Int. J. Mol. Sci. 2014, 15(4), 5940-5951; doi:10.3390/ijms15045940
Published: 9 April 2014
Abstract: Endogenous melatonin is a known free radical scavenger that removes reactive oxygen species (ROS), thus, alleviating oxidative stress. The purpose of this study was to demonstrate its effect against kainic acid (KA)-induced oxidative stress in organotypic hippocampal slice cultures (OHSCs). To observe neuroprotective effects of melatonin, different concentrations (0.01, 0.1 and 1 mM) of melatonin were administrated after KA treatment for 18 h in OHSCs of rat pups. Dose-response studies showed that neuronal cell death was significantly reduced after 0.1 and 1 mM melatonin treatments based on propidium iodide (PI) uptake and cresyl violet staining. The dichlorofluorescein (DCF) fluorescence which indicates ROS formation decreased more in the melatonin-treated group than in the KA group. The expression of 5-lipoxigenase (5-LO) and caspase-3 were reduced in the melatonin-treated groups compared to the KA group. These results suggest that melatonin may be an effective agent against KA-induced oxidative stress in the OHSC model.
It is well known that the excessive production of oxygen free radicals may generate neuronal disorders. The brain is one of the most oxygen consuming organs ; therefore, reactive oxygen species (ROS) production in the brain is higher than in the rest of the body. In general, an antioxidant maintains and regulates the equilibrium between ROS formation and extinction. If the equilibrium is disrupted, however, ROS act as a stressor and damage intracellular elements such as proteins, lipids, and DNA. Because neuronal cells are especially sensitive and vulnerable to ROS, apoptosis or necrosis can occur easily . Therefore, oxidative stress produces neurotoxicity in the brain. Specially, mitochondrial oxidative stress has frequently been associated with various neuronal disorders .
Melatonin is a known antioxidant secreted from various organs, including the pineal gland, retina, lens, and gastrointestinal tract. Melatonin plays a variety of physiological roles such as the adaptation of the day and night cycle, acclimation, and participation in immune reaction. Its protective effect in many neurodegenerative disorders (e.g., Alzheimer’s disease, Parkinson’s disease, ischemia-reperfusion injury, mental disorders) have also been implicated [4–7]. Because of its favorable physicochemical proprieties, melatonin is able to pass biological barriers such as the cellular membrane . In addition, because it is an electron-rich molecule, melatonin produces stabilized molecules by reacting with various ROS. Particularly, melatonin produces stabilized molecules without generating any other ROS because redox cycling is not required for melatonin. Melatonin is referred to as a suicidal or terminal antioxidant, because the body excretes metabolites produced by melatonin, via urine, without any secondary influence on body tissue . Melatonin binds to the membrane receptor with high affinity in the picomolar range, and also to the nuclear receptor as well as calmodulin in the nanomolar range . Melatonin has a free radical scavenging function at even higher concentrations. As a result, melatonin acts as an antioxidant [8,11–14].
Kainic acid (KA) is an agonist of the ionotrophic glutamate receptor. Its action as an excitotoxin leads to neuronal excitotoxicity and oxidative damage in the central nervous system . KA binds to the kainate receptor and produces neuronal death . Therefore, KA has been used to study the neuroprotective effects of various agents against oxidative stress.
In our previous studies, we have shown that antioxidants, such as Coenzyme Q10 and ascorbic acid, have elicited neuroprotective effects against KA-induced neurotoxicity in organotypic hippocampal slice culture (OHSC) [17–19]. The goal of the present study was to investigate the ability of melatonin to protect cell viability in the same in vitro model system.
2. Results and Discussion
2.1. Effects of Melatonin on KA-Induced Neuronal Toxicity in OHSCs
PI uptake was used to investigate the effects of melatonin on KA-induced neuronal injury. Hippocampal tissues showed almost no damage in the pre-phase. The intensity of PI uptake was increased in the hippocampus CA1, CA3, and dentate gyrus 18 h after KA treatment. However, reduced intensity was shown in 0.01, 0.1, and 1 mM melatonin-treated groups compared with the KA only-treated group (Figure 1A). The values in % of PI uptake in the CA1 and CA3 region of the hippocampus layers are shown in Figure 1B,C. Reduced levels of PI uptake in CA1 and CA3 were observed in the 0.01, 0.1, and 1 mM melatonin-treated groups.
