Open AccessArticle
Energies 2017, 10(2), 168; doi:10.3390/en10020168

An N-k Analytic Method of Composite Generation and Transmission with Interval Load

1
Department of Electrical Engineering, Shanghai Jiao Tong University, Shanghai 200240, China
2
Electric Power Research Institute of China, Beijing 100192, China
*
Author to whom correspondence should be addressed.
Academic Editor: Josep M. Guerrero
Received: 2 October 2016 / Revised: 28 December 2016 / Accepted: 16 January 2017 / Published: 29 January 2017
View Full-Text   |   Download PDF [1115 KB, uploaded 13 February 2017]   |

Abstract

N-k contingency estimation plays a very important role in the operation and expansion planning of power systems, the method of which is traditionally based on heuristic screening. This paper stringently analyzes the best and worst states of power systems given the uncertainties of N-k contingency and interval load. For the sake of simplification and tractable computation, an approximate direct current (DC) power flow model was used. Rigorous optimization models were established for identifying the worst and best scenarios considering the contingencies of generators and transmission lines together with their uncertain loads. It is very useful to identify the worst N-k contingencies with interval loads. If the worst existing scenario meets security standards, all scenarios must satisfy it. The mathematical model established for finding the worst N-k contingency with interval load is a bi-level optimization model. In this paper, strong duality theory and mathematical linearization were applied to the solution of bi-level optimization. The computational results of standard cases validate the effectiveness of the proposed method and illustrate that generator contingency has more impact on minimum load shedding than transmission line contingency. View Full-Text
Keywords: mixed integer linear programming; interval load; the worst contingency of power system; minimum load shedding; transmission expansion planning mixed integer linear programming; interval load; the worst contingency of power system; minimum load shedding; transmission expansion planning
Figures

Figure 1

This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited. (CC BY 4.0).

Scifeed alert for new publications

Never miss any articles matching your research from any publisher
  • Get alerts for new papers matching your research
  • Find out the new papers from selected authors
  • Updated daily for 49'000+ journals and 6000+ publishers
  • Define your Scifeed now

SciFeed Share & Cite This Article

MDPI and ACS Style

Hong, S.; Cheng, H.; Zeng, P. An N-k Analytic Method of Composite Generation and Transmission with Interval Load. Energies 2017, 10, 168.
