Open AccessArticle
Sensors 2015, 15(4), 7691-7707; doi:10.3390/s150407691

A Non-Chemical System for Online Weed Control

1
Department of Weed Science (360b), University of Hohenheim, 70599 Stuttgart, Germany
2
Proyecto Prometeo–SENESCYT. General Coordination of Laboratories, Agencia Ecuatoriana de Aseguramiento de la Calidad del Agro, AGROCALIDAD, Vía Interoceánica, km 14 1/2 y Eloy Alfaro, Granja MAGAP, EC170184 Tumbaco, Ecuador
3
Institute of Agricultural Sciences, Consejo Superior Investigaciones Científicas, CSIC, Serrano 115b, 28006 Madrid, Spain
*
Author to whom correspondence should be addressed.
Academic Editor: Gonzalo Pajares Martinsanz
Received: 22 December 2014 / Revised: 12 March 2015 / Accepted: 20 March 2015 / Published: 30 March 2015
(This article belongs to the Special Issue Agriculture and Forestry: Sensors, Technologies and Procedures)
View Full-Text   |   Download PDF [723 KB, uploaded 30 March 2015]   |

Abstract

Non-chemical weed control methods need to be directed towards a site-specific weeding approach, in order to be able to compete the conventional herbicide equivalents. A system for online weed control was developed. It automatically adjusts the tine angle of a harrow and creates different levels of intensity: from gentle to aggressive. Two experimental plots in a maize field were harrowed with two consecutive passes. The plots presented from low to high weed infestation levels. Discriminant capabilities of an ultrasonic sensor were used to determine the crop and weed variability of the field. A controlling unit used ultrasonic readings to adjust the tine angle, producing an appropriate harrowing intensity. Thus, areas with high crop and weed densities were more aggressively harrowed, while areas with lower densities were cultivated with a gentler treatment; areas with very low densities or without weeds were not treated. Although the weed development was relatively advanced and the soil surface was hard, the weed control achieved by the system reached an average of 51% (20%–91%), without causing significant crop damage as a result of harrowing. This system is proposed as a relatively low cost, online, and real-time automatic harrow that improves the weed control efficacy, reduces energy consumption, and avoids the usage of herbicide. View Full-Text
Keywords: selectivity; soil covering; crop-weed-soil variability; fuzzy logic; site-specific harrowing selectivity; soil covering; crop-weed-soil variability; fuzzy logic; site-specific harrowing
This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited. (CC BY 4.0).

Scifeed alert for new publications

Never miss any articles matching your research from any publisher
  • Get alerts for new papers matching your research
  • Find out the new papers from selected authors
  • Updated daily for 49'000+ journals and 6000+ publishers
  • Define your Scifeed now

SciFeed Share & Cite This Article

MDPI and ACS Style

Rueda-Ayala, V.; Peteinatos, G.; Gerhards, R.; Andújar, D. A Non-Chemical System for Online Weed Control. Sensors 2015, 15, 7691-7707.