2.2. Cresyl Violet Staining
Cresyl violet staining was used to detect neuronal cell survival. Normal tissue had numerous neuronal cells throughout all the cell layers. KA only-treated tissue had fewer cells in the layer, especially in the CA3 region compared with the CA1 region. More cells survived in melatonin-treated than in KA only-treated tissue, but this number was lower than that in normal tissue (Figure 2).
2.3. Formation of ROS in KA-Induced Oxidative Stress
DCFH-DA fluorescence dye was used to detect ROS formation in the hippocampal tissue (Figure 3). ROS formation was detected from the overall cell layers. 10 μM dye was represented in a green fluorescence. Fluorescence in the tissue was minute before the KA treatment, but 5 μM KA generated fluorescence beyond normal. After melatonin treatment, the fluorescence was significantly reduced compared with KA-treated groups (p < 0.01).
2.4. Western Blotting
The 5-lipoxigenase (5-LO) expression is a marker of lipid peroxidation. The KA group had higher 5-LO expression than the other groups (Figure 4A). Twenty-four hours after melatonin treatment, 0.1 and 1 mM of melatonin significantly reduced the 5-LO expression. Caspase-3 expression is a marker of apoptosis, and also plays a role in necrosis and inflammation. The normal group showed lower expression than the KA-treated group. The 0.01, 0.1, and 1 mM melatonin-treated groups also showed reduced caspase-3 expression (Figure 4B).
It has been previously shown that KA generates ROS in the brain [20,21]. Recently, some studies have demonstrated that melatonin may attenuate brain injury through its antioxidant effect. According to Juliana et al. , amyloid-β neurotoxicity was reduced by melatonin in organotypic culture. It has also been shown that the administration of melatonin in rats attenuates oxidative stress-induced neurodegeneration and microglial generation . Especially, Zaja-Milatovic et al.  have noticed that MT1A and MT1B receptors are abundant in the CA1 and CA3 region of the hippocampus which regulates the activation of melatonin.
In our study, to demonstrate the antioxidant effects of melatonin, the KA-induced oxidative stress model was chosen because the KA-induced injury is more effective in the hippocampal CA3 region than CA1 which makes it easy to specify an injury model [24–26]. There was no PI uptake observed at different concentrations (0.01–1 mM) of melatonin alone in the OHSC (data not shown). This study would be a valuable support for previous studies related to antioxidant effects of melatonin on KA-induced oxidative stress. The results demonstrated that melatonin effectively suppresses neuronal cell death in CA1 and CA3 regions in the hippocampus, based on measurement of PI uptake.
The DCFH-DA method is widely used in ROS measurement in the mitochondria. It is a major advantage of DCFH-DA that it detects both mitochondria and live cells . The results from fluorescence measurements using DCFH-DA demonstrated the association between neuronal death and ROS. We also found a relationship between PI and cresyl violet staining. Unlike the ROS generation, the results from PI uptake and cresyl violet staining were dependent on melatonin concentration, which increased as the concentration of melatonin increased.
According to Flavia et al. , KA-induced damage showed up-regulation of 5-LO expression in limbic system. In addition, increased endogenous ROS up-regulated 5-LO expression. The generation of the endogenous ROS by antimycin A increases up-regulation of 5-LO activity three-fold . Apoptotic neuronal death with KA injury induces rapid induction of bax, collapse of mitochondrial membrane potential, release of cytochrome c from mitochondria, and activation of caspase-3, suggesting that multiple apoptotic pathways are activated in response to KA . Caspase-3 participates in various apoptosis pathways including KA-induced injury. From our study, melatonin gradually reduced caspase-3 activity, especially, that 1 mM melatonin significantly attenuated in caspase-3 expression. This finding indicates that melatonin has neuroprotective effects that regulate viability of cells against ROS and apoptosis. Several studies have demonstrated that antioxidants can attenuate KA-induced neuronal damage [31,32]. Especially, mitochondria superoxide radical production generates ROS and hippocampus destruction demonstrated that the oxygen free radical was generated in the limbic structure by KA-induced seizures, and another study demonstrated that KA-induced damage in neuron generated a mitochondrial superoxide production [20,23,33].
