A Focusing Method in the Calibration Process of Image Sensors Based on IOFBs
Electronics Department, Superior Polytechnic School, University of Alcalá, Universitary Campus, Alcalá de Henares 28871, Madrid, Spain
Telecommunication Department, University of Oriente, Av. de las Américas, SN, Santiago de Cuba 90900, Cuba
* Author to whom correspondence should be addressed.
Received: 29 October 2009; in revised form: 14 November 2009 / Accepted: 27 November 2009 / Published: 24 December 2009
Abstract: A focusing procedure in the calibration process of image sensors based on Incoherent Optical Fiber Bundles (IOFBs) is described using the information extracted from fibers. These procedures differ from any other currently known focusing method due to the non spatial in-out correspondence between fibers, which produces a natural codification of the image to transmit. Focus measuring is essential prior to carrying out calibration in order to guarantee accurate processing and decoding. Four algorithms have been developed to estimate the focus measure; two methods based on mean grey level, and the other two based on variance. In this paper, a few simple focus measures are defined and compared. Some experimental results referred to the focus measure and the accuracy of the developed methods are discussed in order to demonstrate its effectiveness.
Keywords: image sensor; image transmission; sensor calibration; optical fiber sensors
Article StatisticsClick here to load and display the download statistics.
Notes: Multiple requests from the same IP address are counted as one view.
Cite This Article
MDPI and ACS Style
Fernández, P.R.; Lázaro, J.L.; Gardel, A.; Cano, Á.E.; Bravo, I. A Focusing Method in the Calibration Process of Image Sensors Based on IOFBs. Sensors 2010, 10, 47-60.
Fernández PR, Lázaro JL, Gardel A, Cano ÁE, Bravo I. A Focusing Method in the Calibration Process of Image Sensors Based on IOFBs. Sensors. 2010; 10(1):47-60.
Fernández, Pedro R.; Lázaro, José L.; Gardel, Alfredo; Cano, Ángel E.; Bravo, Ignacio. 2010. "A Focusing Method in the Calibration Process of Image Sensors Based on IOFBs." Sensors 10, no. 1: 47-60.
