
Genes 2018, 9(1), 41; https://doi.org/10.3390/genes9010041

Network-Based Methods for Identifying Key Active Proteins in the Extracellular Electron Transfer Process in Shewanella oneidensis MR-1

1,2
and
1,*
1
State Key Laboratory of Bioelectronics, School of Biological Science and Medical Engineering, Southeast University, Nanjing 210096, China
2
Department of Mathematics and Computer Science, Chizhou College, Chizhou 247000, China
*
Author to whom correspondence should be addressed.
Received: 13 December 2017 / Revised: 7 January 2018 / Accepted: 12 January 2018 / Published: 16 January 2018
(This article belongs to the Section Microbial Genetics and Genomics)
View Full-Text   |   Download PDF [2864 KB, uploaded 16 January 2018]   |

Abstract

Shewanella oneidensis MR-1 can transfer electrons from the intracellular environment to the extracellular space of the cells to reduce the extracellular insoluble electron acceptors (Extracellular Electron Transfer, EET). Benefiting from this EET capability, Shewanella has been widely used in different areas, such as energy production, wastewater treatment, and bioremediation. Genome-wide proteomics data was used to determine the active proteins involved in activating the EET process. We identified 1012 proteins with decreased expression and 811 proteins with increased expression when the EET process changed from inactivation to activation. We then networked these proteins to construct the active protein networks, and identified the top 20 key active proteins by network centralization analysis, including metabolism- and energy-related proteins, signal and transcriptional regulatory proteins, translation-related proteins, and the EET-related proteins. We also constructed the integrated protein interaction and transcriptional regulatory networks for the active proteins, then found three exclusive active network motifs involved in activating the EET process—Bi-feedforward Loop, Regulatory Cascade with a Feedback, and Feedback with a Protein–Protein Interaction (PPI)—and identified the active proteins involved in these motifs. Both enrichment analysis and comparative analysis to the whole-genome data implicated the multiheme c-type cytochromes and multiple signal processing proteins involved in the process. Furthermore, the interactions of these motif-guided active proteins and the involved functional modules were discussed. Collectively, by using network-based methods, this work reported a proteome-wide search for the key active proteins that potentially activate the EET process. View Full-Text
Keywords: active protein; extracellular electron transfer; network-based methods; protein–protein interaction; transcriptional regulatory interaction active protein; extracellular electron transfer; network-based methods; protein–protein interaction; transcriptional regulatory interaction
Figures

Figure 1

This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited. (CC BY 4.0).

Supplementary material

SciFeed

Share & Cite This Article

MDPI and ACS Style

Ding, D.; Sun, X. Network-Based Methods for Identifying Key Active Proteins in the Extracellular Electron Transfer Process in Shewanella oneidensis MR-1. Genes 2018, 9, 41.
