Sensors 2011, 11(10), 9182-9206; doi:10.3390/s111009182
Article

Kalman-Filter-Based Orientation Determination Using Inertial/Magnetic Sensors: Observability Analysis and Performance Evaluation

Received: 4 August 2011; in revised form: 21 September 2011 / Accepted: 23 September 2011 / Published: 27 September 2011
(This article belongs to the Section Physical Sensors)
View Full-Text   |   Download PDF [955 KB, uploaded 21 June 2014]
Abstract: In this paper we present a quaternion-based Extended Kalman Filter (EKF) for estimating the three-dimensional orientation of a rigid body. The EKF exploits the measurements from an Inertial Measurement Unit (IMU) that is integrated with a tri-axial magnetic sensor. Magnetic disturbances and gyro bias errors are modeled and compensated by including them in the filter state vector. We employ the observability rank criterion based on Lie derivatives to verify the conditions under which the nonlinear system that describes the process of motion tracking by the IMU is observable, namely it may provide sufficient information for performing the estimation task with bounded estimation errors. The observability conditions are that the magnetic field, perturbed by first-order Gauss-Markov magnetic variations, and the gravity vector are not collinear and that the IMU is subject to some angular motions. Computer simulations and experimental testing are presented to evaluate the algorithm performance, including when the observability conditions are critical.
Keywords: ambulatory human motion tracking; orientation determination; inertial measurement unit; Extended Kalman filter; Lie derivatives; observability of nonlinear systems ambulatory human motion tracking; orientation determination; inertial measurement unit; Extended Kalman filter; Lie derivatives; observability of nonlinear systems
This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited.

Export to BibTeX |
EndNote


MDPI and ACS Style

Sabatini, A.M. Kalman-Filter-Based Orientation Determination Using Inertial/Magnetic Sensors: Observability Analysis and Performance Evaluation. Sensors 2011, 11, 9182-9206.

AMA Style

Sabatini AM. Kalman-Filter-Based Orientation Determination Using Inertial/Magnetic Sensors: Observability Analysis and Performance Evaluation. Sensors. 2011; 11(10):9182-9206.

Chicago/Turabian Style

Sabatini, Angelo Maria. 2011. "Kalman-Filter-Based Orientation Determination Using Inertial/Magnetic Sensors: Observability Analysis and Performance Evaluation." Sensors 11, no. 10: 9182-9206.
