Polymers 2016, 8(12), 435; doi:10.3390/polym8120435

Influence of a Crosslinker Containing an Azo Group on the Actuation Properties of a Photoactuating LCE System

Institute of Organic Chemistry, Johannes Gutenberg-Universität Mainz, D-55099 Mainz, Germany
*
Author to whom correspondence should be addressed.
Academic Editor: Leonid Ionov
Received: 15 October 2016 / Revised: 6 December 2016 / Accepted: 8 December 2016 / Published: 14 December 2016
(This article belongs to the Special Issue Polymeric Soft Actuators)
View Full-Text   |   Download PDF [3984 KB, uploaded 14 December 2016]   |

Abstract

Photoactuating liquid crystalline elastomers (LCE) are promising candidates for an application as artificial muscles in microdevices. In this work, we demonstrate that by optimizing (1) the illumination conditions and (2) the mixture of azo monomer and azo crosslinker, thick films of an all-azo LCE can be prepared, which show a strong length change without bending during photoactuation. This becomes possible by working with white light (about 440 nm), whose absorption is low, leading to a large penetration depth. By adding an azo crosslinker to a previously prepared system, several improvements of the actuation properties—like a stronger photoactuation at lower operational temperatures—could be achieved. In addition, films of different crosslinker concentrations and thicknesses were produced by photopolymerization at varying temperatures within a magnetic field, and their thermo- and photoresponsive behavior was investigated. An extraordinarily strong maximal thermal actuation of 46% and—by exposure to white light at 70 °C—a photoresponsive change in length of up to 40% in just about 13 s could be obtained. Even densely crosslinked samples were still able to photoactuate remarkably. Isothermal back-deformation could either be achieved by irradiation with red light (7 min) or by keeping the film in the dark (13 min). View Full-Text
Keywords: liquid crystalline elastomers; photoactuation; polymer film; light-responsive; azo; crosslinker; actuator; vis photo polymerization; liquid crystalline network liquid crystalline elastomers; photoactuation; polymer film; light-responsive; azo; crosslinker; actuator; vis photo polymerization; liquid crystalline network
Figures

Figure 1

This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited. (CC BY 4.0).

Supplementary material

Scifeed alert for new publications

Never miss any articles matching your research from any publisher
  • Get alerts for new papers matching your research
  • Find out the new papers from selected authors
  • Updated daily for 49'000+ journals and 6000+ publishers
  • Define your Scifeed now

SciFeed Share & Cite This Article

MDPI and ACS Style

Braun, L.B.; Linder, T.G.; Hessberger, T.; Zentel, R. Influence of a Crosslinker Containing an Azo Group on the Actuation Properties of a Photoactuating LCE System. Polymers 2016, 8, 435.