Taken together, this study demonstrated the effect of melatonin on KA-induced oxidative damage using different concentrations of melatonin. Treatment with melatonin significantly attenuated neuronal damage and the generation of ROS. Higher concentrations of melatonin were more effective than that of lower concentrations. These results suggest that melatonin could be an effective antioxidant in the context of oxidative stress.
3. Experimental Section
3.1. Organotypic Hippocampal Slice Culture (OHSC)
All animal experiments were approved by the Institutional Animal Care and Use Committee of Yonsei University Health System. OHSC was conducted in accordance with our previous experimental protocols [16–18] modified from Stoppini et al. . In brief, the brains of 6–8 day-old Sprague-Dawley rats (Koatech, Gyeonggi-do, Korea) were removed and transferred to Gey’s Balanced Salt Solution (GBSS, Sigma, St. Louis, MO, USA) containing 0.5% glucose and 3 mM KCl, 1 N HCl. Rat hippocampi were separated from the whole brains and then dissected to 350 μm with a McIlwain tissue chopper (Vibratome, O’Fallon, MO, USA). Undamaged and clear layered dissected tissues were selected. Six to eight tissues were transferred onto a Millicell-CM membrane insert (Millipore, Billerica, MA, USA) in 6-well plate containing 1 mL culture media (pH 7.2) composed of 50% Opti-MEM, 25% Hank’s Balanced salt solution (HBSS), 25% heat inactivated horse serum (all from GIBCO BRL, Grand Island, NY, USA), and 6.5 mg/mL d-glucose (AMRESCO Inc., Solon, OH, USA). Cultured slices were incubated at 36 °C in a humidified atmosphere of 5% CO2. Culture media was changed three times a week. Slices were grown for 3 weeks in the culture medium.
3.2. Drug Preparation and Treatment
Five micro moles per liter kainic acid (KA, K0250, Sigma, St. Louis, MO, USA) was dissolved in DW and applied to cultured slices for 18 h in OHSC. Melatonin (Sigma) was dissolved in ethanol (Merk, Darmstadt, Germany) then diluted and treated with culture medium at 0.01, 0.1, and 1 mM concentrations. Afterwards, KA-injured hippocampal slices were kept on melatonin for 24 and 48 h. The experimental procedure is shown in Figure 5.
3.3. Measurement of Neuronal Injury
To observe neuronal cell death, we used propidium iodide (PI, Sigma, St. Louis, MO, USA) staining. Three weeks after OHSCs, cultured normal hippocampal slices were added with 5 μM PI in culture medium and detected the neuronal death in the pre-phase which has no PI uptake in the hippocampal layers. After KA treatment for 18 h, degenerated tissue was removed from the membrane insert and PI uptake was monitored. Effects of 0.01, 0.1, and 1 mM melatonin treatment for 24 and 48 h were observed by PI. Full kill was performed with 10 mM NMDA (Sigma) to produce neuronal death in all tissue areas. Finally, pre, 24 h, 48 h, and full-kill phase results were detected by the fluorescence microscope and analyzed with a MetaMorph program (Universal Imaging, Downingtown, PA, USA). All values of the fluorescence were calculated using the following formula: % of PI uptake = (Ft − Fpre)/ (Ffk − Fpre) × 100 (Ft = PI uptake at 24 or 48 h after melatonin treatment, Fpre = pre, Ffk = full kill).
3.4. Evaluation of Intracellular ROS Formation
Tissues were incubated with 10 μM 2′,7′-dichlorohydrofluorescein diacetate (DCFH-DA, Sigma) in a 36 °C humidified incubator for 30 min and washed twice with phosphate-buffered saline, pH 7.4 (1× dPBS, GIBCO, Grand Island, NY, USA). DCFH-DA expression level was detected at pre, 18 h after KA injury and 24 h after melatonin treatment using a fluorescence microscope (IX-71, Olympus, Tokyo, Japan). The DCFH-DA fluorescence intensity was measured by a MetaMorph program (Universal Imaging).
