Comprehensive Qualitative Ingredient Profiling of Chinese Herbal Formula Wu-Zhu-Yu Decoction via a Mass Defect and Fragment Filtering Approach Using High Resolution Mass Spectrometry

1
National and Local Joint Engineering Laboratory for Key Technology of Chinese Material Medica Quality Control, School of Pharmacy, Shenyang Pharmaceutical University, 103 Wenhua Road, Shenyang 110016, China
2
Liaoning Institute of Analytical Science, 103 Wanliutang Rd., Shenyang 110015, China
*
Author to whom correspondence should be addressed.
Academic Editor: Derek J. McPhee
Received: 12 April 2016 / Revised: 10 May 2016 / Accepted: 16 May 2016 / Published: 19 May 2016
(This article belongs to the Section Natural Products)
View Full-Text   |   Download PDF [2066 KB, uploaded 19 May 2016]   |

Abstract

The Wu-Zhu-Yu decoction is a traditional Chinese medicine formula for the treatment of headache. To reveal its material basis, a rapid and reliable liquid chromatography-high resolution mass spectrometry method was established for comprehensive profiling of the chemical ingredients in the Wu-Zhu-Yu decoction. The method was used on a quadrupole time-of-flight mass spectrometer along with an advanced data processing procedure consisting of mass accuracy screening, mass defect filtering and fragment filtering. After eliminating interference with a filtering approach, the MS data profiling was made more distinct and accurate. With the optimized conditions of only 35 min LC separation and single sample injection of each positive or negative ion mode, a total of 168 compounds were characterized, including 23 evodiamine and its analogous alkaloids, 12 limonoids, 17 gingerols, 38 ginsenosides, 15 flavonoids, 16 organic acids, 14 alkaloids, 5 saponins, 3 2,2-dimethylchromenes and 25 other compounds. The fragmentation patterns of representative compounds were illustrated as well. Integrative qualitative analysis of the Wu-Zhu-Yu decoction by high resolution mass spectrometry was accomplished and reported for the first time. The study demonstrated that the established method was a powerful and reliable strategy for comprehensive detection and would be widely applicable for identification of complicated components from herbal prescriptions, and may provide a basis for chemical analysis of other complex mixtures. View Full-Text
Keywords: ingredients qualitative analysis; Wu-Zhu-Yu decoction; Traditional Chinese Medicine formula; high resolution mass spectrometry ingredients qualitative analysis; Wu-Zhu-Yu decoction; Traditional Chinese Medicine formula; high resolution mass spectrometry
Figures

Figure 1a

This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited. (CC BY 4.0).
