Open AccessArticle
Sensors 2014, 14(11), 20149-20164; doi:10.3390/s141120149

A Study of the Effect of the Fringe Fields on the Electrostatic Force in Vertical Comb Drives

Department of Mechanical Engineering, University of Alberta, 4-9 Mechanical Engineering Building, Edmonton, AB T6G 2G8, Canada
*
Author to whom correspondence should be addressed.
Received: 9 September 2014 / Revised: 18 October 2014 / Accepted: 20 October 2014 / Published: 27 October 2014
(This article belongs to the Section Physical Sensors)
View Full-Text   |   Download PDF [1853 KB, uploaded 27 October 2014]   |

Abstract

The equation that describes the relationship between the applied voltage and the resulting electrostatic force within comb drives is often used to assist in choosing the dimensions for their design. This paper re-examines how some of these dimensions—particularly the cross-sectional dimensions of the comb teeth—affect this relationship in vertical comb drives. The electrostatic forces in several vertical comb drives fabricated for this study were measured and compared to predictions made with four different mathematical models in order to explore the amount of complexity required within a model to accurately predict the electrostatic forces in the comb drives. View Full-Text
Keywords: fringe electrostatic fields; vertical comb drives; net electrostatic force fringe electrostatic fields; vertical comb drives; net electrostatic force