3.5. Cresyl Violet Staining
To detect the survival of cells using the cresyl violet staining, each slide was soaked in 4% paraformaldehyde (Duksan, Incheon, Korea) for 20 min, washed out twice with 1× dPBS, soaked into cresyl violet solution (Sigma), and washed with flowing tap water. The tissue sections were dehydrated with 70%, 90%, and 100% EtOH (Ducksan), soaked into the 50:50 (EtOH and xylene) mixture, and stored in 100% xylene (Ducksan). Finally the slides were mounted with permount. The MetaMorph program was used to detect the survived neurons in CA3.
3.6. Western Blot Analysis
Cultured slices were collected and homogenized with lysis buffer containing 10% SDS, 1 M Tris–HCl (pH 7.4), 5% Triton X-100, 50% sodium deoxycholate, 1 M DTT, 0.5 M sodium orthovanadate, 2 mg/mL PMSF, 10× protease inhibitor (all from Sigma). The homogenized solution was frozen and thawed in −80 °C three times. Proteins were separated by SDS-PAGE, and transferred to a nitrocellulose membrane (Millipore, Billerica, MA, USA). The membrane was blocked by 5% skim milk in Tris-buffered saline added with 0.5% Tween-20, and was incubated with primary antibodies (5-LO, Cayman, Ann Arbor, MI, USA; caspase-3, Santacruz Biotechnology, Santa Cruz, CA, USA; β-actin, Abcam, Cambridge, UK) overnight at 4 °C. The membrane was developed with a peroxidase-conjugated secondary anti body, and protein was detected by enhanced chemiluminescence (ECL) procedure (Amersham, Arlington, IL, USA).
3.7. Statistical Analysis
All data were expressed as mean ± SEM. Differences among groups were analyzed by LSD post-hoc test. The level of significance was accepted at * p < 0.05, ** p < 0.01 and *** p < 0.001.
The present study used PI, cresyl violet, and DCFH-DA fluorescence staining to demonstrate that KA-induced injury is related to generation of ROS, which has a neurotoxic effect in the hippocampus. We found that melatonin reduced ROS generation and neuronal cell death. This suggests that melatonin has neuroprotective effects on KA-induced oxidative stress in the hippocampus as an antioxidant. Melatonin may therefore be important for alleviating neuronal disorders that can be generated by oxidative stress.
This research was supported by the Basic Science Research Program through the National Research Foundation (NRF) funded by the Ministry of Education, Science and Technology (20090076605) and by a faculty research grant of Yonsei University College of Medicine for 2011 (6-2011-0102).
Conflicts of Interest
The authors declare no conflict of interest.
- Author ContributionsAll authors contributed to the conception and design. H.A.K. conducted the experiments. Manuscript was drafted by H.A.K. and edited by K.H.L. and B.H.L.
- Floyd, R.A.; Carney, J.M. Free radical damage to protein and DNA: Mechanisms involved and relevant observations on brain undergoing oxidative stress. Ann. Neurol 1992, 32, 22–27, doi:10.1002/ana.410320706.
- Floyd, R.A. Antioxidants, oxidative stress, and degenerative neurological disorders. Proc. Soc. Exp. Biol. Med 1999, 222, 236–245, doi:10.1046/j.1525-1373.1999.d01-140.x. 10601882
- Liang, L.P.; Ho, Y.S.; Patel, M. Mitochondrial superoxide production in kainate-induced hippocampal damage. Neuroscience 2000, 101, 563–570, doi:10.1016/S0306-4522(00)00397-3. 11113305
- Alvira, D.; Tajes, M.; Verdaguer, E. Inhibition of the cdk5/p25 fragment formation may explain the antiapoptotic effects of melatonin in an experimental model of Parkinsons disease. J. Pineal Res 2006, 40, 251–258, doi:10.1111/j.1600-079X.2005.00308.x. 16499562
