Materials 2016, 9(8), 636; doi:10.3390/ma9080636

Broadband Anti-Reflective Coating Based on Plasmonic Nanocomposite

1
Nanochemistry and Nanoengineering, Institute for Materials Science, Faculty of Engineering, Christian-Albrechts-Universität zu Kiel, Kiel 24143, Germany
2
Institute of Condensed Matter Theory and Optics, Abbe Center of Photonics, Friedrich-Schiller-Universität Jena, Max-Wien-Platz 1, Jena 07743, Germany
3
Institute of Theoretical Solid State Physics, Karlsruhe Institute of Technology, Wolfgang-Gaede-Str. 1, Karlsruhe 76131, Germany
4
Institute of Nanotechnology, Karlsruhe Institute of Technology, P.O. Box 3640, Karlsruhe 76021, Germany
5
Nanochemistry and Nanoengineering, Helmholtz-Zentrum Geesthacht, Geesthacht 21500, Germany
6
Nanochemistry and Nanoengineering, School of Chemical Technology, Aalto University, Kemistintie 1, Aalto 00076, Finland
*
Authors to whom correspondence should be addressed.
Academic Editor: Klara Hernadi
Received: 12 June 2016 / Revised: 5 July 2016 / Accepted: 25 July 2016 / Published: 28 July 2016
(This article belongs to the Section Energy Materials)
View Full-Text   |   Download PDF [2012 KB, uploaded 29 July 2016]   |

Abstract

We report on the fabrication, the characterization, and the optical simulation of a gold–silica nanocomposite and present its integration into a broadband anti-reflective coating (ARC) for a silicon substrate. The two-layer ARC consists of a nanocomposite (randomly distributed gold cluster in a silica matrix) and a pure silica film. We capitalize on the large refractive index of the composite to impose an abrupt phase change at the interface of the coating to diminish the light reflection from the substrate through the ultrathin nanocoating. The average reflectivity of the silicon can be reduced by such a coating to less than 0.1% in the entire visible spectrum. We experimentally and numerically prove that percolated nanocomposites with an overall thickness of 20 nm can provide anti-reflectivity up to near infrared (NIR). The ARC bandwidth can be shifted more than 500 nm and broadened to cover even the NIR wavelength by changing the volume filling fraction of the gold clusters. The angular sensitivity of thin ultrathin antireflective coating is negligible up to 60°. The present ARC could find applications in thermo-photovoltaics and bolometers. View Full-Text
Keywords: antireflective coating; plasmonic nanocomposite; absorbing antireflective coating; antireflection antireflective coating; plasmonic nanocomposite; absorbing antireflective coating; antireflection
Figures

Figure 1

This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited. (CC BY 4.0).

Scifeed alert for new publications

Never miss any articles matching your research from any publisher
  • Get alerts for new papers matching your research
  • Find out the new papers from selected authors
  • Updated daily for 49'000+ journals and 6000+ publishers
  • Define your Scifeed now

SciFeed Share & Cite This Article

MDPI and ACS Style

Keshavarz Hedayati, M.; Abdelaziz, M.; Etrich, C.; Homaeigohar, S.; Rockstuhl, C.; Elbahri, M. Broadband Anti-Reflective Coating Based on Plasmonic Nanocomposite. Materials 2016, 9, 636.
