Open AccessReview
Sensors 2016, 16(7), 1144; doi:10.3390/s16071144

Fiber Optic Sensors for Temperature Monitoring during Thermal Treatments: An Overview

1
Universita’ Campus Bio-Medico di Roma, Unit of Measurements and Biomedical Instrumentation, via Alvaro del Portillo 21, 00128 Roma, Italy
2
School of Engineering, Nazarbayev University, 53 Kabanbay Batyr, 01000 Astana, Kazakhstan
3
Institute of Image-Guided Surgery (IHU), S/c Ircad, 1 place de l’Hôpital, 67091 Strasbourg Cedex, France
4
Optical Fibre Sensors Research Centre (OFSRC), University of Limerick, V94 T9PX Limerick, Ireland
5
School of Mechanical Engineering & SAINT, Sungkyunkwan University, 53 Myeongnyun-dong 3-ga, Jongno-gu, 110-745 Suwon, Korea
*
Author to whom correspondence should be addressed.
Academic Editor: Manuel Lopez-Amo
Received: 8 June 2016 / Revised: 15 July 2016 / Accepted: 18 July 2016 / Published: 22 July 2016
(This article belongs to the Special Issue Optical Fiber Sensors 2016)
View Full-Text   |   Download PDF [1419 KB, uploaded 22 July 2016]   |

Abstract

During recent decades, minimally invasive thermal treatments (i.e., Radiofrequency ablation, Laser ablation, Microwave ablation, High Intensity Focused Ultrasound ablation, and Cryo-ablation) have gained widespread recognition in the field of tumor removal. These techniques induce a localized temperature increase or decrease to remove the tumor while the surrounding healthy tissue remains intact. An accurate measurement of tissue temperature may be particularly beneficial to improve treatment outcomes, because it can be used as a clear end-point to achieve complete tumor ablation and minimize recurrence. Among the several thermometric techniques used in this field, fiber optic sensors (FOSs) have several attractive features: high flexibility and small size of both sensor and cabling, allowing insertion of FOSs within deep-seated tissue; metrological characteristics, such as accuracy (better than 1 °C), sensitivity (e.g., 10 pm·°C−1 for Fiber Bragg Gratings), and frequency response (hundreds of kHz), are adequate for this application; immunity to electromagnetic interference allows the use of FOSs during Magnetic Resonance- or Computed Tomography-guided thermal procedures. In this review the current status of the most used FOSs for temperature monitoring during thermal procedure (e.g., fiber Bragg Grating sensors; fluoroptic sensors) is presented, with emphasis placed on their working principles and metrological characteristics. The essential physics of the common ablation techniques are included to explain the advantages of using FOSs during these procedures. View Full-Text
Keywords: fiber optic sensors; temperature monitoring; medical applications; minimally invasive thermal treatments fiber optic sensors; temperature monitoring; medical applications; minimally invasive thermal treatments
Figures

Figure 1

This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited. (CC BY 4.0).

Scifeed alert for new publications

Never miss any articles matching your research from any publisher
  • Get alerts for new papers matching your research
  • Find out the new papers from selected authors
  • Updated daily for 49'000+ journals and 6000+ publishers
  • Define your Scifeed now

SciFeed Share & Cite This Article

MDPI and ACS Style

Schena, E.; Tosi, D.; Saccomandi, P.; Lewis, E.; Kim, T. Fiber Optic Sensors for Temperature Monitoring during Thermal Treatments: An Overview. Sensors 2016, 16, 1144.

Show more citation formats Show less citations formats

Note that from the first issue of 2016, MDPI journals use article numbers instead of page numbers. See further details here.