- Mayo, J.C.; Sainz, R.M.; Tan, D.X.; Antolín, I.; Rodríguez, C.; Reiter, R.J. Melatonin and Parkinson’s disease. Endocrine 2005, 27, 169–178, doi:10.1385/ENDO:27:2:169. 16217130
- Srinivasan, V.; Pandi-Perumal, S.R.; Maestroni, G.J.; Esquifino, A.I.; Hardeland, R.; Cardinali, D.P. Role of melatonin in neurodegenerative diseases. Neurotox. Res 2005, 7, 293–318, doi:10.1007/BF03033887. 16179266
- Antolin, I.; Rodriquez, C.; Sainz, R.M.; Mayo, J.C.; Aria, H.; Kotter, M. Neurohormone melatonin prevents cell damage: Effect on gene expression for antioxidant enzymes. FASEB J 1996, 10, 882–890. 8666165
- Hashimoto, S.; Minami, N.; Takakura, R. Low oxygen tension during in vitro maturation is beneficial for supporting the subsequent development of bovine cumulus-oocyte complexes. Mol. Reprod. Dev 2000, 57, 353–360, doi:10.1002/1098-2795(200012)57:4<353::AID-MRD7>3.0.CO;2-R. 11066064
- Costa, E.J.; Lopes, R.H.; Lamy-Freund, M.T. Permeability of pure lipid bilayers to melatonin. J. Pineal Res 1995, 19, 123–126, doi:10.1111/j.1600-079X.1995.tb00180.x. 8750345
- Ekmekcioglu, C. Melatonin receptors in humans: Biological role and clinical relevance. Biomed. Pharmacother 2006, 60, 97–108, doi:10.1016/j.biopha.2006.01.002. 16527442
- Hung, M.W.; Tipoe, G.L.; Poon, A.M.; Reiter, R.J.; Fung, M.L. Protective effect of melatonin against hippocampal injury of rats with intermittent hypoxia. J. Pineal Res 2008, 44, 214–221, doi:10.1111/j.1600-079X.2007.00514.x. 18289174
- Cheung, R.T.; Tipoe, G.L.; Tam, S.; Ma, E.S.; Zou, L.Y.; Chan, P.S. Preclinical evaluation of pharmacokinetics and safety of melatonin in propylene glycol for intravenous administration. J. Pineal Res 2006, 41, 337–343, doi:10.1111/j.1600-079X.2006.00372.x. 17014690
- Cheung, R.T. The utility of melatonin in reducing cerebral damage resulting from ischemia and reperfusion. J. Pineal Res 2003, 34, 153–160, doi:10.1034/j.1600-079X.2003.00034.x. 12614473
- Hardeland, R. Antioxidative protection by melatonin: Multiplicity of mechanisms from radical detoxification to radical avoidance. Endocrine 2005, 27, 119–130, doi:10.1385/ENDO:27:2:119. 16217125
- Reiter, R.J. Oxidative damage in the central nervous system: Protection by melatonin. Prog. Neurobiol 1998, 56, 359–384, doi:10.1016/S0301-0082(98)00052-5. 9770244
- Kristensen, B.W.; Noraberg, J.; Zimmer, J. Comparison of excitotoxic profiles of ATPA, AMPA, KA and NMDA in organotypic hippocampal slice cultures. Brain Res 2001, 917, 21–44, doi:10.1016/S0006-8993(01)02900-6. 11602227
- Kim, E.J.; Won, R.; Sohn, J.-H.; Chung, M.-A.; Nam, T.S.; Lee, H.-J.; Lee, B.H. Anti-oxidant effect of ascorbic and dehydroascorbic acids in hippocampal slice culture. Biochem. Biophys. Res. Commun 2008, 366, 8–14, doi:10.1016/j.bbrc.2007.11.050. 18036337
- Won, R.; Lee, K.H.; Lee, B.H. Coenzyme Q10 protects neurons against neurotoxicity in hippocampal slice culture. Neuroreport 2011, 22, 721–726, doi:10.1097/WNR.0b013e32834acb8d. 21849914
- Jung, N.Y.; Lee, K.H.; Won, R.; Lee, B.H. Neuroprotective effects of α-tocotrienol on kainic acid-induced neurotoxicity in organotypic hippocampal slice cultures. Int. J. Mol. Sci 2013, 14, 18256–18268, doi:10.3390/ijms140918256. 24013375
- Zaja-Milatovic, S.; Gupta, R.C.; Aschner, M.; Montine, T.J.; Milatovic, D. Pharmacologic suppression of oxidative damage and dendritic degeneration following kainic acid-induced excitotoxicity in mouse cerebrum. Neurotoxicology 2008, 29, 621–627, doi:10.1016/j.neuro.2008.04.009. 18556069
