Curvature and Temperature Measurement Based on a Few-Mode PCF Formed M-Z-I and an Embedded FBG

1
Physics Department, Northwest University, Xi’an 710069, China
2
National Key Laboratory of Thermostructure Composite Materials, Northwestern Polytechnical University, Xi’an 710072, China
3
Photonics Research Centre, University of Malaya, 50603 Kuala Lumpur, Malaysia
*
Author to whom correspondence should be addressed.
Received: 17 June 2017 / Revised: 15 July 2017 / Accepted: 24 July 2017 / Published: 27 July 2017
(This article belongs to the Special Issue Optical Fiber Sensors 2017)
View Full-Text   |   Download PDF [9073 KB, uploaded 27 July 2017]   |

Abstract

We have experimentally demonstrated an optical fiber Mach-Zehnder interferometer (MZI) structure formed by a few-mode photonic crystal fiber (PCF) for curvature measurement and inscribed a fiber Bragg grating (FBG) in the PCF for the purpose of simultaneously measuring temperature. The structure consists of a PCF sandwiched between two multi-mode fibers (MMFs). Bending experimental results show that the proposed sensor has a sensitivity of −1.03 nm/m−1 at a curvature range from 10 m−1 to 22.4 m−1, and the curvature sensitivity of the embedded FBG was −0.003 nm/m−1. Temperature response experimental results showed that the MZI’s wavelength, λa, has a sensitivity of 60.3 pm/°C, and the FBG’s Bragg wavelength, λb, has sensitivity of 9.2 pm/°C in the temperature range of 8 to 100 °C. As such, it can be used for simultaneous measurement of curvature and temperature over ranges of 10 m−1 to 22.4 m−1 and 8 °C to 100 °C, respectively. The results show that the embedded FBG can be a good indicator to compensate the varying ambient temperature during a curvature measurement. View Full-Text
Keywords: Mach-Zehnder interferometers (MZI); few-mode photonic crystal fiber FBG Mach-Zehnder interferometers (MZI); few-mode photonic crystal fiber FBG
