Open AccessArticle
Energies 2015, 8(2), 1181-1194;

Energy Management of a Hybrid AC–DC Micro-Grid Based on a Battery Testing System

School of Mechanical, Electronic, and Industrial Engineering, University of Electronic Science and Technology of China, Chengdu 611731, China
Department of Electronics & Information Engineering, Chonbuk National University, Jeonju 567, Korea
Department of Software Engineering, Chonbuk National University, Jeonju 567, Korea
Author to whom correspondence should be addressed.
Received: 3 December 2014 / Revised: 14 January 2015 / Accepted: 28 January 2015 / Published: 3 February 2015
(This article belongs to the Special Issue Electrical Power and Energy Systems for Transportation Applications)
Full-Text   |   PDF [3479 KB, uploaded 17 March 2015]   |


Energy Recovery Battery Testing Systems (ERBTS) plays an important role in battery manufacture. The conventional ERBTS configuration contains a fundamental transformer, and a bidirectional Direct Current (DC)–DC and Alternating Current (AC)–DC converter. All ERBTS are connected in parallel, thus constituting a special and complicated AC micro-grid system. Aiming at addressing their low energy recovery efficiency, complex grid-connected control algorithm issues for islanded detection, and complicated power circuit topology issues, a hierarchical DC-link voltage hybrid AC–DC micro-grid that contains composite energy storing devices is proposed. Moreover, an energy management optimal scheme for the proposed scheme is put forward. The system configuration of the proposed scheme is described in detail. Compared to the conventional scheme, the proposed scheme has the merits of simplified power circuit topology, no need for phase synchronous control, and much higher energy recovery efficiency and reliability. The validity and effectiveness of the proposed technique is verified through numerous experimental results. View Full-Text
Keywords: energy recovery; battery testing system; micro-grid; energy management energy recovery; battery testing system; micro-grid; energy management

Figure 1

This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited. (CC BY 4.0).

Share & Cite This Article

MDPI and ACS Style

Long, B.; Jeong, T.W.; Deuk Lee, J.; Jung, Y.C.; Chong, K.T. Energy Management of a Hybrid AC–DC Micro-Grid Based on a Battery Testing System. Energies 2015, 8, 1181-1194.