- Kotler, M.; Rodriquez, C.; Sainz, R.M.; Antolin, I.; Menendez-Pelaez, A. Melatonin increases gene expression for antioxidant enzymes in rat brain cortex. J. Pineal Res 1998, 24, 83–89, doi:10.1111/j.1600-079X.1998.tb00371.x. 9510432
- Juliana, B.H.; Rudimar, L.F.; Ana, P.H.; Ricardo, A.C.; Andressa, B.; Maria, M.C. Amyloid-β neurotoxicity in organotypic culture is attenuated by melatonin: Involvement of GSK-3β, tau and neuroinflammation. J. Pineal Res 2010, 48, 230–238, doi:10.1111/j.1600-079X.2010.00747.x. 20136701
- Chung, S.Y.; Han, S.H. Melatonin attenuates kainic acid-induced hippocampal neurodeneration and oxidative stress through microglial inhibition. J. Pineal Res 2003, 34, 95–102, doi:10.1034/j.1600-079X.2003.00010.x. 12562500
- Holopainen, I.E.; Jarvela, J.; Lopez-Picon, F.R.; Pelliniemi, L.J.; Kukko-Lukjanov, T.K. Mechanisms of kainate-induced region-specific neuronal death in immature organotypic hippocampal slice cultures. Neurochem. Int 2004, 45, 1–10, doi:10.1016/j.neuint.2004.01.005. 15082216
- Noraberg, J.; Kristensen, B.W.; Zimmer, J. Markers for neuronal degeneration in organotypic slice cultures. Brain Res. Protoc 1999, 3, 278–290, doi:10.1016/S1385-299X(98)00050-6.
- Vornov, J.J.; Tasker, R.C.; Coyle, J.T. Direct observation of the agonist-specific regional vulnerability to glutamate, NMDA, and kainate neurotoxicity in organotypic hippocampal cultures. Exp. Neurol 1991, 114, 11–22, doi:10.1016/0014-4886(91)90079-R. 1717307
- Zelko, I.N.; Mariani, T.J.; Folz, R.J. Superoxide dismutase multigene family: A comparison of the CuZn-SOD (SOD1), Mn-SOD (SOD2), and EC-SOD (SOD3) gene structures, evolution, and expression. Free Radic. Biol. Med 2002, 33, 337–349, doi:10.1016/S0891-5849(02)00905-X. 12126755
- Flavia, R.; Laura, P.; Milena, D.N.; Claudia, C.; Sergio, A.; Annalida, B. Rapid and transient stimulation of intracellular reactive oxygen species by melatonin in normal and tumor leukocytes. Toxicol. Appl. Pharmacol 2009, 239, 37–45, doi:10.1016/j.taap.2009.05.012. 19463840
- Werz, O.; Szellas, D.; Steinhilber, D. Reactive oxygen species released from granulocytes stimulate 5-lipoxygenase activity in a B-lymphocytic cell line. Eur. J. Biochem 2000, 267, 1263–1269, doi:10.1046/j.1432-1327.2000.01000.x. 10691962
- Liu, W.; Liu, R.; Schreiber, S.S.; Baudry, M. Role of polyamine metabolism in kainic acid excitotoxicity in organotypic hippocampal slice cultures. J. Neurochem 2001, 79, 976–984. 11739609
- Monyer, H.; Hartley, D.M.; Choi, D.W. 21-Aminosteroids attenuate excitotoxic neuronal injury in cortical cell cultures. Neuron 1990, 5, 121–126, doi:10.1016/0896-6273(90)90302-V. 2166544
- Ries, W.L.; Key, L.L., Jr.; Rodriguiz, R.M. Nitroblue tetrazolium reduction and bone resorption by osteoclasts in vitro inhibited by a manganese-based superoxide dismutase mimic. J. Bone Miner. Res 1992, 7, 931–939. 1442207
- Yalcin, A.; Kilinc, E.; Kocturk, S.; Resmi, H.; Sozmen, E.Y. Effect of melatonin cotreatment against kainic acid on coenzyme Q10, lipid peroxidation and Trx mRNA in rat hippocampus. Int. J. Neurosci 2004, 114, 1085–1097, doi:10.1080/00207450490475535. 15370175
- Stoppini, L.; Buchs, P.A.; Muller, D.A. Simple method for organotypic cultures of nervous tissue. J. Neurosci. Methods 1991, 37, 173–182, doi:10.1016/0165-0270(91)90128-M. 1715499
